IDTECH SecureHead Manuel utilisateur

USER MANUAL

SecureHead™

Encrypted Magnetic Read Head

SPI Interface with FPC

80101515-001-C

28 December 2020

User Manual, SecureHead SPI Interface

Page 2 of 67

Agency Approved

Specifications for subpart B of part 15 of FCC rule for a Class A computing device.

Limited Warranty

ID TECH warrants to the original purchaser for a period of 12 months from the date of invoice that this

product is in good working order and free from defects in material and workmanship under normal use

and service. ID TECH’s obligation under this warranty is limited to, at its option, replacing, repairing,

or giving credit for any product which has, within the warranty period, been returned to the factory of

origin, transportation charges and insurance prepaid, and which is, after examination, disclosed to ID

TECH’s satisfaction to be thus defective. The expense of removal and reinstallation of any item or

items of equipment is not included in this warranty. No person, firm, or corporation is authorized to

assume for ID TECH any other liabilities in connection with the sales of any product. In no event shall

ID TECH be liable for any special, incidental or consequential damages to Purchaser or any third party

caused by any defective item of equipment, whether that defect is warranted against or not. Purchaser’s

sole and exclusive remedy for defective equipment, which does not conform to the requirements of

sales, is to have such equipment replaced or repaired by ID TECH. For limited warranty service during

the warranty period, please contact ID TECH to obtain a Return Material Authorization (RMA)

number & instructions for returning the product.

THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES OF MERCHANTABILITY OR

FITNESS FOR PARTICULAR PURPOSE. THERE ARE NO OTHER WARRANTIES OR

GUARANTEES, EXPRESS OR IMPLIED, OTHER THAN THOSE HEREIN STATED. THIS

PRODUCTIS SOLD AS IS. IN NO EVENT SHALL ID TECH BE LIABLE FOR CLAIMS BASED

UPON BREACH OF EXPRESS OR IMPLIED WARRANTY OF NEGLIGENCE OF ANY OTHER

DAMAGES WHETHER DIRECT, IMMEDIATE, FORESEEABLE, CONSEQUENTIAL OR

SPECIAL OR FOR ANY EXPENSE INCURRED BY REASON OF THE USE OR MISUSE, SALE

OR FABRICATIONS OF PRODUCTS WHICH DO NOT CONFORM TO THE TERMS AND

CONDITIONS OF THE CONTRACT.

provided to the user as a convenience. While every effort has been made to ensure accuracy, ID TECH

is not responsible for damages that might occur because of errors or omissions, including any loss of

profit or other commercial damage. The specifications described herein were current at the time of

publication, but are subject to change at any time without prior notice.

ID TECH is a registered trademark of International Technologies & Systems Corporation. SecureHead

and Value through Innovation are trademarks of International Technologies & Systems Corporation.

User Manual, SecureHead SPI Interface

Page 3 of 67

Revision History

Revision

Date

Description of Changes

10/01/2013

Initial Release

Candy H

11/19/2020

Updated Appendix I

12/28/2020

Removed commands related to Fixed Keys.

User Manual, SecureHead SPI Interface

Page 4 of 67

Table of Contents

1. INTRODUCTION ..............................................................................................................................................................................................5

2. SPECIFICATIONS ............................................................................................................................................................................................ 6

3. SPI OPER ATION...............................................................................................................................................................................................9

3.1. SPI Da ta Tra nsm ission ........................................................................................................................................................................... 9

3.2. Clock Polarity and Pha se....................................................................................................................................................................... 9

3.3. Master Input, Slave Output (MISO)...................................................................................................................................................10

3.4. Master Output, Slave Input (MOSI)...................................................................................................................................................10

3.5. Data Available Output (DAV) ............................................................................................................................................................11

3.6. Chip Select..............................................................................................................................................................................................12

3.7. Voltage Input and Ground...................................................................................................................................................................13

3.8. Communication......................................................................................................................................................................................13

4. CONFIGURATION .........................................................................................................................................................................................14

4.1. Communication Tim in g .......................................................................................................................................................................15

4.2. Default Settings .....................................................................................................................................................................................15

4.3. General Se lect ions .................................................................................................................................................................................16

4.4. Review Settings .....................................................................................................................................................................................17

4.5. Review Firmware Ve rsion ...................................................................................................................................................................17

4.6. Review Serial Number.........................................................................................................................................................................17

4.7. Message Formatting Selections (Only for Security Level 1 & 2).................................................................................................18

4.8. Magnetic Track Selections (Only for Security Level 1 & 2).........................................................................................................19

4.9. Review KSN ( DUKPT Key m a na gement only)...............................................................................................................................20

4.10. Review Security Level .......................................................................................................................................................................21

4.11. Encrypt External Data Comma nd.....................................................................................................................................................21

4.12. Encrypted Output for Decoded Data................................................................................................................................................21

4.12.1. Encrypt Functions...............................................................................................................................................................21

4.13. Level 4 Activate Authentication Sequence.....................................................................................................................................32

4.14. Other Command Protocol Settings...................................................................................................................................................36

5. APPE NDIX A. DEFAULT SETTING T ABLE ..........................................................................................................................................38

5.1. Default Setting Table............................................................................................................................................................................38

6. APPE NDIX B: MAGNE TIC STRIPE STANDAR D FORM ATS ..........................................................................................................39

6.1. ISO Credit Card Format.......................................................................................................................................................................39

6.2. AAMVA Driver’s License Format.....................................................................................................................................................40

7. APPENDIX C: OTHER M ODE CARD DATA OUTPUT.......................................................................................................................42

