IBM 37L1414 Manuel utilisateur

Serial I/O SST8P DB Adapter

37L1414

Installation Guide

37L1475

560154/A

October1998

OPTIONS

by IBM

560154_A.p65 11/25/98, 6:52 PM1

IBM Serial I/O SST-8P Installation Guide 2

IBM Serial I/O Adapters are intelligent, high-speed (up to 230.4

kbps on each port) Multiport Boards providing high performance

serial I/O solutions for PCI bus systems. All port interfaces are

standard RS-232 with full modem control and voltage surge protec-

tion on every pin.

IBM Serial I/O Adapters appear to the system host processor as

memory. That is, they are memory mapped devices. Each Adapter is

automatically mapped into system memory at the time of device

driver installation. The device driver soft-configures all adapters

each time the system is initialized (booted). See the Software

Reference Manuals located on the CD ROM for detailed Device

Driver information.`

The IBM Serial I/O Adapter (see Figure 1 below) occupies a single

PCI slot in the host computer and provides the intelligent functions to

"off-load" the CPU serial communications processing tasks.

Overview

Figure 1. Serial I/O SST8P Adapter

560154_A.p65 11/25/98, 6:52 PM2

IBM Serial I/O SST-8P Installation Guide 3

Hardware Installation

Note: Please refer to the user manual that came with your personal

computer for detailed installation instructions.

Use the following procedure to install your PCI Serial I/O 8 Port

Adapter.

1. Set the host computer system power switch to OFF and

disconnect the power cord.

2. Locate a free PCI expansion slot.

3. Insert and secure the board firmly into the expansion slot.

4. Replace the power cord and turn the host computer system ON.

PCI System Setup

Peripheral Component Interconnect (PCI) system architecture has a

design feature termed Plug and Play. This feature automatically

detects, identifies and configures the currently installed devices each

time the system is booted. Therefore, whenever an Adapter is

installed (or removed) in a PCI system, the Adapter is recognized and

configured immediately upon restart.

Software Installation

Refer to the Quick Start Card that came with the CD ROM for

detailed instructions on loading the Software Driver

560154_A.p65 11/25/98, 6:52 PM3

IBM Serial I/O SST-8P Installation Guide 4

Figure 3. Fan Out Cable Pin Outs

Figure 2. Fan Out Cable

Fan Out Cables

Serial Fan Out Cables (FOCs) provide eight RS-232 interfaces. The

FO8 DB-25 has eight male DTE connectors (see Figure 3 below).

DB-25 Fan Out Cable to Device Cabling

Figures 4 through 6 show the pin outs required to make a cable to go

between the DB-25 FOC ports and your terminals, printers, modems,

etc.

560154_A.p65 11/25/98, 6:52 PM4

IBM Serial I/O SST-8P Installation Guide 5

Figure 4. Cable Pin Outs for FO-8 DB-25 to Terminal/Printer DB-25

Figure 5. Cable Pin Outs for FO-8 DB-25 to PC DB-9

Figure 6. Cable Pin Outs for FO-8 DB-25 to Modem DB-25

560154_A.p65 11/25/98, 6:52 PM5

IBM Serial I/O SST-8P Installation Guide 6

Help and Service Information

Before calling, please prepare for your call by following these steps:

Preparing for the Call

To assist the technical support representative, have available as much

of the following information as possible:

• Computer manufacturer and computer model.

• Options part number (Table 1).

• Options part name (Table 1).

• Serial number (if available).

• Proof of purchase (including date and place).

• Exact wording of the error message (if any)

• Description of the problem

• Hardware and software configuration information for your

system

If possible, be at your computer. Your technical support representative

might want to walk you through the problem during the call.

Placing the Call to IBM

Technical support is available during the warranty period to answer

any questions about your new IBM option. Support response time will

vary depending on the number and nature of calls received.

Marketing, installation, and configuration support will be withdrawn

from the PC Company HelpCenter 90 days after the option has been

withdrawn from marketing.

If you call 90 days after the date of withdrawal or after your warranty

has expired, you might be charged a fee. Additional support is

available through the IBM PC Company automated Fax system, the

PC Company Web Page, the PC Company Electronic Bulletin Board

System and HelpWare offerings.

