Honeywell SS2 Series Manuel utilisateur

Installation Guide and Operating Manual

Multi-Spectrum Digital

Electro-Optical Fire Detectors

Models SS2-A, SS2-AN, SS2-AH, and SS2-AM

Stand-Alone Mode

OPERATOR MANUAL // NOTICES AND TRADEMARKS

HONEYWELL 1

Notice

and Trademarks

While this information is presented in good faith and believed to be

accurate, Honeywell disclaims the implied warranties of merchantability

and fitness for a particular purpose and makes no express warranties

except as may be stated in its written agreement with and for its

customers.

In no event is Honeywell liable to anyone for any indirect, special or

consequential damages. The information and specifications in this

document are subject to change without notice.

The detector must be installed only by qualified professional personnel in

accordance with local codes.

The protection provided by the gas detector may be impaired if it is used in

a manner not specified by Honeywell Analytics.

ACCTTL, ALERT-1, ALARM-2, ALERT-1: ALARM 2, ALERT-1: ALARM-2,

ATAG, Clean Room Sentry, COP-i, Complete Optical Path Integrity, CM1,

CM1-A, DartLogic, FireLogic, Fire Signature Analysis, FireBusI, FireBusII,

FirePic, FirePicII, FirePicIII, FirePix, FirePicture, FSC, Fire Sentry

Corporation, Fire Sentry Corp., FSX, All FSX Nomenclature Variations

(such as: FS2, FS2X, FS3, FS3X, FS4, FS4X, FS5, FS5X, FS6, FS6X,

FS7, FS7X, FS8, FS8X, FS9, FS9X, FS10X, FS10X, FS11, FS11X, FS12,

FS12X, FS14, FS14X, FS15, FS15X, FS16, FS16X, FS17, FS17X FS18,

FS18X, FS19, FS19X, FS20, FS20X, FS24, FS24X, FS24XN, FS26,

FS26X, FS26XN), FS7-2173-2RP, FS System 7, FS System 10, FS7-2173,

FS7-2173-RP, FS2000, FS System 2000, High Speed Flame &

Surveillance Detector, Multi-Spectrum QuadBand Triple IR, Multi-Spectrum

TriBand, Multi-Spectrum Tri-Band, Near Band Infrared, Near Band IR,

NearBand IR, QuadBand IR, Room Sentry, RS, RS2, SM2, SM3, SS, SS2,

SS2X, SS2-A, SS3, SS3-A, SS3X, SS4, SS4-A, SS4X, SnapShot, SLR-BIT,

SuperBus, SuperSentry, System 2000, Tri-Mode Plot, QuadBand Triple IR

Plus, TriBand, Tri-Band, “FS & FSC triangle logo’s”, WBIR, Wide Band

Infrared, WideBand IR, Wide Band IR

are registered trademarks of Honeywell International Inc.

Other brand or product names are trademarks of their respective owners.

Honeywell Analytics

OPERATOR MANUAL // SYMBOL DEFINITIONS

HONEYWELL 2

SymbolDefinitions

The following table lists those symbols used in this document to denote

certain conditions.

Symbol Definition

ATTENTION: Identifies information that requires

special consideration.

Indicates a situation which, if not avoided, may

result in equipment or work (data) on the system

being damaged or lost, or may result in the

inability to properly operate the process.

CAUTION: Indicates a potentially hazardous

situation which, if not avoided, may result in

minor or moderate injury. It may also be used to

alert against unsafe practices.

CAUTION:Symbol on the equipment refers the

user to the product manual for additional

information. The symbol appears next to

required information in the manual.

