InFocus LP610 Manuel utilisateur

TABLE OF CONTENTS

Safety Summary iii

Introduction 1

Image Resolution 1

Compatibility 2

Unpacking the Projector 2

Usage Guidelines 4

If You Need Assistance 4

Warranty 4

Setting up the Projector 5

Connecting the CableWizard to the Projector 6

Selecting Connectors on the CableWizard 7

Preparing to Connect Your Equipment to the Projector 8

Connecting an IBM-CompatibleDesktop Computer 9

Connecting an IBM-CompatibleLaptop Computer 11

Connecting a Macintosh Desktop Computer 13

Connecting an Apple PowerBook Computer 15

Connecting a Video Player 17

Connecting anExternal Speaker and a Subwoofer 19

Connecting a Microphone 19

Connecting a PS/2-Compatible Mouse 20

Connecting the Remote Control Cable 20

Powering up the Projector and Adjusting the Image 21

Turning Off the Projector 23

Using the Projector 25

Basic Image Adjustment 25

Using the Remote Control 25

Adjusting the Projector 26

Changing between Color and Monochrome Modes 28

Using the Remote and Keypad Buttons 29

Using the Disk Mouse 32

Using the On-Screen Menus 32

Display Menu Functions 34

Audio Menu Functions 35

Image Menu Functions 37

Controls Menu Functions 39

Table of Contents

Maintenance & Troubleshooting 41

Cleaning the Lens 41

Replacing the Projection Lamp 41

Resetting the Lamp Monitor Light 44

Replacing the Batteries in theRemote Control 44

Using the Kensington Lock 44

Troubleshooting 45

Solutions to Common Problems 46

Appendix 51

Specifications 51

Accessories 53

Portable and Laptop Activation Chart 55

Using Video Mirroring with a PowerBook Computer 59

Projected Image Size 60

Index 63

iii

SAFETY SUMMARY

Please read these instructions carefully before using your LitePro

610 or 620. Failure to comply with them could result in fire, elec-

trical shock, personal injury or damage to equipment.

These graphics are used throughout this manual to draw your

attention to important information about the projectors.

NOTE: Additional useful details or tips.

CAUTION: Steps to avoid damage to your equipment.

WARNING: Steps to avoid personal injury.

These graphics are used onLitePro labels.

Attention: Refer to this User’s Guide for important

safety information.

Hot Surfaces: Avoid touching hot surfaces. Do nottouch

until the LitePro has cooled.

Lamp Explosion Hazard: If you continue to use the

lamp after the lamp monitor light comes on, it may

explode, severely damaging your LitePro. Be sure to

replace the lamp when the lamp monitor light comes on

as described in this User’s Guide. Refer to the section

titled “Replacing the Projection Lamp” for information

about changing the bulb.

Safety Summary

Do not look into the lens!

Be extremely careful not to look intothe projection lens when the

LitePro is turned on. The bright light may harm your eyes. Be

especially careful to keep children from looking into the lens.

Turning projector on and off

Allow the projector to warm up for three minutes before turning

it off; allow the projector to cooldown for three minutes before

turning it back on. Repeatedly turning the projector on and off

without waiting three minutes may cause the lamp to explode.

Power source

Useonly a three-wire grounding type power source. Thenominal

power source should not exceed 240 volts rms between the sup-

ply conductors or between either conductor and the ground.

Power cord

Use only the power cord that was shipped with the LitePro.

Although other power cords mightbe similar in appearance,they

have not beensafety-tested with the 610 or 620. Do not use a

power cord if it has become damaged or frayed. Contact your In

Focus dealer or call In Focus if you need to replace your power

cord.

CAUTION: Be sure to replace

the projection bulb when the lamp

monitor light comes on as

described on page 41. If the lamp

remains in use too long, there is a

danger of bulb explosion. If this

happens, your LitePro will be

severely damaged.

Grounding

The projector is grounded through the grounding conductor on

the power cord. To avoid electric shock, plug the power cord into

a properly wired receptacle. Do not defeat the purpose of the

grounding-type plug.

Lamp

To avoid overheating and unacceptable image quality, replace

the projection lamp with a lamp of thespecified type. Refer to

page 52 for lamp specifications and to page 41 for instructions on

replacing the lamp.

