Huawei ELTE2.2 eA660 Series Caractéristiques techniques

eLTE2.2 eA660 Series CPEs

Product Description

Date

2013-07-18

HUAWEI TECHNOLOGIES CO., LTD.

Issue Draft A (2013-04-30)

Huawei Proprietary and Confidential

Page 2 of 18

No part of this document may be reproduced or transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The purchased products, services and features are stipulated by the contract made between Huawei and

the customer. All or part of the products, services and features described in this document may not be

within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,

information, and recommendations in this document are provided "AS IS" without warranties, guarantees or

representations of any kind, either express or implied.

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute a warranty of any kind, express or implied.

Huawei Technologies Co., Ltd.

Address:

Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website:

http://www.huawei.com

Email:

[email protected]

eLTE2.2 eA660 Series CPEs

Product Description

Issue Draft A (2013-04-30)

Huawei Proprietary and Confidential

Page 3 of 18

Contents

1 Product Overview .........................................................................................................................4

2 Application Scenarios ..................................................................................................................6

3 Technical Specifications ..............................................................................................................8

3.1 Hardware..........................................................................................................................................................8

3.2 Software .........................................................................................................................................................10

3.3 User Interfaces ...............................................................................................................................................12

4 Services and Applications .........................................................................................................14

5 Adopted Standards .....................................................................................................................15

6 Packing List ..................................................................................................................................16

7 Acronyms and Abbreviations...................................................................................................17

eLTE2.2 eA660 Series CPEs

Product Description

Issue Draft A (2013-04-30)

Huawei Proprietary and Confidential

Page 4 of 18

1 Product Overview

Introduction

The Huawei eA660 Series CPEs are the Long Term Evolution (LTE) customer premises

equipments (CPEs). As a wireless gateway, the eA660s can be deployed outdoors to provide

services such as data collection and video surveillance.

The eA660 Series CPEs (eA660-160 and eA660-135, eA660s for short) supports LTE Release

8. The eA660s provide the following functions:

Data services

Security services

Local maintenance and management

Data routing

Product Features

The eA660s are developed based on the Software Development Platform (SDP). It supports

LTE and quick customization. The eA660's main features are as follows:

Compatible with 2.3 GHz(B40), 2.6 GHz(B38) 3.5GHz(B42) and 3.5 GHz(B43) LTE

Time-Division Duplex (TDD) networks; supports customization of different frequency

bands

High-speed data services

Dynamic Host Configuration Protocol (DHCP) and Network Address Translation (NAT)

that provide high-speed routing service

IEEE 802.11 b/g/n WLAN(unavailable when LTE works at band 40)

Routing behind MS

Firewall functions

Web-based configuration utility that has an intuitive user interface

Device management that supports TR-069

Intuitive LED indicators, for easy identification of the device status

Built-in high-gain antennas that improve product performance and make the device easy

to carry

Provide external antennas ports and the antennas path can be configured via TR069 or

WEBUI.

eLTE2.2 eA660 Series CPEs

Product Description

Issue Draft A (2013-04-30)

Huawei Proprietary and Confidential

Page 5 of 18

Surge protection in outdoor environments

Anti-shock capabilities that meet the IEC61373 (railway) and MIL-STD-810F (USA

military) standards

Shell protection that meets the IP67 standard

Appearance

Figure 1-1 Appearance of eA660s

eLTE2.2 eA660 Series CPEs

Product Description

Issue Draft A (2013-04-30)

Huawei Proprietary and Confidential

Page 6 of 18

2 Application Scenarios

The eA660s provide wireless broadband and wired Ethernet data services.

The eA660 is deployed outdoors and provides wireless gateway services. The eA660 can be

deployed independently.

The eA660s provide a variety of data services, such as LTE-TDD wireless routing and

converting LTE wireless data into wired Ethernet data, and vice versa.

Figure 2-1 The eA660s deployed in industrial private networks

1. The power adapter is provided to supply power to the eA660s or devices such as a video

camera.

Figure 2-2shows an application scenario where eA660s being connected to a video

camera.

eLTE2.2 eA660 Series CPEs

Product Description

Issue Draft A (2013-04-30)

Huawei Proprietary and Confidential

Page 7 of 18

Figure 2-2 The eA660s connected to a video camera.

2. The eA660s are connected to other devices using the network cable. A single device,

such as a camera or a Remote Terminal Unit (RTU), can connect to the eA660s using the

power adapter. Multiple devices can connect to the eA660s simultaneously using a hub

or switch.

Figure 2-3 shows an application scenario where eA660s being connected to multiple

devices.

Figure 2-3 The eA660s connected to multiple devices

eLTE2.2 eA660 Series CPEs

Product Description

Issue Draft A (2013-04-30)

Huawei Proprietary and Confidential

Page 8 of 18

3 Technical Specifications

3.1 Hardware

Table 3-1 Technical specifications of eA660s

Category

Description

Receiving

sensitivity

LTE

eA660-160& eA660-135

< -100 dBm/5 MHz（eA660-160 only）

< -97 dBm/10 MHz

< -94 dBm/20 MHz

WLAN

-64 dBm@65Mbit/s, typical for 802.11n

-65 dBm@54Mbit/s, typical for 802.11g

-76 dBm@11Mbit/s, typical for 802.11b

Power

consumption

<25W

Power supply

POE comply with IEEE802.3at

Dimensions

(W×D×H)

280 mm x 250 mm x 90 mm

Weight

About 1.5kg (The power supply adapter is not included)

Water and dust

proof

IP67

Temperature

Working temperature: -40℃~ +65℃

Storage temperature: -40℃~ +70℃

Humidity

5% ~ 95%

Installation

Mounted on poles or walls

(WLAN unavailable when LTE works at band 40)

Table 3-2 eA660s LTE antenna specifications

Item

eA660-160

eA660–135

Band

2300 MHz to 2400 MHz (LTE

Band 40)

2570 MHz to 2620 MHz (LTE

Band 38)

3400 MHz to 3600 MHz (LTE

Band 42)

3600 MHz to 3800 MHz (LTE

Band 43)

Gain

13 dBi

16 dBi

Input impedance

50 ohm

SWR

< 2

Polarization

Dual polarization

Radiation pattern

Directional antenna

eLTE2.2 eA660 Series CPEs

Product Description

Issue Draft A (2013-04-30)

Huawei Proprietary and Confidential

Page 10 of 18

Table 3-3 WLAN antenna specifications

Item

Description

Frequency

2.4 GHz ~ 2.483 GHz

Input

impedance

50 Ω

Standing

wave ratio

< 3

efficiency

≥50%

Gain

≥3dBi

Polarization

Linear polarization

3.2 Software

Table 3-4 Software specifications

Item

Description

Gateway

Router: The default routing address is 0.0.0.0. The default routing table

items can be generated accordingly.

Supports Address Resolution Protocol (ARP)

Supports domain name service (DNS)

Supports Internet Control Message Protocol (ICMP)

NAT

Supports Network Address Translation (NAT) and Network Address

Port Translation (NAPT). (Compatible with

RFC2663/RFC3022/RFC3027)

Supports fragment message identification for normal NAT

Supports NAT traverse

DHCP server

The default DHCP server address ranges from 192.168.1.2 to

192.168.1.254. The default gateway address is 192.168.1.1.

The default DHCP lease is 24 hours.

The DHCP server can be enabled or disabled.

The DHCP server's address pool can be configured.

The DHCP lease can be configured.

IP address status such as the hostname, Media Access Control (MAC)

address, IP address, and remaining DHCP lease can be displayed.

Supports static IP address reservation
