The exploding growth of unstructured content changes the storage landscape. HP StoreAll Storage enables customers to tame and

mine their content explosion - reducing the cost, complexity, and time to store, protect, and extract business value from massive

amounts of unstructured data. HP StoreAll Storage is hyperscale, harnessed, instant, economic storage for today's and tomorrow's

datacenter.

Scale massively without complexity to 16 petabytes of billions of files and objects with centralized management. Bring structure to

unstructured data with custom metadata attributes, data retention policies, and autonomic protection for data durability. Use StoreAll

Express Query to extract value by finding files more quickly and cost effectively than traditional methods. Scale down costs of storing

data over time with policy-based tiering and a modular architecture.

NOTE:

HP StoreAll 9000 Storage has been superseded by HP StoreAll 8000 Storage. The new generation family includes:

HP StoreAll 8800 Storage - a converged hyperscale, economic, ultra-dense appliance that can be flexibly configured for a broad

range of archive workloads.

HP StoreAll 8200 Gateway Storage - providing file archive and object storage services in combination with HP 3PAR StoreServ

7000 and 10000 Storage.

Existing HP StoreAll 9320 Storage, HP StoreAll 9730 Storage, and HP StoreAll 9300 Gateway Storage can be seamlessly clustered with

new HP StoreAll 8800 Storage and HP StoreAll 8200 Gateway Storage when upgraded to StoreAll OS v6.5.

What's New

Innovative features to tame and mine enterprise information and industry-specific archives, unstructured Big Data, and cloud

solutions:

StoreAll Express Query enables meaning to be added to data via custom metadata attributes and value to be extracted from

data with ultra-fast search

SMB 2.1, Alternate Data Streams (ADS), and DFS Namespace target support provides tighter Windows IT integration

Feature setup and configuration wizards simplify management

Platform health monitoring and firmware version verification provide robust supportability

Installation wizard for HP StoreAll 9730 Storage and storage provisioning tool for HP StoreAll 9320 Storage speed deployment

Ultra-dense 5U 6Gb SAS 70 LFF HDD enclosure for HP StoreAll 9730 Storage delivers end-to-end 6Gb architecture for greater

performance

HP StoreAll Storage Specifications

Common Specifications

Operating System

StoreAll OS v6.3 with rich, all inclusive data services for:

- Data protection including Snapshots and Constant Validation

- Data retention including WORM file immutability and Data Retention Policies

- Data mobility including Rebalancing, Tiering and Continuous Remote

Replication

- Data management including Express Query plus user and directory quotas

Protocol Support

NFS, CIFS and SMB, NDMP, HTTP and HTTPS, WebDAV, REST API with File

Compatibility Mode and Object Mode, FTP and FTPS

Optical Drive

DVD-RW standard for QuickRestore

Remote Access

HP ProLiant Integrated Lights-Out 3 with Advanced Pack license

QuickSpecs

HP StoreAll 9000 Storage

Overview

DA - 13467 North America — Version 20 — December 9, 2013

Page 1

Key Features and Benefits

Hyperscale: Massive

scalability without

complexity

Efficiently scale out capacity and performance to 16 petabytes in a single namespace with autonomic

rebalancing of data between nodes.

Administer centrally without complexity using the web browser-based GUI and CLI.

Harnessed: Structure for

unstructured data

Add meaning and value to data with integrated support for custom metadata attributes.

Drive corporate compliance with data retention policies to ensure files cannot be deleted and WORM to

ensure that files cannot be modified.

Leverage data durability with local and remote autonomic protection including data integrity validation and

replication.

Instant: Ultra-fast search

and value extraction

Use StoreAll Express Query to find files and generate file system analytics up to 100,000 times faster than

traditional methods and without the cost or complexity of an external database.

Economic: Scale down

costs of storing data over

time

Reduce ongoing storage costs while optimizing utilization with transparent and autonomic policy-based

data tiering.

Flexibly expand storage capacity and performance with the modular "pay-as-you-grow" scale-out

architecture and support for the mixing of models in a single cluster.

Leverage the rich set of all inclusive data services that provide data protection, retention, mobility, and

management.

QuickSpecs

HP StoreAll 9000 Storage

Overview

DA - 13467 North America — Version 20 — December 9, 2013

Page 2

HP StoreAll 9320 Storage

HP StoreAll 9320 Storage is a flexible, turnkey, highly available scale-out appliance that can be configured as needed to match the

customer's performance and capacity needs.

