Hytronik HBIR30/CA Guide rapide

1. Technical Speciﬁcations

Installation and Instruction Manual

3. Installation

1. Ceiling (drill hole φ66~68mm)

2. Carefully prise off the cable clamps.

3. Make connections to the pluggable

terminal blocks.

4. Insert plug connectors and secure using

the provided cable clamps, then clip

terminal covers to the base.

5. Fit detection blind (if required) and

desired lens.

6. Clip fascia to body.

7. Bend back springs and insert into ceiling.

Ø 78

75.2

70.5

Ø 66~68mm

* Install blind as required

A B

* Install lens as required

1 2 3

Mechanical Structure & Dimensions

HBIR30/CA HBIR30/CA/R

HBIR30/CA/H HBIR30/CA/RH

PIR Standalone Motion Sensor with Mesh

One DALI Channel Output

2. Download the App

HBIR30/CA-20210811-A0

Subject to change without notice.

Free smartphone App for set-up and commissioning

App Store

Download on the

Protocol

Max 4 dBm

2.4 GHz - 2.483 GHz

Operation frequency

Transmission power

Range (Typical indoor)

10~30m

Stand-by power

Operating voltage

0.2W

220~240VAC 50/60Hz

20s

Warming-up

360

Ta:-20

OC~+50OC

PIR detection

Sensor principle

Detection angle

Operation temperature

IP20IP rating

4.0

Detection range (Max.)*

HBIR30/CA

Detection range (Max.)*

HBIR30/CA/H

Installation height：15m (forklift)

12m (person)

Detection range (Ø)：24m

Installation Height : 6m

Detection Range (Ø) :9m

Installation height：15m (forklift)

12m (person)

Detection range (Ø)：40m

Detection range (Max.)*

HBIR30/CA/R

Installation Height : 6m

Detection Range(Ø) :10m

Detection range (Max.)*

HBIR30/CA/RH

EMC standard (EMC)

Safety standard (LVD)

Certiﬁcation

EN55015, EN61000, EN61547

CB, CE , EMC, LVD, RCM

RED EN300328, EN301489-1,

EN301489-17

EN60669-1, EN60669-2-1

HBIR30/CA-20210811-A0

Subject to change without notice.

4. Detection Pattern & Optional Accessories

Radial (B)

Tangential (A)

2.5m

Mount height

insensitive sensitive insensitive sensitive

A: Tangential movement

Tangential: max. 9m

h = max.6m

B: Radial movement

Radial: max. 4m

h = max.6m

HBIR30/CA: Low-bay ﬂat lens detection pattern for single person @ Ta = 20ºC

(Recommended ceiling mount installation height 2.5m-6m)

max 64m

(Ø = 9m) max 13m

(Ø = 4m)

max 13m

(Ø = 4m)

max 13m

(Ø = 4m)

max 13m

(Ø = 4m)

max 13m

(Ø = 4m)

max 50m

(Ø = 8m)

max 38m

(Ø = 7m)

max 38m

(Ø = 7m)

max 38m

(Ø = 7m)

Optional Accessory --- Ceiling/Surface Mount Box: HA03

1. HBIR30/CA (Low-bay)

Valid Range

Blind Option 1 --- Aisle Detection

Optional Accessory --- Blind Insert for Blocking Certain Detection Angles

Ø 94

Blind Option 2 --- 180º Detection

Valid Range

4.2

HBIR30/CA-20210811-A0

Subject to change without notice.

Radial (B)

Tangential (A)

2.5m

Mount height

HBIR30/CA/R: Low-bay convex lens detection pattern for single person @ Ta = 20ºC

(Recommended ceiling mount installation height 2.5m-6m)

max 79m

(Ø = 10m)

max 79m

(Ø = 10m)

max 64m

(Ø = 9m)

max 50m

(Ø = 8m)

max 50m

(Ø = 8m)

max 20m

(Ø = 5m)

max 20m

(Ø = 5m)

max 20m

(Ø = 5m)

max 20m

(Ø = 5m)

max 20m

(Ø = 5m)

2. HBIR30/CA/R (Reinforced Low-bay)

A: Tangential movement

Tangential: max. 10m

h = max.6m

B: Radial movement

Radial: max. 5m

h = max.6m

Optional Accessory --- Ceiling/Surface Mount Box: HA03

Optional Accessory --- Blind Insert for Blocking Certain Detection Angles

Ø 94

Valid Range

Blind Option 1 --- Aisle Detection Blind Option 2 --- 180º Detection

Valid Range

insensitive sensitive insensitive sensitive

4.2

HBIR30/CA-20210811-A0

Subject to change without notice.

