Honeywell HD40 Manuel utilisateur

The Performance Series rounds out Honeywell’s camera portfolio with a variety

of indoor, outdoor and low light cameras that lets end users pick the perfect

camera for virtually any installation. Ideal for a diverse range of applications, the

Performance Series includes a wide range of high performing IR bullet cameras

and mini-domes that are easy to install and even easier to use.

The HD40 is an indoor dome providing a versatile, cost-effective, integrated

surveillance solution. A high-quality 1/3" Sony CCD sensor and a precision lens

are all packaged within this sleek, compact housing. The integrated housing

protects the camera from dust and dirt. The visually appealing low profile

design blends with its surroundings, making the HD40 the obvious choice for

architecturally sensitive installations. The HD40 incorporates a 1/3" CCD that offers

380 TV lines of crisp, clear horizontal resolution. The cameras come equipped with

a built-in fixed lens (f=3.8 mm) and a 3-D axis gimbal that is capable of 360° of

pan, 180° of tilt and 360° of horizontal rotation.

The HD40 installs quickly and easily. It comes standard with a two-conductor

pigtail that connects to the barrel connector so there is no need to cut wires

during installation. The HD40 is designed for use in challenging environments,

easy to install and offer the flexibility of mounting on a wall or ceiling.

Market Opportunities

The HD40 is a cost effective surveillance solution for applications that experience

changing light conditions throughout the day. The HD40 offers a simple yet

solid design that provides optimum performance indoor applications including

lobbies, commercial, residential, foyers, hotel lobbies – anywhere surveillance must

be discreet.

Features

www.honeywellvideo.com

HD40

• Standard resolution color: 380

TVL - 1/3" Sony Super HAD CCD

• Built-in fixed lens (f=3.8 mm)

• ABS housing and Acrylic dome

• Surface mount enclosure,

ceiling or wall

• Auto White Balance

• 3-D axis gimbal

• Two-conductor pigtail is standard for

connection to barrel connector

• 12 VDC Input

STANDARD RESOLUTION FIXED LENS INDOOR MINI-DOME

CAMERA

HD40

L/HD40D/D

July 2008

Honeywell Security

Honeywell Video Systems

2700 Blankenbaker Pkwy, Suite 150

Louisville, KY 40299

1.800.796.CCTV (2288)

www.honeywell.com

www.honeywellvideo.com

SPECIFICATIONS

Operational

Video Standard NTSC, PAL

Scanning System 2:1 Interlace

Image Sensor 1/3" Sony HAD CCD sensor

Number of Pixels

(H x V) 537 x 505 (NTSC)

537 x 597 (PAL)

Minimum

Illumination 0.1 lux

Horizontal

Resolution 380 TVL

Video Output 1.0 Vp-p, composite @ 75 Ohms

Sync System Internal

S/N Ratio 50 dB or more (AGC Off)

Auto Gain Control On/Off

Automatic

Electronic Shutter 1/60–1/100,000 second (NTSC)

1/50–1/100,000 second (PAL)

White Balance Auto

BLC On/Off

Gamma 0.45

Lens Type Built-in fixed (f=3.8 mm)

Angle of View H: 68º

V: 50º

Electrical

Input Voltage 12 VDC

Input Range 10-14 VDC

Power

Consumption 2 W (max)

Mechanical

Dimensions See Diagram

Weight 0.5 lb (0.210 kg)

Construction Housing: ABS

Dome: Acrylic

Finish: Light gray

Connector Main Video: BNC connector

Power Input: 2.1 mm Plug

Environmental

Temperature Operating: 14°F to 122°F (-10°C to 50°C)

Storage: -4°F to 140°F (-20°C to 60°C)

Relative

Humidity 0% to 90% non-condensing

Regulatory

Emissions FCC, CE: (EN55022) Class A

Immunity CE: EN 50130-4

Safety EU: EN 60065

Ordering

HD40 1/3"CCD Standard Resolution Indoor Dome Camera, 380 TVL, Fixed 3.8 mm, 12 VDC NTSC

HD40X 1/3"CCD Standard Resolution Indoor Dome Camera, 380 TVL, Fixed 3.8 mm, 12 VDC PAL

Accessories

Power Supplies

HPT12DC500 12 VAC/500 mA Plug-in Regulated 2.1 mm

Coaxial Plug UL Listed/CSA Certified

2- 0.18" (4.5 mm)

3.35" (85.00 mm)

3.35" (85 mm)

4.45" (113 mm)

1.68" (42.7 mm)

1.34" (34 mm) 3.02" (76.7 mm)