HP StoreAll 9320 1GbE Storage Node Pair

QP330B

HP StoreAll 9320 10GbE Storage Node Pair

QP331B

HP StoreAll 9320 48TB LFF 2TB 7.2K Mdl SAS Storage Base Capacity Block

QP335B

HP StoreAll 9320 48TB LFF 2TB 7.2K Mdl SAS Storage Expansion Capacity Block

QP336B

HP StoreAll 9320 72TB LFF 3TB 7.2K Mdl SAS Storage Base Capacity Block

QZ722B

HP StoreAll 9320 72TB LFF 3TB 7.2K Mdl SAS Storage Expansion Capacity Block

QZ723B

HP StoreAll 9320 7.2TB SFF 300GB 10K Ent SAS Storage Base Capacity Block

QZ724B

HP StoreAll 9320 7.5TB SFF 300GB 10K Ent SAS Storage Expansion Capacity Block

QZ725B

HP StoreAll 9320 21.6TB SFF 900GB 10K Ent SAS Storage Base Capacity Block

QZ726B

HP StoreAll 9320 22.5TB SFF 900GB 10K Ent SAS Storage Expansion Capacity Block

QZ727B

QuickSpecs

HP StoreAll 9000 Storage

HP StoreAll 9320 Storage

DA - 13467 North America — Version 20 — December 9, 2013

Page 3

Storage Node Pair

Base Capacity

Block

Expansion

Capacity Block

QuickSpecs

HP StoreAll 9000 Storage

HP StoreAll 9320 Storage

DA - 13467 North America — Version 20 — December 9, 2013

Page 4

Node Pairs

Each HP StoreAll 9320 Storage Node Pair model contains two nodes. The difference between the three

Node Pair SKUs is the network interfaces included. Each node is 2U rack-mount and built on HP ProLiant

DL380 G7 Server DNA with two quad core Intel® Xeon® Processor E5620 and 48GB memory.

Network Ports

Description

Part Number

1 GbE Ports

10 GbE Ports

HP StoreAll 9320 1GbE Storage Node Pair

QP330B

16 0

HP StoreAll 9320 10GbE Storage Node Pair

QP331B

8 8

NOTE:

Each node comes with 4 1GbE ports for optional connectivity to one or more secondary networks. All

other ports are intended for client network connectivity. All nodes must be deployed in pairs. Single nodes

are not supported

External Storage HBA

(2) HP SC08e SAS HBA per node

Disk Drives

(2) 300GB Enterprise SAS 10K SFF per node for StoreAll OS only

Power / Cooling

Redundant hot plug replaceable power supply and fan modules in all nodes.

2 high voltage power cords (IEC C13 to C14) standard per node.

NOTE:

HP StoreAll 9320 Storage is primarily connected to PDUs in racks. The SKUs ship standard with only

PDU C-14 to C13 power cord(s). Alternative power cords and power connectivity options are available. See

the ProLiant DL Server and HP MSA QuickSpecs on

hp.com

for additional information on available options.

Base Capacity Block

The Base Capacity Block is the primary storage building block for the system. HP StoreAll 9320 Storage

can be configured with 1 or 2 Base Capacity Blocks. Each Base Capacity Block includes a SAS Dual

Controller LFF/SFF Array System and 24 HDDs. There are four Base Capacity Block models. The difference

in the kits is the type and capacity of HDDs included:

Controller:

Based on HP MSA P2000 G3 SAS Dual Controller LFF/SFF Array System

Number of controllers:

RAID levels:

RAID 5 for SFF 10K Ent SAS Capacity Blocks

RAID 6 for LFF 7.2K Mdl SAS Capacity Blocks

LUNs:

512

Host interconnect:

4 6Gb SAS host ports per controller

QuickSpecs

HP StoreAll 9000 Storage

Standard Features – HP StoreAll 9320 Storage

DA - 13467 North America — Version 20 — December 9, 2013

Page 5

Disk Drives

Base Capacity Block models include 24 HDDs.

HDD options:

300GB Enterprise SAS 10K SFF

900GB Enterprise SAS 10K SFF

2TB Midline SAS 7.2K LFF

3TB Midline SAS 7.2K LFF

Power / Cooling

Redundant hot plug replaceable power supply and fan modules in all Capacity Blocks.

2 high voltage power cords (IEC C13 to C14) standard per Capacity Block.

