HPE Apollo 2000 Gen10 Manuel utilisateur
HPE Apollo 2000 Gen10 Chassis User
Guide
Part Number: 879112-003
Published: June 2018
Edition: 3
Abstract
This document contains setup, installation, and configuration information for the HPE Apollo
2000 Chassis. This document is for the person who installs, administers, and troubleshoots
the system. Hewlett Packard Enterprise assumes that you are qualified in the servicing of
computer equipment and trained in using safe practices when dealing with hazardous energy
levels.
© Copyright 2017, 2018 Hewlett Packard Enterprise Development LP
Notices
The information contained herein is subject to change without notice. The only warranties for Hewlett
Packard Enterprise products and services are set forth in the express warranty statements accompanying
such products and services. Nothing herein should be construed as constituting an additional warranty.
Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained
herein.
Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession,
use, or copying. Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer
Software Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government
under vendor's standard commercial license.
Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard
Enterprise has no control over and is not responsible for information outside the Hewlett Packard
Enterprise website.
Acknowledgments
Intel®, Itanium®, Pentium®, Intel Inside®, and the Intel Inside logo are trademarks of Intel Corporation in
the United States and other countries.
Microsoft® and Windows® are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
Adobe® and Acrobat® are trademarks of Adobe Systems Incorporated.
Java® and Oracle® are registered trademarks of Oracle and/or its affiliates.
UNIX® is a registered trademark of The Open Group.
Contents
HPE Apollo 2000 Gen10 System............................................................6
Introduction................................................................................................................................... 6
Planning the installation.........................................................................7
Safety and regulatory compliance.................................................................................................7
Product QuickSpecs......................................................................................................................7
Configuration guidelines............................................................................................................... 7
Determining power and cooling configurations............................................................................. 7
Power requirements........................................................................................................... 7
HPE Apollo Platform Manager........................................................................................... 7
Hot-plug power supply calculations....................................................................................8
Compiling the documentation....................................................................................................... 8
Warnings and cautions..................................................................................................................8
Space and airflow requirements................................................................................................... 9
Temperature requirements..........................................................................................................10
Grounding requirements............................................................................................................. 10
Connecting a DC power cable to a DC power source................................................................ 10
Identifying components and LEDs...................................................... 12
System components................................................................................................................... 12
Front panel components............................................................................................................. 12
Front panel LEDs........................................................................................................................ 14
Power fault LEDs........................................................................................................................ 16
Rear panel components..............................................................................................................17
Power supply LEDs.....................................................................................................................18
Fan locations...............................................................................................................................19
Drive bay numbering...................................................................................................................19
Hot-plug drive LED definitions.................................................................................................... 24
SmartDrive hot-plug drive LED definitions....................................................................... 24
Low-profile LFF hot-plug drive LED definitions................................................................ 25
NVMe SSD components.................................................................................................. 27
RCM module components.......................................................................................................... 29
RCM module LEDs..................................................................................................................... 29
Installing the chassis ...........................................................................31
Installation overview....................................................................................................................31
Unpacking the system.................................................................................................................31
Preparing the chassis for installation.......................................................................................... 31
Installing the Smart Storage Battery for the regular Power Supply..................................34
Installing the Smart Storage Battery for the H-Watt Power Supply.................................. 36
Installing the redundant fan option................................................................................... 38
Installing the chassis into the rack.............................................................................................. 40
Installing the 2U rack rail kit............................................................................................. 42
Installing hardware options into the server................................................................................. 45
Installing the system components...............................................................................................45
Installing a server............................................................................................................. 45
Contents 3
Installing the server tray blank......................................................................................... 46
Installing a hot-plug AC power supply..............................................................................47
Installing a hot-plug DC power supply..............................................................................48
Drive options.................................................................................................................... 54
Installing the optional 2U bezel................................................................................................... 58
Cabling................................................................................................... 60
Cabling guidelines.......................................................................................................................60
Cabling the chassis.....................................................................................................................61
Front I/O cabling...............................................................................................................61
Drive backplane power cabling........................................................................................ 62
Fan power cabling............................................................................................................64
Fan module cabling..........................................................................................................65
Smart Storage Battery cabling......................................................................................... 65
RCM 2.0 cabling...............................................................................................................66
Connecting the chassis to the network....................................................................................... 66
Installing the RCM module............................................................................................... 66
Connecting multiple chassis to the network with the RCM module iLO ports.................. 68
Connecting the optional HPE APM module..................................................................... 69
Connecting power cables and applying power to the chassis.................................................... 69
Configuring the system........................................................................ 70
Power capping............................................................................................................................ 70
Power capping modes......................................................................................................70
Configuring a power cap............................................................................................................. 71
Setting the chassis power cap mode with HPE APM.......................................................71
Troubleshooting.................................................................................... 72
Troubleshooting resources..........................................................................................................72
Electrostatic discharge.........................................................................73
Preventing electrostatic discharge.............................................................................................. 73
Grounding methods to prevent electrostatic discharge...............................................................73
Specifications........................................................................................74
Environmental specifications...................................................................................................... 74
Mechanical specifications........................................................................................................... 74
Power supply specifications........................................................................................................75
HPE 800W Flex Slot Platinum Hot-plug Low Halogen Power Supply..............................76
HPE 800W Flex Slot Universal Hot-plug Low Halogen Power Supply.............................77
HPE 800W Flex Slot -48VDC Hot-plug Low Halogen Power Supply...............................77
HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply........................... 78
HPE 2200W Flex Slot Platinum Hot Plug Low Halogen Power Supply........................... 79
Hot-plug power supply calculations............................................................................................ 80
Websites................................................................................................ 81
Support and other resources...............................................................82
Accessing Hewlett Packard Enterprise Support......................................................................... 82
4Contents
Accessing updates......................................................................................................................82
Customer self repair....................................................................................................................83
Remote support.......................................................................................................................... 83
Warranty information...................................................................................................................83
Regulatory information................................................................................................................84
Documentation feedback............................................................................................................ 84
Acronyms and abbreviations...............................................................85
Contents 5
HPE Apollo 2000 Gen10 System
Introduction
The HPE Apollo 2000 Gen10 System consists of a chassis and servers. There are four chassis options
with different storage configurations. To ensure proper thermal cooling, all server tray slots on the chassis
must be populated with servers or server tray blanks.
