HP P650 Manuel utilisateur

p650

Digital Camera

Appareil photo numérique

Cámara digital

Câmera digital

Quick Start Guide

Guide de démarrage rapide

Guía rápida

Guia rápido de instruções

For the full version of the p650 product user manual go to: www.hp.com/support

Pour la version complète du manuel d’utilisateur du modèle p650, allez sur: www.hp.com/support

Para descargarse la versión completa del manual de instrucciones del modelo p650, puede acceder al siguiente enlace: www.hp.com/support

Para a versão completa do manual da p650, visite: www.hp.com/support

•Camera

NOTE

• Note that the battery of a newly purchased camera is not charged. Perform the

steps below to load the battery into the camera and charge it.

• Use only the provided  or type of battery and charger that came with your

camera. Using other types of battery or charger may damage the equipment and

invalidate the warranty.

Quick Start Guide

General Guide

ENGLISH

1 2 3 4 5 6 7

[ ]

[

SET

]

[ ]

18 17 16 15 14

11 12 13

1 Zoom controller

2 Shutter button

3 Front lamp

4 [ON/OFF] (Power)

5 Flash Cover

6 Flash 

7 Strap 

8Lens

9 Microphone

10 [ ] (REC) button

11 LED 

12 [ ] (Movie) button

13 Strap 

14 [SET] button

15 [ ] (Delete) button

16 [ ] (PLAY) button

17

([ ][ ][ ][ ])



Back

19 Battery/memory card slots

20 Tripod hole

Use this hole when attaching to a tripod.

Front

Bottom

The first time you load a battery into the camera, a screen appears for configuring the

display language, date, and time settings. Failure to set the date and time correctly

will cause the wrong date and time data to be recorded with images.

1. Press [ON/OFF] (Power) to  on the

camera.

2. Use [ ], [ ], [ ], and [ ] to select the

language you want and then press

[SET].

3. Use [ ] and [ ] to select a date format and then press [SET].

4. Set the date and the time.

Use [ ] and [ ] to select the setting you want to

change and then use [ ] and [ ] to change it.

To switch between 12-hour and 24-hour format, press

[ ] (Movie).

5. After setting the date and time, use [ ] and [ ]

to select “Apply” and then press [SET].

Configuring Basic Settings the First Time You Turn On the

Camera

[ ]

[

SET

]

[ ]

[ON/OFF] (Power)

[ ] (Movie)

There are 5 modes can be set by turning the Mode dial, such as Voice REC,

Intelligent Scene, Scene mode, Record Mode, ART mode. Once turning the Mode

dial, it will enter the selected mode immediately even in Playback mode or during

movie recording.For detail operation, please see the following sections.

The table below shows the available settings for Mode dial.

Using the mode dial

Voice REC This mode is used to record audio clips.

Intelligent

Scene

The camera detects the shooting conditions

and automatically switches to the appropriate

scene mode.

Scene mode

Turns the mode dial to enter last used Scene

mode. Press the MENU button to select other

scene mode.

Auto Mode

Turns the mode dial to enter Auto mode. It’s

the simplest way to shoot basic images.

Settings are adjusted automatically.

ART mode This function applies different art  on the



1. In the , press [SET].

This will select one of the Control Panel icons and display its settings.

2. Use [ ] and [ ] to select the setting you want to change.

*!"#$

3. Use [ ] and [ ] to change the setting.

4. If you want to configure another setting, repeat steps 2 and 3.

5. After all of the settings are the way you want, press [SET].

This will apply the settings and return to the mode.

If you selected “MENU”, the REC menu will appear.

If you selected “SCN”, the Scene Mode scene menu will appear.

• You can close the Control Panel by pressing (Disable).

Using the Control Panel

Control Panel

Available settings

[SET]

[][][][]

1 size/quality*

2 Movie image quality

3Flash

4Self-timer

5SoftSkin

%&'*

7 Silent

8

9 Scene Mode

1. Configure the quality setting for the movie.

The length of the  you can record will depend on the quality setting you

select.

2. In the REC mode, point the camera

at the subject and then press

[ ] (Movie).