Blind Option 1 --- Aisle Detection Blind Option 2 --- 180º Detection

3. HBIR30/CA/H (High-bay)

Tangential: max. 20m

h = max.12m

Radial: max. 3m

h = max.12m

Radial (B)

Tangential (A)

10m

Mount height

14m

15m

13m

12m

11m max 452m

(Ø = 24m)

max 380m

(Ø = 22m)

max 452m

(Ø = 24m)

max 452m

(Ø = 24m)

max 452m

(Ø = 24m)

max 452m

(Ø = 24m)

max 201m

(Ø = 16m)

max 201m

(Ø = 16m)

max 201m

(Ø = 16m)

max 177m

(Ø = 15m)

max 133m

(Ø = 13m)

max 113m

(Ø = 12m)

A: Tangential movement

Tangential: max. 24m

h = max.15m

B: Radial movement

Radial: max. 16m

h = max.15m

HBIR30/CA/H: High-bay lens detection pattern for forklift @ Ta = 20ºC

(Recommended ceiling mount installation height 10m-15m)

Optional Accessory --- Ceiling/Surface Mount Box: HA03

Optional Accessory --- Blind Insert for Blocking Certain Detection Angles

Valid Range Valid Range

Radial (B)

Tangential (A)

2.5m

Mount height

11m

12m

10m

6m max 104m

(Ø = 11.5m)

max 50m

(Ø = 8m)

max 154m

(Ø = 14m)

max 227m

(Ø = 17m)

max 269m

(Ø = 18.5m)

max 314m

(Ø = 20m)

max 7m

(Ø = 3m)

max 7m

(Ø = 3m)

max 7m

(Ø = 3m)

max 7m

(Ø = 3m)

max 7m² (Ø = 3m)

A: Tangential movement B: Radial movement

HBIR30/CA/H: High-bay lens detection pattern for single person @ Ta = 20ºC

(Recommended ceiling mount installation height 2.5m-12m)

insensitive sensitive insensitive sensitive

Ø 94

4.2

HBIR30/CA-20210811-A0

Subject to change without notice.

Radial (B)

Tangential (A)

10m

Mount height

14m

15m

13m

12m

11m

max 907m

(Ø = 34m)

max 962m

(Ø = 35m)

max 1075m

(Ø = 37m)

max 660m

(Ø = 29m)

max 346m

(Ø = 21m)

max 1256m

(Ø = 40m)

max 154m

(Ø = 14m)

max 177m

(Ø = 15m)

max 177m

(Ø = 15m)

max 154m

(Ø = 14m)

max 113m

(Ø = 12m)

max 113m

(Ø = 12m)

A: Tangential movement

Tangential: max. 40m

h = max.15m

B: Radial movement

HBIR30/CA/RH: Reinforced high-bay lens detection pattern for forklift @ Ta = 20ºC

(Recommended ceiling mount installation height 10m-15m)

Radial: max. 15m

h = max.15m

Optional Accessory --- Ceiling/Surface Mount Box: HA03

4. HBIR30/CA/RH (Reinforced High-bay with 3-Pyro)

Tangential: max. 30m

h = max.12m

Radial: max. 4m

h = max.12m

Radial (B)

Tangential (A)

2.5m

Mount height

11m

12m

10m

6m max 154m

(Ø = 14m)

max 38m

(Ø = 7m)

max 314m

(Ø = 20m)

max 531m

(Ø = 26m)

max 615m

(Ø = 28m)

max 707m

(Ø = 30m)

max 7m

(Ø = 3m)

max 7m

(Ø = 3m)

max 7m

(Ø = 3m)

max 13m

(Ø = 4m)

max 13m

(Ø = 4m)

max 13m

(Ø = 4m)

A: Tangential movement B: Radial movement

HBIR30/CA/RH: Reinforced high-bay lens detection pattern for single person @ Ta = 20OC

(Recommended ceiling mount installation height 2.5m-12m)

insensitive sensitive insensitive sensitive

Ø 94

4.2

Wire Preparation

Pluggable screw terminal. It is recommended to make

connections to the terminal before ﬁtting to the sensor.

0.75 - 2.5mm

7-8mm

HBIR30/CA-20210811-A0

Subject to change without notice.

5. Additional Information / Documents

Wiring Diagram

P N L

Casambi Bluetooth

device

HBIR30/CA

1. To learn more about detailed product features/functions, please refer to www.hytronik.com/download ->knowledge ->Introduction of App Scenes and Product Functions

2. Regarding precautions for PIR Sensors installation and operation, please kindly refer to www.hytronik.com/download ->knowledge ->PIR Sensors - Precautions for Product Installation and Operation

3. Data sheet is subject to change without notice. Please always refer to the most recent release on www.hytronik.com/products/bluetooth technology ->Partnership

4. Regarding Hytronik standard guarantee policy, please refer to www.hytronik.com/download ->knowledge ->Hytronik Standard Guarantee Policy
