Ikelite 200DLM/B Manuel utilisateur

200DLM/B Underwater Housing for

Olympus OM-D E-M1 Mark II Mirrorless Camera

Product # 69532

Introduction

Thank you for your purchase of Ikelite products.

Our primary focus is to provide quality, professional grade products

for use in and under water. Our products are designed, manufactured,

and distributed from our sole facility in Indianapolis, USA where we

started in 1962.

We are available if you have any questions or want photo advice.

Send us an email 24 hours a day to [email protected]. We strive to

reply within 1 business day.

An electronic version of this instruction manual is available for

download via the product page on our website:

https://www.ikelite.com

In the Box

• Housing

• Rear o-ring # 0110 (installed)

• Front o-ring # 0132.36 (installed)

• Camera mount (installed)

• .050” hex key # 0945.11

• 1/16” hex key # 0945.16

• Silicone lubricant 1cc tube

Important Notices

»This housing requires a compatible DLM lens port for

waterproof operation. The housing is not waterproof without a

DLM lens port attached.

»Do not pull the shutter trigger without a camera installed. You

may accidentally detach or damage the control spring.

»Never leave a housing in a rinse tank, even if it is the only

system in the tank. Accidental damage may occur when the

user walks away from a housing while it is in the rinse tank.

»Do not use alcohol, cleaning agents, spray lubricants, Rain-X,

or other solvents on the housing or lens port. Use of an

incompatible chemical compound can damage the plastic and

o-rings, and may result in leaking.

»If you will be using the system in strong surf it is

recommended to draw a vacuum on the housing using the

optional vacuum kit (sold separately).

Contents

Introduction 2

In the Box 2

Important Notices 3

Getting to Know Your Housing 6

Tray Mounts 9

Accessory Ports 9

Trigger Extension 9

Setting Up Your Camera 10

Pre-Installation Checklist 10

Camera Settings 10

Exposure Settings 10

Power Save 10

Back Button Focus 11

Setting Up Your Housing 11

Opening the Housing 11

Installing the Camera 12

Closing the Housing 13

Attaching a Lens Port 13

Installing the Lens and Port 14

Setting Up An External Strobe 17

About Sync Cords 17

Attaching a Sync Cord or TTL Converter 17

Getting in the Water 19

Final Check 19

Entering the Water 19

Shooting Underwater 20

Learning about Underwater Photography 20

Maintaining Your Housing 21

Post-Dive 21

Lens Port 21

Storage 22

Servicing Recommendations 22

Lubricating Controls 23

Lubricating Push Buttons 23

Lubricating Control Shafts 24

Troubleshooting 26

Spare Parts 28

Limited Warranty 28

Service and Repairs 28

Getting to Know Your Housing

Shutter

Lid snap

Tray mounts

Lens

release

Port mount Bulkhead

with cap

69532 OLYMPUS OM-D E-M1 II

MADE IN USA

INFO

Rear o-ring

69532 OLYMPUS OM-D E-M1 II

MADE IN USA

INFO

Left

Erase

Lid

snap

hook

Playback

Right

Viewnder

Down

INFO Fn1

Thumbscrew

groove

Front dial

Exposure

compensation

Rear dial

Front o-ring

Movie

On/off Mode dial

Buklhead

without cap

Flash

Accessory

port

AF / Metering

mode

AEL/AFL

Tray Mounts

This housing features two 1/4-20 threaded tray mounts on the bottom

of the housing. The spacing between the tray mounts is 3” (76.2 mm).

Optional tray with handles and mounting hardware are sold separately.

It is recommended to detach and thoroughly rinse the tray mounts,

tray, and mounting hardware, with fresh water routinely during

continuous use and prior to storage.

Accessory Ports

This housing features a spare accessory port which may be used

for the attachment of optional accessories. This port accepts ttings

designed for a 1/2” through or 1/2-20 threaded hole.

The optional Vacuum Kit # 47012 may be installed in place of the side

accessory port. A hand pump with gauge allows you to draw a vacuum

on the house to simulate water pressure and check for leaks prior to

entering the water.

Visit ikelite.com for an updated list of compatible products.

»Do not remove or loosen the accessory port plug unless you

are installing a compatible accessory.

Trigger Extension

The shutter lever may be extended to be closer to your hand when

using an optional tray with right-hand quick release handle. This

requires the Trigger Extension # 4077.95 (housings serial # 73600 and

above) or Trigger Extension # 4077.93 (below serial # 73600).

Trigger extension and tray with quick release handle are sold

separately.

Setting Up Your Camera

Pre-Installation Checklist

1. Insert a fully charged camera battery.

2. Insert a properly formatted memory card.

3. Remove any attached lanyard or neck strap.

Camera Settings

• Set EVF Auto Switch to “Off.”

• Set X-Sync. to “1/250” when using an external strobe.

• Set Flash mode to “Fill in” when using an external strobe.

“Slow2” rear-curtain sync may alternatively be used when using a

compatible DL3 DS Link TTL converter.

Exposure Settings

Refer to the Camera Settings Cheat Sheets in the Photo School

section of our website for recommendations on exposure settings for a

wide variety of shooting situations:

https://www.ikelite.com/blogs/cheat-sheets

Power Save

It is recommended to set the Sleep and Auto Power Off settings to

the shortest intervals that makes sense for your shooting.

Instead of turning the camera off and on to conserve battery, the

camera will automatically sleep after the pre-set interval. To wake the

camera, simply perform an operation such as pressing the shutter

button halfway down.
