MS7600 Horizon

Honeywell’s MS7600 Horizon®is a compact in-counter hands-free laser

scanner designed with a dense 20-line scan pattern that provides fast,

efﬁcient throughput.

Horizon is equipped with an integrated RF EAS deactivation antenna.

The EAS security tag, designed to reduce shrink, is deactivated and the

bar code is scanned with a single pass.These simultaneous operations

help improve operator comfort and increase throughput.To further

enhance operator efﬁciency and productivity, Horizon is equipped with

IR laser activation.This allows the user to “wake” the unit from a power

save or sleep mode and read a bar code instantaneously.

Each Horizon includes an RS232 auxiliary port that allows for hand-

held bar code scanners to be connected providing easy scanning of

bulky, oversized objects. Other peripherals such as check readers or

magnetic stripe readers can also utilize the ﬂexibility of the auxiliary port.

The Horizon also provides multiple interfaces and data parsing making

it compatible with almost every POS system on the market today.

The combination of performance, ruggedness, and a myriad of features

make the Horizon an ideal choice for grocery, supermarket, retail,

package depot, and a multitude of other applications.

For more information on the MS7600 Horizon omnidirectional laser

scanner, please visit www.honeywell.com/aidc

Omnidirectional Laser Scanner

Durable Die-Cast Construction:• Withstands abuse in

the harshest environments

Flash ROM:• Protects POS investment with free ﬁrmware

updates via MetroSet®2 software and standard PC

Built In RF EAS Antenna:• Increases efﬁciency by

simultaneously deactivating RF EAS tags and decoding

bar codes

Field Replaceable Window:• Fast repairs without

removing unit from service

Auxiliary Port:• Connect an external scanner or other

peripheral directly to the scanner

Features

Honeywell Security & Data Collection

Honeywell Scanning & Mobility

90 Coles Road

Blackwood, NJ 08012

856.228.8100

www.honeywell.com

For more information:

www.honeywell.com/aidc

RoHS

2002/95/EC

MS7600-DS Rev A 01/09

MS7600 Horizon Technical Speciﬁcations

Operational

Light Source Visible Laser Diode 650 nm ± 10 nm

Visual Indicators Yellow = ready to scan; Red = good read

Host System Interfaces USB, RS232, Keyboard Wedge, IBM 46xx (RS485), OCIA, Laser Wand Emulation

Auxiliary Ports RS232: Secondary Scanner or Scale, EAS

Mechanical

Dimensions (LxWxH) 88 mm x 229 mm x 193 mm (3.5˝ x 9.0˝ x 7.6˝)

Weight 2.9 kg (6.3 lbs)

Electrical

Input Voltage 5 VDC ± 0.25 V

Operating Power (typical) 2.6 W (500 mA @ 5 V)

Standby Power (typical) 830 mW (<165 mA @ 5 V)

DC Transformers Class 2: 5.2 VDC @ 1 A

Laser Class Class 1: IEC 60825-1, EN60825-1

EMC FCC Part 15, ICES-003, EN55022 Class A

Environmental

Operating Temperature 0°C to 40°C (32°F to 104°F)

Storage Temperature -40°C to 60°C (-40°F to 140°F)

Humidity 5% to 95% relative humidity, non-condensing

Environmental Sealing Sealed to resist airborne particulate contaminants

Light Levels 4842 Lux (450 foot-candles)

Scan Performance

Scan Pattern Omnidirectional: 5 ﬁelds of 4 parallel lines

Scan Speed 2000 scan lines per second

Print Contrast 35% minimum reﬂectance difference

Pitch, Skew 60°, 60°

Decode Capability Reads standard 1D and GS1 DataBar symbologies. Visit www.honeywell.com/aidc/symbologies for details.

Warranty 3 year factory warranty

Typical Performance*

Narrow Width Depth of Field

5.2 mil 0 mm - 38 mm (0˝ - 1.5˝)

7.5 mil 0 mm - 114 mm (0˝ - 4.5˝)

10.4 mil 0 mm - 178 mm (0˝ - 7.0˝)

13 mil 0 mm - 203 mm (0˝ - 8.0˝)

19 mil 0 mm - 229 mm (0˝ - 9.0˝)

*Resolution: 5 mil (0.125 mm)

*Performance may be impacted by bar code

quality and environmental conditions
