AZERA QUICK REFERENCE GUIDE

INSTRUMENT PANEL

SET 1 2

ESC

OFF

1: I.M.S. (Integrated Memory System) (If Equipped)

The Integrated Memory System controls are located on the

driver's door trim.

MEMORIZING DRIVER POSITION

Place the shift lever into "P" while the ignition switch is ON.

Adjust the driver's seat, outside rearview mirrors and steering

wheel column (with electric tilt and telescopic type) to the

desired position.

Push the "SET" button on the I.M.S. until the signal beeps.

Within five seconds, push button "1" or "2" until the signal beeps

twice. The beep confirms that the positions are memorized in the I.M.S.

TO ACTIVATE THE MEMORIZED POSITION

Place the shift lever into "P" while the ignition switch is ON.

When you push button "1" or "2", the driving position will be

automatically adjusted to the position recorded for that button.

See Owner’s Manual for conditions in which I.M.S. will not operate.

2: Electronic Stability Control (ESC)

The ESC system is designed to help the driver maintain vehicle

control under adverse driving conditions. The indicator light in the

instrument panel will illuminate for 6 seconds after the key is turned

ON. If the light remains illuminated, take your car to a Hyundai dealer.

If you turn the system off by pressing the ESC switch, the ESC-OFF

indicator will illuminate and stay on. In the ESC-OFF mode, the

stability

control will be deactivated. Adjust your driving accordingly.

To turnthe system back on, press the switch again. The ESC-OFF

indicator will turn off.

AUTO

OFF

ESC

OFF

AUTO

OFF

4: Headlights and Fog Lights

HEADLIGHT SWITCH

To operate the headlights, turn the switch on the end of the lever:

OFF

–Headlights are off

– Parking lights

–Headlights

AUTO

–Auto Light

(If Equipped)

NOTE: The ignition must be in the ON position to turn on the headlights.

High Beam Activation: Push the lever forward

Flash-To-Pass Feature: Pull the lever towards you and release

FOG LIGHT SWITCH

Rotate the switch to the ON position.

NOTE: Fog lights will only function on low beam.

5: Windshield Wiper / Washer

WIPER SPEED

The windshield wiper switch has four positions: intermittent or AUTO

(if equipped), low speed, high speed and mist. For mist (single wipe),

move the lever up one position.

INTERMITTENT OPERATION

With the windshield wiper switch in the “INT” position, the interval

between wipes can be varied by turning the intermittent wiper switch.

WIPE / WASH OPERATION

To use the windshield washer, pull the wiper / washer lever toward

you. When the washer is operated, the wipers automatically make

two passes across the windshield. The washer continues to operate

until the lever is released.

AUTO WIPER OPERATION (If Equipped)

When the windshield wiper switch is placed in the "AUTO" position,

the rain sensor, located on the windshield behind the rearview mirror,

senses the amount of rainfall and controls for the appropriate length

of the intervals between wipes appropriately.

3: Adjustable Pedals

Turn the ignition key to the “ON” position with the selector lever in

the “P” position and push the switch.

If you move the portion of the switch, the pedals move rearward.

If you move the portion of the switch, the pedals move forward.

OFF

AUTO

MIST

PULL

MIST

OFF

AUTO

PULL

MIST

OFF

AUTO

PULL

MIST

OFF

AUTO

OFF

AUTO

MIST

PULL

MIST

OFF

AUTO

ESC

OFF

ESC

OFF

MODE

VOL

RES

ACCEL

OFF

CANCEL

COAST

SET

R3:27

6: Adjustable Steering Wheel (If Equipped)

POWER ADJUSTABLE STEERING COLUMN (If Equipped)

To adjust the steering wheel to the desired position, operate the

adjusting switch on the left side of the steering wheel.

MANUAL ADJUSTABLE TILT & TELESCOPIC STEERING COLUMN

Pull the lever downward to unlock the steering wheel. Adjust the

steering wheel up or down and forward or backward to the desired

position. After adjustment, securely tighten the lever by pushing

it upward.

