DIGITAL NAVIGATION SYSTEM

User's Manual

DIGITAL NAVIGATION SYSTEM

User's Manual

PART 1

PRE-OVERVIEW

Introduction ……………………… 1-2

Controller and functions ………… 1-3

Basic operation and setting ……… 1-6

PART 2

AUDIO SYSTEM

Operating the radio ……………… 2-2

Operating the CD Player ………… 2-10

Operating external devices ……… 2-22

PART 3

NAVIGATION SYSTEM

Limitations of the navigation

system …………………………… 3-2

Map Functions …………………… 3-5

Setting a destination …………… 3-12

Operating after setting

a destination ……………………… 3-28

Route guidance …………………… 3-30

Setup and Information …………… 3-36

PART 4

XM DATA

Entering XM Data mode ………… 4-2

PART 5

VOICE COMMAND SYSTEM

Operating voice command ……… 5-2

Setting up the voice command

system …………………………… 5-4

Voice command list ……………… 5-6

Table of contents

PART 6

BLUETOOTH HANDS FREE

Before using the Bluetooth

Handsfree ………………………… 6-2

Converting Bluetooth Handsfree

mode ……………………………… 6-2

Pairing and connecting a Bluetooth

phone ……………………………… 6-4

Bluetooth Handsfree screen

layout ……………………………… 6-9

Making a call ……………………… 6-11

Answering a call ………………… 6-13

Operating menus during a call …… 6-14

Phone Book ……………………… 6-16

Call History List …………………… 6-19

Phone Music ……………………… 6-21

Bluetooth settings ………………… 6-24

Important information …………… 6-30

PART 7

PGS (Parking Guide System)

About PGS (Parking Guide System)

… 7-2

PART 8

APPENDIX

Troubleshooting guide …………… 8-2

Map legend ……………………… 8-5

INDEX ……………………………… 8-8

Table of contents

PRE-OVERVIEW 1-1

PRE-OVERVIEW

PART 1

PRE-OVERVIEW

Introduction ……………………… 1-2

Important information about this

manual …………………………………1-2

Precaution for safe usage ………………1-2

Controller and functions ………… 1-3

Control panel ……………………………1-3

Steering wheel remote controller ………1-5

Basic operation and setting ……… 1-6

Turning the Power ON …………………1-6

System Power ON …………………… 1-6

Turning the Power OFF …………………1-6

Turning the Audio ON/OFF ……………1-6

Adjusting audio volume …………………1-7

How to operate the screen menu ………1-7

Operating typical screen menu ……… 1-7



Inputting letter by using screen

keyboard ……………………………… 1-7



Displaying the list …………………… 1-7



Selecting an item in a list …………… 1-8



Sorting items from list ……………… 1-8

How to operate menu by voice

command ………………………………1-8



Conditions for voice recognition

system ………………………………… 1-8

Giving voice command ……………… 1-9

Sound setting ……………………………1-9

FAD/BAL ……………………………… 1-9

BASS/MID/TREB ……………………… 1-10

Auto volume control ON/OFF ……… 1-10

Touch screen beep ON/OFF ………… 1-10

Variable EQ Setup (Optional) ………… 1-10

Operating Variable EQ ……………… 1-10

Display setting ……………………… 1-11

Display mode ………………………… 1-11

Brightness …………………………… 1-11

Display OFF ………………………… 1-11

Display ON …………………………… 1-11

Viewing Current Time ………………… 1-12

Setting the Clock …………………… 1-12

Setting Display OFF ………………… 1-13

Display Photo Frame ………………… 1-13

PART 1 PRE-OVERVIEW

Thank you for purchasing this Audio

Navigation System.

This user's manual explains how to use

the Hyundai Motor Audio Navigation

System.

Before using the product, read the

contents of this user's manual carefully

and use this product safely.

● The screens shown in this manual

may differ with the actual screens of

the product.

●



The design and specification of this

product may change without prior

notification for product improvement.

● When transferring the vehicle to

another individual, include this user's

manual so that the next driver can

continue its use.

iPod®

iPod® is a registered trademark of Apple

Inc.

Bluetooth®

The Bluetooth® word mark and logos

are registered trademarks owned by

Bluetooth SIG, Inc. and any use of such

marks by Hyundai is under license.

A Bluetooth® enabled cell phone is

required to use Bluetooth® wireless

technology.

Preface

This is protected by U.S. copyright laws. All rights not expressly granted are reserved.

You may not otherwise reproduce, modify, and distribute the content without M&Soft, Inc's prior written consent.

1-2 PRE-OVERVIEW

PART 1 PRE-OVERVIEW

Introduction

Important information about this

manual

This user manual contains instructions related

to safety. Closely observe and comply with all

of the safety instructions found within this

manual.

WARNING !

Disobeying the warnings listed within this

user's manual may cause fatal or serious inju-

ries. Warnings indicate matters which may

directly lead to accidents.

