I-Tech RKP2419 Manuel utilisateur

RKP2419

Series

I-TECH COMPANY

I-Tech’s provide the most variety of Rackmount LCD

Display solution. RKP 2419 has integrated with 19”

SamSung LCD Panel with ultra-high resolution of 1280

x 1024. Moreover RKP2419 has dual slides drawers for

monitor and keyboards in 19” deep. Optional 8-ports

or 16 ports KVM switches. And more option for S-

Video, -48V Power Supply input.

Phone: 888-483-2418

Fax: 510-372-2736

Email: sales@i-techcompany.com

P.O. Box 4134

Hayward, CA 94540

I-TECH COMPANY

19” LCD in 19” Chassis Deep

Resolution 1280 x 1024

Features

•SumSung LCD Panel

•19” deep Chassis only for more space saving

•2U dual slides for Monitor and keyboard

•Front-access lock for security

•Unique mechanical design to maximize rack mountable space

•Unique monitor flip up design allows viewing through closed glass door of cabinet

•Adjustable mounting brackets from 15.35" to 25.61"( 390 to 650 mm) (front to rear 19"

mounts)

•Suitable for 23.64" to 39.4"(600 to 1000mm) deep 19"cabinet

•Built-in on screen display controlled by integral membrane switches

•Notebook Type & Cherry keyboard selections supporting multiple languages

•Three models to choose from 13.3", 15" or 17" LCD panel

•Standard D-sub 15-pin VGA input connector

•Supplied with 12V 5A remote power adapter (single power source)

•Lightweight aluminum construction - with a black anodize finish

•Slide rails have two fixed positions to prevent movement of the keyboard

•All mounting hardware included

•Optional for 8-ports or 16-ports KVM

•Optional for S-Video and Composite Video input

•Optional for –24 V or –48V power supply input

KVM Features

•High reliability, low cost, easy to use

•Multi-platform-mix PCs, SUNs, IBMs, HPs, Compaq and Dell

•Built-in KVM switch function for easy controlling and monitoring up to 16 residing servers/

platforms

•Easily switch individuals button to select the PC channel using the push-button channel selector

switches, Hot keys, or via the On-Screen Display (OSD)Menu

•New keep alive feature safeguards server for power loss to the switch

•Built-in microprocessor emulation for each port boots up process

•Hot-pluggable when adding to 16 characters long

•Scan mode –Monitor your servers at intervals 5 to 99 seconds

•Support eight characters password protection and search PC server name

•Cascades for use with up to 128 servers

16-channel, 8- channel & 4- channel rackmount model

•VGA, keyboards & mouse all in one by 15 pin HDB connector

•No software needed

•Supplied with 12V 1A remote power adapter ( single power source)

•All mounting hardware included

•LED display for easy status monitoring

Supplied with eight screened cables 6 ft long

www.i-techcompany.com

SamSung LCD Features

Item Description

Size 19"

Resolution SXGA

Number of Pixels 1,280 x 1,024

Active Area(mm) 376.3 x 301.1

Pixel Pitch(mm) 0.294

Mode PVA

Number of Colors 16.7M

Contrast Ratio(typ.) 500:01:00

Brightness(cd/m2) 250

Response Time(ms at 25°C) <25 ms

Viewing Angle(U/D/L/R) 85/85/85/85

Interface LVDS 2Ch

Supply Voltage(V) 5

Backlight 4 CCFL

Outline Dimension(mm) 404.2 x 330 x 20

Weight(g) 2,700

Viewing Angle 170o(Horiz.) / 170o(Vert.)

Storage Temp. 0oC to 50oC

Operating Temp. -25oC to 60oC

MTBF 20,000 hours

Power Supply

•Remote adapter : 110V - 220 V AC Input , 12V 5A Output

•Adapter Size : 4.3”(L) x 2.4”(W) x 1.2”(H)inch(10.8 x 6.1 x 3cm)

•Cable length from mains plug to adapter : 6ft (182cm)

•Cable length from adapter to unit : 6ft (180cm)

•Safety approval : UL, CE

•Mains plug options available

•Optional -48V DC input

www.i-techcompany.com

Product Dimension

For 19" LCD: 17.3”(W) x 3.46”(H) x 19”(D)inch (44.2x 8.8x 48cm)

Packing Dimension

23.44”(L) x 22.46”(W) x 8.67”(H)inch(59.5x57x22mm)

www.i-techcompany.com

Keyboard Selections

•“e” Type Notebook type keyboard

with touch pad mouse.

•With GlidepointTM touchpad,

88keys (US layout).

•Operating life of individual keys : 10

million operations

•“c” Type Cherry keyboard with inte-

grated trackball

•High-quality PS/2 compatible 16mm

Logitech trackball, 83keys (US layout)