OPERATOR MANUAL //

TABLE OFCONTENTS

HONEYWELL 3

TABLE OF CONTENTS

TABLE OF CONTENTS ............................................................... 3

APPROVALS .............................................................................. 4

SECTION 1: FAMILIARIZATION...................................................................... 5

1.1 Introduction .............................................................................................5

1.2 Stand-Alone Operation.............................................................................5

1.3 FS2000 System Operation ....................................................................... 6

1.4 Overview6

1.4.1 Model SS2 Detector Status Indications................................. 6

1.4.2 Detection Range..................................................................6

1.4.3 Field-of-View....................................................................... 6

1.5 Testing 7

1.5.1 Special Conditions for Testing.............................................. 7

1.5.2 Automatic Testing................................................................ 7

1.5.3 Manual Testing....................................................................7

SECTION 2: INSTALLATION............................................................................ 9

2.1 Installation Procedure..............................................................................9

2.1.1 Installation Precautions........................................................ 9

2.1.2 Conduit Installation..............................................................9

2.1.3 Wiring Recommendations ....................................................9

2.1.4 Power Supply Considerations...............................................9

2.2 Enclosure Installation (Optional)............................................................. 10

2.2.1. Swivel Mount (SM2):.......................................................... 10

2.2.2 Install Conduit (If not already installed)............................... 10

Figure 2. Model SS2 Detector with SM2 Swivel Mount.................... 10

2.3 Wiring Detectors.................................................................................... 10

Figure 3: Model SS2 Detector Enclosure - Side View....................... 11

Figure 4. Model SS2 Detector Enclosure - Back View...................... 12

Figure 5. Models SS2-A, SS2-AN, SS2-AH, and SS2-AM................ 12

SECTION 3 / MAINTENANCE AND TROUBLESHOOTING..............................15

3.1 Personnel.............................................................................................. 15

3.2 Cleaning Windowed Enclosures and Detectors........................................ 16

3.3 SS2-A, -AN, -AH, and –AM Detectors’ Faults.......................................... 16

3.4 SS2-A, -AN, -AH, and -AM Detector Modules Replacement..................... 17

3.5 Detector Repair ..................................................................................... 17

SECTION 4 / DETECTOR PINOUT DATA.......................................................18

TABLE 1: Stand-Alone Model SS2 Detector Connectors -

Pinouts.............................................................................. 18

SECTION 5 / DETECTOR LABEL DRAWINGS ...............................................19

INDEX .....................................................................................20

OPERATOR MANUAL // APPROVALS

HONEYWELL 4

APPROVALS

The Model SS2 Optical Fire Detectors have been manufactured in

compliance with the requirements of the ISO-9001 standard and have been

approved by:

•California State Fire Marshal (CSFM)

•Factory Mutual (FM)

•Canadian Standards (CSA)

•CENELEC approval by FM Approvals Ltd. Certification Service

in compliance with the ATEX Directive.

Marking: Class I, Div. 1 & 2, Groups A, B,C, & D

Class II, Div. 1 & 2, Groups E, F, & G

Class III

Class I , Zone 1 AEx d IIC

Ex d IIC; Ex tb IIIC T135°C

Read and understand this manual before installing or

operating equipment.

OPERATOR MANUAL // SECTION 1: FAMILIARIZATION

HONEYWELL 5

SECTION 1: FAMILIARIZATION

1.1 Introduction

The Model SS2 Multi-Spectrum Electro-Optical Fire/Flame Detectors may

be used in the FS2000 Fire Early Warning System or in the Stand-Alone

mode. Detectors of this model are housed in Explosion-Proof Class I, Div.

1 enclosures. The only difference between an FS2000 System Model SS2

Detector and a Stand-Alone SS2 Detector is in the wiring. The wiring

differences are described in Sections 1.2 and 1.3.

Model SS2-A Detectors have a latching relay. They are used for

hydrocarbon and non-hydrocarbon fires

Model SS2-AN Detectors have a non-latching relay. They are otherwise

identical to the SS2-A.

Model SS2-AH is the same as Model SS2-A except for the programming to

assure High Speed millisecond response to non-UV emitting sodium azide

fires (in addition to the normal fire response) for air bag industries. The

Detector is housed in a Class I, Div. 1 Explosion-Proof enclosure. For more

information, refer to corresponding specification sheets.

Model SS2-AM is the same as Model SS2-A except for the programming to

assure Ultra High Speed millisecond response to normal non-sodium azide

burning materials radiating UV and IR energy for munitions and air bag

industries. The Detector is housed in a Class I, Div. 1 Explosion-Proof

enclosure. For more information, refer to corresponding specification

sheets.

There are operational advantages when the Detector is connected to an

FS2000 Controller and FireBus. The Detector also has flexibility to be re-

configured in the field. It is simple to install and operate due to built in self-

testing. The maintenance consists in wiping the lens and performing

periodic testing required by the manufacture of the Fire Control and

Suppression Systems.

There are operational advantages when the Detector is connected to an

FS2000 Controller and FireBus. The Detectors also have flexibility to be re-

configured in the field. The maintenance consists in wiping the lens and

performing periodic testing required by the manufacture of the Fire Control

and Suppression Systems.

1.2 Stand-Alone Operation

The Model SS2 Detectors may be connected to an approved Fire/Security

Panel for Stand-Alone operation. The Detectors operate on 24 Volts DC. In

this mode the Detectors utilize Fire and Fault relays to interface to FM/UL

approved Fire/Security Panels. For Stand-Alone operation, the Detector’s

Fault relay is automatically configured by the on-board microprocessor.

The input current of the Detector is about 15 mA higher in the Stand-Alone

mode compared to operation as part of FS2000 System.