This will start recording and display

on the monitor screen.

Movie recording includes monaural

audio.

3. Press [ ] (Movie) again to stop

recording.

Movie recording also will stop

automatically if memory becomes full

before you press [ ] (Movie).

1. In the REC mode, press [SET].

2. Use [ ] and [ ] to select the

bottom Control Panel option (SCN)

and then press [SET].

This will display a menu of Scene Mode

scenes.

• The initial default selection is

(Auto).

3. Use [ ], [ ], [ ], and [ ] to move

the boundary to the scene you

want to select.

• The scene menu has multiple pages.

Use [ ] and [ ] to scroll between menu pages.

• You can access information about the currently selected scene.

• To return to normal snapshot recording, select Scene 1 (Auto).

To record a movie

To  with Scene Mode

Recording time

Remaining recording time

[ ] (Movie)

Scene number

Scene name

[SET]

[ ] [ ] [ ] [ ]

Currently selected scene

(with boundary)

4. Press [SET] to configure the camera with the settings for the currently

selected scene.

This returns to the REC mode.

• The settings of the scene you selected remain in effect until you select a

different scene.

• To select a different Scene Mode scene, repeat the above procedure from

step 1.

5. Press the shutter button (if you are ) or

(Movie) (if you are ).

•Example REC Menu Screen Operation

1. In the REC mode, press [SET].

2. Use [ ] and [ ] to select the second Control Panel

option from the bottom (MENU) and then press

[SET].

This will display the REC menu screen.

3. Use [ ] and [ ] to select the tab where the menu

item you want to configure is located.

4. Use [ ] and [ ] to select the menu item you

want, and then press [ ].

5. Use [ ] and [ ] to change the setting of the

selected menu item.

6. After the setting is the way you want, press

[SET] to apply the setting and return to the

viewfinder screen.

• Pressing [ ] instead of [SET] applies the

selected setting and returns to the menu item

selection.

• To configure settings on another tab after

pressing [ ] to return to the menu item selection,

use [ ] or [ ] (Delete) to move the highlighting

up to the tabs, and then use [ ] and [ ] to select

the tab you want.

NOTE

• [ ] (Delete) provides a helpful way to navigate around tabs and menus.

– Pressing [ ] (Delete) while a tab is selected will display the viewfinder screen.

– Pressing [ ] (Delete) while menu item or setting is selected will “back step” in

the following sequence: Settings Menu items Tab.

Using On-screen Menus

[SET]

[ ] [ ] [ ] [ ]

Quality

EV Compensation

White Balance

ISO

Color Mode

REC SetupQuality

Fine

Normal

Example:

When “ Quality” is

selected on the “Quality”

tab

Tabs

Selected menu item

Settings

Pressing [SET] in the PLAY mode will display the PLAY Panel.

•Example PLAY Panel Operation

1. In the PLAY mode, press [SET].

The PLAY Panel will appear along the

right side of the monitor screen.

2. Use [ ] and [ ] to select the PLAY

Panel item you want, and then

press [SET].

3. The following describes the

operations you can perform for

each of the PLAY Panel items.

Using the PLAY Panel

Exit Exits the PLAY Panel.

Start

The operation that is performed when this item is selected

depends on the type of file that is currently displayed on the

monitor screen.

Slideshow Displays a slideshow menu.

Silent

The Silent mode turns off camera operation sounds so you

can avoid disturbing others around you when playing back

images.

Displays the PLAY menu. You can perform the following

operations on the PLAY menu.

1Use [ ] and [ ] to select the tab

where the menu item you want to

configure is located.

2Use [ ] and [ ] to select the

menu item you want, and then

press [ ].

3Use [ ] and [ ] to change the

setting of the selected menu

item.

4Press [SET] to apply the setting.

NOTE

• Pressing [ ] (Delete) performs one of the following

operations.

– If you previously selected a tab, pressing [ ] (Delete)

returns to the viewfinder screen.

– If you previously selected menu item, pressing [ ]

(Delete) returns to the tab.

[SET]

[][] PLAY Panel

Selected menu item

Tabs
