HP F2B56AA Manuel utilisateur

Models

Optical Drives

HP External USB DVD/RW

New!

F2B56AA

HP 2011 BNB Notebook Upgrade Bay DL DVD+/-RW

LZ835AA

Removable Hard Drives

HP 500 GB 7200 rpm SED Hard Drive (US Only)

E8D48AA

HP 500 GB 7200 rpm Primary SATA Hard Drive

New!

F3B97AA

HP 750 GB 7200 rpm Primary SATA Hard Drive

H2P67AA

HP Upgrade Bay 750 GB Hard Drive

H2P66AA

Solid State Drives

HP 128 GB Solid State Drive

F4P50AA

HP 180 GB Solid State Drive

H4T75AA

HP 256 GB SED Solid State Drive

H2C38AA

HP Storage Solutions

HP storage solutions for your HP business notebook provide additional flexibility and expandability with a range of options that include

optical drives, hard drives, and solid state drives.

QuickSpecs

HP Storage Solutions for HP Business Notebooks

Overview

DA - 13066 North America — Version 27 — December 20, 2013

Page 1

Optical Drives

HP External USB DVD/RW

With the HP External USB Optical Drive, any available USB port on your notebook or Ultrabook™ becomes a ticket to optical storage.

Simply connect the drive with the included USB cable, and get immediate read/write access to your optical media.

Key Benefits

Write to or access large files, media or music from CDs or DVDs

Connect easily through a USB 2.0 port

Lightweight, compact design stores easily into a carrying case or backpack

HP 2011 BNB Notebook Upgrade Bay DL DVD+/-RW

The HP 2011 BNB Notebook Upgrade Bay DL DVD+/-RW and HP Upgrade Bay SuperMulti (DL) DVD+/-RW SATA Drives are user-

removable, drawer-load data storage devices that can write to CD-R, CD-RW, DVD+R, DVD-R, DVD+RW, and DVD-RW media and can

read from any industry-standard CD and DVD media. The drives are an exceptional solution for creating CDs and DVDs, and for backing

up or archiving permanent data files on CD or DVD media. Model LZ835AA is designed specifically to fit into 2011 HP Business Notebook

platforms and HP Advanced Docking Stations (A7E36AA/A7E38AA). Model AK869AA works with HP Docking Stations

(A7E32AA/A7E34AA) and pre-2011 HP Business Notebooks.

Key Benefits

Single user-removable drive with 8X DVD-ROM, 10X CD-RW, and 2X DVD+/-RW Dual Format

functionality

Up to 4.7 GB of data storage capacity (up to 8.5 GB double layer)

NOTE:

Don't copy copyright-protected materials. Double Layer is a new technology. Double Layer media compatibility will widely vary

with some home DVD players and DVD-ROM drives. Note that DVD-RAM cannot read or write to 2.6GB Single Sided/5.2 Double Sided-

Version 1.0 Media.

Removable Hard Drives

HP 500 GB 7200rpm SED Hard Drive , and HP 500/750 GB 7200rpm Primary SATA Hard Drive

The HP Hard Drives are convenient and affordable solutions for users who require additional storage or a faster dedicated second hard

drive.

Key Benefits

Extend the life of your HP Business Notebook by providing additional storage

Easy low-cost back-up solution without burdening network resources

Switch drives between most HP business notebooks

SMART predictive failure analysis (PFA)

QuickSpecs

HP Storage Solutions for HP Business Notebooks

Standard Features

DA - 13066 North America — Version 27 — December 20, 2013

Page 2

HP Upgrade Bay 750 GB Hard Drive and HP 2011 BNB Notebook Upgrade Bay

The HP Upgrade Bay 750 GB Hard Drive and 2011 is convenient and affordable solutions for users who require additional storage or a

faster dedicated second hard drive. Model H2P66AA fits into select 20111 and 2012 HP Business Notebooks and works with HP

Advanced Docking Stations. Model LX733AA fits into select 2010 and 2011 HP Business Notebook platforms and does not work with HP

Docking Stations. Model AU097AA works with HP Advanced Docking Stations and pre-2011 HP Business Notebooks.

Key Benefits

Extend the life of your HP Business Notebook by providing additional storage

Easy back-up solution without burdening network resources

Switch drives between most HP business notebooks

Warm swappable

High speed SATA data transfer

Power/drive activity LED indicator

Solid State Drives

HP 128 GB, 180 GB, and 256 GB Solid State Drives

The HP 128 GB and 180 GB Solid State Drives provide many performance and durability improvements over traditional Hard Disk Drive

(HDD) technology. With no moving parts, solid state drives do not need to spin up or mechanically seek files like conventional hard disk

drives do. These drive characteristics significantly improve boot-up, shut down, and application loading times as well as overall

application responsiveness.