Lamp compartment

To avoid burns or an explosion hazard, do not open the lamp

module door until the projector is turned off and the lamp has

cooled. The hot lamp contains high pressure and can explode if

damaged or old. Follow the instructions in this manual for lamp

replacement carefully.

Hot surfaces

Allow the projector to cool at least 45 minutes before replacing a

lamp. When you open the lamp housing, be very careful not to

touch the hot surfaces inside.

Ventilation and overheating

Openings in the projector case provide ventilation to protect it

from overheating. Keep loose papers and other objects well away

from the bottom, top and side grills. Do not place the projector on

top of or close to a computer or other heat-producing equipment.

Liquid spills

Do not set drinks on top of the projector. Spilled liquids can flow

inside and cause damage.

NOTE: If you open the projector,

you will void the warranty.

Do not disassemble

All service must be performed by an In Focus Authorized Service

Provider. The only user-serviceable part in the projector is the

projection lamp, which you can replace by opening the lamp

cover in the front of the projector as described on page 41.Do not

open any other part of the projector. If your LitePro needs repair,

call In Focus Customer Service as described on page 4. Before

you call Customer Service, you may want to refer to “Trouble-

shooting” starting on page 45 to see if you can resolve the prob-

lem yourself.

INTRODUCTION

The In Focus Systems LitePro®610 and 620 multimedia projec-

tors combine powerful and sophisticated features with easy-to-

use, intuitive controls. Built-in multimedia features include high-

fidelity stereo audio by JBL™, a palette of 16.7 million colors and

Digital Light Processing™ (DLP) technology. The 600 series pro-

jectors are ideal for high-performance business, training and

imaging applications that demand exceptional color quality. The

610 has VGA graphics, the 620 has SVGA graphics. The user

interfaces of the two products are identical; information in this

User’s Guide applies to both products.

Image Resolution

LitePro 610

The VGA resolution of the projected image of the 610 is 640x480.

The projector displays computer images that are 640x480 or

lower just as they appear on your computer’s monitor. Screen

resolutions between640x480 and 800x600 are compressed to

640x480. The projector cannot compress screen resolutions above

800x600. If your computer’s screen resolution is higher than

800x600, reset it to a lower resolution before you connect the pro-

jector.

LitePro 620

NOTE: The 620 automatically

expands 640x480 images to

800x600. You can display these

images at 640x480 by turning off

the Auto Resize feature.See “Auto

Resize” on page 37 for more

information.

TheSVGA resolution of the projected image of the 620 is800x600.

The projector displays computer images that are 800x600 or

lower just as they appear on your computer’s monitor. Screen

resolutions between800x600 and 1024x768 are compressed to

800x600. The projector cannot compress screen resolutions above

1024x768. If your computer’s screen resolution is higher than

1024x768, reset it to a lower resolution before you connect the

projector.

Introduction

Compatibility

The projector is compatible with a wide variety of computers and

video devices, including:

•IBM-compatible computers, including laptops, up to 800x600

resolution (LitePro 610) or 1024x768 resolution (LitePro 620) at

60Hz.

•IBM PS/2 in VGA and MCGA modes.

•Apple Macintosh and PowerBook computers up to 800x600

resolution (LitePro 610) or 1024x768 resolution (LitePro 620).

•Various VCRs, camcorders and laser disc players.

The projector is not compatible with these systems:

•IBM-compatible computers in CGA or EGA graphics mode.

•Macintosh 128, 512, Plus, SE, SE/30 or Classic.

Unpacking the Projector

The projector comes with theparts shown in Figure 1. Check to

make sure all are included. If any parts are missing, contact your

In Focus dealer immediately.

If you are experienced in setting up presentation systems, use the

LitePro 610/620 Quick Start card that was included in the shipping

box. For complete details on connecting and operating the projec-

tor, refer to the appropriatesections of this User’s Guide.

NOTE: The contents of your

shipping box may varydepending

on the LitePro 610/620

configuration you ordered.

FIGURE 1

Shipping box contents

1. LitePro 610 or 620 projector 6. CableWizard

2. LitePro 610/620 User’s Guide 7. CableWizard computer cable

3. power cord 8. CableWizard mouse cable

4. remote and batteries 9. CableWizard audio cable

5. RCA audio/video (A/V) cable Not shown: Quick Start card,

remote cable

Introduction

Usage Guidelines

•Do not look directly into the projection lens when the projector

is turned on. The bright light may harm your eyes.

