HP x2 210 G1 Manuel utilisateur
HP Pavilion x2 Detachable Notebook PC
HP x2 210 G1 Tablet
Maintenance and Service Guide
IMPORTANT! This document is intended for HP
authorized service providers only.
© Copyright 2015, 2016 HP Development
Company, L.P.
Bluetooth is a trademark owned by its
proprietor and used by HP Inc. under license.
Intel is a U.S. registered trademark of Intel
Corporation. Microsoft and Windows are U.S.
registered trademarks of Microsoft
Corporation. SD Logo is a trademark of its
proprietor.
The information contained herein is subject to
change without notice. The only warranties for
HP products and services are set forth in the
express warranty statements accompanying
such products and services. Nothing herein
should be construed as constituting an
additional warranty. HP shall not be liable for
technical or editorial errors or omissions
contained herein.
Third Edition: January 2016
First Edition: June 2015
Document Part Number: 814660-003
Product notice
This guide describes features that are common
to most products. Some features may not be
available on your tablet.
Software terms
By installing, copying, downloading, or
otherwise using any software product
preinstalled on this tablet, you agree to be
bound by the terms of the HP End User License
Agreement (EULA). If you do not accept these
license terms, your sole remedy is to return the
entire unused product (hardware and software)
within 14 days for a refund subject to the
refund policy of your place of purchase.
For any further information or to request a full
refund of the tablet, please contact your local
point of sale (the seller).
Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the device, do not place the
device directly on your lap or obstruct the device air vents. Use the device only on a hard, at surface. Do not
allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or
clothing, to block airow. Also, do not allow the AC adapter to contact the skin or a soft surface, such as
pillows or rugs or clothing, during operation. The device and the AC adapter comply with the user-accessible
surface temperature limits dened by the International Standard for Safety of Information Technology
Equipment (IEC 60950).
iii
iv Safety warning notice
Table of contents
1 Product description ....................................................................................................................................... 1
2 External component identication .................................................................................................................. 3
Right side ............................................................................................................................................................... 3
Left side ................................................................................................................................................................. 4
Display .................................................................................................................................................................... 5
Top edge ................................................................................................................................................................. 6
Bottom edge .......................................................................................................................................................... 6
3 Illustrated parts catalog ................................................................................................................................ 7
Locating the product number and serial number ................................................................................................. 7
Tablet major components ...................................................................................................................................... 9
Miscellaneous parts ............................................................................................................................................. 12
Sequential part number listing ........................................................................................................................... 13
4 Removal and replacement preliminary requirements ..................................................................................... 21
Tools required ...................................................................................................................................................... 21
Service considerations ......................................................................................................................................... 21
Plastic parts ....................................................................................................................................... 21
Cables and connectors ...................................................................................................................... 21
Grounding guidelines ........................................................................................................................................... 22
Electrostatic discharge damage ........................................................................................................ 22
Packaging and transporting guidelines .......................................................................... 23
Workstation guidelines ................................................................................ 23
5 Removal and replacement procedures for Authorized Service Provider parts ................................................... 25
Releasing the tablet from the keyboard base ..................................................................................................... 25
Tablet component replacement procedures ....................................................................................................... 25
Unlocking the device and disabling Always On Remote Management (select products only) ........................... 26
Back cover ............................................................................................................................................................ 26
Battery ................................................................................................................................................................. 28
Audio board .......................................................................................................................................................... 30
Speakers .............................................................................................................................................................. 31
Touch board ......................................................................................................................................................... 33
System board ....................................................................................................................................................... 34
Wireless antenna ................................................................................................................................................. 37
v
Power/volume button board ............................................................................................................................... 38
Webcam module .................................................................................................................................................. 40
Middle frame ........................................................................................................................................................ 42
POGO (10-pin) docking connector cable ............................................................................................................. 43
Keyboard base ..................................................................................................................................................... 44
Hard drive (select products only) ........................................................................................................................ 46
Keyboard board ................................................................................................................................................... 47
TouchPad .............................................................................................................................................................. 48