Chassis
• HPE Apollo r2200 Gen10 Chassis (12 low-profile LFF model)
• HPE Apollo r2600 Gen10 Chassis (24 SFF model, supports a maximum of 24 SFF SmartDrives or a
mix of 16 SFF SmartDrives and 8 NVMe drives)
• HPE Apollo r2800 Gen10 Chassis with 16 NVMe
• HPE Apollo r2800 Gen 10 Chassis (24 SFF model with storage expander backplane)
Servers
• HPE ProLiant XL170r Gen10 Server (1U)
• HPE ProLiant XL190r Gen10 Server (2U)
The chassis supports the combination of 1U and 2U servers. One chassis can support a maximum of the
following:
• Four 1U servers
• Two 1U servers and one 2U server
• Two 2U servers
For more information about product features, specifications, options, configurations, and compatibility, see
the product QuickSpecs on the Hewlett Packard Enterprise website.
6 HPE Apollo 2000 Gen10 System
Planning the installation
Safety and regulatory compliance
For important safety, environmental, and regulatory information, see Safety and Compliance Information
for Server, Storage, Power, Networking, and Rack Products, available at the Hewlett Packard Enterprise
website (http://www.hpe.com/support/Safety-Compliance-EnterpriseProducts).
Product QuickSpecs
For more information about product features, specifications, options, configurations, and compatibility, see
the product QuickSpecs on the Hewlett Packard Enterprise website (http://www.hpe.com/info/qs).
Configuration guidelines
Operate the chassis only when a device or blank is installed in all device bays. Before powering up the
chassis, be sure to do the following:
• Install a drive or drive blank into all drive bays.
• Install a server or server tray blank into all server bays.
• Install a power supply or power supply blank into all power supply bays.
Determining power and cooling configurations
Validate power and cooling requirements based on location and installed components.
Power requirements
Installation of this equipment must comply with local and regional electrical regulations governing the
installation of IT equipment by licensed electricians. This equipment is designed to operate in installations
covered by NFPA 70, 1999 Edition (National Electric Code) and NFPA-75, 1992 (code for Protection of
Electronic Computer/Data Processing Equipment). For electrical power ratings on options, refer to the
product rating label or the user documentation supplied with that option.
WARNING: To reduce the risk of personal injury, fire, or damage to the equipment, do not overload
the AC supply branch circuit that provides power to the rack. Consult the electrical authority having
jurisdiction over wiring and installation requirements of your facility.
CAUTION: Protect the server from power fluctuations and temporary interruptions with a regulating
UPS. This device protects the hardware from damage caused by power surges and voltage spikes
and keeps the server in operation during a power failure.
HPE Apollo Platform Manager
HPE Apollo Platform Manager, formerly named HPE Advanced Power Manager, is a point of contact for
system administration.
To install, configure, and access HPE APM, see the HPE Apollo Platform Manager User Guide on the
Hewlett Packard Enterprise website (http://www.hpe.com/support/APM_UG_en).
Planning the installation 7
Hot-plug power supply calculations
For more information on the hot-plug power supply and calculators to determine server power
consumption in various system configurations, see the Hewlett Packard Enterprise Power Advisor website
(http://www.hpe.com/info/poweradvisor/online).
Compiling the documentation
The documentation, while delivered individually and in various formats, works as a system. Consult these
documents before attempting installation. These documents provide the required important safety
information and decision-making steps for the configuration. To access these documents, see the Hewlett
Packard Enterprise website.
