HP System/E41 Manuel utilisateur

Rack System/E

User’s Manual

System/E41

System/E33

System/E25

Notice

The information contained in this document is subject to change without notice.

Hewlett-Packard makes no warranty of any kind with regard to this material, including, but

not limited to, the implied warranties of merchantability and fitness for a particular purpose.

Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages

in connection with the furnishing, performance, or use of this material.

This document contains proprietary information that is protected by copyright. All rights are reserved. No

part of this document may be photocopied, reproduced, or translated to another language without the

prior written consent of Hewlett-Packard Company.

Hewlett-Packard Company

10955 Tantau Avenue

Cupertino, CA 95014

Warranty

HP offers a one-year warranty for Quartz Gray model A4902A, A4901A, A4900A

and Graphite model A4902D, A4901D.

1. HP warrants HP hardware, accessories, and supplies against defects in

materials and workmanship for the period specified above. If HP receives

notice of such defects during the warranty period, HP will, at its option, either

repair or replace products that prove to be defective. Replacement products

may be either new or like-new.

2. HP does not warrant that the operation of HP products will be uninterrupted

or error free. If HP is unable, within a reasonable time, to repair or replace any

product to a condition as warranted, customer will be entitled to a refund of

the purchase price upon prompt return of the product.

3. HP products may contain remanufactured parts equivalent to new in

performance or may have been subject to incidental use.

4. The warranty period begins on the date of delivery or on the date of

installation if installed by HP. If customer schedules or delays HP installation

more than 30 days after delivery, warranty begins on the 31st day from

delivery.

5. Warranty does not apply to defects resulting from (a) improper or

inadequate maintenance or calibration; (b) software, interfacing, parts or

supplies not supplied by HP; (c) unauthorized modification or misuse;

(d) operation outside of the published environmental specifications for the

product; or (e) improper site preparation or maintenance.

6. TO THE EXTENT ALLOWED BY LOCAL LAW, THE ABOVE

WARRANTIES ARE EXCLUSIVE AND NO OTHER WARRANTY OR

CONDITION, WHETHER WRITTEN OR ORAL, IS EXPRESSED OR

IMPLIED AND HP SPECIFICALLY DISCLAIMS ANY IMPLIED

WARRANTIES OR CONDITIONS OF MERCHANTABILITY,

SATISFACTORY QUALITY, AND FITNESS FOR A PARTICULAR

PURPOSE.

7. HP will be liable for damage to tangible property per incident up to the

greater of $300,000 or the actual amount paid for the product that is the

subject of the claim, and for damages for bodily injury or death, to the extent

that all such damages are determined by a court of competent jurisdiction to

have been directly caused by a defective HP product.

8. FOR CONSUMER TRANSACTIONS IN AUSTRALIA AND NEW

ZEALAND: THE WARRANTY TERMS CONTAINED IN THIS

STATEMENT, EXCEPT TO THE EXTENT LAWFULLY PERMITTED,

DO NOT EXCLUDE, RESTRICT, OR MODIFY AND ARE IN ADDITION

TO THE MANDATORY STATUTORY RIGHTS APPLICABLE TO THE

SALE OF THIS PRODUCT TO YOU.

Contents

1Safety and Regulatory Information ...................................................................... 1

Safety Warnings ................................................................................................................... 1

Grounding........................................................................................................................ 1

Leakage Current ................................................................................................................ 1

Power Limitations................................................................................................................ 1

Cabinet Stability ................................................................................................................ 2

Accessories....................................................................................................................... 2

2Description........................................................................................................... 3

Standard Racks..................................................................................................................... 3

Physical Specifications ........................................................................................................ 4

Accessories.......................................................................................................................... 6

3Installation Guidelines........................................................................................ 11

Floor Space and Loading ..................................................................................................... 11

Rack Space .................................................................................................................... 11

Installing Equipment in the Rack ............................................................................................. 11

Ventilation and Heat Dissipation.......................................................................................... 11

Installing Rail Mounted Equipment into the Rack..................................................................... 12

Stability .......................................................................................................................... 13

4Procedures......................................................................................................... 19

Receiving........................................................................................................................... 19

Unpacking, Handling and Moving...................................................................................... 19

Leveling the Rack ............................................................................................................. 22

Repackaging the Rack for Shipment..................................................................................... 22

Installation of Standard Rack Accessories................................................................................. 25

Installing Universal Shelf ....................................................................................................... 25

Installing Keyboard Shelf ...................................................................................................... 26

Installing Monitor Shelf......................................................................................................... 28

Installing Filler Panels ........................................................................................................... 30

Installing Spacers ................................................................................................................ 31

Installing Front Door............................................................................................................. 32

iii

1Safety and Regulatory Information

For your protection, this product has been tested for conformance to various national and international

regulations and standards. The scope of this regulatory testing includes electrical and mechanical safety,

electromagnetic emissions, immunity, ESD, and hazardous materials.

