Iluminarc LOGIC DRIVE 2X Manuel utilisateur

Model ID: LOGICDRIVE2X

User Manual

LΩGIC Drive 2X User Manual Rev. 1

Edition Notes

The LΩGIC Drive 2X User Manual includes a description, safety precautions, installation, programming,

operation and maintenance instructions for the LΩGIC Drive 2X as of the release date of this edition.

Trademarks

CHAUVET, the Chauvet logo, LΩGIC, and LΩGIC Drive 2X are registered trademarks or trademarks of

Chauvet & Sons, LLC (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries.

Other company and product names and logos referred to herein may be trademarks of their respective

companies.

The works of authorship contained in this manual, including, but not limited to, all design, text and images

are owned by Chauvet.

Electronically published by Chauvet in the United States of America.

Manual Use

Chauvet authorizes its customers to download and print this manual for professional information purposes

only. Chauvet expressly prohibits the usage, copy, storage, distribution, modification, or printing of this

manual or its content for any other purpose without written consent from Chauvet.

Document Printing

For best results, print this document in color, on letter size paper (8.5 x 11 in), double-sided. If using A4

paper (210 x 297 mm), configure the printer to scale the content accordingly.

Intended Audience

Any person installing, operating, and/or maintaining this product should completely read through the guide

that shipped with the product, as well as this manual, before installing, operating, or maintaining this

product.

Disclaimer

Chauvet believes that the information contained in this manual is accurate in all respects. However,

Chauvet assumes no responsibility and specifically disclaims any and all liability to any party for any loss,

damage or disruption caused by any errors or omissions in this document, whether such errors or

omissions result from negligence, accident or any other cause. Chauvet reserves the right to revise the

content of this document without any obligation to notify any person or company of such revision, however,

Chauvet has no obligation to make, and does not commit to make, any such revisions. Download the latest

version from www.iluminarc.com.

Document Revision

This LΩGIC Drive 2X User Manual is the 1st edition of this document. Go to www.iluminarc.com for the

latest version.

LΩGIC Drive 2X User Manual Rev. 1

Table of Contents

TABLE OF CONTENTS

1. Before You Begin ....................................................................... 1

What Is Included ........................................................................................... 1

Claims ........................................................................................................... 1

Text Conventions .......................................................................................... 1

Symbols ........................................................................................................ 1

FCC Compliance........................................................................................... 1

Safety Notes.................................................................................................. 2

Personal Safety.................................................................................................. 2

Mounting and Rigging ........................................................................................ 2

Power and Wiring............................................................................................... 2

Operation ........................................................................................................... 2

2. Introduction ................................................................................ 3

Description .................................................................................................... 3

Features........................................................................................................ 3

Product Overview.......................................................................................... 3

Front Panel Overview......................................................................................... 3

Front Panel Description ........................................................................................... 3

Rear Panel Overview ......................................................................................... 3

Rear Panel Description............................................................................................ 3

Product Dimensions ...................................................................................... 4

3. Setup ........................................................................................... 5

AC Power...................................................................................................... 5

Emergency Backup Power................................................................................. 5

AC Plug .............................................................................................................. 5

Fuse Replacement ............................................................................................. 5

LΩGIC Wall Controller .................................................................................. 6

RJ12 Cable Wiring ............................................................................................. 6

Signal Connections ....................................................................................... 7

Control Personalities .......................................................................................... 7

DMX Linking....................................................................................................... 7

Remote Device Management (RDM)....................................................................... 7

DMX/RDM Connection Diagram.............................................................................. 7

Art-Net™ Connection ......................................................................................... 8

sACN Connection............................................................................................... 8

Ethernet Connection Diagram ................................................................................. 8

Terminating CAT6 Cables with RJ45 Connectors......................................... 8

LΩGIC Product Chaining .............................................................................. 9

Mixing LΩGIC Products...................................................................................... 10

LΩGIC POE X Linking........................................................................................ 10