NOTE:

HP StoreAll 9320 Storage is primarily connected to PDUs in racks. The SKUs ship standard with only

PDU C-14 to C13 power cord(s). Alternative power cords and power connectivity options are available. See

the ProLiant DL Server and MSA array QuickSpecs on hp.com for additional information on available

options.

Storage Capacity

Base Capacity Block storage capacity

7.2TB raw capacity (5.7TB after RAID) with 24 300GB Enterprise SAS 10K SFF drives

21.6TB raw capacity (17.1TB after RAID) with 24 900GB Enterprise SAS 10K SFF drives

48TB raw capacity (32TB after RAID) with 24 2TB Midline SAS 7.2K LFF drives

72TB raw capacity (48TB after RAID) with 24 3TB Midline SAS 7.2K LFF drives

Expansion Capacity Block storage capacity

7.5TB raw capacity (6TB after RAID) with 25 300GB Enterprise SAS 10K SFF drives

22.5TB raw capacity (18TB after RAID) with 25 900GB Enterprise SAS 10K SFF drives

48TB raw capacity (32TB after RAID) with 24 2TB Midline SAS 7.2K LFF drives

72TB raw capacity (48TB after RAID) with 24 3TB Midline SAS 7.2K LFF drives

QuickSpecs

HP StoreAll 9000 Storage

Standard Features – HP StoreAll 9320 Storage

DA - 13467 North America — Version 20 — December 9, 2013

Page 6

Introduction

Configuring and ordering HP StoreAll 9320 Storage is an easy process. The ordering tools are pre-populated with built-in rules to

ensure your HP StoreAll 9320 Storage is properly configured. You will only need to specify the Node Pair model based on the customer

network, the number and type of Capacity Blocks, and any system options required. The ordering system will then build the

appropriate HP StoreAll 9320 Storage solution.

There are three major components used in an HP StoreAll 9320 Storage:

HP StoreAll 9320 Storage Node Pair

HP StoreAll 9320 Storage Base Capacity Block

HP StoreAll 9320 Storage Expansion Capacity Block

Step 1 Choose a Node Pair model

The difference between the three Node Pair models is the network interface. The model ordered must have the network interface

required to connect the HP StoreAll 9320 Storage to the customer's network.

HP StoreAll 9320 1GbE Storage Node Pair

Includes 4 1GbE ports per node for connectivity to the customer's network

QP330B

HP StoreAll 9320 10GbE Storage Node Pair

Includes 4 10GbE ports per node for connectivity to the customer's network

QP331B

NOTE:

All HP StoreAll 9320 Storage Node Pair models include 2 nodes with 4 1GbE ports per node for optional

connectivity to one or more secondary networks and 2 HP SC08e 6 Gb SAS HBAs.

Step 2 Choose the Base Capacity Block(s) (minimum 1, maximum 2)

The Base Capacity Block is the primary storage building block for the system. HP StoreAll 9320 Storage can be configured with 1 or 2

Base Capacity Blocks. There are four Base Capacity Block models to choose from. The difference between the Base Capacity Block

models is the type and capacity of HDDs included. The different Base Capacity Block models can be mixed in a system.

HP StoreAll 9320 7.2TB 300GB 10K SFF Ent Storage Base Capacity Block

Includes SAS Dual Controller Array System and 24 300GB Ent SAS 10K SFF drives

QZ724B

HP StoreAll 9320 21.6TB 900GB 10K SFF Ent Storage Base Capacity Block

Includes SAS Dual Controller Array System and 24 900GB Ent SAS 10K SFF drives

QZ726B

HP StoreAll 9320 48TB 2TB 7.2K LFF Storage Base Capacity Block

Includes SAS Dual Controller Array System , drive enclosure and 24 2TB Mdl SAS 7.2K LFF drives

QP335B

HP StoreAll 9320 72TB 3TB 7.2K LFF Mdl Storage Base Capacity Block

Includes SAS Dual Controller Array System, drive enclosure and 24 3TB Mdl SAS 7.2K LFF drives

QZ722B

QuickSpecs

HP StoreAll 9000 Storage

Configuration Instructions - HP StoreAll 9320 Storage

DA - 13467 North America — Version 20 — December 9, 2013

Page 7

Step 3 Choose the Expansion Capacity Block(s) (minimum 0, maximum 6 or 10)

The Expansion Capacity Blocks are optional blocks to increase storage capacity. With each Base Capacity Block, a maximum of 3 LFF

Mdl SAS Expansion Capacity Blocks or 5 SFF Ent SAS Expansion Capacity Blocks can be added. The HDD type and capacity of the

Expansion Capacity Block must match the HDD type and capacity of the Base Capacity Block. A fully configured HP StoreAll 9320

Storage with 2 Base Capacity Blocks can have maximum of 6 LFF Expansion Capacity Blocks or 10 SFF Expansion Capacity Blocks.

