Honeywell Domonial Manuel utilisateur

User Manual

Congratulations on your purchase of our DOMONIAL

security system.

This system is designed to operate on an authorised

radio frequency and will in no way endanger the user.

To make the best out of your DOMONIAL we advise

you to read this manual carefully. This manual has been

written for your special attention and integrates

remarks and suggestions of existing users.

You can write here the places of the detectors :

Channel 1 : Channel 11 :

Channel 2 : Channel 12 :

Channel 3 : Channel 13 :

Channel 4 : Channel 14 :

Channel 5 : Channel 15 :

Channel 6 : Channel 16 :

Channel 7 : Channel 17 :

Channel 8 : Channel 18 :

Channel 9 : Channel 19 :

Channel 10 : Channel 20 :

TABLE OF CONTENTS

①

Introduction to your security system 4

②

Understand the audible acknowledgements 6

③

How to use your keyfob ? 9

④

How to use your wireless keypad ? 12

⑤

Detectors operating principle 16

⑥

How to manage your system 17

via a telephone ?

⑦

Maintenance and recommendations 19

456

SOS

456

SOS

Introduction to your security system

The DOMONIAL control panel/communicator unit is the brain of your security system. It

exchanges information with the associated wireless peripherals. DOMONIAL centralises the data

sent by the detectors, records the arming and disarming operations and communicates with

your central monitoring station.

SPECIFICATIONS

Radio

●

Narrow band frequency modulation

●

Identification code specific to each

component (no possible interference

between neighbouring systems)

●

Protection against attempted jamming

●

Radio monitoring of the system

detectors and sounders

Electrical

●

230V mains with battery backup

●

Built-in voltage surge protection

●

System supply monitoring

Transmission

●

Built-in telephone transmission

●

Telephone line loss detection

●

Transmission monitoring by periodical tests (as programmed)

Operational

●

3 protected area groups - 20 detection points

●

Alert functions, with sounder or silent

●

All door and window contacts closed position

checked upon arming

●

Control panel tamper protection against opening

●

Audio verification

①

1- LED INDICATOR “AC MAINS POWER”

ON : The Control Panel is supplied by the Mains power

OFF : There is a Mains Power Failure – The Control Panel is supplied by its built – in battery

2- LED INDICATOR “SYSTEM ARMED”

ON : The system is totally armed

OFF : The system is disarmed

BLINKING : The system is Part Armed

3- LED INDICATOR “OPENED DETECTOR FAULT”

BLINKING : It means that one of the window or door protected by a magnetic contact is

opened. It blinks until the window or door get closed

4- LED INDICATOR “ALARM MEMORY”

ON : It means that an alarm occurred during the ARMING mode

BLINKING : It means that an alarm occurred during the Part arm mode

The indicator remains ON until the next arming

5- LED INDICATOR “TECHNICAL FAULT”

ON : It indicates a fault on a technical channel

BLINKING : It indicates a fault on the system ( Battery fault, Supervision, Tamper, Phone line

failure or Radio Jamming )

The indicator remain ON or BLINKING until the End of the technical or system fault

The front cover of the control panel

features LEDS indicators which show

the status of your security system.

Light indicator

Understand the audible acknowledgements

SIGNALLING EQUIPMENT

The sounder, whether it is built in the control panel 1 or mounted in the house 2 is an effective

deterrent thanks to its power and very aggressive loudness.

Both these components emit an audible confirmation of your arming and disarming the security

system. The sound volume can be adjusted by the installer.

②

ARMING

confirmation

DISARMING

confirmation

PART or

ANNEX

zone arming

confirmation

FAULT signal

ALERT

confirmation

Exit delay

confirmation

Sequence of 3 modulated sounds

Duration : 4 seconds

When Arming, confirms that the control

panel has received the information.

When Disarming, confirms that the

control panel has received the

information.

This confirmation indicates

Part arming of the security system

This signal corresponds to a fault in the

system

Confirms the transmission of an alert to

your central monitoring station

After Arming, this is the Exit delay

count down (programmable option)

Long and continuous beep

Duration : 2,5 seconds

Sequence of 2 modulated sounds

Duration : 2,5 seconds

2 times 7 fast beeps

4 beeps in case of alert...

sent via the keypad

10 sec. before actual arming...

one beep every second

AUDIBLE CONFIRMATIONS OF YOUR ACTIONS

Built-in audio verification version

DOMONIAL can have a built-in audio verification function, allowing you to call and talk to the

persons who are in the monitoring station, just by pressing the button. Then the monitoring station

will ask you to talk.

How to use your keyfob ?

The keyfob is used to arm, totally or partly, and disarm your security system as well as to

trigger an audible or silent alert.

CHARACTERISTICS

●

Power requirement: one 3V lithium CR 1/3 type battery

●

Weight: 30 grs

OPERATION

●ARMING

✔ Press key :

✔ The indicator light on the keyfob comes on briefly when you release

the button

An audible confirmation

is simultaneously emitted by all the signalling equipments.

Always make sure that your arming the system is followed by the audible confirmation. Your

house will be under effective protection about 2 minutes after you have armed the system.

Arming can be controlled from inside the house or from outside, in the immediate vicinity.

If, upon arming, a door or window contact is in the "open" position (e.g. window not properly

shut), a FAULT signal will inform you. Disarm the system, shut the corresponding window

and repeat arming.

●DISARMING

✔ Press key :

✔ The indicator light on the keyfob comes on briefly when you release the button.

③

The audible confirmation is emitted by the

signalling equipment.

Action on the key immediately disarms the security system of your house.

●PARTIALARMING

Provided that this function has been programmed by the installer, you can choose to protect

only a part of your house while you are in the other part. For instance, you can protect the

ground floor while your are sleeping upstairs.

✔ Press key

✔ The indicator light on the keyfob comes on when you release the button.

The audible confirmation is simultaneously

emitted by the signalling equipment.

Part protection becomes effective about 2 minutes after you have armed it. Any intruder in the

protected zone will trigger an alarm. Part protection is disarmed by action on the key.

●ALERT FUNCTION

This key enables you to send an instant alarm if you need urgent assistance at home.

✔ Push simultaneously the 2 “SOS” keys during 2 secondes

✔ The indicator light comes on.
