Huawei AP Series Manuel utilisateur

AP Series Outdoor Wireless LAN Access Points

Quick Start Guide

No part of this document may be reproduced or transmitted in any form or by any means without prior written

consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective holders.

Notice

The purchased products, services and features are stipulated by the contract made between Huawei and the

customer. All or part of the products, services and features described in this document may not be within the

purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,

and recommendations in this document are provided "AS IS" without warranties, guarantees or

representations of any kind, either express or implied.

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute the warranty of any kind, express or implied.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People‟s Republic of China

Website: http://enterprise.huawei.com

Preface

This document describes the hardware configuration, installation preparation, installation method, installation

procedure, cable connection, and procedure for logging in to the outdoor APs.

The preface is organized as follows:

•Intended Audience

•Symbol Conventions

•Documentation Obtaining

•Technical Support

Symbol Conventions

The symbols that may be found in this document are defined as follows:

Intended Audience

This document is intended for:

•Hardware installation engineers

•Onsite maintenance engineers

•Network administrators configuring and maintaining the network

Symbol

Description

Indicates a hazard with a high level or medium level of risk which, if not

avoided, could result in death or serious injury.

Indicates a hazard with a low level of risk which, if not avoided, could result in

minor or moderate injury.

Indicates a potentially hazardous situation that, if not avoided, could result in

equipment damage, data loss, performance deterioration, or unanticipated

results.

Provides a tip that may help you solve a problem or save time.

Provides additional information to emphasize or supplement important points

of the main text.

Documentation Obtaining

You can visit http://enterprise.huawei.com to obtain the latest product documentations. Choose Support >

Product Support > Enterprise Networking > WLAN > AP, and then select the document of a specified

product.

You can select the document as required. For example, if you want to obtain AP6610DN-AGN documents,

select AP6610DN-AGN.

NOTE

Technical Support

If you have trouble in locating or rectifying faults during maintenance or troubleshooting by following

instructions in this document, contact the Huawei customer service center (CSC) for help.

You can also visit http://enterprise.huawei.com, click Contact Us in the lower area of the page, and select the

country to obtain contact information about Huawei local office.

Change History

Changes between document issues are cumulative. Therefore, the latest document issue contains all the

changes in previous issues.

Changes in Issue 02 (2013-01-30)

This version has the following updates:

The following information is added:

FCC compliance and sales regions of AP products

Change in Issue 01 (2012-10-31)

Initial commercial release.

Device Introduction

The Huawei AP series outdoor wireless LAN access point provides two models: AP6510DN-AGN,

AP6610DN-AGN. The outdoor AP supports 2.4GHz and 5 GHz frequency bands, and has enhanced

coverage performance and protection capabilities. It supports wireless bridging, complies with IEEE

802.11a/b/g/n, connects a large number of users, and works as a Fit AP. The outdoor AP features high

reliability, high security, simple network deployment, automatic AC discovery and configuration, and

real-time management and maintenance.

The APs are recommended for use in residential or commercial properties without wired resources. The

APs can be deployed at both ends of a commercial street or in the building opposite to a commercial

property. The APs must be equipped with external antennas to implement wireless signal coverage.

Different outdoor AP models are sold in different regions depending on whether the APs have passed

the FCC certification.

Table 1 FCC compliance and sales regions of AP products

Passed FCC

Certification

Product Model

Sales Region

AP6510DN-AGN

All regions except

Japan and

regions that

require FCC

certification

AP6610DN-AGN

Yes

AP6510DN-AGN-US

Regions that

require FCC

certification

(except the U.S)

AP6510DN-AGN-USA

U.S

AP6610DN-AGN-US

Regions that

require FCC

certification

(except the U.S)

AP6610DN-AGN-USA

U.S

The AP products sold in the U.S have a fixed country code US, and the country code change function

is disabled.

The AP6510DN-AGN, AP6510DN-AGN-US, and AP6510DN-AGN-USA have the same specifications

and are installed in the same way. This document collectively calls the three models AP6510DN-AGN.

The AP6610DN-AGN, AP6610DN-AGN-US, and AP6610DN-AGN-USA have the same specifications

and are installed in the same way. This document collectively calls the three models AP6610DN-AGN.

NOTE

Device Introduction

Table 2 lists the dimensions and weights of outdoor APs.

Table 2 Dimensions and weight

Model

Dimensions

Weight

AP6510DN-AGN

255mm×255mm×83mm（W×D×H）

2.2kg

AP6610DN-AGN

255mm×255mm×83mm（W×D×H）

2.65kg

Table 3 Interfaces on outdoor APs

AP6510DN-AGN

5 5 6 6

1 2

AP6610DN-AGN

Device Introduction

No.

Name

Description

ETH port

(ETH/PoE port)

Connected to a switch or PD.

Default

Press and hold down the Reset button for 3 seconds to restore the

factory settings and restart the AP.

SFP port

Connected to fiber. An optical module is required.

AC power port

Connected to an AC power module.

2.4 GHz

antenna port

A port connected to the 2.4 GHz antenna.

5 GHz

antenna port

A port connected to the 5 GHz antenna.

Ground screw

Connect the ground cable to the AP with a ground screw.

Table 3 Interfaces on outdoor APs

Table 4 Interfaces on outdoor APs

1 2

5 5 6 6

4 7

Installation Preparations

1. Safety Precautions

2. Installation Environment Check

Before installation, verify that the device runs in a favorable environment.

The table lists requirements on the environment that a device works in, including the temperature,

humidity, altitude, and pressure.

Table 5 Requirements on the environment

Only the qualified personnel are permitted to install and remove the device and its accessories.

Before installation and operation, read the safety precautions carefully.

Take proper measures to prevent injuries and device damage.

Place the device in a dry and flat position away from any liquid and prevent the device from

slipping.

Keep the device clean.

Do not put the device and tools in the aisles.

Item

Range

Operating temperature

AP6510DN-AGN: -40℃～60℃

AP6610DN-AGN: -40℃～60℃

Storage temperature

AP6510DN-AGN: -40℃～70℃

AP6610DN-AGN: -40℃～70℃

Relative humidity

0% to 100%

Altitude

-60 m to +4000 m

Pressure

70 kPa to 106 kPa

WARNING

Installation Preparations

3. Device Accessories

The following accessories are delivered together with outdoor APs:

4. Installation Tools

To install outdoor APs, prepare the following tools:

Phillips screwdriver Flat-head screwdriver

Utility knife

Wire stripper

Network cable tester Multimeter

Adjustable wrench

Maker

RJ45 crimping toolDiagonal pliers

Ladder

COAX crimping tool

Hammer drill

Hammer

ESD gloves Level 8mm drill bit

M4x12 hexagon

socket head cap screw

Installation suite Hose clamp Expansion bolt

Hex key
