Honeywell Cloud Link 4G Modem Manuel utilisateur

Cloud Link 4G Modem User Manual

FD-585 | 1.0 | 2016

Honeywell Process Solutions

Mercury Instruments 512 Virginia Drive. Ft. Washington, PA 19034 USA

Honeywell | Cloud Link 4G Modem

Information in this document is subject to change without notice. The software described in

this document is furnished under a license agreement or non-disclosure agreement. The soft-

ware may be used or copied only in accordance with the terms of those agreements. No part of

this publication may be reproduced, stored in a retrieval system, or transmitted in any form or

any means electronic or mechanical, including photocopying and recording for any purpose

other than the purchaser's personal use without the written permission of Honeywell Process

Solutions.

Mercury Instruments 512 Virginia Drive. Ft. Washington, PA 19034 USA

1 General 5

1.1 Cloud Link 4G Modem Overview 6

1.2 Cloud Link 4G Modem Feature Summary 6

2 Safety 7

2.1 Accordance to regulations 8

2.2 Label 9

3 Mechanical Assembly 11

3.1 Device Dimensions 12

3.2 Power options 14

3.3 Antenna Options 15

3.4 Installation Drawing 17

3.5 Field Installation 18

4 Electrical Assembly 19

4.1 Power Supply options 20

4.1.1 Power Port - Battery 21

4.1.1.1 Battery pack drawing 22

4.1.2 Power Port – External Supply 23

4.2 Serial Communication – RS232/485 24

4.3 Pulse Counter 27

4.4 Antenna Interface 28

4.5 Magnetic REED Switch 29

4.6 SIM Card 30

4.7 BLE (Bluetooth Low Energy) 33

4.8 LED Indicators 34

5 Configuring Cloud Link 4G Modem 37

5.1 Working Modes 38

5.2 Getting started with MasterLink iOS application 39

5.2.1 Login and Registration 39

5.2.2 Adding a New Site 40

5.2.3 Connecting to Existing Site 41

5.3 Bluetooth Pairing with MasterLink iOS application 43

5.3.1 Pairing with Just Works (without passkey) 43

5.3.2 Pairing with Passkey Entry 44

5.4 Item Reference 46

5.5 Device Configuration Over Bluetooth 54

5.5.1 Configuration by Group 54

5.5.2 Configuration by Item 55

CONTENTS

5.6 Firmware Upgrade 56

5.7 Server Mode 58

5.8 Pulse Counting 59

5.9 Changing the Battery 60

5.10 Factory Reset 61

5.11 Time Sync 62

5.12 Secure Sign On 63

5.12.1 Secure Sign On Over Bluetooth 64

5.12.2 White List 65

5.13 Logs 66

5.13.1 Event Logs 66

5.13.2 Diagnostic Logs 68

5.13.3 Alarm Logs 69

5.13.4 Cellular Logs 71

CONTENTS

1 General

This chapter introduces the Cloud Link 4G Modem and also talks about the device fea-

tures.

CHAPTER 1

1.1 Cloud Link 4G Modem Overview

Cloud Link 4G Modem is a cellular radio that can be used as a component in Electronic Volume Cor-

rectors platforms and in wireless platforms. Cloud Link 4G Modem can function as a standalone trans-

parent modem, and can also be included as a component in EC 350 and MiWireless. Cloud Link 4G

Modem can also interface with MasterLink.

1.2 Cloud Link 4G Modem Feature Summary

RS-232 & RS-485

Bluetooth Low Energy V4.0

GSM / GPRS (2G)UMTS / HSPA (3G)  LTE (4G)

IPv4

Secure Socket Layer (SSL / TLS 1.2)

Client Mode

Server Mode

Cellular Statistics

Over-the-Air Firmware Configuration Updates

North American Cellular Network Approvals

Alarm-Sensing or Pulse-Counting Input

Built-In magnetic call switch

External power supply (30V max)

Diversity Antenna Connection

Single or Dual 3.6V battery operation

Transparent Modem

1 General

1.1 Cloud Link 4G Modem Overview

Honeywell 2016 6

2 Safety

This chapter describes the different safety aspects involved with the Cloud Link 4G

Modem, along with the agency approvals.

CHAPTER 2

2.1 Accordance to regulations

CSA C/US Class I, Division 2, Group A, B, C & D; T4

IEC 61000-6-2

IEC 61000-6-4

CAN/CSA-C22.2 No. 0-M91 General Requirements – Canadian Electrical Code, Part II

C22.2 No. 142-M1987 Process Control Equipment

C22.2 No. 213-15 Non-Incendive Electrical Equipment for Use in Class I, Division 2 Hazardous

Locations

FCC Title 47 CFR sub-part B

IC Canada (ICES-003 Issue 6)

PTCRB (55982)

List of USA and Canada Carriers certification in Progress: Verizon, AT&T, T-Mobile, Rogers, Bell

Mobility

Bluetooth 4.0 (Declaration ID: D031443)

Supporting 3GPP Release 9 LTE, E-UTRA operating bands 2, 4, 5, 13 and 17

ROHS compliant

Operating Temp: -25 °C to +65 °C

Compliance with FCC and IC Rules and Regulations

The integration is limited to fixed or mobile categorized host devices, where a separation dis-

tance between the antenna and any person of min. 20cm can be assured during normal oper-

ating conditions.

For mobile and fixed operation configurations the antenna gain, including cable loss, must not

exceed the limits 1.10 dBd (850 MHz), 5.50 dBi (AWS) and 2.51 dBi (1900 MHz).

Verizon FOTA support:

Cloud Link 4G Modem does not support FOTA upgrade for the cellular module (Gemalto’s PLS8-X).

2 Safety

2.1 Accordance to regulations

Honeywell 2016 8

2 Safety

2.2 Label

Honeywell 2016 9

Conditions for safe use

The Cloud Link 4G Modem is available with battery pack 51203165-100 which is comprised of a

single cell and a Y connector. A second battery pack (same model) may be connected to this con-

nector to create a 2 cell parallel pack. If a second pack is to be added to an existing pack, the

user shall ensure that both packs are new and unused. The single battery pack or the assembly

of two battery packs shall only be replaced in a non-hazardous area. The connection of more

than 2 battery packs may pose a serious hazard.

None of the battery packs shall be recharged under any circumstances.

The battery packs shall not be replaced in a hazardous area.

The Cloud Link 4G Modem battery packs shall be housed within an enclosure providing a min-

imum ingress protection level of IP 20.

The SIM card connection shall only be used with SIM cards. The SIM card may be connected or

disconnected only in a non-hazardous area or when the device has been de-energized.

All connections into the Cloud Link 4G Modem shall be sourced from Class 2 circuits.

This device shall be installed in a suitable end use enclosure providing a degree of protection

acceptable to the local authority having jurisdiction.

Non-Incendive when Installed As Per Drawing 40-6114

2.2 Label

Figure 2.1 - Cloud Link 4G Modem Label

This page intentionally left blank to ensure new chapters start on right (odd number) pages.
