HP Vectra VLi 8 Manuel utilisateur

IBM Turbo 16/4 Token Ring ISA

Adapter

Installation Guide

Notice

The information contained in this document is subject to change without notice.

Hewlett-Packard makes no warranty of any kind with regard to this

material, including, but not limited to, the implied warranties of

merchantability and fitness for a particular purpose.

Hewlett-Packard shall not be liable for errors contained herein or for incidental

or consequential damages in connection with the furnishing, performance, or use

of this material.

Hewlett-Packard assumes no responsibility for the use or reliability of its

software on equipment that is not furnished by Hewlett-Packard.

This document contains proprietary information that is protected by copyright.

All rights are reserved. No part of this document may be photocopied,

reproduced, or translated to another language without the prior written consent

of Hewlett-Packard Company.

Microsoft®, Windows® and MS-DOS® are registered trademarks of Microsoft

Corporation.

MMXTM is a trademark of Intel Corporation.

Pentium® is a registered trademark of Intel Corporation.

Hewlett-Packard France

Commercial Desktop Computing Division

38053 Grenoble Cedex 9

France

General information to read before installing

On all systems: before installing LAN card, go into Bios setup and set PnP OS field to NO.

• This network card failed HP tests on Vectra VEi7 and VEi8.

• Installation on Win 3.11 with Novell server fails on Vectra VLi8.

• How to change LAN card configuration if needed (Advanced users only)

This is a general advisory on how to forcibly modify resources for ISA and PCI network

cards.

ISA cards:

• For ISA network adapters, start the configuration tool provided in driver

kit (See install documentation)

• Under CMOS setup, go to Advanced > PnP/PCI ISA IRQ Resource Exclu-

sion > reserve an IRQ for the adapter.

PCI cards:

• For PCI network adapters, go to CMOS setup > Advanced > PnP/PCI ISA

IRQ Resource Exclusion > reserve the IRQ for Legacy ISA.

• ISA cards can’t use IRQ9

• IRQ 9 is reported as being used by ACPI during POST. This is due to ISA’s

inability to share IRQs.

• Using a different IRQ (e.g. 5, 7, 10, and 11) will work. For this:

1Install the NIC then power up the system.

2Press F2 to go to CMOS setup.

3Set PnP OS to NO and reserve IRQ 5, 7, 10, or 11 (explained in installation

section).

4Save the configuration settings and boot to the applicable OS.

5Follow installation steps.

Sound conflict under Win 95 on VLi8 only

• On VLi8, LAN cards cause an IRQ conflict with the embedded sound de-

vice under Win95.

• To solve the problem: Reserve IRQ 5 and sett PNP OS to no. For this:

General information to read before installing

1Install the NIC then power up the system

2Press F2 to go to CMOS setup.

3Set PNP OS to NO and reserve IRQ 5.

4Save settings and boot to applicable OS.

1 Installing the IBM Turbo 16/4 Token Ring ISA Adapter

Microsoft Windows 95 SR2.5

1 Installing the IBM Turbo 16/4 Token Ring ISA Adapter

Microsoft Windows 95

SR2.5

Connecting to a

Windows NT 3.51 Server

Requirements

• HP Vectra with Windows 95 SR2.5.

• IBM Turbo 16/4 Token Ring ISA adapter and drivers disk version 2.22.

• Driver File: IBMTOK.SYS, version 10.27

• Microsoft Windows 95 SR2.5 media.

• Microsoft Windows NT 3.51 Server system that supports NetBEUI,

NWLink IPX/SPX Compatible Transport, and NWLink NetBIOS network

protocols.

Device Configuration

Procedure

1With the HP Vectra turned off, install the IBM Turbo 16/4 Token-Ring ISA

adapter into an ISA slot.

2Connect network cable media to the IBM Turbo 16/4 Token-Ring ISA

adapter.

3Power on the machine and start Windows 95SR2.5 and the Token Ring

card will be recognized as “IBM Turbo 16/4 Token Ring ISA Adapter”.

Insert the “IBM Turbo 16/4 and Auto Wake Token-Ring ISA Adapter disk

2” and click on “Next”.

4Verify that “IBM Turbo 16/4 Token-Ring ISA Adapter” is listed and click

on “Finish”.

5Click on “OK” when the system prompts for the computer and workgroup

names.

6Enter the Computer Name, Workgroup, and Computer Description in the

appropriate spaces and click on “Close” (Contact your network

administrator if you do not have the required information).

