Installation Guide

Notice

The information contained in this document is subject to change without notice.

Hewlett-Packard makes no warranty of any kind with regard to this

material, including, but not limited to, the implied warranties of

merchantability and fitness for a particular purpose.

Hewlett-Packard shall not be liable for errors contained herein or for incidental

or consequential damages in connection with the furnishing, performance, or use

of this material.

Hewlett-Packard assumes no responsibility for the use or reliability of its

software on equipment that is not furnished by Hewlett-Packard.

This document contains proprietary information that is protected by copyright.

All rights are reserved. No part of this document may be photocopied,

reproduced, or translated to another language without the prior written consent

of Hewlett-Packard Company.

Microsoft®, Windows® and MS-DOS® are registered trademarks of Microsoft

Corporation.

MMX TM is a trademark of Intel Corporation.

Pentium® is a registered trademark of Intel Corporation.

Hewlett-Packard France

Business Desktop Division

38053 Grenoble Cedex 9

France

Read This First

Before installing the network adapter:

If your OS is Windows NT 4.0, go into the BIOS setup and set PnP OS field to NO.

If your OS is Windows 98 2nd edition, go into the BIOS setup and set PnP OS field to

YES.

If your OS is Windows 2000 Professional, go into the BIOS setup and set PnP OS

field to YES.

If your OS is Windows NT4.0 and Wake on LAN capability is needed, go into the

BIOS setup and enable power-up when a specific command is received by the

Network Interface.

For all OS, remove any previously installed network adapter (usually located in slot

#5) if it is not needed.

Installing the network adapter in slot #4 is recommended. HP has tested this

installation procedure using slot #4.

For advanced users only: In case of resource conflict, you can try to change the

resources for the network adapter. To do this, turn the Vectra system power off,

remove the network adapter and install it into a different PCI slot.

Connecting to a Novell NetWare 5.1 or 4.11 Server

Microsoft Windows NT 4.0 Workstation

Requirements

Operating System Windows NT 4.0 Workstation

Driver Version 5.00.66.0000

Driver File E100BNT.SYS

Server OS NetWare 5.1 or 4.11 Server

Client OS Client v4.80 for Windows 95/98

Procedure

1. With the HP Vectra turned off, install the network adapter into an available PCI

slot.

2. Connect the network cables to the newly installed network adapter.

3. Power on the machine and boot to Windows.

4. Logon to Windows with administrator privileges.

5. Click OK to ignore the warning message indicating a driver failed during system

startup. This is caused the removal of the previously installed network adapter.

This message should no longer appear after removing the driver from the

Network properties.

6. The following steps are based on a subsequent installation of Networking on the

system. Adding a network adapter for the first time has some minor differences.

Ask your administrator for more information.

7. Open the Network properties windows to remove a previously installed network

adapter and to add a new one.

8. Click on the “Adapters”tab and highlight the network adapter you want removed

then click on the “Remove”button.

9. Click on the “Adapters”tab then on the “Add”button.

10. Insert the driver disk and click on “Have Disk”.

11. Type in the location of the drivers and click on “OK”.

12. With “Intel(R) PRO Adapter”highlighted, click on “OK”.

13. Additional changes in the Network properties, such as: workgroup name,

computer name, TCP/IP properties, etc. may be necessary. Ask your Network

Administrator for more information.

14. The NetBEUI protocol can not be used. The installation of the NetBEUI protocol

for each port registers the computer name twice in the same workgroup. In

Windows, computers can not have the same name within a workgroup. Under

the Protocols tab, select the NetBEUI Protocol and click on the Remove button.

15. Click on “Close”to complete the installation.

16. Remove the driver disk and click on “Yes”when prompted to restart your

computer.

17. Logon to Windows with administrator privileges.

18. From the location of the “Novell Client v4.80 for Windows NT/2000”installation

files, execute “SETUPNW.EXE”.

19. Select either “Typical”or “Custom”and click on “Install”. Typical Installation is

normally chosen. Select Custom Installation only if you are an administrator or an

advanced user. When prompted for options during installation, ask your Network

Administrator for more information.

20. Click on “Yes”to agree with the Novell Terms and Conditions to proceed with the

installation.

21. Click on “Reboot”to restart the system once the installation is complete.

22. Logon to Windows with administrator privileges and re-install the current service

pack.

