HP Quick Release EM870AA Instructions d'utilisation
1.
Release/locking
1.
Four 100 mm VESA mount screw holes
1.
Locking pin screw
2.
Four 100 mm VESA mount screw holes
2.
Locking pin hole on release/locking arm
Models
Part Numbers:
HP Quick Release: EM870AA
Introduction
HP offers a variety of optional products (each sold separately) designed to complement our monitors and enhance the overall
computing experience. The HP Monitor Quick Release is designed for use with 100 mm VESA-compatible flat panel monitors.
HP Quick Release is an easy to use, 100 mm VESA-compliant, LCD monitor mounting solution that allows you to quickly and securely
attach a flat panel monitor to a variety of stands, brackets, arms or wall mounts. HP Quick Release can also be used for mounting any
combination of devices that are compatible with the 100 mm VESA Flat Display Mounting Interface Standard. The failsafe "Sure-Lock"
mechanism snaps the monitor (or mounted device) securely in place, and can be further secured with a theft-deterrent security screw.
QuickSpecs
HP LCD Monitor Quick Release
Overview
DA - 12397 North America — Version 37 — April 1, 2014
Page 1
Uniquely flexible product configurations
HP Quick Release enables uniquely flexible product configuration alternatives in a variety of settings, such as:
Storefronts/kiosks: Mount flat panel monitors for easy viewing and add touchscreens for interactivity.
Trade shows: Securely mount LCD TVs or monitors in common areas and quickly remove them for safekeeping at the end of the
day.
Front office environments: Minimize desk space requirements with wall or swing-arm mounting of monitors in reception areas.
Training labs: Mount a monitor directly on a 100 mm VESA-compatible PC such as the HP Compaq 8200 Elite USDT or an HP Thin
Client for all-in-one convenience.
Medical/institutional settings: Securely mount monitors in nursing stations and public areas.
Conference rooms: Mount projectors (with 100 mm VESA-compliant pre-drilled holes) on ceilings, and monitors on walls or
tables.
Compatibility
The HP LCD Monitor Quick Release is designed to integrate with select HP flat panel monitors, in configurations as noted below, as well
as HP Thin Clients or an HP USDT PC.
Compatible HP LCD monitor
mounting scenarios
Direct mounting of monitor to
wall
Direct mounting of monitor to
mounting arm or bracket
Mounting of select thin client
products or HP USDT between
monitor and
wall/arm/bracket
***
ProDisplay
All ProDisplay Series Products are
compatible with the HP Quick
Release
EM870AA
*
EM870AA
*
EM870AA
*
LE1852ms
EM870AA
*
EM870AA
*
EM870AA
*
EliteDisplay
All EliteDisplay Series Products
are compatible with the HP Quick
Release
EM870AA
*
EM870AA
*
EM870AA
*
Business Touchscreen & Specialty Monitors
L2206tm, S230tm
EM870AA
*
EM870AA
*
EM870AA
*
E221c, L2311c, L2401x
EM870AA
*
EM870AA
*
EM870AA
*
*Requires removal of the monitor head from the monitor stand prior to mounting HP Quick
Release.
**Requires use of a second HP Quick Release attached to the base of the monitor stand.
***Requires two separate Quick Release devices.
Performance Monitors
ZR2040w, ZR2240w, ZR2330w, Z22i, Z23i, Z24i, ZR2440w, LP2480zx, ZR30w
Value Monitors
V201, V201a, V241, V241a
QuickSpecs
HP LCD Monitor Quick Release
Overview
DA - 12397 North America — Version 37 — April 1, 2014
Page 2
COMPATIBLE THIN CLIENTS
t310 (requires VESA mount), t410, t510, t5335z, t5550, t5565, t5565z, t5570, t5570e, t5400, T5740, t5740e, t5745, t610, t610PLUS.
COMPATIBLE PC
HP Ultra-Slim Desktop PC
Service and Support
Your Option Limited Warranty is a one (1) year (HP Option Limited Warranty Period) parts replacement warranty on any HP-branded or
Compaq-branded options (HP Options). If your HP Option is installed in an HP Hardware Product, HP may provide warranty service
either for the HP Option Limited Warranty Period or the remaining Limited Warranty Period of the HP Hardware Product in which the HP
Option is being installed, whichever period is the longer but not to exceed three (3) years from the date you purchased the HP Option.
QuickSpecs
HP LCD Monitor Quick Release
Overview
DA - 12397 North America — Version 37 — April 1, 2014
Page 3
1.
2.
3.
Mechanical
Dimensions
(H x W x D)
Packaged:
7.8 x 6.25 x 1.5 in (19.8 x 15.9 x 3.8 cm)
Unpackaged:
6.3 x 5.2 x 0.65 in (16 x 13.2 x 1.65 cm)
Weight
Packaged:
1.1 lb (0.49 kg)
Unpackaged:
0.82 lb (0.37 kg)
Additional components
Eight 10 mm mounting screws (for attachment to VESA compliant monitor mounts)
Eight 15.5 mm mounting screws (for attachment to HP thin client products)
Four 20 mm mounting screws (for attachment to back of select HP flat panel monitor stands)
One Quick Release "locking" screw
2mm and 7mm spacers
2 mm spacer accommodates:
Advantage: LA2006x, LA2206x, LA2206xc, LA2306x
Specialty: L2311c
7 mm spacer accommodates:
ZR2240W, ZR2440W, Z24i
Color
Black
Notes:
No HP monitors allow positioning of a thin client product between a monitor screen and its stand.
The Quick Release device is not to be used between a monitor screen and its stand unless provided
that way from the factory.
Under no circumstances is the Quick Release device intended to be used in an orientation where the
Release/Lock lever is oriented downward.
Supported weight
capacity
The HP Quick Release has been designed to support a maximum of up to 24 lbs (10.9 kg) depending upon
the mounting configuration used. Please note this is a total weight limit for all devices mounted, i.e. the
combined weight of the monitor and a second device such as an HP thin client product cannot exceed 24
pounds. Because mounting surfaces vary widely and the final mounting method and configuration may
vary, mounting fasteners are not supplied (other than the VESA-compliant screws). HP recommends that
you consult with a qualified engineering, architectural or construction professional to determine the
appropriate type and quantity of mounting fasteners required for your application and to ensure that your
mounting solution is properly installed to support applied loads.
© 2009-2014 Hewlett-Packard Development Company, L.P. HP shall not be liable for technical or editorial errors or omissions
contained herein. The information is provided as is without warranty of any kind and is subject to change without notice. The
warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein
should be construed as constituting an additional warranty. All performance specifications are provided by the component
manufacturer. Performance specifications represent component manufacturer averages and actual performance may vary.
QuickSpecs
HP LCD Monitor Quick Release
Technical specifications (EM870AA)
DA - 12397 North America — Version 37 — April 1, 2014
Page 4