The HP 256 GB SED Solid State Drive includes Trusted Computing Group (TCG) Opal-compliant self-encryption for enhanced data

security that adds a layer of authentication to your drive.

Key Benefits

Store your data with a hard drive with no moving parts

Get faster transfer speeds and higher cell endurance with Multi Level Cell (MLC) NAND flash memory

Significantly improve boot up, shut down, and application loading times

Improved protocol for enhanced data integrity

Performance increase to up to 6 Gb/s maximum external (burst) data transfer rate

Native Command Queuing allows the drive to have several write or read commands outstanding at

the same time

QuickSpecs

HP Storage Solutions for HP Business Notebooks

Standard Features

DA - 13066 North America — Version 27 — December 20, 2013

Page 3

Optical Drives

HP External USB DVD/RW

Drive

Manual tray-load

Interface

USB 2.0

Dimensions

(HxWxD)

0.55 x 5.41 x 5.94 in (1.40 x 14.40 x 13.75 cm)

Form Factor

External

Access Times

1/3 Stroke: 140 ms

DVD

1/3 Stroke: 160 ms

Supported Media

(read)

DVD-ROM, DVD-R

DVD-R , DVD-R DL, DVD-RW,

DVD-RAM, DVD+R, DVD+R DL, and +RW

CD-ROM, CD-ROM XA,

CD-DA

Super Audio CD

CD-R discs

CD-RW discs

CPRM (DVD-R/RW/RAM) supported

Supported Media

(write)

DVD-R

DVD-R DL

DVD-RW

DVD-RAM

DVD+R

DVD+R DL

DVD+RW

CD-R/RW

Maximum speed

Normal

Write

DVD-RW

6X maximum by ZCLV

DVD+RW

8X maximum by ZCLV

CD-RW

24 X maximum by ZCLV

Read

DVD-R/RW/ROM

8 X maximum

DVD-R DL

8 X maximum

DVD-RAM

6 X maximum

DVD-Video

4 X maximum

M-DISC(DVD+R SL)

8 X maximum

DVD+R/+RW

8 X maximum

DVD+R DL

8 X maximum

CD-R/RW/ROM

24 X maximum

CD-DA

24 X maximum

Environmental

(all conditions, non-

condensing)

Temperature

(operating)

Read and Write

5 to 40 ºC

QuickSpecs

HP Storage Solutions for HP Business Notebooks

Technical Specifications

DA - 13066 North America — Version 27 — December 20, 2013

Page 4

condensing)

Relative Humidity

(operating)

10% to 80%

Read

15% to 85% (Non-Condensing)

Write

15% to 80% (Depend on the Temperature)

Temperature

(non-operating)

-30 to 40 ºC

Relative Humidity

(non-operating)

10% to 90% (Non-Condensing)

Operating systems

supported

Windows 8,Windows 7,Windows Vista,Windows

XP,Windows2008,Windows2003,Mac OS X

System requirements

Pentium IV 2.4 GHz or higher, compatible (Recommended: Pentium IV 3.2 GHz

or Higher)

RAM: 256 MB or higher (Recommended: 128 MB)

HDD: 20 GB or more of available space

Video Memory: 64 MB or higher (Recommend: 128 MB)

Interface: USB 2.0

Option kit contents

HP Mobile USB DVD/RW Drive, software, documentation

HP 2011 BNB Notebook

Upgrade Bay DL DVD+/-

Drive

Manual tray-load

Orientation

Horizontal or vertical

Technology

SATA

Interface

Gen 1 SATA

Transfer Mode

UDMA Mode 5

Dimensions

(HxWxD)

0.37 x 5.75 x 5.04 in (0.95 x 14.6 x 12.8 cm)

Form Factor

12.7mm SuperMulti

Capacity

Read

Up to 8.5 GB

Write

Up to 8.5 GB

Access Times

< 175 ms

DVD

< 230 ms

Max Data transfer rates

(sustained)

24X CD-ROM

Up to 3,600 KB/s

8X DVD

Up to 10,800 KB/s

24X CD-R

Up to 3,600 KB/s

16X CD-RW

Up to 2,400 KB/s

8X DVD+R

Up to 10,800 KB/s

4X DVD+RW

Up to 5,400 KB/s

8X DVD-R

Up to 10,800 KB/s

4X DVD-RW

Up to 5,400 KB/s

2.4X DVD+R(9)