Where required, certifications are obtained from third party test agencies. Certification marks, when

required, appear on the product label. In addition, various regulatory bodies require some information

under the headings below.

This product and related documentation must be reviewed for familiarization with safety markings and

instructions before operation.

WARNING The WARNING sign denotes a hazard. It calls attention to a procedure, practice, or situation

which, if not done correctly or adhered to, could result in injury. Do not proceed beyond a

WARNING sign until the indicated conditions are fully understood and met.

CAUTION The CAUTION sign denotes a hazard. It calls attention to an operating procedure, practice,

or situation which, if not done correctly or adhered to, could damage or destroy part or

the entire product. Do not proceed beyond a CAUTION sign until the indicated conditions

are fully understood and met.

Safety Warnings

The following warnings and cautions are applicable to the System/E rack. Please observe all safe-

ty precautions and warnings.

This product has not been evaluated for connection to an IT power system (an AC distribution

system having no direct connection to earth ground)- according to IEC/EN60950.

Grounding

WARNING This is a safety class I product and has a protective earthing (grounding) terminal. There

must be an uninterruptable safety earth ground from the main power source to the

product’s input wiring terminals, power cord, or supplied cord set. Whenever it is likely

that the protection has been impaired, disconnect the power cord until the ground has

been restored.

Leakage Current

WARNING Due to types of products that can be installed in this cabinet, there is a risk of high

leakage current (3.5 mA). Reliable ground circuit continuity is vital for safe operation of

this product. To reduce the risk of electric shock, earth (ground) connection is essential

before connecting the power supply. Never operate this cabinet with the ground conductor

disconnected.

Power Limitations

CAUTION To reduce the risk of overload, do not load any single PDU with more than its rated maximum.

Cabinet Stability

CAUTION To reduce the risk of cabinet instability, attach the anti-tip feet before installing or extend-

ing any devices. Extend only one device at a time. Do not stand or sit on any extended

device. Qualified service personnel should do all non-operator servicing.

Accessories

CAUTION This product is designed for use with specific electrical accessories (i.e.,PDUs and UPSs).

The use of any other accessory is not recommended or supported.

Chapter 1 Safety and Regulatory Information

WARNING!

IMPORTANT SAFETY NOTE FOR INSTALLATION

For installations using wide-voltage-range-rated switchless power distribution units (PDU part numbers E7670A,

E7671A, E7674A, and E7676A) for connection to an uninterruptable power supply (UPS) or other AC source

• CHECK THE VOLTAGE before connecting any equipment to the PDU! Failure to check the voltage could

lead to severe equipment damage!

The voltage of the PDU receptacles equals the voltage of the receptacle to which the PDU is connected.

This voltage must be within the input voltage range of the equipment and the PDU installed in the rack.

• CHECK THE POWER SOURCE RECEPTACLE to be sure it is installed near the rack and is easily

accessible, so that the plug on the PDU power supply cord can serve as the disconnect device for the rack.

• CHECK THE TOTAL INPUT CURRENT ratings of the equipment installed in the rack to avoid overloading

the PDU or any uninterruptable power supply (UPS) to which it may be connected.

The output current rating of the PDU equals the output current rating of the power source to which the

PDU is connected, but not more than the maximum current rating (amperage) marked on the PDU.

• CHECK THE GROUNDING when installing rack-mounted products with this PDU, there is a risk of high

leakage current. Reliable ground circuit continuity is vital for safe operation of this product. To reduce

the risk of electric shock, earth (ground) connection is essential before connecting the PDU. Never

operate this PDU with the ground conductor disconnected.

WARNING!

To prevent instability leading to possible injury when moving the 2 meter racks (e.g.: A4902A, A4902D)

• Follow all stability instructions in the user guide.