•The IBM web site at “http://www.pc.ibm.com

•The IBM Fax system at (800) 426-3395 or (919) 517-0011

•The IBM BBS system at (919) 517-0001

For the support telephone and support hours by country, refer to the

following table or to an optional enclosed technical support insert. If

the number is not provided in the table or insert, contact your IBM

reseller or IBM marketing representative.

keewasyad7,yadasruoh42troppuS

adanaC8737-624-008-1

ociRotreuP/setatSdetinU8737-624-008-1

560154_A.p65 11/25/98, 6:52 PM6

IBM Serial I/O SST-8P Installation Guide 7

SNOITPOMBI

traPMBI ebmuNr

sretpadAO/IlaireSICP

4141L73retpadABDP8TSSO/IlaireS

5141L73retpadAJRP61TSSO/IlaireS

3241L73retpadABDP61TSSO/IlaireS

6141L73retpadAelbadnapxE821TSSO/IlaireS

7141L73eludoMtroPJR61MPO/IlaireS

8141L73eludoMtroPBD61MPO/IlaireS

1241L73ylppuSrewoP4SPO/IlaireS

2241L73ylppuSrewoPTW4SPO/IlaireS

9141L73teSrexelpitluMJR61O/IlaireS

0241L73teSrexelpitluMBD61O/IlaireS

4241L73teSrexelpitluMTWJR61O/IlaireS

5241L73teSrexelpitluMTWBD61O/IlaireS

Table 1. Options Parts Names and Numbers

Cable Options

Please refer to www.equinox.com for cabling alternatives.

560154_A.p65 11/25/98, 6:52 PM7

IBM Serial I/O SST-8P Installation Guide 8

Product Warranty

The following warranty information applies to products purchased in

the United States, Canada, and Puerto Rico. For warranty terms and

conditions for products purchased in other countries, see the enclosed

Warranty insert, or contact your IBM reseller or IBM marketing

representative. International Business Machines Corporation

Armonk, New York, 10504

Statement of Limited Warranty

The warranties provided by IBM in this Statement of Limited War-

ranty apply only to Machines you originally purchase for your use,

and not for resale, from IBM or your reseller. The term “Machine”

means an IBM machine, its features, conversions, upgrades, elements,

or accessories, or any combination of them.

Unless IBM specifies otherwise, the following warranties apply only

in the country where you acquire the Machine. If you have any

questions, contact IBM or your reseller.

Production Status

Each Machine is manufactured from new parts, or new and used parts.

In some cases, the Machine may not be new and may have been

previously installed. Regardless of the Machine’s production status,

IBM’s warranty terms apply.

The IBM Warranty for Machines

IBM warrants that each Machine

1) is free from defects in materials and workmanship and

2) conforms to IBM’s Official Published Specifications.

The warranty period for a Machine is a specified, fixed period

commencing on its Date of Installation. The date on your receipt is the

Date of Installation, unless IBM or your reseller informs you other-

wise. During the warranty period IBM or your reseller, if authorized

by IBM, will provide warranty service under the type of service

designated for the Machine and will manage and install engineering

changes that apply to the Machine. For IBM or your reseller to

provide warranty service for a feature, conversion, or upgrade, IBM or

your reseller may require that the Machine on which it is installed be

560154_A.p65 11/25/98, 6:52 PM8

IBM Serial I/O SST-8P Installation Guide 9

1) for certain Machines, the designated, serial-numbered

Machine and

2) at an engineering-change level compatible with the feature,

conversion, or upgrade.

Many of these transactions involve the removal of parts and their

return to IBM.

You represent that all removed parts are genuine and unaltered. A

part that replaces a removed part will assume the warranty service

status of the replaced part.

If a Machine does not function as warranted during the warranty

period, IBM or your reseller will repair it or replace it with one that is

at least functionally equivalent, without charge. The replacement may

not be new, but will be in good working order. If IBM or your reseller

is unable to repair or replace the Machine, you may return it to your

place of purchase and your money will be refunded.

If you transfer a Machine to another user, warranty service is

available to that user for the remainder of the warranty period. You

should give your proof of purchase and this Statement to that user.

However, for Machines which have a life-time warranty, this

warranty is not transferable.

Warranty Service

To obtain warranty service for the Machine, you should contact your

reseller or call IBM.

IBM or your reseller will provide certain types of repair and exchange

service, either at your location or at IBM’s or your reseller’s service

center, to restore a Machine to good working order.

When a type of service involves the exchange of a Machine or part,

the item IBM or your reseller replaces becomes its property and the

replacement becomes yours.

You represent that all removed items are genuine and unaltered. The

replacement may not be new, but will be in good working order and at

least functionally equivalent to the item replaced. The replacement

assumes the warranty service status of the replaced item. Before IBM

or your reseller exchanges a Machine or part, you agree to remove all

taMBIllac,setatSdetinUehtnI 8737-624-008-1

taMBIllac,adanaCnI 8737-624-008-1 esahcrupfofoorptneserpotderiuqerebyamuoY

560154_A.p65 11/25/98, 6:52 PM9

IBM Serial I/O SST-8P Installation Guide 10

features, parts, options, alterations, and attachments not under

warranty service. You also agree to ensure that the Machine is free of

any legal obligations or restrictions that prevent its exchange.

