M2M CONTROL C660

Technical Manual

Version 2.0

M2M CONTROL C660 - Technical Manual V2.00

www.m2mcontrol.de

[email protected] Page 2 of 36

Introduction

This manual contains technical documentation which allows for easy installation and use of the

M2M Control C660 unit. For information on the programming and software configuration of the

M2M Control C660 please refer to the M2M CONTROL IDE documentation.

The M2M Control C660 adds a new chapter to the highly successful era of the C6xx series offering

a wide range of new features and performance improvements while still resting on the proven

track record and confidence of the M2M Control C600 series.

The M2M Control C660 uses the next generation NX32 execution model, and is fully backward

compatible with the X32 execution model of the former C6xx series. Existing software will

therefore be able to operate without any changes or costly re-testing. Mechanically and electrically

the C660 is fully back-ward compatible with the C600 and constitutes therefore a direct plug-in

replacement.

The M2M Control C660 has been designed from the ground up for professional telemetry /

telematics applications and has been designed according to the highest technical standards for

professional automotive and industrial use. The product has all necessary regulatory approvals –

including 2004/104/EC / UN ECE R10 –edition 3 and CE mark.

The advanced power-management features on the M2M Control C660 combined with the on-

board high-capacity Li-Ion battery allows the unit to stay in power-saving mode for a longer

period of time still being connected to the GSM network and capable of waking up on for example

GSM activity, change of digital inputs or a vibration sensor.

For demanding applications the M2M Control C660 offers a 4G LTE Cat.1 cellular communication

with fallback to 3G and 2G. The positioning is enhanced with a state-of-the-art GNSS receiver with

GPS and GLONASS support.

The M2M Control C660 rests on the M2M CONTROL Professional Series RTCU Platform which

brings all the necessary tools together to develop, implement and maintain today’s sophisticated

M2M/IoT applications.

The term “RTCU”stands for Remote Terminal Control Unit and constitutes a unique combination

of a programmable control-unit with the possibility of both digital- and analog I/O plus a GSM

modem.

The development task is supported by the M2M CONTROL IDE development environment,

complimented by a large and comprehensive documentation and application example library.

M2M Control GPRS Gateway is the corner stone of the communication infrastructure and ensures

reliable two-way device communication in any network environment.

Deploying and maintaining new application and firmware versions for devices in the field is

handled by the powerful M2M Control Upgrade & Deployment Server.

M2M CONTROL C660 - Technical Manual V2.00

www.m2mcontrol.de

[email protected] Page 3 of 36

The technical highlights of the M2M Control C660:

Based on the M2M CONTROL RTCU Platform.

NX32 execution architecture.

oM2M CONTROL IDE development tool with full a featured device simulator.

oHuge standard API with more than 800+ functions.

oComprehensive protocol support, including:

TCP-UDP/IP, FTP, SMTP, RACP, MQTT, MODBUS, FMS/J1939, NMP/Garmin FMI.

High-speed 4G LTE Cat. 1 engine. Backward compatible with 3G/2G

Internal and external SIM-card reader selectable from the application.

Digitized audio can be played over GSM or to an external device.

DTMF support for implementation of Interactive Voice Response applications.

State-of-the art Multi-GNSS positioning engine with GPS,GLONASS,QZSS.

High-performance 3-axis accelerometer with 16g scale.

Enhanced memory sub-system with fast program execution.

Huge data-flash/logger memory with a capacity of 8.5 MB.

Internal 8 MB FAT32 flash drive.

Standard FAT32 SD-CARD reader with up to 32 GB capacity.

2 x RS232 channels and 1 x RS485 channel.

2 x analog inputs with 0..10 volt / 12 bit precision.

5 x digital inputs and 4 high-power solid-state digital outputs.

Full CAN 2.0B controller with hardware filtering and multi-speed support.

1-Wire bus for accessories such as ID-button reader, temperature sensors, etc.

Wide operating range from 8..36 VDC.

