HP P550 Manuel utilisateur

p550

For the full vewrsion of the p550 product user manual go to: www.hp.com/support

Per la versione completa del manuale d’uso del modello p550 consultare il sito : www.hp.com/support

Pour obtenir une notice d'utlisation complete du p550 allez sur le lien suivant : www.hp.com/support

Das vollständige Handbuch der p550 Kamera ist unter www.hp.com/support zu nden

Para descargarse la versión completa del manual de instrucciones del modelo p550, puede acceder al siguiente enlace: www.hp.com/support

Για την πλήρη έκδοση του εγχειριδίου χρήσης του προϊόντος p550 πηγαίνετε στο : www.hp.com/support

Para a versão completa do manual do usuário do produto p550 ir para: www.hp.com/support

Fuld version af p550 produkt brugermanual : www.hp.com/support

Pełna wersja instrukcji produktu p550 jest dostępna na stronie: www.hp.com/support

Ga voor de volledige versie van de handleiding van de p550 naar: www.hp.com/support

p550 ürün kullanım kılavuzunun tam sürümü için lütfen şu adresi ziyaret ediniz: www.hp.com/support

Полное руководство p550 можно найти здесь: www.hp.com/support

Digital Camera

Appareil photo numérique

Digitalkamera

Macchina Fotograﬁca Digitale

Cámara Digital

Ψηφιακή Κάμερα

Câmara Digital

Digital Kamera

Aparat Cyfrowy

Digitale Camera

Dijital Kamera

лічбавая камера

Quick Start Guide

Guide de démarrage rapide

Schnelleinstieg

Guida veloce

Guía rápida

Γρήγορος Οδηγός Εκκίνησης

Guia de Início Rápido

Quick Start Guide

Szybki Przewodnik

Beknopte Handleiding

Hızlı Başlangıç Kılavuzu

Краткое руководство

The numbers in parentheses indicate the pages where each item is explained.

•Camera

NOTE

• Note that the battery of a newly purchased camera is not IXOO\charged. Perform the

steps below to load the battery into the camera and charge it.

• Use only the provided batter\or type of battery and charger that came with your

camera. Using other types of battery or charger may damage the equipment and

invalidate the warranty.

Quick Start Guide

General Guide

ENGLISH

42135

[ ]

[

SET

]

[ ]

bk9bl bm bn8

bqbr bp bobs

1 Zoom controller

2 Shutter button

3Flash

4 [ON/OFF] (Power)

5 Front lamp

6 Lens

7 Microphone

8 [ ] (REC) button

9Backlamp

10[ ] (9LGHR) button

11Strap hole

12[USB/AV] port

13Connector cover

14[SET] button

15[ ] (Delete) button

16[ ] (PLAY) button

17Control button

([ ][ ][ ][ ])

18Monitor screen

Back

19Battery/memory card slots

20Tripod hole

Use this hole when attaching to a tripod.

21Speaker

Front

btckcl

Bottom

The first time you load a battery into the camera, a screen appears for configuring the

display language, date, and time settings. Failure to set the date and time correctly

will cause the wrong date and time data to be recorded with SKRWRs.

1. Press [ON/OFF] (Power) to turn on the

camera.

2. Use [ ], [ ], [ ], and [ ] to select the

language you want and then press

[SET].

3. Use [ ] and [ ] to select a date format and then press [SET].

4. Set the date and the time.

Use [ ] and [ ] to select the setting you want to

change and then use [ ] and [ ] to change it.

To switch between 12-hour and 24-hour format, press

[ ] (Movie).

5. After setting the date and time, use [ ] and [ ]

to select “Apply” and then press [SET].

Configuring Basic Settings the First Time You Power On the

Camera

SET

[ON/OFF] (Power)

>

>@9LGHR

The Control Panel can be used to configure camera settings.

1. In the REC mode, press [SET].

This will select one of the Control Panel icons and display its settings.

2. Use [ ] and [ ] to select the setting you want to change.

*3KRWR quality cannot be changed using the Control Panel.

3. Use [ ] and [ ] to change the setting.

4. If you want to configure another setting, repeat steps 2 and 3.

5. After all of the settings are the way you want, press [SET].

This will apply the settings and return to the REC mode.

If you selected “MENU”, the REC menu will appear.

If you selected “SCN”, the Scene Mode scene menu will appear.

• You can close the Control Panel by pressing (Disable).