8. APPENDIX D: GUIDE TO E NCRYPTING AND DECR YPTING DATA .........................................................................................43

9. APPENDIX E: KEY MANAGEME NT FLOW CH ART .........................................................................................................................44

10. APPENDIX F: EXAMPLE OF DEC ODED DAT A DECRYPTION...................................................................................................46

11. APPENDIX G: E XAM PLE OF IDTECH RAW DATA DECRYPTION ...........................................................................................53

12. APPENDIX H: E XAM PLE OF SPI MASTER CHIP CONTROLI NG ...............................................................................................55

13. APPENDIX I: MAGNETIC HEADS MECH ANICAL DE SIGN GUIDELI NES .............................................................................61

Track Locations...........................................................................................................................................................................................61

Reference Surface/Wear-Plate ................................................................................................................................................................62

Card Reader Rails/Slot and Magnetic Head Protrusion..................................................................................................................63

User Manual, SecureHead SPI Interface

Page 5 of 67

1. INTRODUCTION

The SPI SecureHead™ magnetic stripe reader can read 1, 2, or 3 tracks of magnetic stripe information.

When connected to the host, the SecureHead is completely compatible with SPI Specification. The raw

data or decoded data send to host through the SPI.

The SecureHead supports both unencrypted and encrypted data output. When the encryption is not

turned on, the decoded data can be formatted with preamble/postamble and terminator characters to

match the format expected by the host.

This document is to describe the electrical, firmware and mechanical information of SecureHead SPI

interface with Flexible Printed Circuit (FPC).

User Manual, SecureHead SPI Interface

Page 6 of 67

2. SPECIFICATIONS

General

1. 1.

Card Speed 5 to 60 inches per second

Electrical

•Operating voltage: 3V or 5V

•Maximum support current: 7mA

ESD

•Units will withstand electrostatic discharge of 4KV anywhere on the unit without damage, 8KV

through air. 8KV ESD to head case with case properly grounded without damage.

Environment

•Operating Temperature: -4°F to 158°F ( -20°C to 70°C)

•Storage Temperature: -40°F to 158°F ( -40°C to 70°C)

•Humidity: Maximum 95% non-condensing

Durability

•Head Wear: 1,000,000 transactions in benign conditions, use by the general public

•MTBF: Calculated for electronics is 300,000 POH minimum

User Manual, SecureHead SPI Interface

Page 7 of 67

Dimension:

PINOUT:

SPI Interface

PIN #

SIGNAL

DAV

NCS

MISO

MOSI

SPCK

GND

Head Case GND

User Manual, SecureHead SPI Interface

Page 8 of 67

Mounting Options:

Wing spring mounting is the standard mounting option and can be used on most swipe readers. The

protrusion of the head for the surface of the spring is 3.50 mm.

SecureHead SPI Interface with FPC User Manual

Page 9 of 67

3. SPI OPERATION

This section describes the SPI (Serial Peripheral Interface), the SPI bus interface timing,

communication protocol, timeouts, and data output format.

3.1. SPI Data Transmission

A serial peripheral interface (SPI) is an interface that enables the serial exchange of data between two

devices, one called a master and the other called a slave. The host (master) generates the clock signal

(SPCK) to trigger data exchange on the SPI bus.

During each SPI clock cycle, the data is transmitted in both directions at the same time (full duplex

transmission)

on the MOSI line, the master sends a bit and the slave reads it

on the MISO line, the slave sends a bit and the master reads it

The SPI bus transmits data in an 8-bit data groups, sending data one bit at a time from MSB to LSB.

An example of bit transmission for byte A and byte B would be

A(bit 7) A(bit 6) … A(bit 0) B(bit 7) B(bit 6) … B(bit 0)

3.2. Clock Polarity and Phase

The clock polarity and phase can be configured with respect to the data. The serial clock input

frequency can go up to 400k bps.

1.2 .

When clock polarity =0 the base value of the clock is 0

1.2.1.

For clock phase=0, data are read on the clock's rising edge (low->high transition) and data

are changed on a falling edge (high->low transition).

1.2.2.

For clock phase=1, data are read on the clock's falling edge and data are changed on a

rising edge.

1.3 .

When clock polarity=1 the base value of the clock is 1

1.3.1.

For clock phase=0, data are read on clock's falling edge and data are changed on a rising

edge.

1.3.2.

For clock phase=1, data are read on clock's rising edge and data are changed on a falling

edge.

The signal is required to read card data from the device. See SPI clock phase and polarity property in

section 3 for commands to configure clock phase and polarity.The device defaults to clock phase = 0

and clock polarity = 0

The following picture shows an example of clock polarity=0 and clock phase=0. The data is read on

the rising edge of the clock and is changed on the falling edge. On MOSI line, the host sends out data

00000010, which is 02h.

SecureHead SPI Interface with FPC User Manual

Page 10 of 67

3.3. Master Input, Slave Output (MISO)

The MISO signal is the serial data output sent from for the device, it’s also the data line that is received

by the host. When the device is not active (Chip Select is high), the MISO becomes high impedance

(disconnected). The MISO signal would be in an indeterminate state after the device is power cycled or

reset for a maximum of 1 second. This signal should be ignored during this time.

3.4. Master Output, Slave Input (MOSI)

The MOSI signal is the serial data input for the device and serial data output for the host. This signal is

sent from the host (master) to the device (slave). The signal might not be required once some device

parameters such as the device key has been set and saved. Set the signal to be high if it is not being

used.