External power can be selectable enabled/disabled by the application.

On-board high-capacity Li-Ion battery.

Advanced power-management with wake-up on a wide range of events.

Hands-free interface with microphone and Class-D audio speaker amplifier.

High-speed USB programming cable support.

Fully supports the Professional Navigation and Messaging device PNM-220.

Support the Garmin Fleet Management Interface.

Fully supported by the M2M Control GPRS Gateway and

the M2M Upgrade and Deployment Server.

Accessories: Wi-Fi, Ethernet, Bluetooth, Camera and PNM-220 Navigation Device.

Exclusive and durable GOLD aluminum encapsulation.

M2M CONTROL C660 - Technical Manual V2.00

www.m2mcontrol.de

[email protected] Page 4 of 36

* * * * THIS PAGE IS INTENTIONALLY LEFT BLANK * * *

M2M CONTROL C660 - Technical Manual V2.00

www.m2mcontrol.de

[email protected] Page 5 of 36

Table of Contents

Introduction......................................................................................................................................................2

The technical highlights of the M2M Control C660:...................................................................................3

Table of Contents.............................................................................................................................................5

Graphical view.................................................................................................................................................6

External connections .......................................................................................................................................6

Overview ......................................................................................................................................................7

Accessories for cable assembly..................................................................................................................9

Power supply.............................................................................................................................................10

Digital Outputs..........................................................................................................................................11

Digital Inputs / Ignition Input .................................................................................................................12

Analog Inputs ............................................................................................................................................13

RS232 port 1 / programming port ...........................................................................................................14

RS232 port 2 ...............................................................................................................................................14

RS485...........................................................................................................................................................15

CAN ............................................................................................................................................................16

1-Wire bus ..................................................................................................................................................17

DC-Out........................................................................................................................................................17

Hands-free connector................................................................................................................................18

External voice output................................................................................................................................18

3D movement sensor.....................................................................................................................................19

LED Indicators ...............................................................................................................................................20

User LED A and B .....................................................................................................................................20

System LED S1 and S2 ..............................................................................................................................21

Switches ..........................................................................................................................................................22

DIP-switch..................................................................................................................................................22

System switch (RST)..................................................................................................................................22

Internal Li-Ion battery...................................................................................................................................23

Internal / External SIM-card readers...........................................................................................................24

Installing the external SIM-card ..................................................................................................................24

Installing the internal SIM-card...................................................................................................................25

SD-CARD reader ...........................................................................................................................................25

Approved SD-CARDs...............................................................................................................................25

Installing the SD-CARD ...........................................................................................................................26

Antennas.........................................................................................................................................................27

Cellular .......................................................................................................................................................27

GNSS ...........................................................................................................................................................27

Device identification label ............................................................................................................................27

Power consumption ......................................................................................................................................28

Specification for the 99-channels multi-GNSS receiver............................................................................29

Appendix A –Assembling/disassembling of the unit..............................................................................30

Appendix B –Installing a SIM-card into the internal SIM-card reader.................................................31

Appendix C –Enabling the CAN bus Write capability ...........................................................................33

M2M Control C660 Specifications...............................................................................................................35

M2M CONTROL C660 - Technical Manual V2.00

www.m2mcontrol.de

[email protected] Page 6 of 36

Graphical view

M2M CONTROL C660 - Technical Manual V2.00

www.m2mcontrol.de

[email protected] Page 7 of 36

External connections

Overview

Connections to external equipment are done via the connectors located on the back and front of the

M2M Control C660.

The front panel is equipped with connectors commonly accessed by the user: SIM-Card, SD-

CARD, DIP-Switch, Headset, LED’s and RS232.

The back panel holds all connectors necessary for installation: 4-pin (X1) power and ignition, 6-pin

(X4) for RS232/Programming, 12-pin (X2) for different communication interfaces and a 16-pin (X3)

for analog and digital I/O. Connection to the GSM antenna is via a SMA female, and connection to

a 3V active GNSS antenna is done via the SMB male connector. Both antenna connectors are

located on the back panel.

