MX7 Tecton™

Hand-Held Computer

Microsoft® Windows® Embedded CE 6 Operating System

User's Guide

Disclaimer

Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this

document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have

been made. The information in this publication does not represent a commitment on the part of HII.

HII shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages

resulting from the furnishing, performance, or use of this material.

This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document

may be photocopied, reproduced, or translated into another language without the prior written consent of HII.

Web Address: www.honeywellaidc.com

RFTerm is a trademark or registered trademark of EMS Technologies, Inc. in the United States and/or other countries.

Microsoft®Windows, ActiveSync®, MSN, Outlook®, Windows Mobile®, the Windows logo, and Windows Media are

registered trademarks or trademarks of Microsoft Corporation.

Marvell®is a registered trademark of Marvell Technology Group Ltd., or its subsidiaries in the United States and other

countries.

Summit Data Communications, the Laird Technologies Logo, the Summit logo, and "Connected. No Matter What" are

trademarks of Laird Technologies, Inc.

The Bluetooth®word mark and logos are owned by the Bluetooth SIG, Inc.

Symbol®is a registered trademark of Symbol Technologies. MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the

Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license.

Hand Held is a trademark of Hand Held Products, Inc., a subsidiary of Honeywell International.

Wavelink®, the Wavelink logo and tagline, Wavelink Studio™, Avalanche Management Console™, Mobile Manager™, and

Mobile Manager Enterprise™ are trademarks of Wavelink Corporation, Kirkland.

RAM®and RAM Mount™ are both trademarks of National Products Inc., 1205 S. Orr Street, Seattle, WA 98108.

Other product names or marks mentioned in this document may be trademarks or registered trademarks of other companies

and are the property of their respective owners.

Patents

For patent information, please refer to www.honeywellaidc.com/patents.

Limited Warranty

Refer to www.honeywellaidc.com/warranty_information for your product’s warranty information.

Table of Contents
Chapter 1: Introduction 1-1
About this Guide 1-1
End User License Agreement (EULA) 1-1
Laser Warnings and Labels 1-2
Label Location 1-2
Label 1-2
Components 1-3
Front 1-3
Back 1-4
I/O Port and Cables 1-5
Scanner / Imager Aperture 1-6
Handle 1-6
Handstrap 1-6
Keypads 1-7
55 Key Delete Primary ANSI Keypad 1-7
55 Key Backspace Primary ANSI Keypad 1-7
32 Key Numeric-Alpha Keypad 1-8
Chapter 2: Set Up A New MX7 Tecton 2-1
Hardware Setup 2-1
Software Setup 2-1
Battery 2-2
Connect or Remove the Battery Pack 2-2
Insert/Replace Battery 2-2
Remove Battery 2-3
Hotswap the Main Battery 2-3
Charge or Recharge the Main Battery 2-4
Backlights and Indicators 2-5
Status LEDs 2-5
System Status LED 2-5
Alpha mode Status LED 2-5
Scan Status 2-5
Toggle Vibrate Indicator 2-6
Tapping the Touch Screen with a Stylus 2-7
Touch Screen 2-8
Calibrating the Touch Screen 2-8
Adjusting the Display Backlight Timer 2-8
Apply the Touch Screen Protective Film 2-8
Set Date and Time Zone 2-9
i