There are four Expansion Capacity Block models. The difference between the Expansion Capacity Blocks is the type and capacity of

HDDs included.

HP StoreAll 9320 7.5TB 300GB 10K SFF Ent Storage Expansion Capacity Block

Includes 1 drive enclosure and 25 300GB Ent SAS 10K SFF drives

QZ725B

HP StoreAll 9320 22.5TB 900GB 10K SFF Ent Storage Expansion Capacity Block

Includes 1 drive enclosure and 25 900GB Ent SAS 10K SFF drives

QZ727B

HP StoreAll 9320 48TB 2TB 7.2K LFF Storage Expansion Capacity Block

Includes 2 drive enclosures and 24 2TB Mdl SAS 7.2K LFF drives

QP336B

HP StoreAll 9320 72TB 3TB 7.2K LFF Mdl Storage Expansion Capacity Block

Includes 2 drive enclosures and 24 3TB Mdl SAS 7.2K LFF drives

QZ723B

QuickSpecs

HP StoreAll 9000 Storage

Configuration Instructions - HP StoreAll 9320 Storage

DA - 13467 North America — Version 20 — December 9, 2013

Page 8

Step 4 Choose the System Options

The following options are available for HP StoreAll 9320 Storage. For more information on compatibility with HP and non-HP hardware

and software please visit the Single Point of Connectivity Knowledge (SPOCK) website:

http://h20272.www2.hp.com/

Add a Rack

HP StoreAll 9320 Storage supports either a standard 42U cabinet based on the HP 10000 G2 Series

Rack or a choice of 42U extended, 36U and 22U heights.

The default rack selection for HP StoreAll 9320 Storage is the HP Intelligent Series Rack. The

following options are automatically added to the configuration by the HP configuration tools

(Watson or SBW) when factory rack integration is selected:

TFT (Keyboard with integrated mouse and 1U 17 inch flat panel display)

KVM server console switch

NOTE:

Factory rack integration should be selected unless a plan has been established for

integrating the HP StoreAll 9320 Storage into the customer's existing environment. Factory racking

for these with other HP products such as additional HP StoreAll Storage, HP ProLiant Servers and

HP storage arrays is available based on the configuration. #0D1 will appear after the part number

on the sales order if HP factory integration is supported.

Add 10 GbE Cables and Transceivers

HP StoreAll 9320 Storage with 10GbE NICs require Direct Attach Cables (DAC) for copper

environments or fiber transceivers and cables for fiber-optic environments to connect to the

customer's network. There are multiple options and they must match that of the customer's

network infrastructure. If the customer does not already have the needed DACs or fiber transceivers

available at their site, then the correct ones should be selected. Up to eight 10GbE connections are

supported per HP StoreAll 9320 Storage Node Pair. Without at least four DACs or fiber transceivers

per HP StoreAll 9320 Storage, you will not be able to connect the system to the customer's network

infrastructure. For more information, please see the HP NC550SFP Dual Port 10GbE Server Adapter

QuickSpecs

http://h18000.www1.hp.com/products/quickspecs/13555_na/13555_na.pdf

Spare Disk Drives

SFF SAS Drives, Hot Plug

HP 300GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive

507127-B21

SFF SAS Drives, Hot Plug

HP 900GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive

619291-B21

LFF SAS Drives, Hot Plug

HP P2000 3TB 6G SAS 7.2K LFF (3.5-inch) Dual Port MDL Hard Drive

QK703A

LFF SAS Drives, Hot Plug

HP P2000 2TB 6G SAS 7.2K LFF (3.5-inch) Dual Port MDL Hard Drive

AW555A

QuickSpecs

HP StoreAll 9000 Storage

Options - HP StoreAll 9320 Storage

DA - 13467 North America — Version 20 — December 9, 2013

Page 9

Storage field upgrades

Storage field upgrades can be ordered for HP IBRIX X9320 Storage and HP StoreAll 9320 Storage based on

HP MSA P2000 G3 with 6Gb SAS capability. HP IBRIX X9320 Storage and HP StoreAll 9320 Storage based on

QP330B, QP331B and QP332B Node Pair SKUs can be field upgraded with QZ722B, QZ723B, QZ724B,

QZ725B, QZ726B, QZ727B, QP335B, and QP336B Base and Expansion Capacity Block SKUs. Previous HP

IBRIX X9320 Storage based on QP330A, QP331A and QP332A Node Pair SKUs can be field upgraded with

QZ722B, QZ723B, QZ724B, QZ725B, QZ726B, QZ727B, QP335B, QP336B Base and Expansion Capacity

Block SKUs.

