HP HN220E Manuel utilisateur

Filename: QS Ethernet 5-Port Switch.doc Title: HP-Print2k.dot

Template: quick_ref_template.dot Author: Elizabeth Stoneburg Last Saved By: Elizabeth Stoneburg

Revision #: 17 Page: 1 of 9 Printed: 09/14/01 03:01 PM

hp digital

home networking

Ethernet 5-port switch

hn220e

quick start guide

Filename: QS Ethernet 5-Port Switch.doc Title: HP-Print2k.dot

Template: quick_ref_template.dot Author: Elizabeth Stoneburg Last Saved By: Elizabeth Stoneburg

Revision #: 17 Page: 4 of 9 Printed: 09/14/01 03:01 PM

The Hewlett-Packard® Company makes no warranty of any

kind with regard to this material, including, but not limited

to, the implied warranties of merchantability and fitness for

a particular purpose.

The information in this document is subject to change

without notice.

HP shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the

furnishing, performance, or use of this material.

This document contains proprietary information that is

protected by copyright. All rights are reserved. No part of

this document may be photocopied, reproduced, or

translated to another language without the prior written

consent of HP.

Hewlett-Packard Company

Home Networking Solutions Organization

3000 Hanover St

Palo Alto, CA 94304

Hewlett-Packard is a registered trademark of Hewlett-

Packard Company in the United States of America and

other countries.

Microsoft, MS, MS-DOS, and Windows are registered

trademarks of Microsoft Corporation.

Other brand or product names are trademarks of their

respective holders.

Ethernet 5-port switch 1

Filename: QS Ethernet 5-Port Switch.doc Title: HP-Print2k.dot

Template: quick_ref_template.dot Author: Elizabeth Stoneburg Last Saved By: Elizabeth Stoneburg

Revision #: 17 Page: 1 of 9 Printed: 09/14/01 03:01 PM

Ethernet 5-port switch

hn220e

Thank you for choosing the Hewlett-Packard

Digital Home Networking Ethernet 5-Port

Switch. This quick start guide provides easy

set-up instructions.

POWER RESET

LAN WAN

1234

box contents

■One Ethernet 5-Port Switch

■One AC Power Adapter

■One quick start guide

■One warranty sheet

Filename: QS Ethernet 5-Port Switch.doc Title: HP-Print2k.dot

Template: quick_ref_template.dot Author: Elizabeth Stoneburg Last Saved By: Elizabeth Stoneburg

Revision #: 17 Page: 2 of 9 Printed: 09/14/01 03:01 PM

connecting the 5-port switch

1Verify that all of the box components are

included.

2Remove the Ethernet 5-Port Switch and

AC Power Adapter from the box.

3Plug the power cable into the POWER port

on rear panel of the 5-Port Switch as shown

in the diagram on the following page.

4Plug the other end of the Power Adapter into

an AC wall outlet.

5Make connections according to these

options:

■Network-ready devices (such as computers,

print servers, or the HP Digital

Entertainment Center). Add these devices to

your Ethernet network by connecting the

Ethernet cable coming from each device to

one of the five blue LAN ports on the rear

panel—see cabling diagram. Do not plug

these devices into the UPLINK port.

■Network infrastructure devices (such as a

hub, Gateway, or another switch). Connect

the Ethernet cable coming from the device

to the yellow UPLINK port of the 5-Port

Switch. Since the UPLINK port shares

wiring with port 5, port 5 will be disabled

if a cable is plugged into the UPLINK port

(and vice versa). See the cabling diagram

in this quick start guide as well as the

diagram on the underside of the Ethernet

5-Port Switch.

Note: If the second device also has an uplink port,

do not connect its uplink port to the UPLINK

port on the 5-port switch. You may use the

uplink port on either device, but the other

end of the cable must go to a standard

Ethernet port on the other device.

Ethernet 5-port switch 3

Filename: QS Ethernet 5-Port Switch.doc Title: HP-Print2k.dot

Template: quick_ref_template.dot Author: Elizabeth Stoneburg Last Saved By: Elizabeth Stoneburg

Revision #: 17 Page: 3 of 9 Printed: 09/14/01 03:01 PM

POWER

12345

LAN UPLINK

Ethernet cable

to PC

Ethernet cable

to AC wall outlet

to hub, Gateway, or another

switch (if UPLINK port is

used, port 5 will not be

functional and vice versa)

Power Adapter

Filename: QS Ethernet 5-Port Switch.doc Title: HP-Print2k.dot

Template: quick_ref_template.dot Author: Elizabeth Stoneburg Last Saved By: Elizabeth Stoneburg

Revision #: 17 Page: 4 of 9 Printed: 09/14/01 03:01 PM

registering the 5-port switch

Make sure you register your product with HP

after the installation process is complete. Enter

the following into the address window of your

Web browser (such as Internet Explorer or

Netscape): http://register.hp.com

Then press Enter.

product and support

information

■HP Customer Care: 1-208-323-2551;

http://www.hp.com/cposupport

■Online product information and technical

support: http://www.hp.com/go/

homenetworking

(includes a home networking tutorial, FAQs,

and other information
