Huawei RT-8LS Manuel utilisateur

Quidway® AR 28 Series 100 M Ethernet Line Module

Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved. 1

http://datacomm.huawei.com

Quidway® AR 28 Series 100 M Ethernet Line Module

Overview

The 10/100 M Ethernet electrical interface module and 100 M Ethernet optical interface module of

the AR28 router provide Fast Ethernet (FE) electrical and optical interfaces respectively, mainly for

communicating with the router and LAN.

At present, the AR28 router has two ordinary 10/100 M Ethernet electrical interface modules: 1-port

fast interface module and 2-port fast interface module (not supported by AR281* and AR2809/B

modules). It also has two optical interface modules: 1-port fast single-mode optical interface

module and 1-port fast multi-mode optical interface module.

Moreover, the AR28 router has a particular 8-port Ethernet layer-2 switching module. This module

is mainly used to implement the layer-2 switching function. Up to eight 10/100 Base-Tx Ethernet

ports can be provided on the router. It is applicable to the small-sized enterprise network, serving as

the switching/routing integrated equipment. It is connected with the PC and network device in the

enterprise directly, lowering the investment of enterprise. The features of layer-2 Ethernet port are

shown in the following:

Support layer-2 forwarding.z

z

z

z

z

z

Support broadcast storm suppression ratio.

Support MAC address aging time.

Support dividing VLANs (802.1Q) based on port (in 8-/16-port).

Not support STP/MSTP/RSTP. So, avoid loopback in the case of networking.

Not support port aggregation.

Specifications

The specifications of 100 M Ethernet line module of the AR28 router are shown as follows.

Quidway® AR 28 Series 100 M Ethernet Line Module

Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved. 2

http://datacomm.huawei.com

Product Number Connector Type Description

RT-1FE RJ45 1-port 10/100Base-T module

RT-2FE RJ45 2-port 10/100Base-T module

RT-1SFX SC

1-port 100M single-mode optical interface Ethernet module

(1310nm,15km, SC)

RT-1MFX SC

1-port 100M multi-mode optical interface Ethernet module

(1310nm,2km, SC)

RT-8LS RJ45 8-prot 10M/100M Ethernet layer-2 switching interface module

Note:

zWhen making network cable, use the shielded cable first, to ensure the requirement of

Electromagnetic Compatibility.

zThe interface cable contained in the standard configuration of FE card is standard network

cable (straight through network cable).

zSC: rectangular fiber connector

SC fiber connector
