Huawei E5 Manuel utilisateur

Wi-Fi Router Huawei E5

User Guide

Content

•Modem Description

•Specification

•SW installation guide

•User manual

•Troubleshooting

•Terms

Modem Description

Huawei E5830 HSDPA Wifi-router and a USB modem combined in one

device (hereinafter ‘Е5’) that supports 3G and allows users to access

the Internet and send/receive short text messages direct from their PC

or multimedia devices connected to the Е5 through WiFi.

The modem is connected to the USB port on the computer or through a

WiFi connection. The MicroSD slot allows using the modem both as

external storage and file depot.

Modem Description

The E5 support the following standards:

•High-Speed Downlink Packet Access (HSDPA)

•High-Speed Uplink PacketAccess (HSUPA)

•UniversalMobile TelecommunicationsSystem (UMTS)

•Enhanced Data Rates for GSM Evolution (EDGE)

•General Packet Radio Service (GPRS)

•Global System for Mobile communications (GSM)

The E5 supports:

•HSDPA/UMTS data service

•EDGE/GPRS data service

•WCDMA/GSM short message service

•The E5 supports Plug and play (PnP), i.e. there is not need to have

setup disks as the device is installed automatically.

•USB (2.0) standard connector

•Supports up to 32GB memory. Insert a memory card to use the

modem as an external storage.

•Wi-Fi 802.11.b/g, encoding type WEP, WPA, WPA2

•OS supported Windows 2000/ Windows XP/ Windows Vista/

Windows7/ Mac OS X 10.4 and higher

Modem Description

Content

•Modem Description

•Specification

•SW installation guide

•User manual

•Troubleshooting

•Terms

Standard

WCDMA/HSDPA

GSM/GPRS/EDGE

R99

Data rate

HSUPA 5.76Mbps;

HSDPA 7.2Mbps

EDGE

–236.8

Kbps

Indication

OLED display

Dimensions

(L х W х H)

95 mm

×48 mm ×13

Weight

<90g

Temperature

Operating

temperature

10°;+45°

Storage temperature

–

20°;+70°

Humidity

-95%

System

requirements

CPU: Pentium4, 1 GHz or above

Memory: 128 MB RAM or above

Hard Disk: 50 MB or above

Operating System : Windows

2000/ХР/Vista/7, Mac OS X10.4 and

10.5 with latest updates

USB Modem Interface: USB2.0 high

speed

Display Resolution: 800 x 600 or above

(1024 x 768 is recommended)

Specification

Main Features

Kcell Connect features

SMS

Sending / receiving short text messages.

Sending long messages

Copying SMS from SIM card and vice versa

Visual notification of new and unread messages

Sending / receiving short text messages

SD card

Editing SD card content.

Direct connection as external storage.

Access to files on the SD card through Wi

-Fi

USSD

Sending / receiving USSD commands

Specification

Data transmission

•

Enabling / disabling data transmission

(Internet).

•

Creating, editing, removing user’s connection

settings (APN). Data transmission is enabled

automatically.

•

Automatic data transmission is enabled by

default.

SW installation

Automatic SW installation when connected to PC

(Plug and Play)

Other

Network settings:

•

Automatic registration mode

•

Manual registration mode

Status: network signal strength, operator, mode

Specification

Kcell Connect features

Status indicator

Signal indicator

•

Network type –2G

•

Network type –3G

•

Wi-Fi indicator

•

Number of connections

Connection status

•

New SMS

•

Number of new SMS

Battery indicator

Roaming indicator

•

Automatic mode

•

Manual mode
