Section 2: Safety
Following is a list of safety symbols and their meanings, which you will find throughout this
manual. Pay attention to these symbols where they appear in the manual.
Wear safety goggles when performing the procedure described!
Caution or Warning! Denotes possible personal injury and/or damage to the equip-
ment.
Caution or Warning! Denotes possible personal injury and/or equipment damage
due to electrical hazard.
NOTE: (Will be followed by a brief comment or explanation.)
Only Diagraph trained personnel should operate and service the equipment.
CAUTION: The IDS3000 Ink Delivery System contains hazardous voltage (115/230VAC).
Turn off the equipment's main power before:
• Performing preventive maintenance.
• Performing any repairs to the unit.
• Servicing the equipment in any manner.
ESD protection should be worn when servicing internal printed circuit boards.
After service to the equipment is completed, replace all protective devices such as ground-
ing cables and covers before operating equipment.
WARNING: This equipment contains ink under pressure. Be sure to depressurize the sys-
tem before servicing.
TSO ink contains ethanol and isopropanol. MEK ink contains methyl ethyl keytone. TWP
ink contains ethylene glycol. It is extremely important to:
• Clean up all spills with the appropriate conditioners immediately and dispose of all
waste according to local and state regulations.
• Wear safety glasses and protective clothing, including gloves, when handling all inks
and conditioners.
• Store inks and conditioners under the recommended conditions found on the MSDS
(Material Safety Data Sheet).
• TWP (Porous Ink) and TSO (Non-Porous Ink) are not miscible.
!
!
!