NOTE: Do not adjust while driving.

7: Steering Wheel Audio Controls

MODE switch

MUTE switch

VOL (

/ )

switches

8: Cruise Control

RES (resume) / ACCEL switch

CANCEL switch

COAST / SET switch

ON / OFF switch (Press to activate the system)

9: Clock Adjustment

There are three control buttons for the digital clock. Their functions are:

Push “H” to advance the hours.

Push "M" to advance the minutes.

Push "R" to reset minutes to ":00". Continue to press and hold

the “R” button to toggle between military time and standard time.

10: Occupant Classification System

PASSENGER AIR BAG OFF INDICATOR

The indicator will illuminate when you turn the ignition key to ON or

START. The light will not illuminate when the passenger's air bag is

enabled. The occupant classification system will disable the right

front passenger's air bags under certain conditions (light on). Refer

to the Owners’ Manual for a complete description of this system.

NOTE: The driver's air bag and the side impact air bag are not part

of the occupant classification system.

11: Seat Warmer (If Equipped)

The front seats can be electrically heated individually when the

ignition switch is on. When the switch is on, a number ranging from 1

to 5 is displayed on the switch (5 = warmest setting). To turn off the

seat warmer, set the switch to 0.

NOTE: The seat warmer may not operate if the ambient temperature

is warm.

12: Transmission / Shiftronic™(If Equipped)

Whether the vehicle is stationary or in motion, sports mode is selected

by pushing the selector lever from the “D” position into the manual

gate. To return to “D” range operation, push the selector lever back

into the main gate. In sports mode, moving the selector lever back-

wards and forwards can make rapid gearshifts simple. In contrast

to a manual transaxle, the sports mode allows gearshifts with the

accelerator pedal depressed.

UP (+): Push the lever forward once to shift up one gear.

DOWN (-): Pull the lever backwards once to shift down one gear.

SKIP: By rapidly moving the selector forward or backward twice, it is

possible to skip one gear.

NOTE: Shift lever in Neutral (N), Drive (D), or Reverse (R) position still

allows for the ignition key to be turned off.

13: Power Rear Sunshade (If Equipped)

The rear window shade switch is located on the center console.

Press the curtain switch to raise or lower the rear window curtain.

NOTE: When the shift lever is shifted into reverse "R", the rear

window curtain will automatically lower if the curtain is in the

raised position.

PASS AIR BAGOFF

AUDIO SYSTEM CONTROLS

POWER ON/OFF,Volume Control Knob

EQUALIZER (EQ) Button

ADJUSTMENT Mode Select

(A.MODE) Button

AM/FM RADIO CONTROLS

TUNE Select Knob

BAND Selector

SCAN Button

SEEK/SELECT Button

PRESET STATION Select Buttons

CASSETTE TAPE CONTROLS

TAPE EJECT Button

AUTO MUSIC Search Button

FF/REW Button

TAPE Program Button

REPEAT (RPT) Button

DOLBY BUTTON

CD/MP3 CONTROLS

LOAD Button –

To insert one disc into the

player, press and release the LOAD button.

To insert up to six CDs, press and hold the

LOAD button for more than one second.

CD Eject Button

DISC UP/DOWN Buttons

CHANGE DIRECTORY(DIR) Button

BOOKMARK Button

RANDOM (RDM) Button

TRACK Up/Down

FF/REW Button

REPEAT (RPT) Button

SCAN Button

FILE SEARCH Knob

CD/MP3 Select Button

1 FF 2 RDM 3

4 REW 5 RPT

DIR

SEEK

TRACK 6

MARK

FM/AM

TAPE

A.MODE

DISC

LOAD

PUSH

POWER

PUSH

ENTER

VOLUME

TUNE

FILE

SCAN

LOGIC CONTROL

M G

14: Audio System (AM / FM / Cassette / 6-CD / MP3 Audio System Shown)

L K

NOTE: The time it takes for the audio system

to recognize an MP3 CD may vary greatly

depending on the folder layout on the CD.