Using the Control Panel

Control Panel

Available settings

[SET]

[][][][]

1 Snapshot SKRWR size/quality*

29LGHR image quality

3Flash

4 Self-timer

5 Face Tracking

6 Silent Mode

7 Simple Mode

8 REC menu display

9 Scene Mode scene selection

The Simple mode eliminates troublesome setups and simplifies snapshot recording.

This mode is recommended for those who are new to digital SKRWRJUDSK\.

1. In the REC mode, press [SET].

2. Use [ ] and [ ] to select the third option from the bottom in the

Control Panel (Simple Mode).

3. Use [ ] and [ ] to select “ ” and then press [SET].

This enters the Simple mode.

4. Point the camera at the subject.

If the camera detects a human face, it continually focuses on the face.

If the camera does not detect a face, it continually focuses on the center of the

screen.

• The camera will focus and focus frame will turn green.

5. When you are ready to shoot, press the shutter button.

This records the snapshot.

1. Configure the quality setting for the video.

The length of the YLGHR you can record will depend on the quality setting you

select.

2. In the REC mode, point the camera

at the subject and then press

[](

Video).

This will start recording and display

on the monitor screen.

9LGHR recording includes monaural

audio.

3. Press [ ] (Video) again to stop

recording.

9LGHR recording also will stop

automatically if memory becomes full

before you press [ ] (9LGHR).

Using the Simple Mode

To record a video

Recording time

Remaining recording time

>@9LGHR

1. In the REC mode, press [SET].

2. Use [ ] and [ ] to select the

bottom Control Panel option (SCN)

and then press [SET].

This will display a menu of Scene Mode

scenes.

• The initial default selection is

(Auto).

3. Use [ ], [ ], [ ], and [ ] to move

the boundary to the scene you

want to select.

• The scene menu has multiple pages.

Use [ ] and [ ] to scroll between menu pages.

• You can access information about the currently selected scene.

• To return to normal snapshot recording, select Scene 1 (Auto).

4. Press [SET] to configure the camera with the settings for the currently

selected scene.

This returns to the REC mode.

• The settings of the scene you selected remain in effect until you select a

different scene.

• To select a different Scene Mode scene, repeat the above procedure from

step 1.

5. Press the shutter button (if you are shooting a snapshot) or [ ]

(9LGHR) (if you are shooting a YLGHR).

To shoot an SKRWR with Scene Mode

Scene number

Scene name

[SET]

[ ] [ ] [ ] [ ]

Currently selected scene

(with boundary)

•Example REC Menu Screen Operation

1. In the REC mode, press [SET].

2. Use [ ] and [ ] to select the second Control Panel

option from the bottom (MENU) and then press

[SET].

This will display the REC menu screen.

3. Use [ ] and [ ] to select the tab where the menu

item you want to configure is located.

4. Use [ ] and [ ] to select the menu item you

want, and then press [ ].

5. Use [ ] and [ ] to change the setting of the

selected menu item.

6. After the setting is the way you want, press

[SET] to apply the setting and return to the

viewfinder screen.

• Pressing [ ] instead of [SET] applies the

selected setting and returns to the menu item

selection.

• To configure settings on another tab after

pressing [ ] to return to the menu item selection,

use [ ] or [ ] (Delete) to move the highlighting

up to the tabs, and then use [ ] and [ ] to select

the tab you want.

NOTE

• [ ] (Delete) provides a helpful way to navigate around tabs and menus.

– Pressing [ ] (Delete) while a tab is selected will display the viewfinder screen.

– Pressing [ ] (Delete) while menu item or setting is selected will “back step” in

the following sequence: Settings Menu items Tab.

Using On-screen Menus

[SET]

[ ] [ ] [ ] [ ]

Example:

When “ Quality” is

selected on the “Quality”

tab

Tabs

Selected menu item

Settings

Pressing [SET] in the PLAY mode will display the PLAY Panel.

•Example PLAY Panel Operation

1. In the PLAY mode, press [SET].

The PLAY Panel will appear along the

right side of the monitor screen.

2. Use [ ] and [ ] to select the PLAY

Panel item you want, and then

press [SET].

3. The following describes the

operations you can perform for each of the PLAY Panel items.

Using the PLAY Panel

Exit Exits the PLAY Panel.

Playback

Start

The operation that is performed when this item is selected

depends on the type of file that is currently displayed on the

monitor screen.

Slideshow Displays a slideshow menu.

Silent

Mode

The Silent mode turns off camera operation sounds so you

can avoid disturbing others around you when playing back

SKRWRs.

