CC330
Digital Camera
Quick Start Guide
For more details about the camera operation and troubleshooting, please read the User
Manual located on the CDROM disc included with your camera or visit
http://www.hp.com/support and download it for the camera support page.
2 1
English
GETTING READY
For more details about the camera operation and troubleshooting, please read the User
Manual located on the CDROM disc included with your camera or visit
http://www.hp.com/support.
Unpacking
Your package should contain the camera model you purchased along with the following
items. If anything is missing or appears to be damaged, please contact your vendor.
AA-size
Alkaline
Batteries
Warranty Card
CD-ROM USB Cable
Wrist Strap
English
2 3
2 3
1 Flash Lamp 9 Menu Button
2 Timer Indicator 10 Mode Selection Button
3 Lens 11 Disp/Up Button
4 Microphone 12 Flash Mode/Right Button
5 LCD Screen 13 Delete Button/Down Button
6 Status Indicator 14 Face Detection/Left Button
7 Zoom Toggle 15 Function/OK Button
8 Playback Button
Camera Views
Front View Back View
76
5
8
9
10
11
12
13
14
15
1 2 3
4
2 3
2 3
English
Left / Right View
16
17 1920
18
16 USB/AV Port 20 Speaker
17 Wrist Strap 21 Card Slot / Battery Compartment
18 Shutter Button 22 Tripod Socket
19 Power Button
Top / Bottom View
2122
4 5
4 5
1. Open the battery compartment.
2. Insert the enclosed batteries into the battery
slot in the correct direction.
3. Insert an SD/SDHC card (not included) into the
memory card slot as shown.
4. Close the battery compartment.
Insert the Battery and SD/SDHC Card (Not included)
4 5
4 5
English
Setting Date/Time and Language
Setting the Language
1. Use the Up and Down buttons to navigate to the Language
option. then press the Ok or Right button to enter the
Language menu.
2. Use the UP/Down/Right/Left buttons to highlight the
desired language.
3. Press the button to select the option and exit the
Language menu.
Setting the Date and Time
1. Use the Up and Down buttons to navigate to the Date/Time
option, then press the Ok or Right to enter the setting.
2. Press the Left/Right buttons to highlight each eld and use
the Up/Down buttons to adjust the value.
3. Press the button to conrm the setting.
6 7
6 7
Using the Mode Button
The camera provides a convenient mode button that allows you to switch between
different modes with ease. Press the to open the mode options menu. Use the Left/
Right buttons to choose the desired mode and press to conrm. For more details about
the Mode button and the numerous camera modes, please review the User Manual located
on the software CD provided with this product.
Auto mode ASCN mode
M
Manual mode Scene mode
Panorama mode Movie mode
Portrait
Turning On and Off
Press the Power button to turn the camera on. To turn off the camera, press the Power
button again.
Power Button
6 7
6 7
English
Using Menu Button
The menu button allows you quick access to the camera settings options.
Press the to open the camera settings menu. Press Left/Right buttons to highlight the
desired option, then press the Down button to select this option/menu, and press to
Taking a picture
1. Hold the camera securely.
2. Use the Zoom toggle to zoom in and out of the
subject. Press the "T" side of the toggle to zoom
in and press the "W" side of the toggle to zoom out.
3. Lightly press the shutter button halfway force the camera
to focus on the subject. When properly in focus, a green
bracket will be displayed on the screen. Press the shutter
button fully to take the picture.
1 Photo Setup 5 General Setup
2 Movie Setup 6 Transmission
3 Playback Setup 7 File/Software
4 Display Setup
conrm. For more details about the Menu button and the camera settings, please review
the User Manual located on the software CD provided with this product.
8 9
8 9
Using the Delete Button
In Playback mode, press the Down/Delete button to delete
pictures or videos.
To delete pictures or videos:
1. Press button to go to the Playback mode.
2. Select a picture or video clip you want to delete with the Left/Right buttons.
3. Press the Down/Delete button and the delete screen appears.
4. Select Yes or Back with Up/Down button and press the button for conrmation.
Viewing your picture
1. Press the Playback button to switch to
2. Use Left/Right buttons to browse through your
photos.
Playback mode.
