Ingersoll-Rand RR100 Series Guide de configuration

80235740

Edition1

June 2007

Save These Instructions

Starter Relay Valve

RR100

Installation and Maintenance

Information

2 80235740_ed1

Description

The RR100-F30-D includes air valve and regulator functions.

The RR100-F30-D is made of three main components:

The master regulator which sets the pilot pressure.

The solenoid valve which will open or close the system when the

operator actuates the switch key.

The slave regulator which is the main body.

The slave regulator will receive the signal from the master regulator

through the solenoid valve. For pre-engage starters the signal

pressure will come from the master regulator through the solenoid

valve to the pilot“In” port of the air starter drive housing, giving the

signal to engage the drive pinion into the ring gear. After engaging

the drive pinion, air will come out through the“Out”port of the drive

housing and will go to the cap of the slave regulator.

The slave regulator using the pressure signal on top of the upper

piston will force the valve piston o its seat. That allows air to ow

into the control chamber below the upper piston, through the

outlet port of the RR100 valve to the starter motor. Outlet pressure

increases in the downstream system and sensing chamber (under

the upper piston) and applies an upward force on the bottom of

the upper piston. The upper piston and valve piston move upward.

Upward movement stops when the forces below the upper piston

balance the force above the upper piston.

WARNING

Do not use this starter relay valve with natural gas or other

ammable gases.

Operation

Clockwise rotation of screw (1) will open the seat in the master

regulator and will increase the pressure between the master

regulator and solenoid valve (2). Do not try to exceed 11 bar or 160

psig (or slightly higher than the working pressure of the starter).

The pressure you adjust at the slave regulator will be slightly higher

than the working pressure at the starter. In order to easily adjust the

working pressure install a gauge on the gauge port.

(Dwg. 45534005)

The master pressure regulator is designed as a relieving regulator.

When the pressure below the diaphragm reaches 1.5 bars over the

adjusted pressure, the regulator exhausts the excess pressure.

(Dwg. 45532504) (Dwg. 45533866)

80235740_ed1 3

Dimensions

(75.8) [2.99]

(68.1) [2.68]

(50.3) [1.98]

(76.3) [3.00]

(73.0) [2.88]

(52.4) [2.06]

4X (9.8) [.39]

(50.8) [2.00]

(26.2) [1.03]

(15.2) [.60]

(25.7) [1.01] (110.0) [4.33] (35.2) [1.39]

(127.5) [5.02]

(43.7) [1.72]

Ø (54.3) [2.14]

91-279

4X 3/8 - 16 UNC Screws

1.00” SAE J518C Flange Head

Outlet Inlet

(Dwg. 45534021)

Schematics Piping Diagram

Master Regulator

For Inertia Drive Applications

For Pre-Engaged Drive Applications

Out

Safety Valve (Optional)

Slave Regulator

Gage

(Optional)

Solenoid Valve

Master Regulator

Out

Air

Safety Valve

(Optional)

Pre-engaged

Air Starter

Slave Regulator

Gage

(Optional)

Solenoid Valve

This line must be diverted if the

valve is used with pre engaged

air starter

(Dwg. 80177223)

4 80235740_ed1

Installation

The RR100-F30 is specially designed and manufactured by

Ingersoll Rand for use on air starter installations. Install it in

accordance with the following instructions.

For installation of the valve on the starter

Install a 50 micron or 300 mesh compressed air Strainer upstream

of the RR100-F30. If possible install the RR100-F30 directly on

the Starter. The valve is delivered with the ange and 4 captive

screws. Using a 14 mm wrench, tighten the 4 captive screws to

40 Nm torque.

Install the O-Ring in the Inlet Flange groove. Attach a 1 inch hose

to the inlet of the valve with a ST400-16 4-bolt split-ange. Using

a 14mm wrench, tighten the four ange bolts to 40 Nm torque.

If desired, connect an outlet pressure gauge to the gauge port.

The gauge ports can also be used as additional outlets. Make sure

unused gauge ports are plugged.

For installation of the valve in a dierent location than

on the starter

Install a 50 micron or 300 mesh compressed air Strainer upstream

of the RR100-F30.

For industrial or Marine applications the valve can be installed on

a steel pipe in a remote location. Apply SMB-441

Ingersoll Rand Sealant to the tapped inlet of Flange ST400-18.