TO REMOVE FROST OR FOG ON

THE WINDSHIELD:

Set the air flow control to the defrost

position. (The A/C will turn on automatically

and the

"Fresh" mode will be activated.)

Set the fan speed control to the maximum speed.

Set the temperature control to the desired setting.

NOTE: If the air conditioner filter for the evaporator blower is not replaced per the scheduled

maintenance section, excessive window fogging may result. This filter is located in the evaporator

housing behind the glove box. Your dealer can replace this filter for you.

DUAL TEMPERATURE CONTROL SELECTION SWITCH

Press the DUAL button to operate the driver and passenger side temperature individually

Press the DUAL button again to deactivate DUAL mode (The indicator light on the button goes off).

The passenger side temperature will be set to the same as the driver side temperature.

AIR QUALITY SYSTEM

Press the automatic air recirculation button to turn the air quality system on.

The light on the button will be illuminated when the system is activated.

TEMP

AUTO OFF MODE DUALA/C

TEMP

PASS

15: Climate Control

E/TRANGEAVG.

TRIP

123.4

mi.

ODO

123456 mi.

TRIP

ODO

MPH

MPG

2 3

23456

TRIP

123.4

mi.

ODO

123456

mi.

TRIP

ODO

2 3

23456

TRIP COMPUTER

Pushing in the MODE switch when the ignition switch is in “ON”

position changes the display as follows:

TRIPMETER

DISTANCE TO EMPTY

AVERAGE SPEED

DRIVE TIME

AVERAGE FUEL CONSUMPTION

Trip Odometer

With the key ON, press the MODE to toggle through the following

display modes:

ODO:

Records the total distance traveled in miles.

TRIP A:

Total distance traveled since the last tripmeter reset.*

TRIP B:

Total distance traveled since the last tripmeter reset.*

*To reset the displayed distance to 0 while viewing TRIP A or TRIP B, press

the reset switch for a few seconds.

16: Trip Computer/Odometer

INSTRUMENT PANEL (CONTINUED)

Power Front Seat Adjustment (If Equipped)

LUMBAR CONTROL

To adjust the lumbar support, press the switch.

SEATBACK ANGLE

Move the control forward or backward to recline the seatback.

SEAT HEIGHT & FORWARD / BACKWARD

Raising / lowering the front of the control will raise / lower the front

part of the cushion. Raising / lowering the back of the control will

raise / lower the rear part of the cushion.

AUTOAU TO

MIRROR

Power Windows

The windows may be opened by depressing the appropriate window

switch and closed by pulling up the the switch.

AUTO UP / DOWN (FRONT WINDOWS)

To fully open the window automatically,press the switch fully down.

To fully close the window automatically, pull the switch fully up.

NOTE: Ignition switch must be on.

Window Lock Switch

To disable the passenger front and rear power windows, press the

window lock switch. To revert to normal operation, press the window

lock switch a second time.

NOTE: Ignition switch must be on.

ADDITIONAL FEATURES & INFORMATION

Immobilizer System

The immobilizer system is an anti-theft device, designed to deter automobile

theft. Please refer to your Owner’s Manual for more information.

Remote Keyless Entry

LOCK

Press to lock all doors and arm the alarm. Press again to hear

confirmation chirp.

UNLOCK

Press to disarm the alarm and unlock the driver’s door. Press again

within four seconds to unlock all doors.

TRUNK UNLOCK

Press for longer than one second to release the trunk lid.

PANIC

Press to activate the horn and flashing lights for 30 seconds. Press

again to turn off panic mode.

Sunroof Controls

OPENING/CLOSING THE SUNROOF

Press the SLIDE OPEN button momentarily to activate the one-touch

feature. Press the button for less than .5 second intervals to move

the sunroof one step at a time. To close the sunroof, press the TILT

UP button and hold it until the sunroof is closed.