OPERATOR MANUAL // SECTION 1: FAMILIARIZATION

HONEYWELL 6

1.3 FS2000 System Operation

For FS2000 System operation, the Detector’s Fire and Fault signals are

sent digitally to the FS2000 System Controller using the four wire FS2000

FireBus. The FireBus provides the 24 Volts DC power for the Detector and

RS-485 digital communication (Refer to Honeywell Analytics document

MN0003: "FS2000 FIRE EARLY WARNING SYSTEM - INSTALLATION and

OPERATIONS GUIDE"). For special remote alarm applications, users may

also connect directly to the Detector’s Fire alarm relay.

NOTE: When the Model SS2 Detector is connected to the FS2000

System using FireBus communication, the Controller automatically

de-energizes the Detector’s Fault relay.

1.4 Overview

1.4.1 Model SS2 Detector Status Indications

The Model SS2 Multi-Spectrum Optical Fire/Flame Detectors are

microprocessor-based devices, which see ultraviolet (UV), visible (VIS),

and infrared (IR) spectral regions. The Detector's logic processor is

capable of quick response to fires while virtually eliminating false alarms.

The Model SS2 Detector has a 120° field-of-view.

There are two (2) LEDs on the Model SS2 Detector for indication of the

Detector status. During Normal Operation both LEDs will blink every 10

seconds.

If a Model SS2 Detector has a Fault, it de-energizes the Fault relay and

turns one (1) LED on. (The LED will not light if the Fault is a “No Power

Fault”). If the Fault condition, such as a “Low Voltage Fault”, is eliminated,

the Detector will automatically return to Normal Operation.

Faults caused by Excessive Input Voltage or temperatures outside the

operating temperature range require factory re-certification. Both LEDs

rapidly blinking (with frequency about 2 Hz) indicate faults requiring re-

certification.

If a Model SS2 Detector alarms to a fire, it energizes the Fire relay and

turns on both LEDs in the following sequence. One LED is turned on

immediately and the second LED will rapidly blink for several seconds

indicating that the Detector's FirePic is being permanently stored in the

Detector's solid-state memory. (FirePic is the several seconds of Detector

data, which precede an alarm event.)

1.4.2 Detection Range

The detection range of the detector is 60 feet to an industrial standard of

one square foot gasoline pan fire within 5 seconds.

1.4.3 Field-of-View

The Detector incorporates a minimum 120-degree conical Field of View.

The fire emissions received by the Detector diminish at extreme edges of

the field-of-view. For the fastest response times to the smallest size fire,

OPERATOR MANUAL // SECTION 1: FAMILIARIZATION

HONEYWELL 7

the Detector should be pointed to the fire threat area. When multiple

detectors are used to cover large areas, the Fields-of-View should overlap.

The Field-of-View is not limited to 120 degrees. Larger fires outside

120 Degrees

Figure 1. Field of View, Horizontal and Vertical.

Maximum Sensitivity to 1 Sq. Ft. Gasoline Pan Fire

1.5 Testing

1.5.1 Special Conditions for Testing

The SS2 Detector should be tested immediately after installation, after

repair or maintenance involving wiring or module replacement, after

periodic maintenance, or after lens contamination has been identified.

1.5.2 Automatic Testing

The Model SS2 Detectors contain an internal source for self-testing. For

testing the Model SS2 Detectors end-to-end for both optical path and

window cleanliness, use a Honeywell Analytics Model FT-2045 Test Lamp.

1.5.3 Manual Testing

For manual testing the Detector may be exposed to an actual industry

standard open flame or to a Test Lamp simulating a fire. For Honeywell

Analytics model SS2 Multi-Spectrum Fire Detectors, it is mandatory to use

the handheld UV/IR Test Lamp, Model No FT-2045 or FT-2145.

NOTE: Other manufacturers UV/IR Test Lamps should not be

utilized to test Honeywell Analytics Detectors, and Honeywell

Analytics Model FT-2045 and FT-2145 Test Lamps should not be

utilized for testing other manufacturer’s Detectors.

OPERATOR MANUAL // SECTION 1: FAMILIARIZATION

HONEYWELL 8

The FT-2045 and FT-2145 Test Lamps are housed in an Explosion-proof

enclosure, powered by internal rechargeable batteries, and designed for

indoor and outdoor use. For additional information on the Test Lamp, refer

to Honeywell Analytics Specification SP0242 for the FT-2045 or 1505-008A

for the FT-2145.

OPERATOR MANUAL // SECTION 2: INSTALLATION

HONEYWELL 9

SECTION 2: INSTALLATION

2.1 Installation Procedure

This section describes the installation of the Model SS2 Detectors for the

Stand-Alone mode. Utilization of junction boxes is recommended for the

Detectors wiring.

2.1.1 Installation Precautions

The following precautions should be observed during installation of Model

SS2 Detectors.

1. Make sure that external electrical power is turned OFF before connecting to

the Detector.