Up to 2,700 KB/s

5X DVD-RAM

Up to 6,750 KB/s

QuickSpecs

HP Storage Solutions for HP Business Notebooks

Technical Specifications

DA - 13066 North America — Version 27 — December 20, 2013

Page 5

Supported Media

(read)

CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD,

CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA,

Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10,

DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW, DVD-RAM

Supported Media

(write)

CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM

Max Media Capacity

(read)

8.5 GB

Max Media Capacity

(write)

8.5 GB

Power

Four-pin, DC power receptacle

DC Power Requirement: 5 VDC ± 5%-100 mV ripple p-p

Environmental

(all conditions, non-

condensing)

Temperature

(operating)

50° to 95° F (10° to 35° C)

Relative Humidity

(operating)

10% to 90%, non condensing

Maximum Wet Bulb

Temperature

(operating)

101.6° F (38.7° C)

Operating systems

supported

Windows® 2000, Windows XP Professional, Windows XP Home, Windows

Vista®, Windows 7

Option kit contents

HP 2011 BNB Notebook Upgrade Bay DL DVD+/-RW or HP SuperMulti (DL)

DVD+/-RW SATA Drive, documentation

Removable Hard Drives

HP 500 GB 7200rpm

SED Hard Drive

Drive Weight

0.21 lb (95 g)

Capacity

500 GB

Height

0.28 in (7 mm)

Width

xx in (xx mm)

Interface

ATA-2, SATA 2.5, xx Gb/s, NCQ

Transfer Rate

Synchronous

(maximum)

Up to 300 MB/s (Drive Capability)

Seek Time

(typical reads, including

settling)

Single Track

1.1ms

Average

13ms

Maximum

25ms

Rotational Speed

7200 rpm

Logical Blocks

976,773,168

Operating Temperature

32° to 140° F (0° to 60° C) [case temp]

Features

ATA Security

QuickSpecs

HP Storage Solutions for HP Business Notebooks

Technical Specifications

DA - 13066 North America — Version 27 — December 20, 2013

Page 6

HP 500 GB 7200rpm

Primary SATA Hard Drive

Drive Weight

0.25 lb (115g)

Capacity

500 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-8, SATA 2.6, 3.0 Gb/s, NCQ

Transfer Rate

Synchronous

(maximum)

150 MB/s (Drive Capability)

Seek Time

(typical reads, including

settling)

Single Track

1.5ms

Average

11ms

Maximum

22ms

Rotational Speed

7200 rpm

Logical Blocks

976,773,168

Operating Temperature

32° to 140° F (0° to 60° C) [case temp]

Features

ATA Security

HP 750 GB 7200rpm

Primary SATA Hard Drive

Drive Weight

0.25 lb (115g)

Capacity

750 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-8, SATA 2.6, 3.0 Gb/s, NCQ

Transfer Rate

Synchronous

(maximum)

300 MB/s (Drive Capability)

Seek Time

(typical reads, including

settling)

Single Track

1.5ms

Average

11ms

Maximum

22ms

Rotational Speed

7200 rpm

Logical Blocks

1,465,149,168

Operating Temperature

32° to 140° F (0° to 60° C) [case temp]

Features

ATA Security

HP Upgrade Bay 750 GB

Hard Drive

Drive Weight

0.44 lb (0.198 kg) with one bezel

Capacity

750 GB

Height

0.50 in (1.27 cm)

Width

5.04 in (12.8 cm)

Interface

ATA-8, SATA 2.6, 3.0 Gb/s, NCQ

Transfer Rate

300 Mb/s

Operating Temperature

32° to 140° F (0° to 60° C) [case temp]

Features

ATA Security

QuickSpecs

HP Storage Solutions for HP Business Notebooks

Technical Specifications

DA - 13066 North America — Version 27 — December 20, 2013

Page 7

Solid State Drives

128 GB Solid State Drive

Capacity

128 GB

NAND Flash Memory

Multi Level Cell (MLC) with wear leveling controller

Interface type

SATA 6.0Gb/sec

Dimensions-external

(W x H x D)

2.75 x 0.26 x 4 in (69.85 x 6.80 x 100.2 mm)

Weight

0.12 lb (55 g)

Internal transfer rate

Write speed

Up to 340 MB/s

Read speed

Up to 120 MB/s

Host transfer rate

Ultra DMA mode

Up to 150 MB/s

Power

DC power requirement

5 VDC 5%-100 mV ripple p-p

Total power consumption

<1.12Watt

Environmental

(all conditions, non-

condensing)

Temperature

(operating)

32° to 158° F (0° to 70° C)

Relative Humidity

(operating)

5% to 95%

Maximum Wet Bulb

Temperature

(operating)

84° F (29° C)

Operating systems

supported

Windows XP Professional, Windows XP Professional x64 or Windows XP

Home, Windows 7/8/8.1No driver is required for this device. Native support is

provided by the operating system.

