HP ProLiant ML150 Gen9 Instructions d'installation

Product End-of-Life Disassembly Instructions

Product Category: Servers

Marketing Name / Model

[List multiple models if applicable.]

HP ProLiant ML150 Gen9

Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions

for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU

directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).

1.0 Items Requiring Selective Treatment

1.1 Items listed below are classified as requiring selective treatment.

1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as

applicable.

Item Description Notes

Quantity

of items

included

in product

Printed Circuit Boards (PCB) or Printed Circuit

Assemblies (PCA)

With a surface greater than 10 sq cm

System board 1, small board 2

Batteries

All types including standard alkaline and lithium

coin or button style batteries

Mercury-containing components

For example, mercury in lamps, display backlights,

scanner lamps, switches, batteries

Liquid Crystal Displays (LCD) with a surface

greater than 100 sq cm

Includes background illuminated displays with gas

discharge lamps

Cathode Ray Tubes (CRT)

Capacitors / condensers (Containing PCB/PCT)

Electrolytic Capacitors / Condensers measuring

greater than 2.5 cm in diameter or height

Depending on Power Supply Model

External electrical cables and cords

Gas Discharge Lamps

Plastics containing Brominated Flame Retardants

weighing > 25 grams (not including PCBs or PCAs

already listed as a separate item above)

Components and parts containing toner and ink,

including liquids, semi-liquids (gel/paste) and toner

Include the cartridges, print heads, tubes, vent

chambers, and service stations. No

Components and waste containing asbestos

Components, parts and materials containing

refractory ceramic fibers

EL-MF877-00 Page 1

Template Revision B

PSG instructions for this template are available at EL-MF877-01

Components, parts and materials containing

radioactive substances

2.0 Tools Required

List the type and size of the tools that would typically be used to disassemble the product to a point where components

and materials requiring selective treatment can be removed.

Tool Description

Tool Size (if

applicable)

Torx Driver

T-15

Philps screwdriver

Medium

3.0 Product Disassembly Process

3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:

1. System Board Battery - Remove the side panel and remove the battery from the system board.

2. Capacitors in 550W power supply=> 2.5 cm () - Remove the power supply bracket from the system with a T-15 torx

driver, and to remove the PSU from PSU bracket with a T-15 torx driver. With a #2 Philips screw driver remove the

screws securing the top cover then locate the capacitors and pry from the PCB with a flat head screw driver or Long

Nose Plier () and dispose of properly.

3. Capacitors in 900W power supply=> 2.5 cm () - Remove the power supply bracket from the system with a T-15 torx

driver, and to remove the PSU from PSU bracket with a T-15 torx driver. With a #2 Philips screw driver remove the

screws securing the top cover then locate the capacitors and pry from the PCB with a flat head screw driver or Long

Nose Plier () and dispose of properly.

4. Locate Megacell an remove.

3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items

contained in the product that require selective treatment (with descriptions and arrows identifying locations).

Attachment 1 – System exploding drawing

Attachment 2 – System battery location

Attachment 3 – 550W PSU capacitor location

Attachment 4 – 900W PSU module capacitor location

Attachment 5 – Remove Megacell

EL-MF877-00 Page 2

Template Revision B

PSG instructions for this template are available at EL-MF877-01

Attachment 1

System battery location

System battery location – BH1

EL-MF877-00 Page 3

Template Revision B

PSG instructions for this template are available at EL-MF877-01

Attachment 2

550W PSU capacitor location

EL-MF877-00 Page 4

Template Revision B

PSG instructions for this template are available at EL-MF877-01

EL-MF877-00 Page 5

Template Revision B

PSG instructions for this template are available at EL-MF877-01

Attachment 3

900W PSU module capacitor location

EL-MF877-00 Page 6

Template Revision B

PSG instructions for this template are available at EL-MF877-01

Attachment 4

Remove Megacell

1. Push latch and remove megacell

EL-MF877-00 Page 7

Template Revision B

PSG instructions for this template are available at EL-MF877-01