Mounting ....................................................................................................... 11

Orientation.......................................................................................................... 11

Rigging ............................................................................................................... 11

Rack Mounting ................................................................................................... 11

Interlocking .............................................................................................................. 11

Wall/Surface Mounting ....................................................................................... 12

Mounting Diagram ................................................................................................... 12

Table of Contents

LΩGIC Drive 2X User Manual Rev. 1

4. Operation .................................................................................... 13

Control Panel Description ............................................................................. 13

Programming................................................................................................. 13

Password ........................................................................................................... 13

Menu Map ..................................................................................................... 13

RDM Chart .................................................................................................... 16

Home Screen ................................................................................................ 17

Control Protocol ............................................................................................ 17

Local.............................................................................................................. 17

Net Switch .......................................................................................................... 17

Universe ............................................................................................................. 17

Password Lock................................................................................................... 17

Output Status ..................................................................................................... 18

Local Information................................................................................................ 18

Priority ................................................................................................................ 18

Reset.................................................................................................................. 18

History ................................................................................................................ 18

Disconnecting Products from the LΩGIC Drive 2X ............................................ 18

Linked Fixture................................................................................................ 19

Linked LΩGIC Product Menu Map ..................................................................... 19

Individual LΩGIC Product Configuration ............................................................ 20

Control Personality (Individual)................................................................................ 20

Starting Address ...................................................................................................... 20

Network Settings ..................................................................................................... 20

Factory Reset .......................................................................................................... 20

Information............................................................................................................... 20

Renew ................................................................................................................ 21

Control Personality (Global) ............................................................................... 21

Power Selection ................................................................................................. 21

Breaking Signal .................................................................................................. 21

Control Channel Assignments and Values.................................................... 22

FULL (10 Channels)........................................................................................... 22

RGBW+D (5 Channels)...................................................................................... 23

RGBW (4 Channels) .......................................................................................... 23

RGB (3 Channels).............................................................................................. 23

TW (Tunable White: 2 Channels) ....................................................................... 23

WHITE (1 Channel)............................................................................................ 24

BLUE (1 Channel) .............................................................................................. 24

GREEN (1 Channel)........................................................................................... 24

RED (1 Channel)................................................................................................ 24

Static ............................................................................................................. 24

Record........................................................................................................... 25

Recording........................................................................................................... 25

Display Menu Playback...................................................................................... 25

Scene Brightness (via Display Menu)...................................................................... 25

LΩGIC Wall Controller Playback ........................................................................ 25

Scene Brightness (via LΩGIC Wall Controller)........................................................ 25

Scene Lock.............................................................................................................. 25

Erase Recording ................................................................................................ 26

LΩGIC Drive 2X User Manual Rev. 1

Table of Contents

iii

System Clock ................................................................................................ 26

Setting Clock ...................................................................................................... 26

Schedule ............................................................................................................ 26

Everyday.................................................................................................................. 26

By date .................................................................................................................... 27

By week ................................................................................................................... 27

Fade In and Fade Out ........................................................................................ 27

Enable Clock ...................................................................................................... 27

Web Server ................................................................................................... 28

Home.................................................................................................................. 28

Status ................................................................................................................. 29

Fixture List.......................................................................................................... 29

Settings .............................................................................................................. 30

Administrator Settings ........................................................................................ 31

Firmware Update ..................................................................................................... 31

5. Maintenance................................................................................ 32

Product Maintenance .................................................................................... 32

6. Technical Specifications ........................................................... 33

Returns............................................................................................ 34

Before You Begin

LΩGIC Drive 2X User Manual Rev. 1

1. Before You Begin

What Is Included

Claims

Carefully unpack the product immediately and check the container to make sure all the parts are in the

package and are in good condition.

If the box or the contents (the product and included accessories) appear damaged from shipping, or show

signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to the carrier

immediately may invalidate your claim. In addition, keep the box and contents for inspection.

