Innophase Talaria TWO EVB-A Manuel utilisateur
User Guide for Talaria TWO Evaluation Board
Version 1.1 1 ©InnoPhase, Inc. 2020
Contents
1Figures......................................................................................................................................2
2Tables.......................................................................................................................................2
3Terms & Definitions .................................................................................................................3
4Introduction .............................................................................................................................4
5INP301x Package Contents .....................................................................................................4
6Description of the board.......................................................................................................... 5
6.1 Block Diagram....................................................................................................................5
6.2 Jumpers on the board........................................................................................................6
6.3 Power Supply and Mode Switch........................................................................................7
6.4 IO Header (J1) .................................................................................................................... 8
6.5 Shield Headers (JP1 to JP4)................................................................................................ 9
6.6 On Board Sensors ............................................................................................................10
7Functional Description...........................................................................................................11
7.1 Stand-alone mode ...........................................................................................................11
7.1.1 Driver Installation for Windows OS..........................................................................12
7.2 Shield Mode.....................................................................................................................17
7.2.1 EVB-A as Wi-Fi Shield with STM32 Nucleo Board ....................................................17
8Power Measurement .............................................................................................................18
9Using Battery as Power Source..............................................................................................19
10 Antenna ............................................................................................................................... 20
11 Power Supply.......................................................................................................................21
12 Talaria TWO Module Integration in End Products ..............................................................22
13 FCC/ISED Regulatory Notices ..............................................................................................23
13.1 Modification Statement...................................................................................................23
13.2 Interference Statement ...................................................................................................23
13.3 Radio Frequency Radiation Exposure Statement ............................................................ 23
13.4 RF Exposure Statement for Module Integration .............................................................24
13.5 Labeling Requirements for the Host Device....................................................................25
14 Support................................................................................................................................27
15 Disclaimers ..........................................................................................................................27
User Guide for Talaria TWO Evaluation Board
Version 1.1 2 ©InnoPhase, Inc. 2020
1Figures
Figure 1: INP3011 EVB-A Board with INP1011 module board installed ............................................................... 4
Figure 2: Block diagram of INP301x Evaluation Board.......................................................................................... 5
Figure 3: INP301x EVB-A control and connectivity points .................................................................................... 6
Figure 4: Power supply section ............................................................................................................................. 7
Figure 5: IO Header................................................................................................................................................ 8
Figure 6: J1 Pinout ................................................................................................................................................. 9
Figure 7: Arduino UNO shield compatible jumpers .............................................................................................. 9
Figure 8: On board sensors ................................................................................................................................. 10
Figure 9: Listing devices in Zadig ......................................................................................................................... 12
Figure 10: Updating Talaria TWO USB driver to libusbK ..................................................................................... 13
Figure 11: Device Manager.................................................................................................................................. 14
Figure 12: Update Devices................................................................................................................................... 15
Figure 13: Select the device driver...................................................................................................................... 16
Figure 14: INP3010 EVB-A as Wi-Fi Shield........................................................................................................... 17
Figure 15: Current measurement setup using Otti Arc....................................................................................... 18
Figure 16: J4 Header............................................................................................................................................ 19
2Tables
Table 1: Jumper Information................................................................................................................................. 6
Table 2: FTDI Layout ............................................................................................................................................ 11
User Guide for Talaria TWO Evaluation Board
Version 1.1 3 ©InnoPhase, Inc. 2020
3Terms & Definitions
BLE Bluetooth Low Energy
DMM Digital Multimeter
DPDT Double Pole Double Throw
FTDI Future Technology Devices International
GPIO General Purpose Input/Output
IO Input Output
JTAG Joint Test Action Group
LED Light Emitting Diode
MPSEE Multi-Protocol Synchronous Serial Engine
SCL Serial Clock
SDA Serial Data
SPI Serial Peripheral Interface
SPDT Single Pole Double Throw
UART Universal Asynchronous Receiver-Transmitter
USB Universal Serial Bus
User Guide for Talaria TWO Evaluation Board
Version 1.1 4 ©InnoPhase, Inc. 2020
4Introduction
Welcome to INP301x Talaria TWO evaluation board user guide. This board is designed as an evaluation
platform for the INP101x modules. This user guide provides an overview of the evaluation board
explaining its key features and functions.