CAUTION!

Disobeying the cautions listed within this user

manual may lead to accidents or cause injury.

Cautions indicate matters which may lead to

vehicle damage or malfunction.

INFORMATION

Information which the user must be aware or

allows for more convenient use of the device.

Precaution for safe usage

WARNING !

●

Do not operate the Audio Navigation system

while driving.

●

Do not disassemble, assemble, or modify the

Audio Navigation system.

●

Do not watch the screen for prolonged peri-

ods of time while driving.

●Set the volume to a level which allows the

driver to be aware of external conditions.

CAUTION!

●

Do not operate the Audio Navigation sys-

tem for prolonged periods of time with the

vehicle ignition in ACC. Such operations

may lead to battery discharge.

●

Be cautious not to spill water or introduce

foreign objects into the device.

●

Do not cause severe shock to the device.

Direct pressure onto the front side of the

monitor may cause damage to the LCD or

touch panel.

●

In case of product malfunction, please con-

tact your place of purchase or service cen-

ter.

●

When cleaning the touch screen, make sure

to turn off the device and use a dry and

smooth cloth. Never use tough materials,

chemical cloths, or solvents (alcohol, ammo-

nia, benzene, thinners, etc.) as such materials

may damage the device panel or cause color

and quality deterioration.

Reference Page

This indicates the title and page that you

should refer to.

This indicates a key on the control panel.

Voice Command

This indicates an operation by voice com-

mand.

PRE-OVERVIEW 1-3

PRE-OVERVIEW

4SEEK/TRACK Up/Down

●SHORT KEY(less than 0.8 second)

• FM/AM Mode : automatically searches for

the previous or next broadcast frequency

and starts playing.

• XM Mode : receives the previous or next

channel.

• CD Mode : plays the previous or next track.

• MP3, USB Mode : Plays the previous or

next file.

• iPod Mode : plays the previous or next song.

● 

LONG KEY(over 0.8 second)

• FM/AM Mode : quickly moves through the

frequencies while the button is pressed.

Once released, automatically searches for

broadcasts which can be received.

• XM Mode : quickly moves to the previous

or next channel.

• CD Mode : REW/FF the current playing

track.

5MEDIA

Each press will change the bands in the fol-

lowing order: DISC(CD, MP3)

→

(USB or iPod)

→

(AUX)

→

(Phone Music)

→

DISC(CD, MP3)...

2FM/AM

Each press will change the bands in the fol-

lowing order: FM1

→

FM2

→

FM1 ...

3XM

Each press will change the bands in the fol-

lowing order: XM1

→

XM2

→

XM3

→

XM1 ...

1Power / Volume control knob

●

Push knob (over 0.8 second) : turns the

power off.

●

Push knob (under 0.8 second) : each time the

knob is pressed, the Audio is turned on and off.

● 

Tune knob : the range of volume adjustment

is between 0 ~ 35.

Controller and functions

Control panel

1 4

2 5

12 14

13 15

7 8 917

1-4 PRE-OVERVIEW

PART 1 PRE-OVERVIEW

• MP3, USB Mode : REW/FF the current play-

ing file.

• iPod Mode : REW/FF the current playing

song.

6PHONE

Displays the Bluetooth handsfree screen.

7DISP

DISP displays the displays setting screen.

8MAPVOICE

Displays the map screen for the current posi-

tion.

9ROUTE

Displays the Route menu screen.

10 DEST

Displays the displays setting screen.

11 TUNE

● 

FM/AM Mode : push the key to search for

the desired frequency. Press the key to

receive the selected frequency.

● 

XM Mode : push the key to search for the

desired channel. After a brief moment, the

selected channel will be displayed.

● 

CD Mode : push the key to search for the

desired track. Press the key to play the

selected track.

● 

MP3, USB Mode : push the key to search

for the desired file. Press the key to play

the selected file.

●

iPod Mode : push the key to search for the

desired song. Press the key to play the

selected song.

12 SETUP

Displays the Setup menu screen.

13 ENTER

Completes the command.

14 RESET

Resets the system - if software locks-up.

INFORMATION

If pressing the power off knob for over 0.8 sec-

ond and the system does not shut down, and

carefully use and insert a straightened paper

clip at the access hole shown next to the right

DISC indicator LED to reset the software.

The system power will shut-off and restart.

15 Clock

●Short Key (under 0.8 second)

• When the screen is turned on : displays

the current time in the center of the

screen.

• When the screen is turned off : turns the

full clock screen on and off.

●Long Key (over 0.8 second)

• Displays the clock setting screen.

16 DISC eject

Ejects the inserted disc.

17 DISC insert indicator LED

Displays whether a DISC has been inserted.

PRE-OVERVIEW 1-5

PRE-OVERVIEW

Steering wheel remote controller

1MODE

Each time the Mode key is pressed, the mode

changes in the following order: FM1

→

FM2

→

XM1

→

XM2

→

XM3

→

(DISC)

→

(USB or iPod)

→

(AUX)

→

(Phone Music)

→

FM1 ...