For other issues, such as missing components or parts, damage not related to shipping, or concealed

damage, file a claim with Chauvet within 7 days of delivery.

Text Conventions

Symbols

FCC Compliance

This device complies with Part 15 Part B of the FCC Rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may cause

undesired operation.

Any changes or modifications not expressly approved by the party responsible for compliance could void

the user's authority to operate the equipment.

•LΩGIC Drive 2X

• Seetronic Powerkon IP65 power cable

•LΩGIC Wall Controller

• 1 Short rack ear bracket

• 1 Long rack ear bracket

• Quick Reference Guide

Convention Meaning

1–512 A range of values

50/60 A set of values of which only one can be chosen

Settings A menu option not to be modified

<ENTER> A key to be pressed on the product’s control panel

Symbol Meaning

Critical installation, configuration, or operation information. Not following these

instructions may make the product not work, cause damage to the product, or cause

harm to the operator.

Important installation or configuration information. The product may not function

correctly if this information is not used.

Useful information.

The term “DMX” used throughout this manual refers to the USITT DMX512-A digital data

transmission protocol.

LΩGIC Drive 2X User Manual Rev. 1

Before You Begin

Safety Notes

Read all the following safety notes before working with this product. These notes contain important

information about the installation, usage, and maintenance of this product.

Personal Safety

• Always disconnect the product from the power source before cleaning or replacing the fuse.

• Always connect the product to a grounded circuit to avoid the risk of electrocution.

• Do not touch the product’s housing when operating because it may be very hot.

Mounting and Rigging

• The product is intended for professional use only.

• DO NOT operate this product outdoors or in any location where dust, excessive heat, water, or

humidity may affect it. (IP20)

•

CAUTION: When transferring product from extreme temperature environments, (e.g., cold truck to warm

humid ballroom) condensation may form on the internal electronics of the product. To avoid causing a

failure, allow product to fully acclimate to the surrounding environment before connecting it to power.

• Mount this product in a location with adequate ventilation, at least 20 in (50 cm) from adjacent

surfaces.

• Make sure there are no flammable materials within 20 in (50 cm) of this product while it is operating.

• When hanging this product, always secure to a fastening device using a safety cable.

• Never carry the product by the power cord.

Power and Wiring

• Make sure the power cord is not crimped or damaged.

• Always make sure you are connecting this product to the proper voltage in accordance with the

specifications in this manual or on the product’s specification label.

• Never connect this product to a dimmer pack or rheostat.

• Make sure to replace the fuse with another of the same type and rating.

• Never disconnect this product by pulling or tugging on the power cable.

• If the external flexible cable or cord of this product is damaged, it shall be replaced with a special

cable or cord exclusively available from the manufacturer or its service agent.

Operation

• Do not operate this product if there is damage on the housing or cables. Have the damaged parts

replaced by an authorized technician at once.

• Do not cover the ventilation slots when operating to avoid internal overheating.

• The maximum ambient temperature is 113 °F (45 °C). Do not operate this product at higher

temperatures.

• The minimum startup temperature is -4°F (-20°C). Do not start the product at lower temperatures.

• The minimum ambient temperature is -22°F (-30°C). Do not operate the product at lower

temperatures.

• In the event of a serious operation problem, stop using this product immediately!

This product contains no user-serviceable parts. Any reference to servicing in this User

Manual will only apply to properly trained, certified technicians. Do not open the housing

or attempt any repairs.

All applicable local codes and regulations apply to proper installation of this product.

If your Chauvet product requires service, contact Chauvet Technical Support.

Introduction

LΩGIC Drive 2X User Manual Rev. 1

2. Introduction

Description

The Iluminarc LΩGIC Drive 2X is the heart of the LΩGIC Lighting System. With two Ethernet outputs

supplying 110W each (Power Over Ethernet), the LΩGIC Drive 2X functions as the central control and

power unit of the LΩGIC System. Accepting a variety of control schemes, the Drive also integrates

calendar and scheduling functions, and easily connects to an included eight button wall panel or any

industry standard wall controller.