Hinge cover .......................................................................................................................................................... 49
POGO connector ................................................................................................................................................... 51
6 Using Setup Utility (BIOS) in Windows 10 ....................................................................................................... 53
Starting Setup Utility (BIOS) ................................................................................................................................ 53
Updating Setup Utility (BIOS) .............................................................................................................................. 53
Determining the BIOS version ........................................................................................................... 53
Downloading a BIOS update .............................................................................................................. 54
Synchronizing a tablet and keyboard (select products only) .............................................................................. 55
7 Using HP PC Hardware Diagnostics (UEFI) in Windows 10 ................................................................................. 56
Downloading HP PC Hardware Diagnostics (UEFI) to a USB device .................................................................... 56
8 Using Setup Utility (BIOS) and HP PC Hardware Diagnostics (UEFI) in Windows 8.1 ............................................. 58
Starting Setup Utility (BIOS) ................................................................................................................................ 58
Updating Setup Utility (BIOS) .............................................................................................................................. 58
Determining the BIOS version ........................................................................................................... 58
Downloading a BIOS update .............................................................................................................. 59
Using HP PC Hardware Diagnostics (UEFI) ........................................................................................................... 60
Downloading HP PC Hardware Diagnostics (UEFI) to a USB device .................................................. 60
9 Specications .............................................................................................................................................. 62
10 Backing up, restoring, and recovering in Windows 10 .................................................................................... 63
Creating recovery media and backups ................................................................................................................ 63
Creating HP Recovery media (select products only) ......................................................................... 63
Using Windows tools ........................................................................................................................................... 64
Restore and recovery ........................................................................................................................................... 65
Recovering using HP Recovery Manager ........................................................................................... 65
What you need to know before you get started ............................................................. 65
Using the HP Recovery partition (select products only) ................................................. 66
Using HP Recovery media to recover .............................................................................. 66
vi
Changing the computer boot order ................................................................................ 67
Removing the HP Recovery partition (select products only) ......................................... 68
11 Backing up, restoring, and recovering in Windows 8.1 ................................................................................... 69
Creating recovery media and backups ................................................................................................................ 69
Creating HP Recovery media (select products only) ......................................................................... 69
Using Windows tools ........................................................................................................................................... 70
Restore and recovery ........................................................................................................................................... 70
Recovering using HP Recovery Manager ........................................................................................... 71
What you need to know before you get started ............................................................. 71
Using the HP Recovery partition (select products only) ................................................. 72
Using HP Recovery media to recover .............................................................................. 72
Changing the computer boot order ................................................................................ 72
Removing the HP Recovery partition (select products only) ......................................... 73
12 Power cord set requirements ...................................................................................................................... 74
Requirements for all countries ............................................................................................................................ 74
Requirements for specic countries and regions ................................................................................................ 75
13 Recycling .................................................................................................................................................. 77
Index ............................................................................................................................................................. 78
vii
viii
1 Product description
Category Description
Product Name HP Pavilion x2 Detachable
HP x2 210 G1 Tablet
Processor Intel Z8300 1.44 GHz quad core processor soldered-on-circuit (SoC)
Panel 10.1-in (1280x800), Antiglare (AG), light-emitting diode (LED), WXGA, TouchScreen display panel
Graphics Internal graphics:
Intel 7th generation graphics and media encode/decode engine 2D/3D graphics
Supports DX11, OpenGL 3.0 (OGL 3.0), OpenCL 1.2 (OCL 1.2), and OpenGLES 2.0 (OGLES 2.0)
Memory On-board; non-accessible
2 GB DDR3L or 4 GB DDR3L
Supports up to 2 GB or 4 GB (select products only) maximum system memory
Mass storage Supports 32- or 64-GB eMMC (v5.0)
Audio and video Stereo speakers (2)
Dual array digital microphones with appropriate beam-forming, echo-cancellation, and noise-
suppression software
Audio codec ALC5642
HD webcam: 1/6-in, F2.4, 1.26-MP max., (1280x720), 720P, 30 fps
Sensor Accelerometer
Ambient Light Sensor
eCompass
Gyroscope
Hall sensor
Thermistor
Wireless networking Integrated wireless options:
Intel 3165NGWG ac, 1x1 Bluetooth 4.0 LE PCIe+USB NGFF 2230 WW (Stone Peak 1)
AzureWave AW-NB177NF Realtek RTL8723BS 802.11 (1x1 b/g/n, Single Band, Bluetooth 4.0) with
single antenna (SDIO+UART)
Supports Miracast
External expansion Integrated microSD Card Reader expandable to 2 TB
Supports SD 3.0
Ports ●Audio: headphone/microphone combo jack
●MicroSD Card Reader
●One USB 2.0 port, one USB 2.0 type C port support charging and data
●Micro HDMI v1.4a port supporting up to 2048x1024, 1920x1080 @ 60Hz
1
Category Description
●POGO-pin (10-pin) docking connector
Keyboard 93% island-style thin cover keyboard (1.5-mm travel distance) with image sensor clickpad
●Multitouch gestures enabled for clickpad
●POGO-pin (10-pin) docking connector
Power requirements Supports a 2-cell, 33-Wh battery (non-removable), USB charging
Supports a 15-W USB Type C AC adapter with DC plug and localized cable plug support
Operating system Preinstalled:
Windows 10 Home Entry EM/SL Tablet + 2-in-1 Notebook
Windows 10 Home Entry EM/SL 64 Tablet + 2-in-1 SEAP (APJ)
Windows 10 Home China/SL 64 CPPP
Serviceability End user replaceable part: AC adapter
2 Chapter 1 Product description