If an unsupported DISC is inserted, if there is

no disc, or if an external device (e.g. iPod, USB

memory stick, etc.) has not been connected,

the mode will not be recognized and auto-

matically switch to the next mode.

●

Press this key for over 0.8 second to turn the

Audio ON and OFF.

●

Press this key when the Power is turned off

to turn the power on.

2Volume Up/Down

Increases or decreases the volume within a

range between 0 ~ 35. Volume for navigation

and voice guidance can be adjusted in the

setup mode.

3Seek Up/Down

●SHORT KEY(less than 0.8 second)

• FM/AM : receives the previous or next pre-

set frequency.

• XM Mode : receives the previous or next

preset channel.

• CD Mode : plays the previous or next

track.

• MP3, USB Mode : plays the previous or

next file.

• iPod Mode : plays the previous or next

song.

●

LONG KEY(Over 0.8 second)

• FM/AM Mode : quickly moves through the

frequencies while the key is pressed.

Once released, automatically searches for

broadcasts which can be received.

• XM Mode : quickly moves to the previous

or next channel.

• CD Mode : REW/FF the current playing track.

• MP3, USB Mode : REW/FF the current play-

ing file.

• iPod Mode : REW/FF the current playing

song.

4Voice Recognition

Starts Voice Recognition.

5CALL

Press this key to receive an incoming call. If

pressed while in Audio/Navigation mode, the

bluetooth handsfree screen will be displayed.

6END

Press this key to reject an incoming call.

If pressed while on a call, then the call will be

terminated.

Table des matières

Autres manuels Hyundai Système de navigation automobile

Hyundai

Hyundai TUCSON 2018 Manuel utilisateur

Hyundai

Hyundai SONATA Manuel utilisateur

Hyundai

Hyundai Gen5W Manuel utilisateur

Hyundai

Hyundai AVANTE MTXM100AD Manuel utilisateur

Hyundai

Hyundai 2011 EQUUS Instructions de montage

Hyundai

Hyundai Santa Fe 2016 Manuel utilisateur

Hyundai

Hyundai TQ8-AN240DKAN Manuel utilisateur

Hyundai

Hyundai IONIQ Hybrid 2018 Manuel utilisateur

Hyundai

Hyundai BlueLink Manuel utilisateur

Hyundai

Hyundai LAC1420IWFS Manuel utilisateur

Hyundai

Hyundai Santa Fe Manuel utilisateur

Hyundai

Hyundai LAN1050EHGD Manuel utilisateur

Hyundai

Hyundai LF-N3000H Manuel utilisateur

Hyundai

Hyundai IX35 Manuel utilisateur

Hyundai

Hyundai HAVN-200CMBR Manuel utilisateur

Hyundai

Hyundai LAN1100EHVF Manuel utilisateur

Hyundai

Hyundai PONTUS Manuel utilisateur

Hyundai

Hyundai AV2B4SDAN Manuel utilisateur

Hyundai

Hyundai Genesis2015 Manuel utilisateur

Hyundai

Hyundai AV240DPAN Manuel utilisateur

Hyundai

Hyundai IX35 Manuel utilisateur

Hyundai

Hyundai AN243DKAN Manuel utilisateur

Hyundai

Hyundai Grand i10 NIOS Manuel utilisateur

Hyundai

Hyundai DIGITAL NAVIGATION SYSTEM Manuel utilisateur

Manuels Système de navigation automobile populaires d'autres marques

Clarion

Clarion Navigation In-Car Entertainment Manuel utilisateur

Rosen

Rosen DP-1001 Manuel utilisateur

Alpine

Alpine INE-W970HD Manuel utilisateur

Skoda

Skoda AMUNDSEN+ Manuel utilisateur

Blaupunkt

Blaupunkt TravelPilot DX-N Manuel utilisateur

Pioneer

Pioneer MZ360500EX Manuel utilisateur

Sanyo

Sanyo NVM-4030 - Easy Street - Automotive GPS... Manuel utilisateur

Kenwood

Kenwood DNN991HD Manuel utilisateur

AvMap

AvMap Geosat 2C Manuel utilisateur

Eonon

Eonon GE01B Manuel utilisateur

Pioneer

Pioneer AVIC-Z920DAB Manuel utilisateur

Nextar

Nextar M3-MX - Automotive GPS Receiver Manuel utilisateur

Furrion

Furrion NV2200 Manuel utilisateur

Mio

Mio MOOV 200-Series Manuel utilisateur

Prestigio

Prestigio GeoVision 5150 Manuel utilisateur

Hummer

Hummer 2006 H3 Manuel utilisateur

Magellan

Magellan Maestro 4210 - Automotive GPS Receiver Guide de configuration

Garmin

Garmin StreetPilot c510 Manuel utilisateur