Tighten the ST400-18 ange on the steel pipe to 80 Nm torque .

If desired, connect an outlet pressure gauge to the gauge port.

Gauge ports can also be used as additional outlets. Make sure

unused gauge ports are plugged.

Mount the RR100-F30 valve to ange ST400-18 with supplied

ange ttings. Tighten the four ange bolts to 40 Nm Torque.

Attach a 1 inch hose to the outlet side of the valve with the

ST400-16 4-bolt split-ange. Tighten bolts to 40 Nm torque.

Attach the 1 inch hose to the Starter Inlet ange. Tighten the 4

bolts to 40 Nm torque.

Pressurize the complete starting system. Using a soap solution,

check for leaks.

Specications

Master Regulator

Specications

Flow Capacity 17 I/s (36 scfm) Air

Maximum Operating

Temperature 82°C (180°F)

Maximum Supply Pressure 30 bars (435 psig)

Adjusting Range Pressure 0 - 11, bars (160 psig)

Port Size NPT 1/4

Gauge Port (s) NPT (2) 1/8

Weight kg (lb) 0.2 (0.48)

Slave Regulator

Specications

Flow Capacity 380 I/s (800 scfm) Air

Maximum Operating

Temperature 82°C (180°F)

Maximum Supply Pressure 30 bars (435 psig)

Adjusting Range Pressure 0 - 11, bars (160 psig)

Port Size SAE 1inch

Gauge Port (s) BSPT (2) 1/4

Weight kg (lb) 0.2 (0.48)

80235740_ed1 5

Materials of construction

Master Regulator

Materials of Construction

Body Brass

Bonnet Brass

Diaphragm Nitrile /Brass/Zinc-plated steel

Valve Assembly Nitrile

Springs Stainless Steel

Seals Nitrile

Slave Regulator

Materials of Construction

Housing Zinc/Steel

Cap Aluminum

Upper Piston Zinc

Valve Piston Assembly Brass/Polyurethane

Springs Stainless Steel

Seals Nitrile

Solenoid Valve

Valve Normally Closed 3/2 Way

Seat Port Diameter 1.3 mm

Max. Ambient Temperature 82°C

Min Temperature Dry Air -20°C

Kv 1.5

Max. working Pressure 10.5 Bars

Pressure to open plunger 16 Bars

Air Flow rate at 6 Bars 53 l/s

Plunger Stainless Steel

Body Material Zinc

Position Any

Seals Nitrile

Springs Stainless Steel

Connector Din 436540 (PG9)

Port 1/8 bsp

Protection IP 65

6 80235740_ed1

Performance

RR100

-F30 Air Flow performance

030 60 90 120 150 180 210 240 270 300 330 360 390 420 450

Liters per second

Secondary Pressure in bars

4 bars

5 bars

6 bars

7 bars

8 bars

9 bars

10 bars

Nomenclature

Pressure at inlet

(Bar)

Pressure Regulator

Relay Valve

1 inch

RR 100 F30

Flange mounted SAE 1”

Maintenance and Recommendations

CAUTION

Always wear eye protection when performing any maintenance on this valve.

Always turn o the air and electrical supply and disconnect the air and electrical supply before installing or removing any

component on this valve, before making any adjustments on this valve or before performing any maintenance on this valve.

•

Disassembly

General Information

Do not disassemble the valve any further than necessary to

replace worn or damaged parts.

When grasping a part in a vise jaw, always use copper-covered

vise jaws to protect the surface of the part and help prevent

distortion. This is particularly true of threaded members.

Do not remove any part which is a press t in or on a subassembly

unless the removal of that part is necessary for replacement or

repairs.

Always have a complete set of seals and O-rings on hand before

starting any overhaul of a valve. Never reuse old seals or gaskets.

Disassembly of the Main Valve Body

Refer to Dwg. 45534054 and Parts List

Disconnect the pilot regulator assembly from the cap (1) of the

valve.

Using a strap wrench, unscrew and remove the housing cover (2).

Pull the return spring and the piston assembly (4) from the valve

housing. Turn the valve housing upside down. Using a retaining

ring pliers remove the retaining ring (5).

Pull cap (1) from the valve housing.

