IHome IB970 Manuel utilisateur

iB970

instruction manual

iB970 English Manual

Size: 6”W x 4 3/4” H

Print in Black

June 28,10

iB970

Introduction

Thank you for purchasing the iHome iB970, the dual dock charging station

for iPad, iPhone and iPod that allows you to charge an iPhone or iPod in half

the typical time, and to sync to a computer. There are two additional USB

ports that let you connect and charge two additional devices such as an

iPad, cellphones, PDAs,portable gaming systems and eBook readers at the

same time. Up to four devices at once!

This instruction booklet explains the basic operation and care of the unit.

Please read it carefully and keep it for future reference.

iB970

FCC Information

This equipment complies with the limits for a Class B digital device as specified in Part 15 of FCC Rules. These

limits provide reasonable protection against radio and TV interference in a residential area.

However, your equipment might cause TV or radio interference even when it is operating properly. To eliminate

interference you can try one or more of the following corrective measures:

• Reorient or relocate the receiving antenna.

• Increase the distance between the equipment and the radio or TV.

• Use outlets on different electrical circuits for the equipment and the radio or TV.

• Consult your dealer or an experienced radio/television technician if the problem still exists.

Modifying or tampering with your system’s internal components can cause a malfunction and might invalidate

the system’s warranty and void your FCC authorization to operate it.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

This device complies with Part 15 of the FCC Rules, operation is subject to the

following two conditions: (1) This device may not cause harmful interference,

and (2) this device must accept any interference received, including interference

that may cause undesired operation.

iB970

Using the

Table of Contents

Meet Your iB970 ........................................................................ 1-2

Getting Started ..............................................................................3

Charging iPhone and iPod............................................................ 4-5

Syncing iPhone or iPod to a Computer ...............................................5

Charging iPad and other Devices Using the USB Ports........................ 6-8

Consumer Safety and Product Maintenance.................................... 9-10

Troubleshooting............................................................................11

Warranty....................................................................................12

Meet Your iB970

iB970

Power Indicator

Sliding Base

USB 2.0 syncing port

Quick Charge Dock (no sync)

Standard Charge Syncing Dock

Sync Switch

iPad rest

Rubberized rest

DC Jack

Top

Rear

Meet Your iB970

iB970

Bottom

Included Cables

Included Inserts

• 36 inch sync cable (to sync iPhone/iPod to computer)

• 12 inch USB to mini USB cable

(to charge compatible devices)

• 12 inch USB to 4mm plug (to charge Sony eReader

and Sony PSP game systems)

• 1 mini USB to micro USB adapter

• 2 iPhone inserts

quick charge standard charge

Cord HoldersCord Holders

Quick Charge/iPad

USB port

A – B Switch for Quick

Charge USB port

Standard Charge

USB port

A – B Switch for

Standard Charge

USB port

Cord Channels

• 12" black cable with USB plug to Nintendo DSi/DSi XL plug

• 12" black cable with USB plug to Nintendo DS Lite plug

• 12" black cable with USB plug to Nintendo DS plug

iB970

Using the

Getting Started

1.Plug the 100V - 240V universal

switching AC adapter into the DC

jack on the rear of the iB970 and

the other end into a working

outlet. A blue LED indicator will

light up, indicating the unit has

power and is ready to charge. If

the blue light does not appear, try

activating any wall switch that

controls the outlet, or try using

another outlet.

RESET

TEST

to computer

Folding Adapter

Blades

iB970

Charging iPhone and iPod

The iB970 has two universal docks for iPhone or iPod.

The left dock is a standard charging dock with sync

that will recharge your iPhone or iPod and and lets you

sync your iPhone or iPod to the iTunes library on your

computer if desired.

The right dock provides quick charging without sync.

The docks will charge your iPhone or iPod until

completely charged then stop charging. Use both docks

to charge two devices at once.

1. Make sure the unit is connected to a working power

source

2. Place the insert that came with your iPod into the

desired dock. If using an iPhone, use the iPhone insert

provided with the iB970.

NOTE: If you do not have an insert for your iPod, please visit www.ihomeaudio.com (or call iHome toll free at

800-288-2792) to purchase one

iB970

3.Gently dock an iPhone or iPod into the desired dock on top of the unit. Do not

force. Make sure your iPhone or iPod is not in a case or “skin”. To avoid damage

to your iPhone or iPod, never dock an iPhone or iPod without using an insert.

Avoid using undue pressure when placing and removing iPhone or iPod from

dock(s). Your docked iPhone or iPod will charge until fully charged.

1.Connect the small end of the included Sync Cable to the Sync Jack on the rear

of the unit and the other end into a USB port on your computer.

2.Slide the Sync Switch located on the top left of the unit to the ON position.

Your iPhone or iPod will begin syncing with your computer.

DO NOT disconnect the Sync Cable or move the Sync Switch during

sync function. A notice should appear on your computer display when

sync is complete and it is safe to disconnect.

Gently dock an iPhone or iPod into the left dock on top of the unit (see above)

4.Once sync is complete, return the Sync Switch to the OFF position.

NOTE: A docked iPhone/iPod will not charge if the sync cable is not connected

to a computer while the Sync Switch is in the ON position

Syncing iPhone and iPod to an iTunes Library on Your Computer

iB970

Using the

Charging iPad and other Devices Using the USB Ports

The iB970 has two additional USB ports on the bottom of the unit, one

quick-charging USB port (left) for iPad and other devices and one standard charging

USB port (right) that can charge most USB-compatible devices such as Blackberries,

eBook readers, portable gaming systems, etc., allowing you to charge two

additional devices at once. Each port has a USB Mode Switch (A–B) to

accommodate the different USB-powered devices.

Charging Devices

A. position: Will charge iPad and most iPod and

iPhone models.

B. position: Will charge Sony Reader™, Amazon

Kindle™, Barnes & Noble Nook™, Border’s

kobo™, Blackberry, Nintendo DS/DS

Lite/DSi/DSi XL™, Sony PSP™/PSP go and

other devices.

If device does not charge, move USB Mode

Switch to A position to see if it charges.

If device still does not charge, try unplugging

the device from the USB port then reconnecting

it.

Use this USB port to charge iPad

USB switch
