10/100/1000 Base-T Ethernet PCI Adapter

Installation and Using Guide

SA23-1231-00

First Edition (September 2000)

Before using this information and the product it supports, read the information in “Safety Information” on page v and

“Appendix B. Notices” on page 23.

Note to U.S. Government Users Restricted Rights--Use, duplication or disclosure restricted by GSA ADP Schedule

Contract with IBM Corp.

Note

Before you install this product and use this information, be sure to read the

product warranties and notices information included with the system unit into

which you are installing the product.

Contents

Safety Information.......................v

Handling Static-Sensitive Devices.................vii

About This Book .......................ix

ISO 9000 ..........................ix

Related Publications ......................ix

Trademarks .........................ix

Chapter 1. Overview ......................1

Software Requirements .....................2

Chapter 2. Preparing for Installation ................3

Verifying Your Hardware Requirements ................3

Checking Prerequisites .....................3

Chapter 3. Installing the Device Driver Software ............5

Chapter 4. Installing the Device Driver on the RS/6000 SP System......7

Checking System Prerequisites...................7

Installing Software on the Control Workstation .............10

Installing Device Drivers on the SP Nodes...............11

Chapter 5. Installing the 10/100/1000 Base-T Ethernet PCI Adapter .....13

Installing the Adapter......................13

Verifying Adapter Hardware Installation................14

Verify AIX Software Installation ..................14

Running Adapter Diagnostics ...................15

Chapter 6. Connecting to an Ethernet Network ............17

Connecting the Network Cables and Adapter ..............17

Understanding the Adapter LEDs..................18

Appendix A. Communications Statements ..............19

Federal Communications Commission (FCC) Statement ..........19

European Union (EU) Statement ..................20

International Electrotechnical Commission (IEC) Statement .........20

United Kingdom Telecommunications Safety Requirements .........20

Avis de conformité aux normes du ministère des Communications du Canada. . . 20

Canadian Department of Communications Compliance Statement .......20

VCCI Statement .......................21

Radio Protection for Germany ...................21

Appendix B. Notices .....................23

Reader’s Comments — We’d Like to Hear From You ..........25

iii

iv 10/100/1000 Base-T Ethernet PCI Adapter Installation and Using Guide

Safety Information

DANGER

An electrical outlet that is not correctly wired could place hazardous voltage

on metal parts of the system or the devices that attach to the system. It is the

responsibility of the customer to ensure that the outlet is correctly wired and

grounded to prevent an electrical shock.

Before installing or removing signal cables, ensure that the power cables for

the system unit and all attached devices are unplugged.

When adding or removing any additional devices to or from the system,

ensure that the power cables for those devices are unplugged before the

signal cables are connected. If possible, disconnect all power cables from the

existing system before you add a device.

Use one hand, when possible, to connect or disconnect signal cables to

prevent a possible shock from touching two surfaces with different electrical

potentials.

During an electrical storm, do not connect cables for display stations, printers,

telephones, or station protectors for communication lines.

vi 10/100/1000 Base-T Ethernet PCI Adapter Installation and Using Guide

Handling Static-Sensitive Devices

Attention: Static electricity can damage this device and your system unit. To avoid

damage, keep this device in its anti-static protective bag until you are ready to install it.

To reduce the possibility of electrostatic discharge, follow the precautions listed below:

vLimit your movement. Movement can cause static electricity to build up around you.

vHandle the device carefully, holding it by its edges or its frame.

vDo not touch solder joints, pins, or other printed circuitry.

vDo not leave the device where others can handle and possibly damage the device.

vWhile the device is still in its anti-static package, touch it to an unpainted metal part

of the system unit for at least two seconds. (This drains static electricity from the

package and from your body).

vRemove the device from its package and install it directly into your system unit

without setting it down. If it is necessary to set the device down, place it on its

static-protective package. (If your device is an adapter, place it component-side up).

Do not place the device on your system unit cover or on a metal table.

vTake additional care when handling devices during cold weather, as heating reduces

indoor humidity and increases static electricity.

vii

viii 10/100/1000 Base-T Ethernet PCI Adapter Installation and Using Guide

About This Book

This book provides information about the 10/100/1000 Base-T Ethernet PCI Adapter, as

well as how to attach the adapter to a network. Use this book together with your

specific system unit and operating system documentation.

ISO 9000

ISO 9000 registered quality systems were used in the development and manufacturing

of this product.

Related Publications

The following publications contain related information:

vSystem unit documentation for information specific to your hardware configuration

vOperating system documentation for information specific to your software

configuration

PCI Adapter Placement Reference Guide

(for the latest version, you may need to

contact your marketing representative)

Trademarks

The following term is a trademark of International Business Machines Corporation in the

United States, other countries, or both:

vAIX

vRS/6000

vSP

Other company, product, and service names may be trademarks or service marks of

others.
