Imit Duo Plus Manuel utilisateur

DUO PLUS

Instruction manual

LIBR. DUO PLUS italiano 24-01-2000 11:57 Pagina 2

SUMMARY

1. Introduction pag. 3

2. Technical data 4

3. Display readings key 6

4. Thermostat controls key 7

5. Dimensions 8

6. Installation and connections 9

7. Thermostat start-up 15

8. Clock setting 15

9. Program setting 17

10. Temperature setting 18

11. Normal operation conditions 19

12. Override mode 19

13. Summer/winter setting 20

14. Knob lock 21

15. Unit reset 21

16. Troubleshooting 22

LIBR. DUO PLUS INGLESE standard 24-01-2000 14:46 Pagina 3

1. INTRODUCTION

Thank you for your confidence in our company and for choosing our products.

This is an easy programming, high-styling design, 24-HOUR electronic THERMOSTAT. It allows an extremely accurate room

temperature adjustment in the hosting room;thus meeting any users' needs as far as room COMFORT.

IN ACCORDANCEWITHTHE STANDARDS:

• EN 60730-1 and later updating

• EN 60730-2-7

• EN 60730-2-9 3

IN ACCORDANCEWITH GUIDELINES:

•B.T.73/23/EEC

•E.M.C.89/336/EEC and later updating 93/68/EEC

LIBR. DUO PLUS INGLESE standard 24-01-2000 14:46 Pagina 4

2. TECHNICAL DATA

POWER SUPPLY= N°2 1.5V alkaline batteries, type LR6

NORMALTEMPERATURE RANGE“T1”= 5°÷30°C

REDUCEDTEMPERATURE RANGE“T2”= 6°C/16°C (winter mode)

23°C/26°C (summer mode)

ROOMTEMPERATURE RANGE ON DISPLAY= 0/40°C (accuracy 0.1°C)

TEMPERATURE UPDATING= once a minute

TEMPERATURE DIFFERENTIAL= 0.2÷0.4K

SENSING ELEMENT = NTC 2%

DEGREE OF PROTECTION= IP 20

OUTPUT= switching relay

CONTACTS RATING= 5(0.5)A/250V~

SWITCH ACTION= 1BU

INSTALLATION LOCATION = normal environment

MAXIMUM STANDING TEMPERATURE= 50°C

STORAGE TEMPERATURE= 0÷60°C

LIBR. DUO PLUS INGLESE standard 24-01-2000 14:46 Pagina 5

ANTIFROST= 6°C fixed

PROGRAMMING= daily

PROGRAM SETTING = by micro-switches

MINIMUM PROGRAMMING RANGE= 1 hour

SOFTWARE CLASS A

SET-TEMPERATURE OVERRIDE MODE

DISPLAY LCD

WINTER/SUMMER SWITCHING (heating/ air conditioning)

UNIT RESET

KNOB LOCK

MOUNTING= to the wall

LIBR. DUO PLUS INGLESE standard 24-01-2000 14:46 Pagina 6

3. DISPLAY READINGS KEY

✲

Operating program activated

Low batteries

function

On display: current time

and room temperature.

Summer

(air conditioning)

Winter

(heating)

Reduced

temperature “T2”

Antifrost

Proper set

confirmation

Time/temperature chart

of the activated program

Operating

system

“Override” mode

activated

LIBR. DUO PLUS INGLESE standard 24-01-2000 14:46 Pagina 7

✲

4. THERMOSTAT CONTROLS KEY

Reset button

Knob for normal

temperature “T1”setting

Reduced

temperature “T2”

selector

Summer (

✲

) or winter ( )

mode selector

“Override”

button

Microswitches for current time

and operating program setting

LIBR. DUO PLUS INGLESE standard 24-01-2000 14:46 Pagina 8

5. DIMENSIONS

60 mm

83,5 mm

27 mm

1,5 mm

130 mm

88 mm

LIBR. DUO PLUS INGLESE standard 24-01-2000 14:46 Pagina 9

6. INSTALLATION AND CONNECTIONS

SAFETY INSTRUCTIONS

Before connecting the thermostat, make sure that the UNITTO BE CONTROLLED

(boiler, pump, air conditioning system, etc.) is NOT CONNECTED from the electrical

source.Make also sure that the power supply is the same as the one specified inside

the thermostat base (250V~ max).

PLACEMENT OFTHETHERMOSTAT

Install the thermostat away from heat sources (radiators, sunrays, kitchens) and away from doors / windows, at 1.5 mt from the

floor. 9

NO YES

LIBR. DUO PLUS INGLESE standard 24-01-2000 14:46 Pagina 10

INSTALLATION

A) Open the front cover by lifting its left side

B) Remove the battery-compartment lid by pressing

along the arrow ...remove the base from the frontal part of the thermostat...

C) Remove the screw inside the battery compartment...

LIBR. DUO PLUS INGLESE standard 24-01-2000 14:46 Pagina 11
