Honeywell Hyperion 1300G Manuel utilisateur

SPO –Systems support

Honeywell Hyperion 1300G

Scanner User Guide

SPO-NA-EN-373, V1.0

IZUM, COBISS, COMARC, COBIB, COLIB, CONOR, SICRIS, E-CRIS are registered

trademarks owned by IZUM.

CONTENTS

1Using the Honeywell Hyperion 1300G scanner.................................................. 1

1.1 Connecting the scanner with USB ...................................................................................1

1.2 Barcode reading techniques .............................................................................................1

1.3 Factory default settings....................................................................................................2

1.4 Troubleshooting ...............................................................................................................2

2Honeywell Hyperion 1300G scanner settings..................................................... 3

2.1 Basic settings....................................................................................................................3

2.2 Settings for Interleaved 2 of 5..........................................................................................4

2.3 Beeper volume settings....................................................................................................5

2.4 Testing the setup parameters and scanning barcodes.......................................................6

Figures

Figure 1: Correct and incorrect scanning........................................................................................1

Figure 2: Factory default settings....................................................................................................2

SPO Honeywell Hyperion 1300G Scanner User Guide

1Using the Honeywell Hyperion 1300G scanner

1.1 Connecting the scanner with USB

Connect one end of the interface cable to the scanner (1), and the

other end to the USB port of your personal computer (2). The scanner

emulates the operation of a keyboard.

Replacing the USB cable:

If the USB cable needs replacing, insert a straightened paperclip through the

small hole on the side of the scanner's handle to release the connector.

1.2 Barcode reading techniques

The scanner has a bright red aiming beam. The aiming beam should be centred horizontally over

the bar code.

Figure 1: Correct and incorrect scanning

Correct

Incorrect

Honeywell Hyperion 1300G Scanner User Guide SPO

2/6 © IZUM, 19. 3. 2019, SPO-NA-EN-373, V1.0

1.3 Factory default settings

To reset the scanner to the factory default settings, scan the barcode below.

Figure 2: Factory default settings

By doing so, the settings that are crucial for the use within the COBISS system are changed and

set to the values below:

Parameter

Setting/parameter value

Keyboard

USA*

Scanning sound

Scanning beeper pitch

Medium (2700 Hz)

LED-indicator

Trigger mode

Manual

Adding CR after scanning

CODABAR

CODABAR –Start/Stop character

Do not transmit

Code 39

Interleaved 2 of 5

CODE 93

CODE 128

EAN 13

*Change to Slovenian.

If necessary, these parameters may be updated (see chapter 2).

1.4 Troubleshooting

The scanner automatically performs a self-test when you turn it on. If your scanner is not

working properly, check the following:

1. Is the power on?

2. Does the red aiming beam illuminate when you press the trigger?

If the aiming beam does not illuminate:

1. Is the cable connected properly on both ends (scanner, computer)?

SPO Honeywell Hyperion 1300G Scanner User Guide

2. Is the computer on and is it powering the scanner?

3. Is the trigger working?

If the scanner is having trouble reading barcodes:

1. Are the barcodes smeared, scratched or dirty?

2. Is the scanner dirty of are there water droplets on its surface?

If the scanner scans the barcode, but you still have to press a key to enter it:

1. You need to program a suffix for the scanner (Enter/Return).

If the scanner won't read the barcode at all:

1. Scan the sample barcode. If the scanner reads the sample barcode, check that your barcode

is readable.

2. If the scanner can't read the sample barcode, enable the scanning of this barcode type.

If you are unsure about the current scanner settings, reset it to the factory default settings and

then reset the required settings.

2Honeywell Hyperion 1300G scanner settings

Set up the scanner by connecting the scanner and reading the barcodes in the right column of the

table below (from top to bottom). Each step is explained next to each barcode (on the left).

2.1 Basic settings

Before setup, return the scanner to

EU factory settings →

Set the Keyboard Country Layout

to:

Slovenia

→

Set up on stand –automatic trigger*

Presentation Mode →

Honeywell Hyperion 1300G Scanner User Guide SPO

4/6 © IZUM, 19. 3. 2019, SPO-NA-EN-373, V1.0

Manual scanning (turn off automatic

trigger) Manual Trigger →

2.2 Settings for Interleaved 2 of 5

To enable Interleaved 2 of 5:

I 2 of 5 = On →

Barcode length parity –even:

validates and transmits check

character:

Validate and Transmit→

Barcode length parity –odd:

validates but doesn't transmit check

character:

Validate, but don't Transmit →

When setting up the Interleaved 2 of 5 barcode, perform step one, followed by either 2a or 2b.

Perform step 2a for Interleaved 2 of 5 barcodes with even parity.

Perform step 2b for Interleaved 2 of 5 barcodes with odd parity.

SPO Honeywell Hyperion 1300G Scanner User Guide

2.3 Beeper volume settings

Select the beeper volume: 1a, 1b, 1c or 1d.

Beeper volume –good read:

Low

→

Beeper volume –good read:

Medium

→

Beeper volume –good read:

High

→

Beeper volume –good read:

Off

→

Honeywell Hyperion 1300G Scanner User Guide SPO

6/6 © IZUM, 19. 3. 2019, SPO-NA-EN-373, V1.0

2.4 Testing the setup parameters and scanning barcodes

Check if the parameter setup was successful with the test barcodes below.

COBISS

Additional barcodes

CODE 93

Brez kontrolnega znaka (4)!
