6
Installation and
Operating Instructions
FAN WILL NOT START
check main circuitbreakers
check wire connectionsto the fan
check speed controllerposition
push reversing switchfully up ordown
Please Read Before Calling for Warranty
To Licensed Installers and Fan owners
FAN SOUNDS NOISY
Check suggested bulb(s)in light kit
Re-tighten all screwson fan bladesbut never
over tighten
Retighten all screwsin the hangingbracket
or plate
Change the controllerto the onesupplied.
MECHANICAL NOISE
allow for atleast 8 hourssettling in time
FAN MOVES BUT DOES NOT MOVE MUCH
AIR
the fan maybe running inreverse
the distance betweenthe ceiling andthe fan
blades maybe toosmall
The room maycontain item whichobstruct
the air flow.
The fan maybe too smallfor the sizeof the
room.
POINTS AT AGLANCE
All electronic motors, including fan motors
make some noise and may feel hot to touch this
is NOT a fault.
Ceiling fans tend to move during operation due
to the fact that they are not generally rigidly
mounted - if they were they could generate
excessive ceiling vibration and stress on the
mountings. Movement of a couple of
centimetres is quite ok and does not suggests
that the fan will fall down.
Ceiling fans are mounted securely on steel
brackets with rubber cushioning or with ball
joints to allow free movement. Please Note -
all ceiling fans are not the same even in the same
model - some may move more than others .
Fan lights can rattle, if they are not supplied with
the fan in the box they are not covered by
warranty.
REVERSING SWITCH
Switch should bein the downposition for summer
(anticlockwise) and inthe up positionfor winter
(clockwise)(fig 11)
FAN OPERATION
A ceilingfan is anenvironmentally smart choice
to cool aswell as helpwarm your room.You
should see areduction in bothcooling and
heating costs byregular use ofyour fans. Donot
hesitate to useyour fans inboth the summerand
winter months. Insummer place thereverse
switch in thedown position (fanshould spin in
an anti clockwisedirection) so coolair is
blowing down producinga cool breeze.
In winter,reverse the switch(fan should spinin a
clock wise direction)so that anupward airflow
will push warmair off the ceiling andcirculate it
downwards into theliving areas. Inthe winter
months use thefan at alower speed thanin
summer.
NORMAL WEAR AND TEAR
Threaded components workingsightly loose or
blade carriers evenslightly bent duringto
vigorous cleaning orbumping can causeextra
wobble and noise.This is not covered under
warranty but alittle care andmaintenance can
reduce or preventthis problem.
Warning: Do not attempt to control the operation of the fan ( or optional light kit ) from any wall
control that is not approved by Hunter Pacific International for use with the fans. Do not use solid state
wall controllers. The use of an unapproved wall control voids the warranty.
Warning : Do not mix blade sets from one fan to another. If only oneblade is damaged you are still
required to replace with a complete new set.
Reversing
Switch
Typhoon Timber 42" 122cm