• Push against the rack at the 1.6M (63 inch) height or lower.

• Exercise extra caution when moving rack sideways (racks are more stable from front to back and when full).

2Description

The HP 19-inch Electronics Industries Association (EIA) racks, options, and accessories are designed

specifically to meet the needs of HP computer and storage product customers and make installing devices

in rack mounting systems simple.

Standard Racks

Your standard HP Rack System/E is a welded steel frame with a removable rear door, casters, side panels,

leveling feet, and an anti-tip feet. Figure 2-1 shows how two basic racks might look tied together. The top

is 11-gauge, cold rolled steel. The base is 11-gauge, cold rolled steel. Threaded grounding connections are

provided near two columns at the base, and another at the top, rear.

Racks heights are measured in meters, inches, EIA units, and “U.” 1 EIA unit equals 1 U, which equals

44.45mm (1.75 in). The columns are numbered EIA units. The U41 rack is 1.96m, or 41 EIA units.

Internally, rails and slides that hold your equipment lock into slots in the vertical mounting columns and are

sometimes fastened to the columns with screws. Column faces are numbered for easy placement of equip-

ment. An extendable top adds 8U of height. Tie-together kits allow easy, secure mating of 1.96m cabinets.

Tied together racks with the accessories are shown in Figure 2-2.

Figure 2-1. Two Basic Racks Tied Together (excluding Rear Doors)

Front

Back

Top cap

Anti-tip feet

NOTE: Drawing may not match actual item.

Chapter 2 Description

Figure 2-2. Two Views of Tied racks showing Accessories

Physical Specifications

The physical specifications for the System/E racks are given below.

Packaged Height Width Depth Weight

1.25m (E25) Rack 1.48 m (58.5 in) 1.016 m (40 in) 1.22 m (48 in) 124.5 kg (274 lbs)

1.6m (E33) Rack 1.84 m (72.5 in) 1.016 m (40 in) 1.22 m (48 in) 133.2 kg (293 lbs)

1.96m (E41) Rack 2.2 m (86.5 in) 1.016 m (40 in) 1.22 m (48 in) 142.7 kg (314 lbs)

Unpackaged

Front column to rear column (E25, E33, E41 racks) 71.12 cm (28 in)

Front edge to rear door (E25, E33, E41 racks 92.7 cm (36.5 in)

Front anti-tip foot to rear anti-tip foot (E25, E33, E41 racks) 135.89 cm (53.5 in)

1.25m (E25) Rack 1.26 m – 25U (49.5 in) 59.7 cm (23.5 in) 92.7 cm (36.5 in) 65 kg (144 lbs)

1.6m (E33) Rack 1.61 m – 33U (63.5 in) 59.7 cm (23.5 in) 92.7 cm (36.5 in) 69 kg (153 lbs)

1.96m (E41) Rack 1.97 m – 41U (77.5 in 59.7 cm (23.5 in) 92.7 cm (36.5 in) 73.5 kg (162 lbs)

Note: Graphite colored racks are only available in 1.6 m and 1.96 m heights.

The following parts are standard with

every System/E rack.

Top Cap and Forehead

The top cap is 16-gauge, cold rolled steel

(CRS). The top cap and forehead are

attached at the factory. The top of the

rack incorporates a ventilation path

through the roof of the rack and a

convection current heat exit for the heat

generated by the installed equipment.

Chapter 2 Description

Heavy-duty Columns

The rack columns are a folded design made

of 12-gauge rolled steel that supports up to

2000 lbs. Running up the inside of the fold

are square mounting slots for the rails,

slides, and screw holes for securing the

rails. The hole placement conforms to EIA

standards.

The mounting columns are welded into

place at the bottom corners of the frame,

and bolted at the top. The columns accept

supporting rails into mounting slots. Each

support rail pair attaches between the

front and rear columns. The equipment is

then mounted on the support rails.

The mounting columns have pre-

positioned threaded inserts pressed into

the hexagonal accessories holes in the

front faces of the columns. The inserts are

positioned to accept tie brackets, hinges,

latches, and PDUs.

Anti-Tip Feet

A front and rear anti-tip foot are included

with HP Rack Systems to provide additional

stability. The anti-tip feet must be attached

before installing, servicing, or removing any

equipment. Do not remove the anti-tip feet

unless the optional tie-together kit is used

with multiple racks.

