InFocus LitePro 210 Manuel utilisateur

USER’S

GUIDE

User’s Guide

FCC Warning

This equipment has been tested and found tocomply with the limits for a Class B

digital device, pursuant to Part 15 of FCC Rules. Theselimits are designed to pro-

vide reasonable protection against harmful interference in a residential installa-

tion.

DOC (Canada)

ThisClass B digitalapparatus meets allrequirements of the Canadian Interfer-

ence-Causing Equipment Regulations. Cet appareilnumerique de la classe B

respecte toutes les exigences du Reglement sur lemateriel brouilleur du Canada.

Instructions to User

This equipment generates, uses andcan radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful inter-

ference to radio communications. However, there is no guarantee that interfer-

encewill not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receivingantenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which

the receiver isconnected.

• Consult the dealer or an experienced radio/TV technician for help.

Any and all modifications to this unit other than thosemade by approved service

personnel are prohibited.

Safety Certifications

UL, CUL, and TÜV

Trademarks

Apple, Macintosh, and PowerBook are trademarks or registered trademarks of

Apple Computer, Inc. IBM and PS/2 are trademarks or registered trademarks of

International Business Machines, Inc. MicroSaver and Kensington are trademarks

or registered trademarks of Kensington Microware Limited. JBL is a trademark or

registered trademark of Harman Interantional. Windows is a trademark or regis-

tered trademark of Microsoft Corporation. CableWizard, In Focus Systems and

LitePro are trademarks or registered trademarks of In Focus Systems, Inc.

Icon copyrighted by and used with the permission of AppleComputer, Inc.

Declaration of Conformity

Manufacturer: In Focus Systems, Inc.

27700BSW Parkway Ave. Wilsonville, Oregon 97070 USA

European Office: Plantenweg 91, 2132 HL Hoofddorp, The Netherlands

We declare under our sole responsibility that the LitePro 210 and 220 LCD Projec-

tors conform to the following directives and norms:

Directive 89/336/EEC

EMI: EN 55022 (1992) Class B

EMC: EN 50082-1 (1992)

IEC 801-2, IEC 801-3, IEC 801-4

Directive 73/23/EEC

Safety: EN 60950: 1992 + A1 + A2 + A3: 1995

May, 1996

TABLE OF CONTENTS

Safety Summary iii

Introduction 1

Image Resolution 1

Compatibility 2

Unpacking the Projector 2

Usage Guidelines 4

If You Need Assistance 4

Warranty 4

Setting up the Projector 5

Connecting the CableWizard to the Projector 6

Selecting Connectors on the CableWizard 6

Preparing to Connect Your Equipment to the Projector 8

Connecting an IBM-CompatibleDesktop Computer 9

Connecting an IBM-CompatibleLaptop Computer 11

Connecting a Macintosh Desktop Computer 13

Connecting an Apple PowerBook Computer 15

Connecting a Video Player 17

Connecting anExternal Speaker and a Subwoofer 19

Connecting a Microphone 20

Connecting a PS/2-Compatible Mouse. 20

Connecting theRemote Control Cable 21

Powering up the Projector and Adjusting the Image 21

Turning Off the Projector 23

Using the Projector 25

Basic Image Adjustment 25

Using the Remote Control 25

Adjusting the Projector 26

Using the Remote and Keypad Buttons 28

Using the Disk Mouse 32

Using the On-Screen Menus 32

Display Menu Functions 33

Audio Menu Functions 35

Image Menu Functions 37

Controls Menu Functions 39

Table of Contents

Maintenance 41

Cleaning theLens 41

Removing and Replacing a Lens 41

Using the Zoom Lens 42

Replacing the Projection Lamp 43

Resetting the Lamp Monitor Light 44

Replacing the Batteries in theRemote Control 45

Replacing the Fuse 45

Using the Kensington Lock 47

Troubleshooting 49

Solutions to Common Problems 50

Appendix 55

Specifications 55

Accessories 57

Portable and Laptop Activation Chart 59

Using Video Mirroring with a PowerBook Computer 63

Projected Image Size 64

Index 67

iii

SAFETY SUMMARY

Please read these instructions carefully before using your LitePro

210 or 220. Failure to comply with them could result in fire, elec-

trical shock, personal injury or damage to equipment.