Features

• 2 POE (Power Over Ethernet) outputs, each supplying up to 110W

• Control options include standard wall controllers, or DMX input via 5-pin XLR, Art-Net, or sACN

• Occupancy sensor-enabled

• Supports fixture hot-swapping and automatic fixture detection

• Current and voltage monitoring

• RDM compliant

Product Overview

Front Panel Overview

Front Panel Description

Rear Panel Overview

Rear Panel Description

#Name Function

1 LED indicators

POWER: green, indicates power connection

NET: yellow, indicates ethernet connection

ACT: white, indicates controller signal

ERROR: red, indicates an error (see Warning Messages in the menu)

<MENU>

knob

Rotate to navigate upwards or downwards through the menu list, and increase or

decrease a selected numeric value. Push to enable the currently displayed menu

option or set the currently selected value into the selected function.

3<ESC/BACK>

button Exits the current menu or function

#Name Function

1 IN/THRU RJ45 connectors for ethernet input and through

2 DMX IN 5-pin phoenix connector for DMX input

3DMXOUT5-pin phoenix connector for DMX output

WALL CON

RJ12 connector for LΩGIC Wall Controller

5OUTPUT1RJ45 connector for output to first group of LΩGIC products

6OUTPUT2RJ45 connector for output to second group of LΩGIC products

23LCD Display1

123 4

Power

Input

Fuse

Holder

LΩGIC Drive 2X User Manual Rev. 1

Introduction

Product Dimensions

9.64 in

245 mm

0.846 in

21.5 mm

1.378 in

35 mm

1.81 in

46 mm

1.14 in

29 mm

0.236 in

6 mm

0.0787 in

2 mm

10.31 in

262 mm

8.6 in

218.5 mm

9.5 in

241.4 mm

18.95 in

481.4 mm

Setup

LΩGIC Drive 2X User Manual Rev. 1

3. Setup

AC Power

The LΩGIC Drive 2X has an auto-ranging power supply and it can work with an input voltage range of 100

to 240 VAC, 50/60 Hz.

To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current

value listed on the label affixed to the product’s back panel, or refer to the Technical Specifications. The

listed current rating indicates the product’s average current draw under normal conditions.

Emergency Backup Power

To keep the LΩGIC system powered on and maintain the lighting in the case of an emergency, it is

recommended to use a battery backup UPS (Uninterruptable Power Supply) between the LΩGIC Drive 2X

and the mains power, as well as between each POE injector and the mains power.

This UPS can be one which is hardwired directly to the power cord included with the LΩGIC Drive 2X, or

one with 120V Edison ports. See AC Plug for wiring information.

AC Plug

The LΩGIC Drive 2X comes with a power input cord terminated with a Seetronic Powerkon IP65 connector

on one end and an Edison plug on the other end (U.S. market). If the power input cord that came with the

product has no plug, if the plug must be changed, or if the cable needs to be hardwired to a UPS, use the

table below ensure correct wiring.

Fuse Replacement

1. Disconnect this product from the power outlet.

2. Using a flat-head screwdriver, unscrew the fuse holder cap from the housing.

3. Remove the blown fuse and replace with another fuse of the same type and rating (F 20 A, 250 V).

4. Screw the fuse holder cap back in place and reconnect power.

Always connect the product to a protected circuit (a circuit breaker or fuse). Make sure the

product has an appropriate electrical ground to avoid the risk of electrocution or fire.

Never connect the product to a rheostat (variable resistor) or dimmer circuit, even if the

rheostat or dimmer channel serves only as a 0 to 100% switch.

Connection Wire (U.S.) Wire (Europe) Screw Color

AC Live Black Brown Yellow or Brass

AC Neutral White Blue Silver

AC Ground Green/Yellow Green/Yellow Green

Uninterruptable

Power Supply