Device Configuration Vectra Vli8

Interrupt 09

I/O Address 300

1 Installing the IBM Turbo 16/4 Token Ring ISA Adapter

Connecting to a Windows NT 3.51 Server

7Insert the Windows 95 CD into the CD-ROM drive, specify the path and

click “OK”.

8Remove the IBM diskette from the floppy drive and click on “YES” to

restart the system when prompted.

9Right-click on the “Network Neighborhood” icon and select “Properties”.

10 Accept the default Network Protocols and the Primary Network Logon

(Client for Microsoft Networks) as seen below and click on “OK”. (If you

do not have the required information, contact your network

administrator)

11 Client for Microsoft Networks

Client for Microsoft Networks

IBM Turbo 16/4 Token-Ring ISA Adapter

IPX/SPX-compatible Protocol

NetBEUI

12 Click on “OK” to accept the configuration.

13 Specify the path to your Windows 95 files when prompted.

2 Installing the IBM Turbo 16/4 Token Ring ISA Adapter

Microsoft Windows 95 SR2.5

2 Installing the IBM Turbo 16/4 Token Ring ISA Adapter

Microsoft Windows 95

SR2.5

Connecting to a

Windows NT 4.0 Server

Requirements

• HP Vectra with Windows 95 SR2.5.

• IBM Turbo 16/4 Token Ring ISA adapter and drivers disk version 2.22.

• Driver File: IBMTOK.SYS, version 10.27

• Microsoft Windows 95 SR2.5 media.

• Microsoft Windows NT 4.0 Server system that supports NetBEUI, NWLink

IPX/SPX Compatible Transport, and NWLink NetBIOS network protocols.

Device Configuration

Procedure

1With the HP Vectra turned off, install the IBM Turbo 16/4 Token-Ring ISA

adapter into an ISA slot.

2Connect network cable media to the IBM Turbo 16/4 Token-Ring ISA

adapter.

3Power on the machine and start Windows 95SR2.5 and the Token Ring

card will be recognized as “IBM Turbo 16/4 Token Ring ISA Adapter”.

Insert the “IBM Turbo 16/4 and Auto Wake Token-Ring ISA Adapter disk

2” and click on “Next”.

4Verify that “IBM Turbo 16/4 Token-Ring ISA Adapter” is listed and click

on “Finish”.

5Click on “OK” when the system prompts for the computer and workgroup

names.

6Enter the Computer Name, Workgroup, and Computer Description in the

appropriate spaces and click on “Close” (Contact your network

administrator if you do not have the required information).

Device Configuration Vectra Vli8

Interrupt 10

I/O Address 300

2 Installing the IBM Turbo 16/4 Token Ring ISA Adapter

Connecting to a Windows NT 4.0 Server

7Insert the Windows 95 CD into the CD-ROM drive, specify the path and

click “OK”.

8Remove the IBM diskette from the floppy drive and click on “YES” to

restart the system when prompted.

9Right-click on the “Network Neighborhood” icon and select “Properties”.

10 Accept the default Network Protocols and the Primary Network Logon

(Client for Microsoft Networks) as seen below and click on “OK”. (If you

do not have the required information, contact your network

administrator)

11 Client for Microsoft Networks

Client for Microsoft Networks

IBM Turbo 16/4 Token-Ring ISA Adapter

IPX/SPX-compatible Protocol

NetBEUI

12 Click on “OK” to accept the configuration.

13 Specify the path to your Windows 95 files when prompted.

3 Installing the IBM Turbo 16/4 Token Ring ISA Adapter

Microsoft Windows 95 SR2.5

3 Installing the IBM Turbo 16/4 Token Ring ISA Adapter

Microsoft Windows 95

SR2.5

Connecting to a Novell

NetWare 3.12 Server

Requirements

• HP Vectra with Windows 95 SR2.5.

• IBM Turbo 16/4 Token Ring ISA adapter and drivers disk version 2.22.

• Driver File: IBMTOK.SYS, version 10.27

• Microsoft Windows 95 SR2.5 media.

• Novell NetWare 3.12 Server system that supports IPX network protocol.

• Novell Client for Windows 95 v2.5 installation media.

Device Configuration

Procedure

1With the HP Vectra turned off, install the IBM Turbo 16/4 Token-Ring ISA

adapter into an ISA slot.

2Connect network cable media to the IBM Turbo 16/4 Token-Ring ISA

adapter.

