ImagePad
Graphics Tablet
User’s Guide
P/N DOC.DP6
UG699050
i
Info
580 Division Street
Campbell CA, 95008
Phone (408) 374-7290 • Fax (408) 378-1068
Copyright © 1996 All rights reserved. No portion of this document
may be reproduced without prior written authorization.
The material in this document is for informational purposes only and is
subject to change without notice. The manufacturer assumes no
responsibility for errors or omissions in this document, nor any
damages resulting from the use of the information contained herein.
Info and ImagePad are trademarks of Info Peripherals. Any other
trademarks, registration marks, or brand names mentioned within this
publication are the property of their respective owners.
ii
Table of Contents
Chapter 1
Introduction ..................................... 1-1
Welcome ........................................ 1-1
Using this manual ............................ 1-1
Assistance ................................. 1-1
Package contents ................................. 1-2
System requirements ............................... 1-2
Chapter 2
Tablet and Driver Installation ........................ 2-1
Installation ....................................... 2-1
Connecting the tablet ......................... 2-1
Installing the device driver ...................... 2-1
Windows 95 installation ................. 2-2
Windows 3.x installation ................. 2-2
Installing the specialty drivers .............. 2-3
Installing the application software ....................... 2-3
Chapter 3
Using your tablet ................................. 3-1
Tablet features and controls ........................... 3-1
Hardware features ........................... 3-1
Stylus buttons ........................ 3-1
Using both the tablet and mouse ........... 3-1
Tablet care and maintenance .............. 3-1
Software controls ............................ 3-2
Appendix
Limited one year warranty ............................ A-1
FCC radio frequency interference statement ............... A-2
iii
1-1
Chapter 1
Introduction
Welcome
Thank you for purchasing an Info ImagePad graphics tablet. This
product is the result of our efforts to develop high technology
computer peripherals that are easy to use, affordably priced, and that
enhance your computing experience.
Using
this
manual
This manual includes complete instructions for scanner installation,
use, and maintenance. Note that “use,” in this context, refers to
scanner operation independent of tasks performed in conjunction with
application software. This guide is organized in a “do as you read”
format. For best results, perform the tasks as they are presented.
This manual assumes that you have a basic understanding of the DOS
and Windows operating system. As a convention, this guide presents
all references to guide names or sections in
italics,
and commands
you must type at a command line are presented in a differenttypeface.
Assistance
If you experience difficulties and cannot find solutions within this
guide, contact Info’s Technical Support Department at (408) 374-
5500, Monday through Friday, between 8:00AM and 4:30PM, Pacific
time. If you wish, you may fax questions to (408) 378-1271. Provide a
fax number for return contact. We maintain a BBS at (408) 378-4799
that contains the latest updates to our software, as well as a web site
at infospot.com.
If all of our technicians are occupied, please leave your name and
phone number on our voice mail system. This system is intended to
avoid excessive “on hold” waiting. You and your questions are
important to us and we will respond as quickly as possible. After
hours calls are returned the following working day.
1-2
Package
contents
Please verify that all materials have been included before setting up
and using your tablet. This package contains:
• ImagePad tablet with stylus
• RS-232 serial interface connector
• 25-pin to 9-pin serial adapter
• Standard keyboard connector
• Mini-DIN keyboard connector
• Utility disk (contains drivers)
• This User’s Guide
• Registration card
• Application software (listed in the Quick Start Guide)
System
requirements
Minimum and recommended system requirements for the ImagePad
graphics tablet are:
• 286 processor or 100% compatible; 486 or higher recommended
• DOS 3.1 or later
• Windows 3.x, Windows 95 or later
• 640 KB RAM; 4 MB RAM or more recommended
• Available 9- or 25-pin serial port
2-1
Chapter 2
Tablet and Driver Installation
Installation
Installation of the tablet is comprised of few
steps and designed to be as easy as possible. The
following instructions walk you through connecting
the tablet to your computer and installing the
drivers.
Connecting the tablet
Before you connect the tablet, determine which
type of keyboard port you have. You need to choose
the correct keyboard connector to use with this
installation. Newer systems use the smaller, Mini-
DIN connector for the keyboards, while previous
systems use the larger connector.
Note: As a safety precaution, the power to the
computer should be off before attaching any new
device.
To connect the tablet:
1. Turn off the power to your computer.
2. Once you’ve determined which keyboard connector
to use, plug it into the small, round socket on
the serial connector.
3. Attach the serial connector to an available
serial port. Use the 25- to 9-pin adapter if
necessary.
4. Unplug your keyboard from the port on your
computer, and attach it to the female port on
the keyboard connector. Plug the male end of
2-2
the keyboard connector into the port on your
computer.
Installing the device driver
In order for the tablet to work properly, you need
to install the device driver. Several drivers are
included for use with Windows 95, Windows 3.x,
AutoDesk, AutoCAD, and PenWindows. This manual
describes installation and operation for WIndows
95 and Windows 3.x.
Windows 95 installation
The driver provided for Windows 95 is a 32-bit VxD
(virtual device driver) to take full advantage of
the performance of Windows 95. This driver enables
the tablet and mouse to coexist on the same system
and be used interchangeably.
To install this driver:
1. Insert the utility disk into the computer’s
floppy drive.
2. Select Run from the Start menu on the desktop.
3. Type A:\win95\setup at the command line and click
OK. Substitute the appropriate drive letter if
the disk is not in the A drive.
4. Follow the on screen directions.
The tablet’s device driver is installed in the
proper directory and configuration files.
5. Reboot the computer after the installation is
complete to activate the tablet driver.
Windows 3.x installation
The driver provided for Windows 3.x is a 16-bit
device driver to enable full functionality under
Windows 3.x. This driver also enables the tablet
and mouse to coexist on the same system and be
2-3
used interchangeably.
To install this driver:
1. Insert the utility disk into the computer’s
floppy drive.
2. Choose Run from the File menu in Windows
Program Manager.
3. Type A:\windows\setup at the command line and click
OK. Substitute the appropriate drive letter if
the disk is not in the A drive.
4. Follow the on screen directions. The tablet’s
device driver is installed in the proper
directory and configuration files.
5. Reboot the computer after the installation is
complete to activate the tablet driver.
Installing the specialty drivers
The ImagePad utility disk contains extensive
instructions for installing the device drivers for
AutoDesk, AutoCAD, and PenWindows. Please refer to
the README files in the corresponding directory
for instructions on installing those drivers.
Installing
the
application
software
When the hardware and device driver software are
installed, install the application software as
described in their respective manuals.