Connecting to a Microsoft Windows 2000 Advanced or NT 4.0

Server

Microsoft Windows NT 4.0 Workstation

Requirements

Operating System Windows NT 4.0 Workstation

Driver Version 5.00.66.0000

Driver File E100BNT.SYS

Server OS Windows 2000 Advanced or NT 4.0

Server

Client OS Microsoft

Procedure

1. With the HP Vectra turned off, install the network adapter into an available PCI

slot.

2. Connect the network cables to the newly installed network adapter.

3. Power on the machine and boot to Windows.

4. Logon to Windows with administrator privileges.

5. Click OK to ignore the warning message indicating a driver failed during system

startup. This is caused the removal of the previously installed network adapter.

This message should no longer appear after removing the driver from the

Network properties.

6. The following steps are based on a subsequent installation of Networking on the

system. Adding a network adapter for the first time has some minor differences.

Ask your administrator for more information.

7. Open the Network properties windows to remove a previously installed network

adapter and to add a new one.

8. Click on the “Adapters”tab and highlight the network adapter you want removed

then click on the “Remove”button.

9. Click on the “Adapters”tab then on the “Add”button.

10. Insert the driver disk and click on “Have Disk”.

11. Type in the location of the drivers and click on “OK”.

12. With “Intel(R) PRO Adapter”highlighted, click on “OK”.

13. Additional changes in the Network properties, such as: workgroup name,

computer name, TCP/IP properties, etc. may be necessary. Ask your Network

Administrator for more information.

14. The NetBEUI protocol can not be used. The installation of the NetBEUI protocol

for each port registers the computer name twice in the same workgroup. In

Windows, computers can not have the same name within a workgroup. Under

the Protocols tab, select the NetBEUI Protocol and click on the Remove button.

15. Click on “Close”to complete the installation.

16. Remove the driver disk and click on “Yes”when prompted to restart your

computer.

17. Logon to Windows with administrator privileges and re-install the current service

pack.

Connecting to a Novell NetWare 5.1 or 4.11 Server

Microsoft Windows 98 2nd edition

Requirements

Operating System Windows 98 2nd edition

Driver Version 3.37.07.0000 (Embedded in OS)

Driver File E100BNT.SYS

Server OS NetWare 5.1 or 4.11 Server

Client OS Client v3.30 for Windows 95/98

Procedure

1. With the HP Vectra turned off, install the network adapter into an available PCI

slot.

2. Connect the network cables to the newly installed network adapter.

3. Power on the machine and boot to Windows.

4. Windows will detect the network adapter as “Intel(R) PRO/100+ Dual Port Server

Adapter”during start up and automatically install its embedded driver.

5. Click on “Yes”when prompted to restart the system.

6. If the NetBEUI protocol is used, two error messages will appear indicating a

duplicate computer name exists on the network. The NetBEUI protocol is utilized

for each port of the network adapter and registers the computer name twice in the

same workgroup. In Windows, computers can not have the same name within a

workgroup. Ignore these error messages temporarily by clicking on OK.

7. If NetBEUI is necessary, make sure that it is used only on one port of the network

adapter. Open the Network properties and under the Configuration tab, select the

NetBEUI Protocol and remove it by clicking on the Remove button.

8. Additional changes in the network properties, such as: workgroup name,

computer name, TCP/IP properties, etc. may be necessary. Ask your Network

Administrator for more information. After changes are made, a restart will be

necessary.

9. From the location of the “Novell Client v3.30 for Windows 95/98”installation files,

execute “Setup.exe”.

10. Click on “Yes”to accept the “Novell Terms and Conditions”.

11. Select either “Typical”or “Custom”and click on “Install”. Typical Installation is

normally chosen. Select Custom Installation only if you are an administrator or an

advanced user. When prompted for options during installation, ask your Network

Administrator for more information.

12. Click on “Reboot”once the installation is complete.

Known Problems

Problem1

There is an issue with waking up the system. Currently there is no resolution to the

problem. However, the problem can be prevented by not placing the system on

Stand by. Also, the Power Management properties’"Turn off monitor:" and “System

standby:”settings must be set to “Never”.

Connecting to a Microsoft Windows 2000 Advanced or NT 4.0

Server

Microsoft Windows 98 2nd edition

Requirements

Operating System Windows 98 2nd edition

Driver Version 5.01 (Embedded in OS)

Driver File DC21X4.SYS
