Ikelite 6171.11 Manuel utilisateur

ProductRegistration

Please register your product at ikelite.com within 15 days of purchase.

Our product registration database is the best way for us to contact you

in the event of a product update.

Underwater TTLHousingforPanasonic LumixLX100,

LeicaD-Lux(Typ109)

Product Number 6171.11

AboutthisProduct

Thank you for your purchase of Ikelite equipment. Please read this

instruction manual completely before attempting to operate or dive

with this product. Please visit ikelite.com to register your product to

receive information on any updates, notices, or recalls pertaining to

your equipment.

IncludedintheBox

• Housing

• O-ring # 0110

• Waterproof bulkhead cap # 9104.5

• Vinyl port cover # 0200.08

• Gear ring # 9299.11

• Control + push button tip assortment # 9249.3

• 1/8” hex key # 0945.18

• Silicone lubricant # 0184.1

ImportantNotices

»To prevent salt build-up and sticking controls, submerge the

empty housing in clean, freshwater. Operate the controls

several times each while underwater to ush out any residue.

»Never leave a housing in a rinse tank, even if it is the only

system in the tank. Most catastrophic oods happen when the

user walks away from a housing while it is in the rinse tank.

»Do not use alcohol, cleaning agents, spray lubricants, Rain-X,

or other solvents on the housing or lens port. Use of an

incompatible chemical compound can damage the plastic and

o-rings, and may result in leaking.

AccessoryPort

»Do not remove the Accessory Port Plug unless you are

installing a compatible accessory.

Your housing features one spare Accessory Port which may be used

for attachment of factory optional or aftermarket housing accessories.

The Accessory Port is 1/2-20 threaded.

Visit ikelite.com for information on optional accessories.

Contents

Product Registration 1

About this Product 2

Included in the Box 2

Important Notices 3

Accessory Port 3

Getting to Know Your Housing 6

Setting Up Your Camera 8

Pre-Installation Checklist 8

Setting Up Your Housing 8

Opening the Housing 8

Inserting the Camera 9

Attaching the Hotshoe 10

Closing the Housing 11

Setting Up An External Strobe 11

Strobe Compatibility 12

Attaching a Sync Cord 12

Taking your Housing in the Water 13

Final Check 13

Entering the Water 14

In the Water 14

Maintenance 15

Post-Dive 15

Travel and Storage 15

Troubleshooting 16

Service and Repairs 18

Limited Warranty 18

GettingtoKnow YourHousing

Shutter

Filter

Zoom

Shutter speed

Bulkhead

Lidsnap Lens Port

Tray mounts

Aperture

Fn3 Fn2

AE/FE

LOCK

Fn1 DISP

ISO

Fn3 Fn2

AE/FE

LOCK

Fn1 DISP

ISO

Accessory

port

Lid hook

O-ring

Camera mount

plate

Lanyard

Exposure

compensation

Rear * dial

ON/OFF

MENU/SET

White Balance

Playback

Drive Mode

Fn1/Delete

AF Mode

SettingUpYour Camera

Pre-Installation Checklist

1. Insert a fully charged camera battery.

2. Insert a properly formatted memory card.

3. In the REC menu, set Red-Eye Removal to OFF.

4. In the C menu, set Shutter AF to ON.

5. In the C menu, set Half Press Release to OFF.

6. In the C menu, set Quick AF to ON.

7. In the C menu, set Eye Sensor AF to OFF.

8. In the C menu, set AF Assist Lamp to OFF.

9. In the C menu, set Focus/Release Priority to FOCUS.

SettingUpYour Housing

Opening the Housing

1. Push the lid snap lock forward and start to lift the curved end away

from the housing.

2. Lid snaps are designed to provide enough force to compress the

o-ring for a proper seal. Keep rm pressure against the lid snap

while lifting it away.

Lid Snap Lock

3. Repeat with remaining lid snaps.

4. Remove the housing back.

Inserting the Camera

1. Remove any lanyard or neck strap which may be attached to the

camera.

2. Orient the Gear Ring with the foam strips on top and bottom and

the white dot at the top center. Attach the Gear Ring to the camera

by gently pressing it onto the camera’s Aperture Ring. The front of

the Gear Ring should be ush with the front of the Aperture Ring.

Lumix

3. Remove the Camera Mounting Plate from the housing.

4. Line up the mounting screw with the camera’s tripod socket. Use a

at head screwdriver to tighten the mounting plate to the camera.

Mounting screw

1/4-20 tripod

mount

Camera tripod

socket

5. Pull out on the housing’s ON/OFF, Shutter Speed, and Exposure

Compensation knobs to move them out of the way.

6. Insert the Mounting Plate into the corresponding slot on the inside

bottom of the housing. Rotate the front aperture knob slightly to

assist Gear Ring engagement with housing gear. Slowly push the

camera all of the way forward until the back of the Mounting Plate is

ush with the back of the housing mount.

7. Check the Gear Ring. If it has slipped backwards slightly, gently

push the top forward to engage with the gearing in the front of the

housing.

8. Orient the On/OFF control so that the legs of the “U” are on either

side of the camera lever.

»The camera’s Aperture Ring does not rotate 360º. Do not force

the control to rotate past its natural stop. Forced over-rotation

may damage the housing’s gearing.

FRONT