A graphical overview of the front- and back are shown below:

Front-side view

Back-side view

System Switch

SER2

Hands-free

Connector

Sim Card Reader

Dipswitch

SD-CARD Reader

Pin 1

antenna

GNSS

antenna

GSM

X4: SER1

X1: PWR

X3: I/O

X2: COM

M2M CONTROL C660 - Technical Manual V2.00

www.m2mcontrol.de

[email protected] Page 8 of 36

Connector X1: 4 pin PWR connector overview

Name

Description

SUPP

Power supply, positive (+) connection

DI5/IGN

Digital input 5 / Ignition input (Shared with X3)

SUPP

Power supply, positive (+) connection

PGND

Power Ground

Connector X2: 12 pin COM connector overview

Name

Description

1Wire

1-Wire bus

SGND

Signal Ground

CAN-H

CAN-bus H-signal

Voice

External voice

RS485+

RS485 non-inverting signal

RS485-

RS485 inverting signal

1W-LED

1-Wire ID-Button LED

SGND

Signal Ground

CAN-L

CAN-bus L-signal

SGND

Signal Ground

SGND

Signal Ground

DC-Out

+3.3V/150mA DC-Out for external equipment. (Shared with X4)

Connector X3: 16 pin I/O connector overview

Name

Description

DOUT 1

Digital output 1

DOUT 3

Digital output 3

DIN 1

Digital input 1

SGND

Signal Ground

DIN 3

Digital input 3

DIN 5/IGN

Digital input 5 / Ignition input (Shared with X1)

AIN 1

Analog input 1

AIN 2

Analog input 2

DOUT 2

Digital output 2

DOUT 4

Digital output 4

DIN 2

Digital input 2

SGND

Signal Ground

DIN 4

Digital input 4

SGND

Signal Ground

AGND

Analog Ground

AGND

Analog Ground

M2M CONTROL C660 - Technical Manual V2.00

www.m2mcontrol.de

[email protected] Page 9 of 36

Connector X4: 6 pin SER1 connector overview

Name

Description

Transmit Data from serial port 1, RS232 compatible

RS-DET

Programming cable detect, normally unconnected

(if programming cable, connect to GND)

DC-Out

+3.3V/150mA DC-Out for external equipment.

(Shared with X2)

Receive Data for serial port 1, RS232 compatible

SGND

Signal Ground

SGND

Signal Ground

Connector SER2: RJ45 connector overview, fully RS232 compatible

Name

Description

DSR

Data Set Ready

DCD

Data Carrier Detect

DTR

Data Terminal Ready

SGND

Signal Ground

Receive Data for serial port 2

Transmit Data from serial port 2

CTS

Clear To Send

RTS

Request To Send

Accessories for cable assembly

Order-code

Name

RT-O-TYCO-H4

TYCO p/n: 794617-4

Tyco, Connector house 4 pins. Bag with 10 pcs

RT-O-TYCO-H6

TYCO p/n: 794617-6

Tyco, Connector house 6 pins. Bag with 10 pcs

RT-O-TYCO-H12

TYCO p/n: 1-794617-2

Tyco, Connector house 12 pins. Bag with 10 pcs

RT-O-TYCO-H16

TYCO p/n: 1-794617-6

Tyco, Connector house 16 pins. Bag with 10 pcs

RT-O-TYCO-CR

TYCO p/n: 794606-1

Tyco, Crimp Contacts for connector house. Wire size 0.2 to 0.5 mm2.

Bag with 100 pcs.

RT-O-TYCO-TOOL

TYCO p/n: 91501-1

Tyco, Crimp hand tool for easy assembly of TYCO crimp contacts.