2. Do not handle the Detector's module (with its printed circuit boards)

without grounding. Printed circuit board components are susceptible to

damage from electrostatic discharge.

2.1.2 Conduit Installation

The following recommendations should be observed when planning

conduits.

1. In case only one of the two 3/4 inch NPT conduit openings on the Detector

enclosure is used, seal the unused opening with a threaded plug and

approved sealing material.

2. In areas where moisture may accumulate, install an approved conduit trap

or drain.

3. For applications requiring a Class I, Div. 1 Explosion-Proof rating, install a

seal within 6 inches of the enclosure.

2.1.3 Wiring Recommendations

Install a junction box near each Detector location. Wire each Detector to

the junction box. Use screw-down terminal strips inside the junction box to

make the connections to the Detector's terminals and an Approved Fire

Alarm Panel. Use only approved junction boxes and terminal strips.

Avoid wire splices. However, if wire splices are necessary, Honeywell

Analytics recommends soldering all splices. The use of good wiring

practices will greatly improve the ease and reliability of installation, and

facilitate servicing.

2.1.4 Power Supply Considerations

Model SS2 Detectors use 24 Volts DC at a maximum current of 100

milliamps. Make sure that the Panel's power supply can handle the current

load of the total number of Detectors connected to it. For example, if 10

Detectors are used on one Panel's power supply, (multiply 100 mA 10 times)

the Panel's power supply must beable to handle at least 1,000 mA (1.0

A). This current load must also be considered while calculating the Panel's

24-hour backup power requirements.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Honeywell Capteur de sécurité

Honeywell

Honeywell C7061M Manuel d'utilisation

Honeywell

Honeywell Activ8 PIR Manuel utilisateur

Honeywell

Honeywell FS20X Series Manuel utilisateur

Honeywell

Honeywell FlexGuard 5853 Manuel utilisateur

Honeywell

Honeywell Miller MightEvac Manuel de l'opérateur

Honeywell

Honeywell Gamewell FCI 2151 Manuel utilisateur

Honeywell

Honeywell 015610.01 Manuel d'instructions

Honeywell

Honeywell MultiPro Manuel utilisateur

Honeywell

Honeywell Miller EN 360 Manuel utilisateur

Honeywell

Honeywell Fire-Lite Alarms D365PL Manuel utilisateur

Honeywell

Honeywell 14506873-001 Manuel utilisateur

Honeywell

Honeywell PEHA LightSpot Mid Range Series Manuel d'installation et d'exploitation

Honeywell

Honeywell FlexGuard FG-1625SN V-Plex Manuel utilisateur

Honeywell

Honeywell Miller Manuel utilisateur

Honeywell

Honeywell ToxiPro CO Manuel utilisateur

Honeywell

Honeywell SC100 Manuel utilisateur

Honeywell

Honeywell FlexGuard 5853 Manuel utilisateur

Honeywell

Honeywell PEHA D MLS2500CDRR4 Manuel d'installation et d'exploitation

Honeywell

Honeywell Sensepoint XCD Manuel utilisateur

Honeywell

Honeywell RAEGuard 2 PID Manuel utilisateur

Honeywell

Honeywell 748LC Manuel utilisateur

Honeywell

Honeywell Friedland FGGA08 Series Manuel utilisateur

Honeywell

Honeywell Miller Revolution Manuel utilisateur

Honeywell

Honeywell Miller AirCore Oil & Gas Harness Manuel utilisateur

Manuels Capteur de sécurité populaires d'autres marques

THORLABS

THORLABS PDA10JT Manuel utilisateur

Waeco

Waeco UV-DETECT Manuel utilisateur

Intermatic

Intermatic IOS-DSIMF Manuel utilisateur

urmet domus

urmet domus 1083 Manuel utilisateur

Siemens

Siemens AZL66 Series Manuel utilisateur

BTI

BTI Profiline Multi Finder Manuel utilisateur

Challenger

Challenger SL01 Manuel utilisateur

DMP Electronics

DMP Electronics 1122INT Manuel utilisateur

Rielta

Rielta Ladoga MK-RK Manuel utilisateur

Mirion Technologies

Mirion Technologies ACCURAD PRD Manuel utilisateur

Bosch

Bosch DS835 Manuel utilisateur

DBI SALA

DBI SALA EZ Stop Manuel de l'opérateur

Lamptime

Lamptime ST05C Manuel utilisateur

Ubiquiti

Ubiquiti MFI-MSC Manuel utilisateur

Subsite

Subsite 910R Instructions d'installation

Satel

Satel OPAL Pro Manuel utilisateur

Aleph

Aleph XC-1XTEU Manuel utilisateur

Pima

Pima LARIS QUAD Manuel utilisateur