These graphics are used throughout this manual to draw your

attention to important information about the projectors.

NOTE: Additional useful details or tips.

CAUTION: Steps to take to avoid damage to your equipment.

WARNING: Steps to take to avoid personal injury.

These graphics are used on LitePro labels.

Attention - Refer to this User’s Guide for important

safety information.

Hot Surfaces - Avoid touching hotsurfaces. Do not

touch until theLitePro has cooled.

Lamp Explosion Hazard - If you continue to use the

lamp after the lamp monitor light comes on, it may

explode, severely damaging your LitePro. Be sure to

replace the lamp when the lamp monitor light comes on

as described in this User’s Guide. Refer to thesection

titled “Replacing the Projection Lamp” for information

about changing the bulb.

Do Not Look Into The Lens!

Be extremely careful not to look intothe projection lens when the

LitePro is turned on. The bright light may harm your eyes. Be

especially careful to keep children from looking into the lens.

Safety Summary

Power Source

Use only a three-wire grounding type power source. The power

source should not exceed 250 volts rms between thesupply con-

ductors or between either conductor and the ground.

Power Cord

Use only the power cord thatwas shipped with theLitePro.

Although other power cords mightbe similar in appearance,they

have not beensafety-tested with the210 or 220. Do not use a

power cord if it has become damaged or frayed. Contact your In

Focus dealer or call In Focus if you need to replace your power

cord.

Grounding

The projector is grounded through the grounding conductor on

the power cord. To avoid electric shock, plug the power cord into

a properly wired receptacle. Do not defeat the purpose of the

grounding-type plug.

CAUTION: Be sure to replace

the projection bulb when the lamp

monitor light comes on as

described on page 43. If the lamp

remains in use too long, there is a

danger of bulb explosion. If this

happens, your LitePro will be

severely damaged.

Fuse

For continued protection against the risk of fire, use only the

specified fuse. It must be a time delay, high breaking capacity

5x20mm fuse with the following amperages: for 6.3amp use

T6.3AH, for 8amp use T8AH. Refer to page 55 for more informa-

tion about fuse specifications and to page 45 for instructions on

replacing the fuse.

Lamp

To avoid overheating and unacceptable image quality, replace

the projection lamp with a lamp of thespecified type. Refer to

page 56 for lamp specifications and to page 43 for instructions on

replacing the lamp.

Lamp Compartment

To avoid burns or an explosion hazard, do not open the lamp

module door until the projector is turned off and the lamp has

cooled. The hot lamp contains high pressure and can explode if

damaged or old. Follow the instructions in this manual for lamp

replacement carefully.

Hot Surfaces

Allow the projector to cool at least 45 minutes before replacing a

lamp. When you open the lamp housing, be very careful not to

touch the hot surfaces inside.

Ventilation and Overheating

Openings in the projector case provide ventilation to protect it

from overheating. Keep loose papers and other objects well away

from the bottom, top and side grills. Do not place the projector on

top of or close to a computer or other heat-producing equipment.

Liquid Spills

Do not set drinks on top of the projector. Spilled liquids can flow

inside and cause damage.

NOTE: If you open the LitePro

case, you will void the warranty.

Do Not Disassemble

All LitePro service must be performed by an authorized In Focus

service center. The only user-serviceable part in the LitePro is the

projection lamp, which you can replace by opening the lamp

cover on the bottom of the projector (see page 43). Do not open

any other part of the LitePro. If your LitePro needs repair, call In

Focus Technical Support as described on page 4. Before you call

Technical Support, you may want to refer to “Troubleshooting”

starting on page 49 to see if you can resolve the problem yourself.

Don’t Set the LitePro on its Lens

To protect the lens when you are transporting the LitePro, adjust

the lens so it is fully retracted (turn it clockwise) before you pack

it.

Place the LitePro in its carrying case with the lens facing

upwards. You may damage the LitePro if you set it on its lens.