Wire size 0.2 to 0.5 mm2

Recommended tool:

Alternative tools:

Tyco 91501-1 (0.20 to 0.50mm2) RS 495-9675, Farnell 1111475

Tyco 91502-1 (0.05 to 0.15mm2) RS 495-9675, Farnell 1111476

Extraction tool:

Tyco 843996-6 extraction tool. RS 495-9704, Farnell 1111477

2.5mm MicroJack

Plug for headset connector. Farnell 5096339 (black plastic house) or

Farnell 8045453 (metal house).

M2M CONTROL C660 - Technical Manual V2.00

www.m2mcontrol.de

[email protected] Page 10 of 36

Power supply

The M2M Control C660 device must be supplied with 8..36 VDC from an external DC power

source connected to the X1 connector. Positive power is applied to the SUPP pin, and ground is

connected to the PGND pin.

The connector has two “SUPP” supply pins as these also supplies power to the digital outputs. If

the total current consumption on the digital outputs exceeds 5A, then power must be applied to

both pins. Otherwise one pin is sufficient.

There are three different labels for the ground connections:

Power Ground (PGND)

Signal Ground (SGND)

Analog Ground (AGND)

The signal and analog grounds are filtered from the power ground. Power ground must only be

used as power supply return path. The signal ground is used as ground reference for digital I/O’s

and serial interfaces, and the analog ground is used as a low noise analog ground reference for the

analog inputs.

The C660 is protected against wrong polarity. If a chassis or system ground is connected to either

SGND or AGND, a wrong polarity on the supply lines will destroy the internal GND connection.

For avoidance of such a scenario, a fuse can be installed on the positive supply.

The C660 also contains an internal high capacity backup battery which will supply the C660 if the

external power supply fails or is disconnected. By default the C660 is powered down when a

power fail occurs. This setting, however, can be changed. Please consult the M2M CONTROL IDE

on-line help for more information. The display will automatically turn off when external power is

removed.

Disabling the external DC power from the application interface and forcing the device to operate

on the internal backup battery is supported. Please consult the M2M CONTROL IDE

documentation for additional information.

When the ignition input is activated with a logical high, the C660 unit will wake-up if it was in

power down mode. The ignition input (digital input 5) is available on the power connector to

minimize the need for connectors in minimal installations, but it is also available on the X3

connector (digital I/O and analog Inputs) - only one should be used at a time.

X1: 4 pin PWR connector overview

Name

Description

SUPP

Power supply, positive (+) connection

DI5/IGN

Digital input 5 / Ignition input (Shared with X3)

SUPP

Power supply, positive (+) connection

PGND

Power Ground

Table des matières

Autres manuels Infranet Technologies Porte

Infranet Technologies

Infranet Technologies M2M CONTROL CX660 Manuel utilisateur

Infranet Technologies

Infranet Technologies M2M CONTROL CX530 Manuel utilisateur

Manuels Porte populaires d'autres marques

LST

LST M500RFE-AS Manuel utilisateur

Kinnex

Kinnex Media Gateway Manuel utilisateur

2N Telekomunikace

2N Telekomunikace 2N StarGate Manuel utilisateur

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manuel utilisateur

Telsey

Telsey CPVA 500 - SIP Manuel utilisateur

RTA

RTA 460A-NNA4 Fiche technique

Shaw

Shaw Gateway HDPVR Manuel utilisateur

ABB

ABB VSN900 Guide de démarrage rapide

Commander

Commander Pulse Manuel utilisateur

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manuel utilisateur

NETGEAR

NETGEAR C6300BD Manuel utilisateur

Amit

Amit CDW531AM Manuel utilisateur

HMS

HMS Netbiter EasyConnect EC150 Manuel utilisateur

Huawei

Huawei EchoLife HG620 Manuel utilisateur

AT&T

AT&T U-verse 3801 Manuel d'utilisation et d'entretien

Logic IO

Logic IO RTCU MX2 turbo Manuel utilisateur

Suttle

Suttle MediaMAX MXM-521 Manuel utilisateur