You agree to:

1. obtain authorization from the owner to have IBM or your

reseller service a Machine that you do not own; and

2. where applicable, before service is provided —

a) follow the problem determination, problem analysis,

and service request procedures that IBM or your

reseller provide,

b) secure all programs, data, and funds contained in a

Machine, and

c) inform IBM or your reseller of changes in a Machine’s

location.

IBM is responsible for loss of, or damage to, your Machine while it is

1) in IBM’s possession or 2) in transit in those cases where IBM is

responsible for the transportation charges.

Extent of Warranty

IBM does not warrant uninterrupted or error-free operation of a

Machine.

The warranties may be voided by misuse, accident, modification,

unsuitable physical or operating environment, improper maintenance

by you, removal or alteration of Machine or parts identification

labels, or failure caused by a product for which IBM is not respon-

sible.

THESE WARRANTIES REPLACE ALL OTHER WARRANTIES OR

CONDITIONS, EXPRESS OR IMPLIED, INCLUDING, BUT NOT

LIMITEDTO,THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITYANDFITNESSFOR A PARTICULAR PUR-

POSE. THESE WARRANTIES GIVE YOU SPECIFIC LEGAL RIGHTS

AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY

FROMJURISDICTION TOJURISDICTION.SOME JURISDICTIONS

DO NOT ALLOW THE EXCLUSION OR LIMITATION OF

EXPRESS OR IMPLIED WARRANTIES, SO THE ABOVE EX-

CLUSION OR LIMITATION MAY NOT APPLY TO YOU. IN

THAT EVENT SUCH WARRANTIES ARE LIMITED IN DURA-

TION TO THE WARRANTY PERIOD. NO WARRANTIES APPLY

AFTER THAT PERIOD.

560154_A.p65 11/25/98, 6:52 PM10

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels IBM Adaptateur

IBM

IBM Emulex Manuel utilisateur

IBM

IBM 10/100 EtherJet CardBus Adapter Manuel technique

IBM

IBM Advanced SerialRAID Adapters SA33-3285-02 Manuel utilisateur

IBM

IBM Gigabit Fibre Channel PCI Mode d’emploi

IBM

IBM TURBOWAYS 622 PCI MMF ATM Mode d’emploi

IBM

IBM FC5022 Manuel utilisateur

IBM

IBM ThinkPad i Series Manuel utilisateur

IBM

IBM 5-1/4" Diskette Drive Adapter Guide d'application

IBM

IBM 10/100/1000 Base-TX Ethernet PCI-X Adapter Mode d’emploi

IBM

IBM 10/100 Mbps Ethernet PCI Adapter II Mode d’emploi

IBM

IBM PCI Dual Channel Ultra3 SCSI Adapter Mode d’emploi

IBM

IBM FC EJ08 Manuel utilisateur

IBM

IBM Netfinity 10/100 Ethernet Adapters Manuel utilisateur

IBM

IBM NetXtreme II 1000 Manuel utilisateur

IBM

IBM OpenCAPI Mode d’emploi

IBM

IBM SSA 32H3816 Manuel utilisateur

IBM

IBM N2125 Manuel d'installation

IBM

IBM 10/100/1000 Base-T Ethernet PCI Mode d’emploi

IBM

IBM RedbooksQLogic 8200 Manuel utilisateur

IBM

IBM Brocade Manuel utilisateur

IBM

IBM USB Serial Parallel Adapter Manuel utilisateur

IBM

IBM Power GXT800P Manuel utilisateur

IBM

IBM 16/4 Token-Ring Manuel utilisateur

IBM

IBM POWER GXT135P Graphics PCI Mode d’emploi

Manuels Adaptateur populaires d'autres marques

PCB Piezotronics

PCB Piezotronics 090B274 Manuel utilisateur

Auvidea

Auvidea J20 Manuel du produit

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuel utilisateur

Akribis

Akribis ITF-21-BISS-MIT Manuel utilisateur

Tenda

Tenda W54U Manuel utilisateur

ROHO

ROHO AGILITY Manuel utilisateur

PROLiNK

PROLiNK WN2001 Manuel utilisateur

Hawking

Hawking HUF2 Manuel utilisateur

Airlink101

Airlink101 AWLC4030 Manuel utilisateur

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuel utilisateur

Philips

Philips SWA4554S/10 Manuel utilisateur

JVC

JVC TS-C9D2B Manuel d'instructions

NETGEAR

NETGEAR A6100 Manuel utilisateur

D-Link

D-Link DWA-121 Manuel utilisateur

Philips

Philips SWA2037 Manuel utilisateur

Basalte

Basalte 0610-20 Manuel utilisateur

Yealink

Yealink EHS40 Manuel utilisateur

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuel utilisateur