Set Power Scheme Timers 2-10
Battery Power Scheme 2-10
AC Power Scheme 2-10
Set Speaker Volume 2-11
Using the Keypad 2-11
Using the Control Panel 2-11
Setup Terminal Emulation Parameters 2-12
Using the AppLock Switchpad 2-13
Using the Keypad 2-13
Using the Touch Screen 2-13
Using the Input Panel / Virtual Keyboard 2-14
Connecting Bluetooth Devices 2-15
Taskbar Connection Indicator 2-15
Reboot Sequences 2-16
Suspend / Resume 2-16
Warmboot 2-16
Attaching the Handstrap 2-17
Attaching the Trigger Handle 2-18
Assemble the Carry Case 2-19
Carry Case with Metal Snaps 2-19
Connecting the Headset Cable 2-20
Adjust Headset / Microphone and Secure Cable 2-21
Cleaning the Touch Screen and Scanner Aperture 2-22
Startup Help 2-23
Continuous Scan Mode 2-23
Chapter 3: Connecting Cables to the MX7 Tecton 3-1
Connecting the USB Client and Power Cable 3-1
Connecting the Serial and Power Cable 3-2
Connecting an External Power Supply 3-3
Connecting Vehicle Power 3-4
DC to DC Power Supply Installation 3-4
Connecting Electrical Cables to Power Sources 3-4
Wiring Schematic 3-5
Connect Vehicle Electrical Connection 3-5
Vehicle 12V Bare Wire Adapter 3-7
Vehicle Cable Connection Cable (Fuse Not Shown) 3-7
Connecting the Power Cable to the Vehicle 3-8
Connect Vehicle 12VDC Connection 3-9
Connect Power Supply to Vehicle Cradle 3-10
ii

Cradle Power Connector Port 3-10
Chapter 4: Product Agency Compliance - MX7 Tecton 4-1
Laser Light Safety Statement 4-3
Vehicle Power Supply Connection Safety Statement 4-5
Chapter 5: Technical Assistance 5-1
iii

Chapter 1: Introduction

The MX7 Tecton™ with Microsoft Windows®Embedded CE 6 operating system is a rugged, portable, hand-held mobile

computer capable of wireless data communications. The MX7 Tecton can transmit information using an 802.11 network card

and it can store information for later transmission through an RS232 or USB port. The MX7CS (Cold Storage) device functions

normally in various temperature ranges.

The MX7 Tecton is vertically oriented and features backlighting for the display. Keypads are available in 55-key alphanumeric

and 32-key numeric-alpha versions.

This device can be scaled from a limited function batch computer to an integrated wireless scanning computer. A trigger handle

is available as an accessory.

The stylus attached to the handstrap is used to assist in entering data and configuration. Protective film for the touch screen is

available as an accessory.

The MX7 Tecton is powered by a 2200mAh Lithium-Ion main battery pack and an internal Super-capacitor (Super-cap) battery.

About this Guide

This MX7 Tecton User's Guide provides instruction for the end-user or system administrator to follow when setting up a new

MX7 Tecton.

This user's guide has been developed for aMX7 Tectonwith a Microsoft® Windows® Embedded CE 6operating system.

End User License Agreement (EULA)

When a new MX7 Tecton starts up a EULA is displayed on the touch screen. It remains on the screen until the Accept or

Decline button is tapped with a stylus.

Tap the Accept button to accept the EULA terms and the MX7 Tecton continues the startup process. The EULA is not

presented to the user again.

Tap the Decline button to decline the EULA and the MX7 Tecton will reboot. It will continue to reboot until the Accept button is

tapped with the stylus.

Note: The EULA will be presented after any operating system upgrade or re-installation, including language-specific

operating systems.

1-1

Laser Warnings and Labels

lDo not look into the laser’s lens.

lDo not stare directly into the laser beam.

lDo not remove the laser caution labels from the MX7 Tecton.

lDo not connect the laser bar code aperture to any other device. The laser bar code aperture is certified for use with the

MX7 Tecton only.

Caution

Laser radiation when open. Please read the caution labels. Use of controls, adjustments or performance of

procedures other than those specified herein may result in hazardous radiation exposure.

Label Location

Label

1-2

Components

Front

1. Scanner/Imager Aperture

2. Speaker

3. System Status LED

4. Scan Button

5. Orange Key (Sticky Key)

6. Blue Key (Sticky Key)

7. Scan Status LED

8. Cable Port

9. On / Off Button

10. Alpha Lock LED (32-Key only)

Diamond Keys

1-3

Back

1. Scanner/Imager Aperture

2. Stylus and Stylus Pocket

3. Trigger Handle Attach Points

4. Main Battery

5. Battery Fastener

6. Cable Port

1-4