5INP301x Package Contents
The package contains:
1. INP3010 or INP3011 board
2. Micro USB cable
3. Antenna (INP3011 board only)
4. Battery box
Figure 1: INP3011 EVB-A Board with INP1011 module board installed
User Guide for Talaria TWO Evaluation Board
Version 1.1 5 ©InnoPhase, Inc. 2020
6Description of the board
6.1 Block Diagram
Figure 2: Block diagram of INP301x Evaluation Board
The block diagram of the INP301x Evaluation board is shown in Figure 2. The main component on
the board is the INP101x module. Key features of the evaluation board are:
1. Standalone mode vs. Shield mode: Using the mode switch U3, either standalone mode or
shield mode can be selected.
a. In standalone mode, the INP101x can be accessed via micro USB cable for
programming and debugging. This mode is recommended for standalone
application development.
b. In shield mode, the INP101x module can be interfaced with any host CPU and can
provide serial to Wi-Fi capabilities.
2. A peripheral IO header (J1) is available using which all the IO’s of the INP101x module can
be accessed.
3. Power supply section: Based on the mode, the power for module is derived from either
USB or shield header. A battery header is available which can be used as power source as
well.
4. On board sensors are available to develop sensor to cloud applications.
User Guide for Talaria TWO Evaluation Board
Version 1.1 6 ©InnoPhase, Inc. 2020
6.2 Jumpers on the board
Figure 3: INP301x EVB-A control and connectivity points
Jumper
Mode and Operation
J1
IO header
J2
Used to enable Console logging in shield mode
J3
Connect LED D1 to GPIO14, for debug purposes
J4
Select power from battery connector, also used for current
measurements
J7
Connect SCL to GPIO4
J8
Connect SDA to GPIO3
J9
Select IO voltage for FTDI IOs
J10
Battery terminal
JP1 to JP4
Arduino UNO shield compatible header (3.3V support only)
U3
Switch between Stand-alone mode and Arduino Shield Mode
Table 1: Jumper Information
User Guide for Talaria TWO Evaluation Board
Version 1.1 7 ©InnoPhase, Inc. 2020
6.3 Power Supply and Mode Switch
The INP301x board is designed to supply power to the INP101x module in following ways:
1. In standalone mode, power is drawn from USB connector
2. In shield mode, power is drawn from shield connector
3. A battery header is also available to provide power to the module
Figure 4: Power supply section
The power supply section is shown in the Figure 4. The INP101x module requires 3.3V supply. The DPDT
switch (U3) selects between USB and Arduino header supply using the common net Vm_3.3V. The
jumper J4 is used to select between battery supply and Vm_3.3V. The same jumper can be used for
measuring current consumption of the module.
User Guide for Talaria TWO Evaluation Board
Version 1.1 8 ©InnoPhase, Inc. 2020
6.4 IO Header (J1)
The J1 header brings out all the IOs from INP101x module. These IOs can be used for debug, and/or
any external interfacing needs. The pinout of this header is shown in Figure 5. To work with on
board sensor, pins 1 & 2 needs to be shorted.
Figure 5: IO Header
User Guide for Talaria TWO Evaluation Board
Version 1.1 9 ©InnoPhase, Inc. 2020
6.5 Shield Headers (JP1 to JP4)
Arduino UNO compatible headers are available in the INP301x board to interface with any
compatible host micro-controller.
The GPIOs assigned to shield headers are carefully chosen to achieve following capability:
1. INP101x’s SPI slave pins available on JP1
2. INP101x’s I2C master pins available on JP1
3. Remaining GPIOs are available on JP2 and JP4
Note that INP301x supports 2.5V IO as the default configuration. The shield header connections
are shown in Figure 6.
Figure 7: Arduino UNO shield compatible jumpers
Figure 6: J1 Pinout