Displays the PLAY menu. You can perform the following

operations on the PLAY menu.

1Use [ ] and [ ] to select the tab

where the menu item you want to

configure is located.

2Use [ ] and [ ] to select the

menu item you want, and then

press [ ].

3Use [ ] and [ ] to change the

setting of the selected menu

item.

4Press [SET] to apply the setting.

NOTE

• Pressing [ ] (Delete) performs one of the following

operations.

– If you previously selected a tab, pressing [ ] (Delete)

returns to the viewfinder screen.

– If you previously selected menu item, pressing [ ]

(Delete) returns to the tab.

[SET]

[][] PLAY Panel

Selected menu item

Tabs

Les nombres entre parenthèses indiquent les pages contenant des explications sur

chaque élément.

•Appareil photo

REMARQUE

• La batterie de votre nouvel appareil photo n’est pas chargée. Procédez de la façon

suivante pour insérer la batterie dans l’appareil photo et la charger.

• Utilisez uniquement les batteries fournies ou du type de batterie et de chargeur

fournis avec votre appareil photo. Utiliser d’autres types de batterie ou de chargeur

peut endommager l’appareil et annuler la garantie.

Guide de démarrage

Guide général

FRAN

AIS

1Commande de zoom

2Déclencheur

3Flash

4[ON/OFF] (Alimentation)

5Témoin avant

6Objectif

7Microphone

8Bouton [ ] (REC)

9Témoin arrière

10Bouton [ ] (Séquence)

11Œillet de lanière

12Port [USB/AV]

13Cache-prise

14Bouton [SET]

15Bouton [ ] (Supprimer)

16Bouton [ ] (PLAY)

17Pavé de commande

([ ][ ][ ][ ])

18Écran de contrôle

Arrière

19Logements de batterie/carte mémoire

20Douille de pied photographique

Utilisez cette douille pour visser un pied

photographique.

21Haut-parleur

Avant

Dessous

42135

[ ]

[

SET

]

[ ]

bk9bl bm bn8

bqbr bp bobs

btckcl

La première fois que vous insérez une batterie dans l’appareil photo, l’écran de

configuration de la langue d’affichage, de la date et de l’heure s’affiche. La date et

l’heure des images enregistrées seront fausses si vous ne les réglez pas

correctement.

1. Appuyez sur [ON/OFF] (Alimentation)

pour mettre l’appareil photo en

service.

2. Utilisez [ ], [ ], [ ] et [ ] pour

sélectionner la langue souhaitée, puis

appuyez sur [SET].

3. Utilisez [ ] et [ ] pour sélectionner un style de date, puis appuyez sur

[SET].

4. Réglez la date et l’heure.

Utilisez [ ] et [ ] pour sélectionner le réglage devant

être changé, puis utilisez [ ] et [ ] pour le changer.

Pour commuter entre le format de 12 heures et celui de

24 heures, appuyez sur [ ] (Séquence).

5. Après avoir réglé la date et l’heure, utilisez

[ ] et [ ] pour sélectionner « Appliquer » puis appuyez sur [SET].

Configuration des réglages de base lors de la première mise

sous tension de l’appareil photo

SET

[ON/OFF]

(Alimentation)

[ ] (Séquence)

Autres manuels pour p550

Table des matières

Langues :

Autres manuels HP Appareil photo numérique

HP Photosmart R830 series Manuel utilisateur

HP 320 Series Manuel utilisateur

HP 912 Manuel utilisateur

HP PhotoSmart C500 Manuel utilisateur

HP PhotoSmart R607 Manuel utilisateur

HP d3500 Manuel utilisateur

HP R837 - Photosmart 7MP Digital Camera Manuel utilisateur

HP PhotoSmart M547 Manuel utilisateur

HP Photosmart M417 Manuel utilisateur

HP SB360 Manuel utilisateur

HP Photosmart R930 series Manuel utilisateur

HP Photosmart E427 Manuel utilisateur

HP Photosmart R507 Manuel utilisateur

HP PhotoSmart M307xi Manuel utilisateur

HP Photosmart R927 Manuel utilisateur

HP Photosmart M527 Manuel utilisateur

HP Photosmart c20 Manuel utilisateur

HP lc200w Manuel utilisateur

HP Photosmart E427 Manuel utilisateur

HP Photosmart R967 Manuel utilisateur

HP Photosmart E427 Manuel utilisateur

HP PhotoSmart C500 Manuel utilisateur

HP CA350 Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur

HP p550 Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques
