Husky HOAA52B11 Manuel utilisateur

THANK YOU

USE AND CARE GUIDE

Questions, problems, missing parts?

Before returning to the store, call

Husky Customer Service

8 a.m. - 7 p.m., EST, Monday-Friday,

1-888-HD-HUSKY

HUSKYTOOLS.COM

We appreciate the trust and confidence you have placed in Husky through the purchase of this pegboard. We strive to continually

create quality products designed to enhance your home. Visit us online to see our full line of products available for your home

improvement needs. Thank you for choosing Husky!

Model # HOAA52JX1

HUSKY 52-72 IN. ADJUSTABLE PEGBOARD

THD.com # 1006 250 269

9 a.m. - 6 p.m., EST, Saturday

Model # HOAA52B11

THD.com # 100X XXX XXX

Table of Contents

Table of Contents ...................................................... 2

Safety Information

........................................................ 2

Warranty ........................................................................ 3

Pre-Assembly

.......................................................

Assembly ................................................................

Operation .....................................................................

Safety Information

Do not alter this product in any manner.

DANGER: Do not stand on this product. You

may fall or cause the product to tip.

WARNING: When assembled to a workbench, keep

the unit on a level surface. The unit may become unstable

and tip if stored or moved on an uneven surface.

CAUTION: Do not exceed the maximum

weight loading capacity. See Specifications on page 4.

CAUTION: Only transport this product when

empty. Properly secure when transporting.

Do not let children approach the product.

Care and Cleaning

.......................................................

Service Parts

.......................................................................

Tools Required .............................................................. 4

Hardware Included .......................................................

Specifications ................................................................ 4

Package Contents

................................................

6-7

2

Warranty

The manufacturer warrants the product to be free from defects in materials and workmanship for a period of three (3) years from date of

purchase. This warranty applies only to the original consumer and only to products used in normal use and service. If this product is

found to be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the product at the

manufacturer’s discretion, provided that the product has not been damaged through misuse, abuse, accident, modifications, alteration

neglect or mishandling. This warranty shall not apply to any product that is found to have been improperly installed, set-up, or used in

any way not in accordance with the instructions supplied with the product. This warranty shall not apply to a failure of the product

as a result of an accident, misuse, abuse, negligence, alteration, faulty installation, or any other failure not relating to faulty material or

workmanship. This warranty shall not apply to the finish on any portion of the products such as surface and/or weathering, as this is

considered normal wear and tear.

The manufacturer does not warrant and specifically disclaims any warranty, whether express or implied, of fitness for a particular purpose,

other than the warranty contained herein. The manufacturer specifically disclaims any liability and shall not be liable for any consequential

or incidental loss or damage, including but not limited to any labor/expense costs involved in the replacement or repair of said product.

Contact the Customer Service Team at 1-888-HD-HUSKY or visit www.huskytools.com.

HUSKYTOOLS.COM

Please contact 1-888-HD-HUSKY for further assistance.

3

Pre-assembly

TOOLS REQUIRED

Safety

goggles

HARDWARE INCLUDED

SPECIFICATIONS

Screw M4 x 10L 8

AA BB

Maximum capacity 150 lbs

4

NOTE: Hardware not shown to actual size.

Part Description Quantity

Phillips

screwdriver

Power

drill

CC DD

Screw M6 x 12L

Bolt 1/4" x 3/4"

10 mm/13 mm wrench

10 mm.

socket

1/8 in.

drill bit

Pre-assembly (continued)

HUSKYTOOLS.COM

PACKAGE CONTENTS

5

Please contact 1-888-HD-HUSKY for further assistance.

Part Description Quantity

A Left pegboard panel 1

B Right pegboard panel 1

C Middle Pegboard panel 1

D Reinforcement panel 1

E Left Support post 1

F Right Support post 1

Assembly

Mounting the Pegboard to

Place the right support post (F) on the back of the mobile

Attach the right support post (F) to the back of the mobile

Attach the left pegboard panel (A) to the left support post (E)

6



6

WARNING: Use special care to not over-tighten any of the

but do not tighten at this time.

Insert the middle pegboard panel (C) to the left pegboard (A)

Husky Mobile Workbench

screws to avoid damage to the pegboard or mobile workbench.

workbench. Ensure the support post is flush and level.

workbench using four screws (BB).

using four screws (BB). Secure the pegboard to the post,

and push it to the deepest position.

Repeat step 1 for left support post (E) .

Attach the right pegboard panel (B) to the right support post (F)

but do not tighten at this time.

using four screws (BB). Secure the pegboard to the post,

Pull the middle pegboard panel (C) back to middle position.

Assembly ( )continued

7

Secure the three panels to each other by using four screws (AA)

Attach the reinforcement panel (D) to the middle pegboard panel

Repeat step 9 to drill four holes for the other support post (E).

to the front side of panels first and four on the top of panels.

10.

HUSKYTOOLS.COM

Please contact 1-888-HD-HUSKY for further assistance.

Using a power drill and 1/8 in. drill bit, drill four holes into the

3/4 in. depth into the wood top to avoid damage to the mobile

sides and back of the wood top of the workbench on right

support post (F). Ensure you drill on a level plane and only

workbench.

and two holes for panel (D) .

11. Secure the right support post (F) to the back of the mobile

Secure the post but do not tighten the screws at this

Repeat step 11 to attach the left support post (E) and using two

workbench using four bolts (CC) and a 10 mm socket.

time so that the support post has some movement.

12.

bolts (CC) to attach the reinforcement panel (D) .

Tighten all screws at this step.

13.

8

□

Care and Cleaning

(Windex or equivalent product) to clean and maintain

To help protect this finish, do not allow harsh chemicals such as

oil or grease to remain on the surface. Use a glass cleaner

all stainless surfaces.

Operation

The peg holes will accommodate all standard size 1/8 in. and 1/4 in.

peg hooks.

Service Parts

9

HUSKYTOOLS.COM

Please contact 1-888-HD-HUSKY for further assistance.

Part Description Quantity

A Left pegboard panel 1

B Right pegboard panel 1

C Middle Pegboard panel 1

D Panel Reinforcement 1

E Left Support post 1

F Right Support post 1

Questions, problems, missing parts? Before returning to the store, call

Husky Customer Service

8 a.m.-7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m. EST Saturday

1-888-HD-HUSKY

HUSKYTOOLS.COM

Retain this manual for future use.