Pull master piston (3) from the valve housing. Remove all the

O-rings to be replaced.

Assembly

General Instructions

Whenever grasping a valve or part in a vise, always use

copper-covered vise jaws. Take extra care with threaded parts or

housings.

Clean every part before installation.

Apply a lm of O-ring lubricant to all O-rings before nal assembly.

Assembly of the Valve

Refer to Dwg. 45534054 and Parts List

Lubricate the valve piston shaft with O-ring lubricant. Slide piston

assembly (4) into the valve housing. Slide the piston spring into

the bottom of the piston.

Place O-ring (8) in the groove of the valve housing.

Install housing cover (2) in the valve housing. Using a strap

wrench tighten it enough not to loosen by hand.

Hold the valve housing in a vise.

Install O-ring (6) in the master piston groove, lubricate it with an

O-ring lubricant, and slide the master piston (3) into the valve

housing.

Install O-ring (7) in the valve housing groove.

Install cap (1) in the valve housing. Install retaining ring (5) using

retaining ring pliers.

Reconnect the pilot regulator assembly to the cap of the valve.

80235740_ed1 7

Valve / Regulator RR100-F30 Parts Diagram

824

(Dwg. 45534054)

Valve / Regulator RR100-F30 Parts List

Item Part Description Part Number

1 Cap RR100-616A

2 Housing Cover RR100-338

3 Upper Piston RR100-1

4 Valve Piston Assembly (includes spring, 6, 8) RR100-K618-3

5 Retaining Ring RR100-352

6 Upper Piston O-Ring RR100-341

7 O-Ring RR100-340

8 O-Ring RR100-337

9 Inlet O-Ring RR100-342

Solenoid Valve 24V-DC 5 watt & Override RR100-2450-5P

Solenoid Valve 24V-DC 5 watt & Screw RR100-2450-5S

Solenoid Valve 24V-DC 8 watt & Override RR100-K2450-8P

Pilot Regulator with Solenoid Valve Assembly RR100-K2450-5P

Valve Tune-Up Kit (Includes Items 4,5,6,7,8,9) RR100-TK1-3

Parts and Maintenance

CAUTION

The use of other than genuine Ingersoll Rand replacement parts may result in safety hazards, decreased motor performance, and

increased maintenance, and may invalidate all warranties.

Ingersoll Rand is not responsible for customer modication of motors for applications on which Ingersoll Rand was not consulted.

Repairs should be made only by authorized trained personnel. Consult your nearest Ingersoll Rand Authorized Service center.

When the life of the Tool has expired, it is recommended that the Tool be disassembled, degreased and parts be separated by material so

that they can be recycled.

Manuals can be downloaded from www.irtools.com.

Refer all communications to the nearest Ingersoll Rand Oce or Distributor.

www.irtools.com

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Ingersoll-Rand Unité de contrôle

Ingersoll-Rand

Ingersoll-Rand VHP600CM Manuel

Ingersoll-Rand

Ingersoll-Rand SRV125F Series Manuel utilisateur

Ingersoll-Rand

Ingersoll-Rand Dor-O-Matic 96000 Series Manuel utilisateur

Ingersoll-Rand

Ingersoll-Rand ARO STOP 23644-400 Manuel utilisateur

Ingersoll-Rand

Ingersoll-Rand MHD56177 Fiche technique

Ingersoll-Rand

Ingersoll-Rand X8I Manuel utilisateur

Ingersoll-Rand

Ingersoll-Rand BAYLOAM335 Manuel utilisateur

Ingersoll-Rand

Ingersoll-Rand RR250-F30 Guide de configuration

Ingersoll-Rand

Ingersoll-Rand Sierra Series Guide de configuration

Ingersoll-Rand

Ingersoll-Rand 635390 Series Manuel utilisateur

Ingersoll-Rand

Ingersoll-Rand THERMO KING TriPac e Manuel utilisateur

Ingersoll-Rand

Ingersoll-Rand IC-PCM Manuel utilisateur

Ingersoll-Rand

Ingersoll-Rand 900-082HMP Manuel utilisateur

Ingersoll-Rand

Ingersoll-Rand RR125-F30 Guide de configuration

Ingersoll-Rand

Ingersoll-Rand LCN 2900 Series Manuel de service

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