TILTING THE SUNROOF

Press to tilt up.

To close the sunroof, press the SLIDE OPEN button and hold it

until the sunroof is closed.

Fuel Cap

After adding fuel, always reinstall the fuel cap fully and make sure it

clicks at least 3 times. Failure to do this may result in the “Check

Engine Light” illuminating.

Outside Rearview Mirrors

ADJUSTING

1. Move the select switch to right or left to activate the

corresponding mirror. 2. Adjust the mirror angle by

depressing the appropriate perimeter switch as illustrated.

3. Place the select switch in the middle position to deactivate the

perimeter switch.

POWER FOLDING (If Equipped)

Both left and right outside rearview mirrors can be folded for parking

in narrow areas by pressing the outside rearview mirror folding

switch.

MIRROR

SLIDE

OPEN

TILT

Autres manuels pour 2013 Azera

Table des matières

Autres manuels Hyundai Automobile

Hyundai

Hyundai Elantra GT 2018 Manuel utilisateur

Hyundai

Hyundai SONATA HYBRID 2018 Manuel utilisateur

Hyundai

Hyundai Grand i10 NIOS Manuel utilisateur

Hyundai

Hyundai Santa Fe Manuel utilisateur

Hyundai

Hyundai 2013 sonata Manuel utilisateur

Hyundai

Hyundai Santa Fe Manuel utilisateur

Hyundai

Hyundai Ioniq Hybrid 2020 Manuel utilisateur

Hyundai

Hyundai i30 Manuel utilisateur

Hyundai

Hyundai VELSOTER Manuel utilisateur

Hyundai

Hyundai 2003 Accent Manuel utilisateur

Hyundai

Hyundai SONATA Manuel utilisateur

Hyundai

Hyundai 2013 Azera Manuel utilisateur

Hyundai

Hyundai Veloster Manuel utilisateur

Hyundai

Hyundai IONIQ 5 Manuel utilisateur

Hyundai

Hyundai SANTA FE 2020 Manuel utilisateur

Hyundai

Hyundai ELANTRA HYBRID Manuel utilisateur

Hyundai

Hyundai Sonata 2020 Manuel utilisateur

Hyundai

Hyundai 2012 Santa Fe Sport Manuel utilisateur

Hyundai

Hyundai 2005 Sonata Manuel utilisateur

Hyundai

Hyundai H-1 Manuel utilisateur

Hyundai

Hyundai 2007 Santa Fe Manuel utilisateur

Hyundai

Hyundai 2009 Accent Manuel utilisateur

Hyundai

Hyundai Accent 2020 Manuel utilisateur

Hyundai

Hyundai Accent 2017 Manuel utilisateur

Manuels Automobile populaires d'autres marques

Toyota

Toyota 2000 Tundra Manuel utilisateur

CITROËN

CITROËN DS4 DSign Manuel utilisateur

Lexus

Lexus 2015 CT 200h Manuel utilisateur

Cadillac

Cadillac CTS 2008 Manuel utilisateur

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuel utilisateur

Porsche

Porsche Boxster S Manuel utilisateur

GMC

GMC 2010 Savana 1500 Cargo Manuel utilisateur

KIAM

KIAM SPORTAGE 2014 Manuel de la liste des pièces

GMC

GMC 2013 Terrain Instructions de montage

GMC

GMC T-Series 1999 Manuel utilisateur

Mercury

Mercury 1998 Mystique Manuel utilisateur

Mercury

Mercury 2007 Mariner Manuel utilisateur

Mazda

Mazda 2007 Mazdaspeed 3 Mode d’emploi

Mazda

Mazda 2014 CX-5 Manuel utilisateur

GMC

GMC Chevrolet Express 2022 Manuel utilisateur

GMC

GMC 1997 Jimmy Manuel utilisateur

Chevrolet

Chevrolet 2012 Malibu Manuel utilisateur

Cadillac

Cadillac 2010 Escalade Manuel utilisateur