3Power on the machine and start Windows 95SR2.5 and the Token Ring

card will be recognized as “IBM Turbo 16/4 Token Ring ISA Adapter”.

Insert the “IBM Turbo 16/4 and Auto Wake Token-Ring ISA Adapter disk

2” and click on “Next”.

4Verify that “IBM Turbo 16/4 Token-Ring ISA Adapter” is listed and click

on “Finish”.

5Click on “OK” when the system prompts for the computer and workgroup

names.

6Enter the Computer Name, Workgroup, and Computer Description in the

appropriate spaces and click on “Close” (Contact your network

administrator if you do not have the required information).

Device Configuration Vectra Vli8

Interrupt 10

I/O Address 300

3 Installing the IBM Turbo 16/4 Token Ring ISA Adapter

Connecting to a Novell NetWare 3.12 Server

7Insert the Windows 95 CD into the CD-ROM drive, specify the path and

click “OK”.

8Remove the IBM diskette from the floppy drive and click on “YES” to

restart the system when prompted.

9Insert the “Novell Client for Windows 95” CD in the CDROM and execute

“Setup.exe”.

10 Click on “Yes” to accept the License Agreement.

11 Select “Custom” installation and click on “Next”.

12 Select “Bindery (NetWare 3.x)” and click on “Next”.

13 Click on “Install” to start the installation.

14 Click on “Yes” to set the Preferred Server. (If you do not have the

required information, contact your network administrator).

15 Click on “Reboot” to complete the installation.

16 Right-click on the “Network Neighborhood” icon and select “Properties”.

17 Accept the default Network Protocols and the Primary Network Logon

(Client for NetWare Networks) as seen below and click on “OK”. (If you

do not have the required information, contact your network

administrator)

18 Client for NetWare Networks

Client for NetWare Networks

IBM Turbo 16/4 Token-Ring ISA Adapter

IPX/SPX-compatible Protocol

NetBEUI

19 Click on “OK” to accept the configuration.

20 Specify the path to your Windows 95 files when prompted.

Autres manuels pour Vectra VLi 8

Autres manuels HP Adaptateur

HP NC370T Manuel utilisateur

HP 4X - DDR InfiniBand Mezzanine HCA Mode d’emploi

HP D5970A - NetServer - LCII Manuel utilisateur

HP D5970A - NetServer - LCII Manuel de l'opérateur

HP 652503-B21 Manuel utilisateur

HP Integrity BL890c - i2 Server Guide de démarrage rapide

HP NC380T Manuel utilisateur

HP 273914-B21 - Smart Array 6404/256 RAID... Manuel utilisateur

HP A6826A Manuel utilisateur

HP FlexFabric 534M Manuel utilisateur

HP Integrity BL860c Mode d’emploi

HP 650926-B21 Manuel utilisateur

HP 90W Manuel utilisateur

HP 570M Instructions d'utilisation

HP StoreFabric CN1100R Manuel utilisateur

HP 331FLR Manuel utilisateur

HP NC542m Instructions d'utilisation

HP NC364T Manuel utilisateur

HP BladeSystem Dual NC370i - Multifunction Network... Manuel utilisateur

HP 652497-B21 Manuel utilisateur

HP 3C509B ISA Manuel utilisateur

HP Photosmart 7100 Manuel utilisateur

HP StorageWorks 2000sa Guide de référence rapide

HP 665240-B21 Manuel utilisateur

Manuels Adaptateur populaires d'autres marques

PCB Piezotronics

PCB Piezotronics 090B274 Manuel utilisateur

Auvidea

Auvidea J20 Manuel du produit

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuel utilisateur

Akribis

Akribis ITF-21-BISS-MIT Manuel utilisateur

Tenda

Tenda W54U Manuel utilisateur

ROHO

ROHO AGILITY Manuel utilisateur

PROLiNK

PROLiNK WN2001 Manuel utilisateur

Hawking

Hawking HUF2 Manuel utilisateur

Airlink101

Airlink101 AWLC4030 Manuel utilisateur

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuel utilisateur

Philips

Philips SWA4554S/10 Manuel utilisateur

JVC

JVC TS-C9D2B Manuel d'instructions

NETGEAR

NETGEAR A6100 Manuel utilisateur

D-Link

D-Link DWA-121 Manuel utilisateur

Philips

Philips SWA2037 Manuel utilisateur

Basalte

Basalte 0610-20 Manuel utilisateur

Yealink

Yealink EHS40 Manuel utilisateur

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuel utilisateur