If only Base and Expansion Capacity Blocks (QZ722B, QZ723B, QZ724B, QZ725B, QZ726B, QZ727B,

QP335B, QP336B) are being added to an existing HP IBRIX X9320 Storage and HP StoreAll 9320 Storage

based on HP MSA P2000 G3 with 6Gb SAS capability then upgrading to IBRIX OS v6.1 or later is not

required. If a new Node Pair is being added, then the existing HP IBRIX X9320 Storage or HP StoreAll 9320

Storage also needs to be upgraded so that the same IBRIX OS or StoreAll OS version is running across the

cluster.

HP IBRIX X9320 Storage and HP StoreAll 9320 Storage with the older Base and Expansion Capacity Blocks

(QP333A, QP334A, QP337A, QP338A) are NOT field upgradable.

QuickSpecs

HP StoreAll 9000 Storage

Options - HP StoreAll 9320 Storage

DA - 13467 North America — Version 20 — December 9, 2013

Page 10

Table des matières

Autres manuels HP Stockage

HP Surestore 64 - Director Switch Manuel utilisateur

HP NetStorage 6000 Manuel utilisateur

HP AD510A - StorageWorks Modular Smart Array 1500 cs 2U Fibre Channel SAN Attach Controller Shelf Hard... Manuel

HP StorageWorks MSL2024 Manuel utilisateur

HP StorageWorks 4400 Manuel utilisateur

HP P5389A - Intel Pentium III-S 1.4 GHz Processor... Manuel utilisateur

HP Storevirtual 4000 Guide de référence rapide

HP AJ765A - StorageWorks RDX Removable Disk Backup... Mode d’emploi

HP S700 Pro 2.5 Manuel utilisateur

HP StorageWorks 4000/6000/8000 - Enterprise Virtual... Mode d’emploi

HP 7957A Manuel utilisateur

HP LTO-4 Ultrium 1760 Manuel du produit

HP Pavilion p6000 - Desktop PC Manuel utilisateur

HP StorageWorks 8B - FC Entry Switch Manuel utilisateur

HP StorageWorks DAT320 USB Mode d’emploi

HP Storevirtual 4000 Manuel utilisateur

HP Surestore Disk Array 12h - And FC60 Manuel de service

HP StorageWorks MSL5000 series Manuel utilisateur

HP v119r Manuel utilisateur

HP AA988A - Modular Smart Array Storage Controller... Manuel utilisateur

HP StoreOnce 3100 Guide de l'utilisateur

HP P2000 G3 Manuel utilisateur

HP HPE Alletra 2140 Instructions d'installation

HP P9000 Manuel utilisateur

Manuels Stockage populaires d'autres marques

QNAP

QNAP TS 32PXU Series Manuel utilisateur

LaCie

LaCie RUGGED RAID Manuel utilisateur

Freecom

Freecom CLS DOCK Manuel utilisateur

PNY

PNY Attache P-FD64MBATT3 Manuel utilisateur

OLT

OLT 6x6 Maximizer Manuel utilisateur

Transcend

Transcend JetFlash 160 Manuel utilisateur

LaCie

LaCie RUGGED MINI Manuel utilisateur

Thunderbolt

Thunderbolt 600 Manuel utilisateur

Panasonic

Panasonic LB-DH8 series Manuel

Intel

Intel RAID High Availability Manuel utilisateur

LaCie

LaCie 12big Thunderbolt 3 Manuel utilisateur

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic

Panasonic LKM-F931-1 Manuel utilisateur

Tabernus

Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor

Rocstor COMMANDER 3F series Manuel utilisateur

Western Digital

Western Digital Ultrastar Data60 Manuel utilisateur

Dell

Dell PowerVault MD3600f Series Manuel utilisateur

CFI

CFI TERA STOR SATA RAID IV Manuel utilisateur