WARNING The stability work sheets should be used whenever a new system is configured, or a

change to a system is made, to assure rack stability.

Chapter 2 Description

Threaded inserts

One

EIA unit

or "U"

Front

Back

Anti-tip feet

Heavy-Duty Casters

Each System/E is provided with four,

7.6 cm (3 in) diameter, smooth rolling,

heavy-duty urethane casters to facilitate

moves over short distances. The casters

are rated at 454.5 kg (1000 lbs) per

caster.

CAUTION A fully loaded cabinet’s maximum gross weight of 995 kg (2188 lbs) can overload a raised floor.

Leveling Feet

Four adjustable leveling feet come with

the rack for stability and leveling.

Levelers are located in each corner to

level and stabilize the rack. For maxi-

mum accuracy, use a level while adjust-

ing the feet.

Rear Door

The rear door comes installed from the

factory. Standard is a right-opening, per-

forated rear door with a lockable slam

latch and sheetmetal catch providing

ventilation and security. The rear door

can be mounted to open from either the

left or the right. They are perforated for

maximum airflow. They lift on and off

their hinges when open to about 45

degrees. The 1.96 m door weighs 11.8

kg (26 lbs). The 1.6 m rear door weighs

9.1 kg (20 lbs). The 1.25 m rear door

weighs 7.7 kg (17 lbs).

Chapter 2 Description

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HP Support et étagère

HP D7171A - NetServer - LPr Manuel utilisateur

HP DL320s - ProLiant 9TB SATA Storage Server... Manuel utilisateur

HP StorageWorks 1000 - Modular Smart Array Manuel utilisateur

HP 245161-B22 - 10642 42U Rack Shock Pallet Instructions d'utilisation

HP StorageWorks SSL1016 Manuel utilisateur

HP E1586A Manuel utilisateur

HP 669048-009 Manuel utilisateur

HP TS5220 Guide d'installation

HP Quick Release EM870AA Instructions d'utilisation

HP P5389A - Intel Pentium III-S 1.4 GHz Processor... Manuel utilisateur

HP 11000 G2 series Manuel utilisateur

HP HP 10000 G2 Series Manuel utilisateur

HP 245161-B22 - 10642 42U Rack Shock Pallet Manuel utilisateur

HP J1530C Manuel utilisateur

HP A4838A Manuel utilisateur

HP Model 745 - VME Workstation Manuel utilisateur

HP 6400/8400 Manuel utilisateur

HP LaserJet Enterprise 600 Manuel utilisateur

HP ProCurve 6600-48G-4XG Manuel utilisateur

HP HP 10000 G2 Series Manuel utilisateur

HP AT-BT10 Manuel utilisateur

HP TFT7600 G2 Manuel utilisateur

HP cc2300 Manuel utilisateur

HP ML110 - ProLiant G5 2TB Storage Server NAS Manuel utilisateur

Manuels Support et étagère populaires d'autres marques

Salamander

Salamander Acadia AC/W/L400/WH Manuel utilisateur

Fohhn

Fohhn VAT-09 Guide de l'utilisateur

ricoo

ricoo FS0522 Manuel utilisateur

AMSOIL

AMSOIL BMK-22 Guide rapide

Kargo Master

Kargo Master 48220 Manuel utilisateur

Milestone AV Technologies

Milestone AV Technologies SIMPLICITY SLF2 Manuel utilisateur

ricoo

ricoo S1222 Manuel utilisateur

Ready-Set-Mount

Ready-Set-Mount RSMCM602 Manuel utilisateur

VidaBox

VidaBox VB MNT FFS2 Manuel utilisateur

Welch Allyn

Welch Allyn 48960 Manuel utilisateur

Arkon

Arkon CM035-ST-2 Manuel utilisateur

PROEL

PROEL PLWIN60C Manuel utilisateur

Agilent Technologies

Agilent Technologies E2609B Manuel utilisateur

Mustang

Mustang MV-ARM4 Manuel utilisateur

Mounting Solutions

Mounting Solutions WRM-320 Manuel utilisateur

Pyle

Pyle PMKSPAD1 Manuel utilisateur

ShelterIt

ShelterIt 21208 Manuel utilisateur

SPL

SPL RackPack?4 1040 Manuel utilisateur
