Hughes HT2000W Manuel utilisateur



HT2000W Wi-Fi Module

User Manual

H57555

Revision A

November 4, 2016

11717 Exploration Lane, Germantown, MD 20876

Phone (301) 428-5500 Fax (301) 428-1868/2830



Allrightsreserved.ThispublicationanditscontentsareproprietarytoHughesNetworkSystems,

LLC.Nopartofthispublicationmaybereproducedinanyformorbyanymeanswithoutthe

writtenpermissionofHughesNetworkSystems,LLC,11717ExplorationLane,Germantown,

Maryland20876.

HughesNetworkSystems,LLChasmadeeveryefforttoensurethecorrectnessand

completenessofthematerialinthisdocument.HughesNetworkSystems,LLCshallnotbeliable

forerrorscontainedherein.Theinformationinthisdocumentissubjecttochangewithout

notice.HughesNetworkSystems,LLCmakesnowarrantyofanykindwithregardtothis

material,including,butnotlimitedto,theimpliedwarrantiesofmerchantabilityandfitnessfor

aparticularpurpose.



Trademarks

HUGHESandHughesNetworkSystemsaretrademarksofHughesNetworkSystems,LLC.All

othertrademarksarethepropertyoftheirrespectiveowners.



User Manual

H57555 Revision A 3

Overview

EthernetSwitch:QualcommQCA8337

2.4GHzModule:QCA9563

5GHzModule:QCA9882

AntennaInterface:3xU.FLPCBAntennafor2.4GHz,2xU.FLPCBAntennafor5GHz

I/OInterface:MDI

Features

DualBandWi‐FiAccessPoint

2.4GHz:IEEE802.11N,B,G

50Mbpsminimumatanunobstructeddistanceof20feet

20Mbpsminimumatarangeof50metershorizontaland15metersvertical

Maxpowerof23dBm

5GHz:IEEE802.11A,N,AC

200Mbpsminimumatanunobstructeddistanceof20feet

50Mbpsminimumatarangeof50metershorizontaland15metersvertical

Maxpowerof20dBm



4 User Manual

H57555 Revision A

Compliance information

FCCCaution:Anychangesormodificationsnotexpresslyapprovedbytheparty

responsibleforcompliancecouldvoidtheuser’sauthoritytooperatethis

equipment.

ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothe

followingtwoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)

thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay

causeundesiredoperation.

ForproductavailableintheUSA/Canadamarket,onlychannel1~11canbe

operated.Selectionofotherchannelsisnotpossible.

Thisdeviceisrestrictedforindooruse.

IMPORTANTNOTE:

FCCRadiationExposureStatement:

ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforan

uncontrolledenvironment.Thisequipmentshouldbeinstalledandoperatedwith

minimumdistance20cmbetweentheradiator&yourbody.

IMPORTANTNOTE:

ThismoduleisintendedforOEMintegratoronlyandlimitedtohostwithbrand:

HUGHESandmodel:HT2000W.TheOEMintegratorisstillresponsiblefortheFCC

compliancerequirementoftheendproduct,whichintegratesthismodule.

USERSMANUALOFTHEENDPRODUCT:

Intheuser’smanualoftheendproduct,theenduserhastobeinformedtokeepat

least20cmseparationwiththeantennawhilethisendproductisinstalledand

operated.TheenduserhastobeinformedthattheFCCradio‐frequencyexposure

guidelinesforanuncontrolledenvironmentcanbesatisfied.

Theenduserhastoalsobeinformedthatanychangesormodificationsnot

expresslyapprovedbythemanufacturercouldvoidtheuser'sauthoritytooperate

thisequipment.

LABELOFTHEENDPRODUCT:

Thefinalendproductmustbelabeledinavisibleareawiththefollowing:"Contains

TXFCCID:RAXHT2000W".

TheFCCpart15.19statementbelowhastoalsobeavailableonthelabel:This

devicecomplieswithPart15ofFCCrules.Operationissubjecttothefollowingtwo

conditions:(1)thisdevicemaynotcauseharmfulinterferenceand(2)thisdevice

mustacceptanyinterferencereceived,includinginterferencethatmaycause

undesiredoperation.



User Manual

H57555 Revision A 5



Gain(dBi)

SetAntBrandModelNumberAntennaTypeConnector

2.4GHz5GHz

1YageoANTA0ZZ10511WLAN1PCBI‐PEX3.2

2YageoANTA0ZZ10511WLAN2PCBI‐PEX3.69

3YageoANTA0ZZ10511WLAN3PCBI‐PEX3.6

4YageoANTA0ZZ10511WLAN4PCBI‐PEX 3.9

1

5YageoANTA0ZZ10511WLAN5PCBI‐PEX 3.1

6AirgainN24011HU‐T6L‐PK1‐G165UPCBI‐PEX3.2

7AirgainN24011HU1‐T6L‐PK1‐B90UPCBI‐PEX1.8

8AirgainN24011HUN1‐T6L‐PK1‐W125UPCBI‐PEX1.6

9AirgainN5X011HU2‐T6L‐PK1‐A45UPCBI‐PEX 4.4

2

10AirgainN5X011HU1‐T6L‐PK1‐R120UPCBI‐PEX 4.0

Figure1:Antennalist