•The top and bottom of the projector can be very hot to the

touch after use. Use extreme care or let it cool before lifting it.

•Do not block the grills at the front, side, top or bottom of the

projector. Restricting the air flow through the projector can

cause it to overheat and turn off.

NOTE: If the projector overheats

and turns off, you must wait 45

seconds before you attempt to

turn it back on.

•Handle the projector as you would any product with glass

components. Be especially careful not to drop it.

•Avoid leaving the projector indirectsunlight or extreme cold

for extended periods of time. If this happens, allow it to reach

room temperature before use.

•Transport the projector in a vendor-approved hard or softcase.

Call your In Focus dealer for more information.

If You Need Assistance

The first place to look for help is in this manual. Be sure to check

theguidelines in “Troubleshooting” on page 45.

If this manual doesn’t answer your question, call your In Focus

dealer. You can also call In Focus Customer Service directly at

1-800-799-9911. Call between 6 a.m. and 5 p.m. PST, Monday

through Friday. In Europe, call In Focus in The Netherlands at

(31) 23-5623200. In Singapore, call (65) 334-9005.

The In Focus World Wide Web address is http:\\www.infs.com.

Warranty

These products are backed by a limited one-year warranty. The

details of the warranty are printed at the back of this manual.

Longer term warranties can be purchased from your In Focus

dealer. Refer to page 54 for part numbers.

SETTING UP THE PROJECTOR

1Place the projector on a flatsurface.

•The projector must be within 10 feet of your power source

and within 10 feet of your computer.

NOTE: An optional extension

cable,sold separately, lets you

increase the distance between the

projectorand your computer to 50

feet. See “Accessories” on

page 53.

•If you want to project from behind a translucentscreen, set

up the projector behind your screen. See “Rear Projection”

on page 40 to reverse the image.

•If you are installing the projector on the ceiling, see the

LitePro 610/620 Ceiling Mount Installation Guide for recom-

mendations. To turn the image upside down, see “Ceiling”

on page 39. The Ceiling Mount Kit is sold separately. See

“Accessories” on page 53.

2Position the projector thedesired distance from thescreen.

•The distance from the lens of the projector to the screen

determines the size of the projected image. Figure 2 shows

three projected image sizes for the 610; Figure 3 shows

imagesizes for the 620. For more information, see “Pro-

jected Image Size” on page 60.

3Make sure the projector and your computer are turned off.

FIGURE 2

Projected image size for LitePro 610

5 ft.10 ft. 25 ft.

PROJECTOR

Autres manuels pour LP610

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels InFocus Projecteur

InFocus

InFocus IN1501 Manuel utilisateur

InFocus

InFocus IN3124 Manuel utilisateur

InFocus

InFocus LP130 Manuel utilisateur

InFocus

InFocus LP 225 Instructions d'installation

InFocus

InFocus LiteBoard IN3902LB Manuel utilisateur

InFocus

InFocus LiteBoard IN3902LB Manuel utilisateur

InFocus

InFocus X1a Manuel utilisateur

InFocus

InFocus LP 740 LiteMount Manuel utilisateur

InFocus

InFocus LASER PROJECTOR LP 540 Manuel utilisateur

InFocus

InFocus LP130 Manuel utilisateur

InFocus

InFocus X1 Guide de configuration

InFocus

InFocus Work Big IN1100 Manuel utilisateur

InFocus

InFocus IN5122 Manuel utilisateur

InFocus

InFocus SP8602 Guide d'installation

InFocus

InFocus X2 multi-use perfomance Manuel utilisateur

InFocus

InFocus IN146 Manuel utilisateur

InFocus

InFocus Proxima DP8200x Manuel utilisateur

InFocus

InFocus ScreenPlay 5000 Manuel utilisateur

InFocus

InFocus LP630 Manuel utilisateur

InFocus

InFocus LP 420 Manuel utilisateur

InFocus

InFocus IN5142 Manuel utilisateur

InFocus

InFocus LP920 Manuel utilisateur

InFocus

InFocus in32 in34 Manuel utilisateur

InFocus

InFocus IN42 Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur

Asus

Asus ZenBeam Latte Manuel utilisateur