Regulations

UL, CSA, EN 60950-2000, CISPR Pub 22 Class B, CNS 13438, AS/NZS CISPR

22:2002 Class B, R1113 and C1172 Class B

Option kit contents

HP 128 GB Solid State Drive, documentation

* For solid state disk drives, GB means 1 billion bytes. 16 GB is the unformatted capacity of this drive

before a portion of the drive is reserved for flash management features. Actual capacity varies by content

and will be less than 15.8GB.

QuickSpecs

HP Storage Solutions for HP Business Notebooks

Technical Specifications

DA - 13066 North America — Version 27 — December 20, 2013

Page 8

HP 180 GB Solid State

Drive

Capacity

180 GB

NAND Flash Memory

Multi Level Cell (MLC)

Interface type

SATA 6Gb/sec (SATA Gen3 compliant)

Dimensions-external

(W x H x D)

2.74 x 0.276 x 3 in (6.98 x 0.70 x 10.2 cm)

Weight

0.17 lb (78 g)

Internal transfer rate

Write speed

Up to 550 MB/s

Read speed

Up to 520 MB/s

Power

DC power requirement

950 mW (typical non-DIPM)

Total power consumption

<3.2 Watts (typical)

Environmental

(all conditions, non-

condensing)

Temperature

(operating)

32° to 158° F (0° to 70° C)

Relative Humidity

(operating)

5% to 95%

Maximum Wet Bulb

Temperature

(operating)

84° F (29° C)

Regulations

UL, CE, C-tick, BSMI, KCC, Microsoft WHQL, VCCI, SATA-IO

Option kit contents

HP 180 GB Solid State Drive, documentation

HP 256 GB SED

Solid State Drive

Capacity

256 GB

NAND Flash Memory

Multi Level Cell (MLC) with wear leveling controller

Interface type

SATA 6 Gb/sec (SATA Gen3 compliant)

Dimensions-external

(W x H x D)

2.74 x 0.276 x 3 in (6.98 x 0.70 x 10.2 cm)

Weight

0.16 lb (73 g)

Internal transfer rate

Write speed

Up to 450 MB/s

Read speed

Up to 260 MB/s

Host transfer rate

Ultra DMA mode

Up to 100 MB/s (Support Ultra DMA 5)

Power

DC power requirement

5 VDC 5%-100 mV ripple p-p

Total power consumption

< 4.50 Watt (max value)

Environmental

(all conditions, non-

condensing)

Temperature

(operating)

32° to 158° F (0° to 70° C)

Relative Humidity

(operating)

5% to 95%

Maximum Wet Bulb

Temperature

(operating)

84° F (29° C)

Operating systems

supported

Windows

7 Home Basic 32-bit, Windows 7 Home Premium 32- and 64-bit,

Windows 7 Professional 32- and 64-bit, Windows XP Professional 32-bit,

Windows XP Professional x64 or Windows XP Home. No driver is required for

this device, although the HP-tested driver is recommended. Native support is

provided by the operating system.

Regulations

UL, CSA, EN 60950-2005, CISPR Pub 22 Class B, CNS 13438, AS/NZS CISPR

22:2002 Class B, R1113 and C1172 Class B

QuickSpecs

HP Storage Solutions for HP Business Notebooks

Technical Specifications

DA - 13066 North America — Version 27 — December 20, 2013

Page 9

Option kit contents

HP 256 GB SED Solid State Drive, documentation

*For solid state disk drives, GB means 1 billion bytes. 16 GB is the unformatted capacity of this drive

before a portion of the drive is reserved for flash management features. Actual capacity varies by content

and will be less than 15.8 GB.

