Heating Controller SDC

District Heating Controller DHC 43

OPERATING INSTRUCTIONS

For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

Contents SDC / DHC 43

1 EN2H-0220 GE51 R1005

CONTENTS

1SOFTWARE VERSION 3

2SAFETY INSTRUCTIONS 4

2.1 Application 4

2.2 Conditions for start-up 4

2.3 Do not separate the controller from the mains 5

2.4 Electric installation 5

2.5 Cable dimensions 5

2.6 Maximum cable length 5

2.7 Cable installation 5

2.8 Cabinet earth and ground 6

2.9 Domestic hot water higher than 60 °C 6

2.10 Connecting accessories 6

2.11 Service and cleaning 7

3DHC 43 / SDC – OVERVIEW 8

4OPERATION 9

4.1 Interface 9

4.1.1 Basic display 10

4.1.2 Operating elements 10

4.1.2.1 Rotary Pushbutton (Press/Turn) 10

4.1.2.2 "Daytime Room Temperature" Key 11

4.1.2.3 "Night-time Room Temperature" Key 11

4.1.2.4 "Daytime DHW Temperature" Key 12

4.1.2.5 "Operating Mode" Key (Basic display) 13

4.1.2.6 "Heating Characteristic" Key 19

4.1.2.7 "System Information" Key 20

4.1.2.8 "Manual Mode" / "Emission Measurement" Key 22

4.2 Menu Selection 24

4.2.1 Time-Date Menu 25

4.2.2 Time programs Menu 26

4.2.3 System Parameter Menu 34

4.2.3.1 Language Selection 34

4.2.3.2 Time Programs 34

4.2.3.3 Control Mode 35

4.2.3.4 Summer Switch-off (heating limit) 37

4.2.3.5 Parameter Reset 38

4.2.4 Domestic Hot Water Menu 39

For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

SDC / DHC 43 Contents

EN2H-0220 GE51 R1005 2

4.2.4.1 DHW Economy Temperature 39

4.2.4.2 Legionella Protection-Day 39

4.2.5 Unmixed Circuit / Mixing Circuit 1 / Mixing Circuit 2 Menu 40

4.2.5.1 Reduced Mode 40

4.2.5.2 Heating System 41

4.3 Malfunction Messages 42

For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

Software Version SDC / DHC 43

3 EN2H-0220 GE51 R1005

1 Software Version

Please use this documentation in conjunction with

software versions V 1.0 and 2.1 of your controller. The

version will be displayed for about 8 s when the controller

is connected to the mains. If you may be using an older

version, please contact your heating specialist.

For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

SDC / DHC 43 Safety Instructions

EN2H-0220 GE51 R1005 4

2 Safety Instructions

2.1 Application

The Smile controller family DHC/SDC is designed

exclusively for the control of warm water heating and

district heating systems including domestic hot water

control. These systems should not exceed a flow

temperature of 120 °C.

2.2 Conditions for start-up

CAUTION The heating installation must be completed and filled with

water in order to prevent the pumps from running dry and

to avoid damage for the boiler.

The control system must be installed according to the

mounting instructions.

All electrical connections (power supply, burner, valve

actuator, pumps and sensors) must be carried out

according to the local rules and standards and must

comply with the attached wiring diagrams.

If a floor heating system is connected, a limiting

thermostat must switch off the pump if the flow

temperatures are too high.

The heating specialist must check the complete

installation before switching on the controller.

IMPORTANT NOTE! The actual time and date are already adjusted from the

factory and backed up by a battery.

There is a basic time program already activated and the

control functions for standard heating systems with low

temperature boilers are pre-adjusted.

For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

Safety Instructions SDC / DHC 43

EN2H-0220 GE51 R1005

2.3 Do not separate the controller from the mains

If this happens, the back-up battery will be unnecessarily

stressed. In addition, the frost protection functions of the

controller will be out of order.

2.4 Electric installation

Qualified personnel must carry out all electrical

connections.

2.5 Cable dimensions

1.5 mm² for all 230 V cable (power supply, burner,

pumps, actuators).

0.5 mm² for sensors, selectors, bus and analogue in- and

outputs.

2.6 Maximum cable length

Sensors selectors and analogue inputs

A maximum cable length of 200 meters is recommended.

Longer distances are possible but increase the risk of

interferences.

Relay outputs

Unlimited cable length.

Bus connections

A maximum cable length of 100 meters is strongly

recommended.

2.7 Cable installation

Cables for 230 V must be installed separate from low

voltage (sensor selector bus) cables.

For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

SDC / DHC 43 Safety Instructions

EN2H-0220 GE51 R1005 6

2.8 Cabinet earth and ground

Please install and connect the controllers according to

local rules and standards!

2.9 Domestic hot water higher than 60 °C

WARNING Please note that in the following cases there is a danger

at hot water tabs (kitchen, bath). In order to avoid

scalding please mix enough cold water.

Anti legionella automatic

If the anti legionella automatic is activated, the domestic

hot water will automatically be heated up to temperatures

around 65 °C order to kill legionella bacteria in the hot

water system.

Manual operation / Emission measurement

In the manual mode / emission measurement mode the

domestic hot water can be heated up to the maximum

possible boiler temperature because the burner and all

pumps are switched on and the valves will be completely

opened. In addition, here there is the danger of scalding

at all warm water tabs in the building. Please mix enough

cold water or switch the domestic hot water loading

pump manually off (if there is a switch at the pump).

Heating and domestic hot water are not temperature

controlled in these modes. These modes are especially

used by the emission measurement specialist or by the

installer in case the controller is defect. The high water

temperatures can however be avoided if the boiler

thermostat is adjusted to a max. of 60 °C.

2.10 Connecting accessories

CAUTION According to VDE 0730 the power supply for the

controller must have a separate main switch for life and

neutral. Please follow local rules and standards for

cabinet earth and ground!

As soon as there is power supply at the terminals 21, 22,

2, 6, 12 and 18, also the terminal rows X3 and X4 will

carry 230 V connections!

For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

Safety Instructions SDC / DHC 43

EN2H-0220 GE51 R1005

External switches must be installed if a manual switch

function is desired for pumps. All accessories (sensors,

selectors, etc.) must be connected according to the

attached wiring.

2.11 Service and cleaning

The controller is service free. The unit can be cleaned

with a moist cloth from the outside.

For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

SDC / DHC 43 Overview

EN2H-0220 GE51 R1005 8

3 DHC 43 / SDC – Overview

This document describes the Smile controller family

DHC/SDC for panel installation and wall mounting. The

product is available in the following variations for use as

a built-in controller and as a wall-mounted controller:

Type

Number of output relays

2nd burner stage or

district heating valve closed

1st burner stage

Direct circuit

variable output 3

Mixing circuit 1

Mixing circuit 2

DHW loading pump

Variable output 2

SDC 3-10 3-Rel. x x x

SDC 3-40 3-Rel. x

SDC 6-20 6-Rel. x x x x

SDC 7-21 7-Rel. x x x x x

SDC 8-21 6-Rel. + 2 Variable x x x x x x
