INNOSILICON D9-DCR Manuel utilisateur

D9-DCR

USER MANUAL

INNOSILICON CONFIDENTIAL

Table of Contents

1. OVERVIEW 1

2. ASSEMBLE THE MINER 2

2.1 Check the miner before power on 2

2.2 Connect the PSU 3

2.3 Connect the Ethernet Cable 3

3. OPERATE THE MINER 4

3.1 Enter the miner console 4

3.2 Set up the pool 4

3.3 Check the hashrate of the miner 5

3.4 Network configuration 5

3.5 Other pages 6

3.5.1 Overview 6

3.5.2 Upgrade 6

3.5.3 Modify the password 7

3.5.4 Reboot 7

3.5.5 Factory reset 7

INNOSILICON CONFIDENTIAL

INNOSILICON D9-DCR

INNOSILICON CONFIDENTIAL

1. OVERVIEW

INNOSILICON CONFIDENTIAL

D9-DCR

Part Number D9

Algorithm Blake256

Hash Rate 2.4Th/s (+-8%)

Power 1000W +/-8%

Size (L×W×H) (L)310mm*(W)130mm*(H)155mm

Net Weight 3.6KG (without PSU)

Operating Temperature 0-40 ℃

Required rated PSU 1400W or above, 7 * PCI-E 6Pin

Network Connection Ethernet

INNOSILICON CONFIDENTIAL

2. ASSEMBLE THE MINER

2.1 CHECK THE MINER BEFORE POWER ON

·Check the warranty sticker is well or not, especially the hashboards PSU port side. If the warranty sticker

is damaged when you received the miner, please contact our After-sales.

·Before you power on the miner, shake the miner softly, if you can hear the sound of metal banging on

metal, please contact our After-sales.

·Check if the fan work well, if you find the fans broken please contact our After-sales.

·Check the cable connection, if it is different from below picture, please connect the cables as below.

INNOSILICON CONFIDENTIAL

D9-DCR

INNOSILICON CONFIDENTIAL

2.2 CONNECT THE PSU

Every hash board needs to be inserted with 2 PSU cables, controller only needs 1 PSU cable according to

the following image .

2.3 CONNECT THE ETHERNET CABLE

Insert one end of the Ethernet cable into the router and the other end into the slot shown in the following

image, you should plug in the miner one by one, only when you have accomplished IP Setting of the

previous one you can plug in another miner .

IP SET button: Press it more than 5 seconds to recover the IP to 192.168.1.25

Press it more than 20 seconds to switch the Dynamic (Static) IP to Static (Dynamic) 4.

RESET button: Your miner will restart if you press it. It wont recover your settings to the default.

INNOSILICON CONFIDENTIAL

D9-DCR

INNOSILICON CONFIDENTIAL

3. OPERATE THE MINER

3.1 ENTER THE MINER CONSOLE

DHCP(the Normal led on the control board should be blinking) is the default IP mode of the miner, find the

IP via the router or the IP scanner.Enter the IP of the miner on the browser and press the Enter button.

The chrome is the suggested browser.

INNOSILICON CONFIDENTIAL

D9-DCR

INNOSILICON CONFIDENTIAL

3.2 SET UP THE POOL

INNOSILICON CONFIDENTIAL

D9-DCR

3.3 CHECK THE HASHRATE OF THE MINER

After set up the pool, the miner will mine for you.

3.4 NETWORK CONFIGURATION

INNOSILICON CONFIDENTIAL

3.5 OTHER PAGES

3.5.1 OVERVIEW

3.5.2 UPGRADE

INNOSILICON CONFIDENTIAL

D9-DCR

INNOSILICON CONFIDENTIAL

D9-DCR

3.5.3 MODIFY THE PASSWORD

3.5.4 REBOOT

3.5.5 FACTORY RESET

INNOSILICON CONFIDENTIAL