Warnings and cautions
WARNING: To reduce the risk of personal injury or damage to equipment, heed all warnings and
cautions throughout the installation instructions.
WARNING: To reduce the risk of personal injury or damage to the equipment, be sure that:
• The rack is bolted to the floor using the concrete anchor kit.
• The leveling feet extend to the floor.
• The full weight of the rack rests on the leveling feet.
• The racks are coupled together in multiple rack installations.
• Only one component is extended at a time. If more than one component is extended, a rack
might become unstable.
WARNING: The chassis is very heavy. To reduce the risk of personal injury or damage to the
equipment:
• Observe local occupational health and safety requirements and guidelines for manual material
handling.
• Remove all servers from the chassis before installing or moving the chassis.
• Use caution and get help to lift and stabilize the chassis during installation or removal, especially
when the chassis is not fastened to the rack.
WARNING: To reduce the risk of personal injury or damage to the equipment, you must adequately
support the chassis during installation and removal.
WARNING: Install the chassis starting from the bottom of the rack and work your way up the rack.
WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal
system components to cool before touching them.
8 Hot-plug power supply calculations
WARNING: To reduce the risk of electric shock or damage to the equipment:
• Never reach inside the chassis while the system is powered up.
• Perform service on system components only as instructed in the user documentation.
CAUTION: Always be sure that equipment is properly grounded and that you follow proper
grounding procedures before beginning any installation procedure. Improper grounding can result in
ESD damage to electronic components. For more information, refer to "Electrostatic discharge on
page 73."
CAUTION: When performing non-hot-plug operations, you must power down the server and/or the
system. However, it may be necessary to leave the server powered up when performing other
operations, such as hot-plug installations or troubleshooting.
CAUTION: Do not operate the server for long periods with the access panel open or removed.
Operating the server in this manner results in improper airflow and improper cooling that can lead to
thermal damage.
Space and airflow requirements
Installation of the chassis is supported in 1200 mm Gen10 racks.
To allow for servicing and adequate airflow, observe the following space and airflow requirements when
deciding where to install a rack:
• Leave a minimum clearance of 63.5 cm (25 in) in front of the rack.
• Leave a minimum clearance of 76.2 cm (30 in) behind the rack.
• Leave a minimum clearance of 121.9 cm (48 in) from the back of the rack to the back of another rack
or row of racks.
Front and rear rack doors must be adequately ventilated to allow ambient room air to enter the cabinet,
and the rear door must be adequately ventilated to allow the warm air to escape from the cabinet.
CAUTION: To prevent improper cooling and damage to the equipment, do not block the ventilation
openings.
When vertical space in the rack is not filled by a chassis or rack component, the gaps between the
components cause changes in airflow through the rack and across the components. Cover all gaps with
blanking panels to maintain proper airflow.
CAUTION: Always use blanking panels to fill empty vertical spaces in the rack. This arrangement
ensures proper airflow. Using a rack without blanking panels results in improper cooling that can
lead to thermal damage.
Space and airflow requirements 9
CAUTION: If a third-party rack is used, observe the following additional requirements to ensure
adequate airflow and to prevent damage to the equipment:
• Front and rear doors—If the 42U rack includes closing front and rear doors, you must allow
5,350 sq cm (830 sq in) of holes evenly distributed from top to bottom to permit adequate airflow
(equivalent to the required 64 percent open area for ventilation).
• Side—The clearance between the installed rack component and the side panels of the rack must
be a minimum of 7 cm (2.75 in).
Temperature requirements
To ensure continued safe and reliable equipment operation, install or position the rack in a well-ventilated,
climate-controlled environment.
The operating temperature inside the rack is always higher than the room temperature and is dependent
on the configuration of equipment in the rack. Check the TMRA for each piece of equipment before
installation.
CAUTION: To reduce the risk of damage to the equipment when installing third-party options:
• Do not permit optional equipment to impede airflow around the chassis or to increase the internal
rack temperature beyond the maximum allowable limits.
• Do not exceed the manufacturer’s TMRA.
Grounding requirements
• The building installation must provide a means of connection to protective earth.
• The equipment must be connected to that means of connection.
• A service person must check whether the socket-outlet from which the equipment is to be powered
provides a connection to the building protective earth. If the outlet does not provide a connection, the
service person must arrange for the installation of a protective earthing conductor from the separate
protective earthing terminal to the protective earth wire in the building.
Connecting a DC power cable to a DC power source
WARNING: To reduce the risk of electric shock or energy hazards:
• This equipment must be installed by trained service personnel, as defined by the NEC and IEC
60950-1, Second Edition, the standard for Safety of Information Technology Equipment.
• Connect the equipment to a reliably grounded Secondary circuit source. A Secondary circuit has
no direct connection to a Primary circuit and derives its power from a transformer, converter, or
equivalent isolation device.
• The branch circuit overcurrent protection must be rated 20 A.
WARNING: When installing a DC power supply, the ground wire must be connected before the
positive or negative leads.
10 Temperature requirements