Spares Information

Optical Drives

HP Mobile USB DVD/RW

SPS-DRV DVD RW

DL LS External

659940-001

SPS-ADAPTER

PWR USB 5V 2A

619240-001

HP Upgrade Bay -- SuperMulti (DL) DVD+/-RW SATA Drive

375197-001

Removable Hard Drives

HP 320 GB 7200rpm SED Hard Drive

618243-001

HP 2011 Upgrade Bay 500 GB Hard Drive

657405-001

(drive)

657406-001

(cradle)

657407-001

(bezel kit)

Compatibility

Optical Drives

Compatible Notebooks

HP Mobile USB DVD/RW

All HP Business Notebook PCs

HP 2011 BNB Notebook Upgrade Bay DL DVD+/-RW

HP ProBook b-series Notebook PCs

HP EliteBook 2170p Notebook PC

All 2011 and 2012 HP EliteBook 8XXX p-series Notebook PCs

All 2011 and 2012 w-series Mobile Workstations

Removable Hard Drives

Compatible Notebooks

HP 500 GB 7200rpm SED Hard Drive

HP EliteBook 8570w and 8770w Mobile Workstations

HP ProBook 6470b, 6475b and 6570b Notebook PCs

HP EliteBook 2170p and 2570p Notebook PCs

Folio 9470m Notebook PC

HP 500 GB 7200 rpm Primary SATA Hard Drive

HP ProBook 430 G1, 440 GO, 450 GO, 470 GO, 445 G1 , 450 G1,470

G1, 640 G1, 650 G1, 645 G1, 655 G1, 4440s, 4540s, 4740s,

4445s/4446s, 4545s, 6470b, 8470p, 6570b, 8570p

Notebook PCs

HP EliteBook 820 G1, 840 G1, 850 G1, 2570P, Folio 9470m

HP ZBook 15 and 17 Mobile Workstations

HP EliteBook 8570w and 8770 Mobile Workstations

HP 750 GB 7200 rpm Primary SATA Hard Drive

HP ProBook 4XXX s-series Notebook PCs larger than 14 diagonal

inches

QuickSpecs

HP Storage Solutions for HP Business Notebooks

Technical Specifications

DA - 13066 North America — Version 27 — December 20, 2013

Page 10

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HP Stockage

HP DW017B - StorageWorks Ultrium 448 Tape Drive Mode d’emploi

HP Surestore Tape Library Model 6/100 Manuel

HP 345524-B21 Manuel utilisateur

HP SCSI Ultra320 Guide d'installation

HP Surestore Tape Library Model 10/180 Guide de démarrage rapide

HP C450W Manuel utilisateur

HP LTO-4 Ultrium 1760 Manuel du produit

HP StorageWorks XP10000 - Disk Array Manuel utilisateur

HP StorageWorks NAS 1000s Manuel utilisateur

HP 624192-B21 Instructions d'utilisation

HP StorageWorks SB920c Tape Blade Instructions de montage

HP 201723-B21 - HP StorageWorks Modular SAN Array 1000 Hard... Mode d’emploi

HP Surestore Tape Library Model 2/28 Manuel utilisateur

HP StorageWorks 1000 - Modular Smart Array Manuel d'utilisation et d'entretien

HP C7401A - SureStore Ultrium 230 Tape Drive Manuel du produit

HP Surestore Disk Array 12h - And FC60 Manuel utilisateur

HP Surestore 6164 - Switch Manuel utilisateur

HP StorageWorks 2000fc Manuel utilisateur

HP StorageWorks SDLT 600 Guide d'installation

HP StorageWorks 4000/6000/8000 - Enterprise Virtual... Mode d’emploi

HP P9000 Manuel utilisateur

HP STORAGEWORKS MSL4048 Instructions d'utilisation

HP EVA P6000 Guide de démarrage rapide

HP Xw4550 - Workstation - 2 GB RAM Manuel utilisateur

Manuels Stockage populaires d'autres marques

QNAP

QNAP TS 32PXU Series Manuel utilisateur

LaCie

LaCie RUGGED RAID Manuel utilisateur

Freecom

Freecom CLS DOCK Manuel utilisateur

PNY

PNY Attache P-FD64MBATT3 Manuel utilisateur

OLT

OLT 6x6 Maximizer Manuel utilisateur

Transcend

Transcend JetFlash 160 Manuel utilisateur

LaCie

LaCie RUGGED MINI Manuel utilisateur

Thunderbolt

Thunderbolt 600 Manuel utilisateur

Panasonic

Panasonic LB-DH8 series Manuel

Intel

Intel RAID High Availability Manuel utilisateur

LaCie

LaCie 12big Thunderbolt 3 Manuel utilisateur

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic

Panasonic LKM-F931-1 Manuel utilisateur

Tabernus

Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor

Rocstor COMMANDER 3F series Manuel utilisateur

Western Digital

Western Digital Ultrastar Data60 Manuel utilisateur

Dell

Dell PowerVault MD3600f Series Manuel utilisateur

CFI

CFI TERA STOR SATA RAID IV Manuel utilisateur
