Huawei DC04 Manuel utilisateur

1

Thank you for purchasing the DC04. This DC04 brings you

a high speed wireless network connection.

This document will help you understand your DC04 so you can start using it right away. Please

read this document carefully before using your DC04.

For detailed instructions for logging in to the web management page, refer to "Logging In to

the Web Management Page" on page 14.

2

Getting to Know Your DC04

Note:

The DC04 function descriptions and illustrations in this document are for your reference

only. The product you have purchased may vary.

Application Scenarios

Wi-Fi devices (such as smartphones, tablet computers, and game consoles) or computers can

all access the Internet through DC04. The specific connection procedure depends on the

operating system of the Wi-Fi device or computer. Establish a connection according to your

device's specific instructions.

To access the Internet through a USB port connection, install the driver according to the

instructions.

3

Scenario 1: Connecting multiple devices

through Wi-Fi

Scenario 2: Connecting multiple devices

through Wi-Fi and USB simultaneously

4

Appearance

2

1

3

4

Power button Lanyard hole

Screen Micro USB port

5

Screen

Status bar

Character zone

When connect to 3G/LTE network, show the operator name

When connect to public Wi-Fi hotspot, show the SSID name of the hotspot

When SIM card is not normal, show "PIN1 code required"/"PIN unlock code required";

Data usage information

6

If user set the data information, show used data and total data.If user turn off the display of

data on Home screen, hide this zone.

Power save settings

usercantapontoviewinformationof“Powersavesettings”.

Wi-Fi connection guide

usercantapontoviewinformationof"Wi‐Ficonnectionguide".

SSID&password

usercantapontosetdataof“Chargingfunction”.

About

usercantapontoviewdeviceinformation.

Public WLAN

usercantapontoviewinformationof“PublicWLANsetting”.

Menu

usercantapontoviewmorefunctions.

7

Signal icon

R: when in roaming status; Show network mode, including "3G/LTE".

: when connecting to public Wi-Fi hotspot.

Icon of traffic.

Show the icon when connect to network. When there is upload and download data the icon

changes color. When disconnect from network, hide the icon.

Time information

Wi-Fi

8

Wi-Fi turned on.

Number of connected Wi-Fi devices.

Wi-Fi Mode

DFS

When DC04 is during DFS checking progress, the DFS icon show and flashes. When DC04

connect to the 5G_W52/W53 network that can be only used indoor only, show this icon.

Otherwise hide the icon.

USB

Show it when connected to USB cable and DC04 supports Charging with standard functions

process. If connected to USB cable only for charging, hide this icon.

Battery

: Battery level from low to high.

Overheating

Ifthedevice’stemperatureisoverheatingin[48,54)degreeandconnecttonetwork,show

9

theicon.

% of current battery.

⓫Flying mode

Ifthedevice’stemperatureisin[54,58)degree,showtheicon.

10

SSID and Wireless Network Encryption Key

When a Wi-Fi device establishes a connection to the DC04 for the first time, you may need to

enter the default Service Set Identifier (SSID) and wireless network encryption key. These are

printed on the DC04.

To view the current SSID and wireless network encryption key on the screen:

1. Press the Menu>SSID&password on

the homepage.

2. The SSID and Password display on the

screen.
