Quick Installation Guide

Lyric™ C1 Wi-Fi Security Camera

For more information visit yourhome.honeywell.com

2

Installation

Launch the Lyric app

4 Launch the Lyric app.

5 Select the Lyric C1 WiFi Camera to install, then create

an account (if necessary), or sign in to your Lyric

account.

6 Follow the instructions in the Lyric app to name the

camera and its location.

Download the Honeywell Lyric app

Note: Have your WiFi password available and

confirm your router communicates at 2.4 GHz before

installation.

1 Make sure bluetooth is enabled on your mobile

device.

2 Search for Honeywell Lyric in the App Store or

Google Play.

3 Download the Honeywell Lyric app.

Connect the power cord

7 Remove the camera base and plug the power

cord’s USB end into the camera.

8 Reinsert the camera base and plug the

camera into a power outlet.

9 Wait until the LED on the camera blinks blue

(about 1 minute), then tap NEXT.

Note: If the LED turns solid red, it means the

connection mode timed out. Unplug the camera and plug it back in.

GET IT ON

Lyric

Select a device to installl

Carrier 100%8:08 AM

Add New Device

Lyric C1 Wi-Fi Camera

Lyric Round

Lyric Water Leak &

Freeze Detector

2 3

Connect

Scan code to connect camera

Carrier 100%8:08 AM

NEXT

Connect

2.7-7.9 in

Connect

Looking for Camera

Connect to Wi-Fi

Note: Be sure you are on the same WiFi

network you wish to connect your camera to.

1 Choose your WiFi network from the list.

Tap NEXT.

2 Enter your WiFi password, if necessary.

Tap DONE.

Note: The camera will beep during some steps

in this process.

Connect to mobile device

1 Enable bluetooth on your mobile device.

2 The app will look for the camera.

• For one camera, it will connect

automatically.

• For more than one camera, the app will

prompt you to select one camera at a

time. Each camera has a unique MAC ID

printed on the back. Use that ID to select

the camera you want to connect.

3 A QR code will display in the app. To

connect your camera to the app, hold the

QR code approximately 38 inches (7

20 cm) from the camera lens.

4 The camera LED turns purple and the

camera beeps.

4

Wi-Fi connection LEDs

During WiFi connection, the LED indicates the following.

LED Camera state

Blinking Green Connecting to WiFi network.

Solid Green Connected to WiFi network.

Solid Red (for

2 seconds)

Connection failed. LED will then turn solid purple.

Solid Purple QR Code scan complete. Re-start “Connect to WiFi” on

page 3.

Blinking Blue Camera has lost bluetooth connection. Unplug camera

and plug it back in. See “Connect the power cord” on page

2 for instructions.

Placement

With stand

Place the camera in a desired location for

viewing and recording.

On the wall

You can also mount the camera directly to the

wall without the stand.

4 5

Operation

Remove/replace the stand

The stand is connected to the camera by a magnet.

If you want to remove the stand to hang the camera

on the wall or replace the SD card, simply pull the

stand off of the camera. To replace, just snap it back

on the camera.

Lyric app experience

When you launch the application, live video from

your camera is displayed.

If you have multiple cameras, a list of them is

displayed. Select a camera from the list to view live

video from that camera.

Testing smoke/CO alarm detection

If your smoke or carbon monoxide alarm goes off

and your camera is on, it will send you an alert that a

smoke or CO alarm has been detected.

To test this feature, press and hold the Test button

on your smoke/CO detector for at least 5 seconds or

3 cycles of the detector’s alarm. A shorter test might

not trigger a sound event.

6

Camera overview

Camera lens

LED indicator

Power cord

Stand Reset hole SD card and slot

Reset

If your WiFi connection fails or you need to connect to a different WiFi network,

insert one end of a paperclip into the reset hole. Press and hold it for 5 seconds to

reset the WiFi connection.

To reset all settings to factory defaults, press and hold the paperclip in the reset hole

for 10 seconds.

SD card

The camera comes with an encrypted 8GB SD card installed. It stores images if the

camera’s connection to the cloud is lost. You can replace it with any compatible

SD card.

6 7

Status LED

The camera has an LED that gives device status.

LED Camera state

During installation

Blinking Blue Powered up. Ready to begin setup.

Solid Blue Connected to App. Ready to complete setup.

Solid Purple QR Code scan complete. Re-start Connect to WiFi process.

Blinking Green Connecting to WiFi network.

Solid Green Connected to WiFi network.

Solid Red Setup timed out. Unplug camera, plug it back in, and restart the

process.

During operation

Blinking Green Connecting to WiFi network.

Solid Green Connected to WiFi and operating.

Blinking Red Not connected to WiFi.

8 9

FCC Regulations

§ 15.19 (a)(3)

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

§ 15.21

Changes or modifications not expressly approved by the party responsible for

compliance could void the user‘s authority to operate the equipment.

§ 15.105(b)

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined

by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

8 9

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with

minimum distance 20cm between the radiator & your body.

This device and its antenna(s) must not be co-located or operating in conjunction

with any other antenna or transmitter.

IC Regulations

This device complies with Industry Canada license-exempt RSSs. Operation is

subject to the following two conditions:

(1)this device may not cause interference, and

(2)this device must accept any interference, including interference that may cause

undesired operation of the device.

IC Radiation Exposure Statement:

This equipment complies with IC RSS102 radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with

minimum distance 20cm between the radiator & your body.

10 11

Need help?

• Web: yourhome.honeywell.com

• Email: MyLyric@honeywell.com

• Phone: 18006333991
